ELITE XC™ SAFETY SUMMARY
PRO
This general safety
information is to be used
by both the Logger
operator and servicing
personnel. DENT
Instruments, Inc.
assumes no liability for
user's failure to comply
with these safety
guidelines.
The ELITEpro XC™ is an Over-Voltage Category III device. Use approved rubber
gloves with mechanical protection and goggles when operating the device.
CAUTION: This LOGGER may contain life threatening voltages. QUALIFIED
PERSONNEL MUST disconnect all high voltage wiring before using or
servicing the LOGGER.
Warning: Use of this device in a manner for which it is not intended may impair
its means of protection.

SYMBOLS ON EQUIPMENT

Denotes caution. See manual for a description of the meanings.
When connecting the ELITEpro XC to an AC load, follow these steps in
sequence to prevent a shock hazard.
Risk of electric shock. Life threatening voltages may be present. Qualified
personnel only.
DO NOT EXCEED 600V Phase to Phase. This logger is equipped to monitor
loads up to 600V. Exceeding this voltage will cause damage to the logger and
danger to the user. Always use a Potential Transformer (PT) for loads in
excess of 600V. The ELITEpro XC is a 600 Volt Over Voltage Category III
device.
4RH8
E186827
1. If possible, de-energize the circuit to be monitored.
2. Connect the CTs to the phases being monitored.
3. Connect the voltage leads to the different phases. Use proper
safety equipment (gloves, mask, and protective clothing) as
required for the voltages monitored.
SPECIFICATIONS
AND
Conforms to UL Std 61010-1
Certified to CSA Std C22.2 No.
61010-1
