ELOG QUICK SETUP
The following diagram shows how to connect the ELITEpro XC CT and voltage leads and configure
ELOG's Setup Table for the single phase, 2-wire power measurement session.
Single Phase, 2-Wire
As an example, configure the Setup Table as follows:
Single Phase, 2-Wire Setup Table in ELOG 14
15
