Summary of Contents for Genie HD-SDI 2MP

  • Page 1 HD-SDI 2MP Real WDR Cameras User Manual...
  • Page 2 Do NOT use power sources other than those specified. • Do NOT expose this appliance to rain or moisture. • This installation should be made by a qualified service person and should conform to all local codes. HD-SDI 2MP Real WDR Cameras...

  • Page 3: Table Of Contents

    Contents General Features..................4 Precautions....................5 Safety Instructions..................6 How to Set Up the Camera Menu..............7 Menu Set Up....................10 Lens......................11 Exposure....................11 WDR......................14 White Balance....................15 Day & Night....................16 NR.......................17 Special......................18 Adjust......................23 Reset......................24 Exit......................24 Specification....................25 Troubleshooting..................32 HD-SDI 2MP Real WDR Cameras...

  • Page 4: General Features

    HD (High Definition) Surveillance • 2DNR / 3DNR • Smart-IR • Sens-Up • Defog • HLC (High Light Compensation) • Privacy Zone • • Privacy Masking • ACCE (Adaptive Color & Contrast Enhanment) • WDR (Wide Dynamic Range) HD-SDI 2MP Real WDR Cameras...

  • Page 5: Precautions

    Please check that the power satisfies • the normal specification before connecting the camera. If it gets wet, wipe dry immediately. If exposed to radioactivity the CCD Liquids can contain minerals that will fail. corrode the electronic components. HD-SDI 2MP Real WDR Cameras...

  • Page 6: Safety Instructions

    Do not expose the camera to direct sunlight. • Do not install the camera in places where humidity is high. • Do not install near cooling or heating devices. • Do not expose an internal grade camera to rain or moisture. HD-SDI 2MP Real WDR Cameras...

  • Page 7: How To Set Up The Camera Menu

    How to Set Up the Camera Menu HD-SDI 2MP Real WDR Cameras...
  • Page 8 HD-SDI 2MP Real WDR Cameras...
  • Page 9 HD-SDI 2MP Real WDR Cameras...

  • Page 10: Menu Set Up

    4. After altering the setting, move the cursor to EXIT and press the SET button to exit. NOTE * Move to the available submenu by moving arrow to desired feature. * A submenu is not available when this symbol is displayed “---”. HD-SDI 2MP Real WDR Cameras...

  • Page 11: Lens

    5.DAY&NIGHT COLOUR 6.NR 7.SPECIAL 8.ADJUST 9.RESET 10.EXIT Exposure 1. On the Main Menu, Select EXPOSURE using the Up or Down buttons. MAIN MENU 1.LENS 2.EXPOSURE 3.WDR 4.WHITE BAL 5.DAY&NIGHT COLOUR 6.NR 7.SPECIAL 8.ADJUST 9.RESET 10.EXIT HD-SDI 2MP Real WDR Cameras...
  • Page 12 - Off: Deactivated status - Auto: Sens-Up is in automatic mode and the gain is decided by the low luminance level. SENS-UP 1.SENS-UP 2.RETURN NOTE * Sens-Up mode does not work when AGC is off. HD-SDI 2MP Real WDR Cameras...
  • Page 13 - HSBLC: If the scene contains an extremely bright light source, such as car headlights, HSBLC can be used to mask them. This is especially useful for number plate recognition. HSBLC 1.SELECT AREA1 2.DISPLAY 3.LEVEL IIIIIIIIII IIIIIIIIII 4.MODE ALL DAY Normal 5.BLACK MASK 6.DEFAULT 7.RETURN HSBLC HD-SDI 2MP Real WDR Cameras...

  • Page 14: Wdr

    - Off: Deactivated Status. - Indoor Compensation: To be used when the camera is installed in the indoor circumstances. - Outdoor Compensation: To be used when the camera is installed in the outdoor circumstances WDR OFF WDR ON HD-SDI 2MP Real WDR Cameras...

  • Page 15: White Balance

    * It is very dark * If the camera is pointed towards fluorescent light, or there is a drastic change in lighting, the White Balance operation may become unstable. * In these conditions, AWB mode is recommended. HD-SDI 2MP Real WDR Cameras...

  • Page 16: Day & Night

    The switching time is adjustable - both day to night and night to day. DAY&NIGHT AUTO 1.DELAY IIII IIIIIIIIIIIIIIII IIIIIIII IIIIIIIIIIII IIIIIIIIII IIIIIIIIII 4.RETURN • EXT: Select the mode using the Right or Left button. 1.S-DELAY IIII IIIIIIIIIIIIIIII 2.E-DELAY IIII IIIIIIIIIIIIIIII 3.RETURN HD-SDI 2MP Real WDR Cameras...
  • Page 17 - 2D-edge preserving & flat area noise reduction 3. Select whether or not to activate 3DNR by using the Left and Right buttons. - Motion adaptive temporal IIR filtering - Edge preserving & ghost elimination - Adaptive weight control by noise level HD-SDI 2MP Real WDR Cameras...

  • Page 18: Special

    CAMERA TITLE using the Up and Down buttons and set to On using the left or Right button. Enter the chosen ID and press the Set button on END to complete the procedure. HD-SDI 2MP Real WDR Cameras...
  • Page 19 D-EFFECT: This function allows the video image to be manipulated. D-EFFECT 1.FREEZE 2.MIRROR 3.D-ZOOM 4.SMART DZOOM 5.RETURN - FREEZE: Causes the video image to freeze. - MIRROR: Causes the video image to be reversed vertically or horizontally. HD-SDI 2MP Real WDR Cameras...
  • Page 20 MOTION: Detects movement of a subject within a pre-defined are(s). When MOTION is On, a new sub-menu is displayed when the Set button is pressed. MOTION 1.SELECT AREA1 2.DISPLAY 3.SENSITIVITY IIIIIIIIIIIIIIII IIII 4.MOTION VIEW 5.DEFAULT 6.RETURN HD-SDI 2MP Real WDR Cameras...
  • Page 21 PRIVACY: The Privacy function is used to mask certain areas of the surveillance scene. Up to 8 areas can be defined and their size is adjustable. Fifteen colours are available to differentiate areas. When RETURN is selected all changes ae saved. PRIVACY 1.SELECT AREA1 2.DISPLAY COLOUR 3.COLOUR 4.TRANS 5.DEFAULT 6.RETURN HD-SDI 2MP Real WDR Cameras...
  • Page 22 - SENS-UP: Up : To eliminate defect, set the high level of Sense Up. You can set to max. 64x, but 32x is the best setting value to eliminate defect. - AGC Level • UTC Mode : MODE1, MODE2 - UTC Control adjustable HD-SDI 2MP Real WDR Cameras...

  • Page 23: Adjust

    - CRT: Select this when you use the CRT monitor. (You can adjust the Level, Blue & Red Gain on the submenu) • LSC : Lens shading • VIDEO OUT: NTSC / PAL • RESOLUTION: FULL HD / HD • FRAME RATE: 30P, 60I, 60P (NTSC) / 25P, 50I, 50P (PAL) HD-SDI 2MP Real WDR Cameras...

  • Page 24: Reset

    9.RESET 10.EXIT Exit Select EXIT and press the Set button to save the current settings and exit the Set Up menu. MAIN MENU 1.LENS 2.EXPOSURE 3.WDR 4.WHITE BAL 5.DAY&NIGHT COLOUR 6.NR 7.SPECIAL 8.ADJUST 9.RESET 10.EXIT HD-SDI 2MP Real WDR Cameras...

  • Page 25: Specification

    -10°C ~ +50°C RH 95% Max. Storage Temperature -20°C ~ +60°C RH 95% Max. Dimensions (W x H x D) 95 x 80 x 265 mm Weight 1500g Features and specifications are subject to change for further improvement without notice HD-SDI 2MP Real WDR Cameras...
  • Page 26 Power Consumption 120mA Power Supply Dual Voltage (DC12V / AC24V) Dimensions (W x H x D) 58 x 52 x 123 mm Weight 350g Features and specifications are subject to change for further improvement without notice HD-SDI 2MP Real WDR Cameras...
  • Page 27 Power Consumption 120mA Power Supply Dual Voltage (DC12V / AC24V) Dimensions (W x H x D) 150 x 120 x 150 mm Weight 600g Features and specifications are subject to change for further improvement without notice HD-SDI 2MP Real WDR Cameras...
  • Page 28 Power Consumption 120mA Power Supply Dual Voltage (DC12V / AC24V) Dimensions (W x H x D) 150 x 120 x 150 mm Weight 1400g Features and specifications are subject to change for further improvement without notice HD-SDI 2MP Real WDR Cameras...
  • Page 29 Power Consumption 120mA Power Supply Dual Voltage (DC12V / AC24V) Dimensions (W x H x D) 150 x 120 x 150 mm Weight 1400g Features and specifications are subject to change for further improvement without notice HD-SDI 2MP Real WDR Cameras...
  • Page 30 ITA / ITA / FRA / GER / KOR / CHN1 / CHA2 / JPN Power Consumption 120mA Power Supply DC12V Dimensions (W x H x D) 54 x 50 x 54 mm Weight 300g Features and specifications are subject to change for further improvement without notice HD-SDI 2MP Real WDR Cameras...
  • Page 31 IR LED ON: 300mA Max Lens 3mm Fixed Board Lens Operating Conditions Temperature: -10 ~ +50°C RH 95% Max. Humidity: -20 ~ +60°C RH 95% Max. Dimension(W x H x D) 54 x 50 x 54 mm Weight 300g HD-SDI 2MP Real WDR Cameras...

  • Page 32: Troubleshooting

    The SENS UP does not work. • Check that the AGC setting in the EXPOSURE menu isn’t set to OFF. • Check that the EXPOSURE menu and make sure SHUTTER is set to ------. HD-SDI 2MP Real WDR Cameras...
  • Page 33 Memo HD-SDI 2MP Real WDR Cameras...
  • Page 34 Memo HD-SDI 2MP Real WDR Cameras...
  • Page 35 Memo HD-SDI 2MP Real WDR Cameras...
  • Page 36 GENIE CCTV LTD. CCTV House, City Park, Watchmead, Welwyn Garden City, Hertfordshire, AL7 ILT Tel: +44 (0) 1707 330541 Fax: +44 (0) 1707 330543 www.geniecctv.com Edition. GN-September 2014...
