TRANSCEIVER OPERATIONS
Select the receiver's filter from the list, which vary depending on the mode type:
Presets for CW mode (Hz): 50, 100, 250, 400, 500, 650, 800, 1000, 1200, User.
Presets for SSB modes (LSB,USB)/DIGL/DIGU (kHz): 1.8, 2, 2.2, 2.5, 2.7, 2.9, 3.0, 3.3,
3.5, User.
Presets for AM/SAM/DSB/NFM modes (kHz): 3, 3.5, 4, 5, 6, 8, 10, 12, 16, User.
Presets for WFM mode (kHz): 150, 200, 250, 260, 270, 280, 290, 300, 310, User.
Presets for DRM mode (kHz): 10.
Presets for SPEC mode: none, because in this mode you receive the whole spectrum scope.
Note:
( Band cannot excess sample rate value set for the audio device in VAC settings.

7.18 ZOOM-In ZOOM-Out the graphics

Zoom the receiver panorama with buttons - Z+, Z-.
Press Z+ to zoom in the transceiver's panorama and more detailed signals.
Press Z- to zoom out the transceiver's panorama and see a "big picture".
Zoom the receiver panorama with mouse - is carried out with the mouse connected to the
transceiver.
Right mouse button:
1. Rollover the mouse cursor on any place of the frequency scale separating the spectrum and
waterfall (cursor will become open hand).
2. Press the right mouse button (cursor will become two-sided needle).
3. . Holding down the right button pressed, drag the mouse right to zoom in.
3.б. Holding down the right button pressed, drag the mouse left to zoom out.
Note:
( Zoom in of the panorama is carried out relative to the Zoom Position marker , which is equal to
the tuned frequency of the VFO A receiver by default.
You can move the Zoom Position with your mouse:
- holding the Zoom Position marker with the left mouse button;
- press the mouse wheel on the required frequency scale between the spectrum and waterfall.
