MAINTENANC
ELECTRICAL HOW TO REMOVE HI-SIM-WARM VALVE
CONNECTION COOKTOP FOR CLEAN- ADJUSTMENT
Appliances which require electrical
ING AND SERVICING
(if equipped)
power are equipped with athree-prong When necessary, follow these proce- The WARM setting should produce a
grounding plug which must be plugged dures to remove appliance for cleaning stable flamewhen turning the knob from
directly into a properly grounded three- or servicing: HI to WARM. On conventional surface
hole 120 volt electrical outlet, burners, the flame should be 1/8 inch or
lower and must be stable on all ports on
1. Shut-off gas supply to appliance. WARM setting. For sealed burners, the
flame should extend to the outer edgeof
2. Disconnect electrical supply to appli- the lip on the burner cap on the WARM
ance. setting.
3. Disconnect gas supply tubing to ap-
__ pliance.
4. Remove screws that secure appli-
ance to cabinet. Remove appliance
Always disconnect power to appfi- from cabinet. To adjust: Operate burner on HI for
ance before servicing. 5. Reverse procedure to reinstall. If gas about 5 minutes to preheat burner cap.
line has been disconnected, check Turn knob back to WARM; remove
for gas leaks after reconnection. (See knob, and insert a small screwdriver into
If an ungrounded, two-hole or other Installation Instructions for gas leak the center of the valve stem. Adjust
type electrical outlet is encountered, IT test method.) Note: Atrained service- flame size by turning adjustment screw
ISTHE PERSONAL RESPONSIBILITY
OF THE APPLIANCE OWNER TO man should make the gas installa- ineitherdirection. Flamemustbeofsuf- ficient size to be stable on all burner
tion, disconnection, and re-connec-
HAVE RECEPTACLE REPLACED ports. NEVERadjustflamesizeattheHI
WITH A PROPERLY GROUNDED tion of gas supply to the appliance, or SIMMER setting.
THREE HOLE ELECTRICAL OUTLET.
The three-prong grounding plug is pro-
vided for protection against shock haz-
ards. DO NOT CUT OR REMOVE THE
THIRD GROUNDING PRONG FROM
THE POWER CORD PLUG. I_
-12-
