Owner's Manual &
Technical Information
HLNA0766
Conquest 10MT XB (US)
HLNA0776
Conquest 10MT XB (UK-EU)
HLNA0786
Conquest 10MT XB (AU)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the conquest 10MT XB and is the answer not in the manual?

Questions and answers

Related Manuals for Helion conquest 10MT XB

Summary of Contents for Helion conquest 10MT XB

  • Page 1 Owner’s Manual & Technical Information HLNA0766 Conquest 10MT XB (US) HLNA0776 Conquest 10MT XB (UK-EU) HLNA0786 Conquest 10MT XB (AU)
  • Page 2 Legal Entire contents ©2016 Helion RC Before using your product, review all documentation and inspect the product carefully. If for some reason you decide it is not what you wanted, then do not continue with unpacking, setup or operation of your product. Your local hobby dealer cannot accept a product for return or exchange after partaking in actions that produce wear and tear.

  • Page 3: Table Of Contents

    Features ..................6 Getting Started ................7 IKONNIK ET3 Radio Sysytem ..........12 Helion 40A ESC ................12 Helion Brushed System Troubleshooting ........ 16 Adjusting and Tuning Your Vehicle .......... 17 General Care & Maintenance ..........18 Storage and Disposal .............. 21 Troubleshooting Problems ............22 Troubleshooting Tables ............23...

  • Page 4: Notice

    Therefore this product is not intended for use or maintenance by children without direct adult supervision. Helion RC and your hobby dealer shall not be liable for any loss or damages, whether direct, indirect, special, incidental, or consequential, arising from the use, misuse, or abuse of this product or any product required to operate or maintain it.

  • Page 5: Package Contents

    Package Contents • 1 x Conquest 10MT XB • 1 x IKONNIK ET3 Krypton 2.4GHz 3-channel transmitter • 1 x Rechargeable Helion 6-cell 7.2V 2000mAh NiMH battery • 1 x Mains charger Items Needed to Complete and Enjoy • 4 x AA alkaline batteries for the transmitter...

  • Page 6: Introduction

    The Conquest 10MT XB is just such a truck. It is, in short, a 2WD, all-weather, all-terrain, all-rounder that’s as happy backyard bashing as it is leaping off ramps, scorching through gravel, or performing rubber-burning wheelies.

  • Page 7: Getting Started

    Getting Started Below are some steps to help get you going right away and most applicable to those who have used RC products before. If you are new to the hobby or it has been a while since you’ve worked with the latest technology, please read through the manual to acquaint yourself with the latest procedures, Warnings, Cautions and Tips.
  • Page 8 Quick Start Guide 1. Remove the components from the box and ensure the contents are correct: ▪ 1 x Conquest 2WD Monster Truck ▪ 1 x 2000mAh 6-cell NiMH battery pack ▪ 1 x IKONNIK ET3 2.4GHz 3-channel transmitter ▪ 1 x 6-cell wall charger ▪...
  • Page 9 6. Re-insert the fully charged battery pack into the cradle and tightly secure it with the hook and loop straps. 7. Remove the battery cover from the underside of the ET3 transmitter and insert four AA alkaline cells. Take care to ensure that the correct polarity is observed.
  • Page 10 11. Switch ON your IKONNIK ET3 transmitter and ensure the LED is lit solid red and that no alarms are audible. Ensure that the CH2 EPA dials are turned fully clockwise and that the D/R (steering rate) dial is centered. Ensure, also, that the CH1 and CH2 (trim) dials are centered at zero.
  • Page 11 Binding/Pairing the Transmitter Having followed steps 1 to 12, in the unlikely event that your car does not operate please follow the 5 stage pairing process detailed here. 1. Remove the body and locate the ET3 Krypton receiver. 2. Place your Conquest and ET3 transmitter in close proximity but not less than 12”...

  • Page 12: Ikonnik Et3 Radio Sysytem

    282g (0.62lb) without batteries Helion 40A Brushed System Overview We’ve included some great features in your Helion Brushed ESC to help keep your system running in top shape while keeping your battery upgrade path open since it is compatible with LiPo batteries.
  • Page 13 Throttle Range Calibration Unlike other systems that require manual setup, your Helion Brushed ESC features automatic calibration. However, for this feature to function properly you need to ensure the throttle channel of the transmitter (CH.2) is set to N (normal).
  • Page 14 D/R, ATV, ATL or EPA. If this is not carried out the ESC may not work properly. Understanding the LED Status Light and Alert Tones Your Helion 40A ESC is programmed to communicate with you to let you know its status.
  • Page 15 Programming your ESC Your Helion 40A brushed ESC is a programmable unit whose direction and battery type can be adjusted by altering the position of the jumper plugs. The plugs are best repositioned using tweezers in conjunction with the following diagram.

  • Page 16: Helion Brushed System Troubleshooting

    Signal Loss Protection If the throttle signal is lost for 0.1 seconds the ESC will cut the output power and the car will stop. Helion Brushed ESC Troubleshooting Trouble Possible Reason Solution After power on, motor can’t work, no The ESC doesn’t get its working Check the battery wires connection sound is emitted, and LED is off.

  • Page 17: Adjusting And Tuning Your Vehicle

    Adjusting and Tuning Your Vehicle The Conquest 10MT XB has been engineered with some available tuning options listed here for reference. The default configuration has been chosen to provide what we feel is the most enjoyable experience for most operating conditions.

  • Page 18: General Care & Maintenance

    General Care • Always use clean, dry cloth or soft bristle brush to clean your equipment. • Never use chemical cleansers to avoid damage to the sensitive electronics and plastics. Maintenance We want you to enjoy your product to its fullest potential. For this to happen it is important to keep your product clean and properly maintained.

  • Page 19: Setting The Gear Mesh

    • Never fold the end of the antenna over the tube, this will reduce the range and damage the antenna. • Ensure the antenna is not being pinched by the set screw that holds the antenna tube in place. Gears Periodically remove the gear cover to clearly inspect the gears and ensure there is no debris in the gear compartment.
  • Page 20 WARNING: NEVER OPERATE YOUR VEHICLE WITH THE SPUR GEAR COVER REMOVED. SEVERE INJURY, DAMAGE TO ELECTRICAL COMPONENTS, AND EXCESSIVE WEAR AND TEAR ON DRIVETRAIN MAY RESULT. Shocks Periodically inspect the shocks for smooth motion, leaking oil and dirt residue build up around the shaft or caps. Do not allow dirt to build up around the shock shaft and bottom of the shock.

  • Page 21: Storage And Disposal

    Tires and Wheels Inspect the tires to ensure they have adequate tread and they are properly glued to the wheels. The tires on your vehicle come pre-glued from the factory; however after running your vehicle it is possible for the glue to come loose in some areas.

  • Page 22: Troubleshooting Problems

    Disposal Your product is considered electronic waste and should never be discarded in standard garbage containers. Please visit your local hobby dealer (and some home improvement centers) and use the FREE battery disposal center for proper disposal/recycling. Consult your local city hall for information on recycling other electronic waste.

  • Page 23: Troubleshooting Tables

    • Healthy gears are crucial to a properly functioning vehicle. If you hear your vehicle making very loud noises, you should immediately stop and check the gears for foreign debris. Even a small pebble can get lodged into the teeth of the pinion gear, which would practically destroy the spur gear in a very short period of time.
  • Page 24 Problem / Possible Cause Possible Solution Symptom Battery voltage too low Charge battery Vehicle will not turn on Battery not connected Re/connect battery Damaged battery Replace battery Battery voltage too low Charge or change batteries Transmitter will not turn on Battery/ies installed improperly Correct installation Check receiver antenna for damage.

  • Page 25: Exploded Views

    Exploded Views Di . Gear Assembly HLNA0981 HLNA0983 HLNA0984 HLNA1022 RDNA5119 HLNA0990 HLNA0984 HLNA0983 HLNA0981 RDNA5119 HLNA1022 HLNA0990 HLNA0988...
  • Page 26 Front End Installation HLNA1005 HLNA1028 HLNA1005 HLNA1041 HLNA1008 HLNA0996 HLNA1043 HLNA1005 HLNA1008 HLNA1043 HLNA1014 HLNA1005 HLNA1043 HLNA0993 HLNA0986 HLNA1007 HLNA0996 HLNA0996 HLNA1007 HLNA0993 HLNA1011 HLNA0985 HLNA1043 HLNA0974 HLNA1045 HLNA1043 HLNA1043 HLNA1044 HLNA1010 HLNA0980 HLNA0980 RDNA5115 RDNA5115 HLNA0980 HLNA1010 HLNA1011 HLNA1043 RDNA5115 HLNA1045 HLNA0992...
  • Page 27 Front End Installation HLNA1062 HLNA1063 HLNA0986 HLNA1026 HLNA1008 HLNA1070 HLNA1008 HLNA1054 HLNA1015 Steering Sway Arm Assembly HLNA1042 HLNA1043 HLNA0992 HLNA0992 HLNA1031 RDNA5115 HLNA1031 HLNA1016 RDNA5115 HLNA1043 HLNA1045 HLNA1031 HLNA1016...
  • Page 28 Front End Installation HLNA0992 HLNA0992 HLNA1004 HLNA1013 HLNA1056 HLNA0991 HLNA1016 HLNA1016 Servo Installation HLNA0976 HLNA0991 HLNA0992 HLNA1043 HLNA1018 HLNA0992...
  • Page 29 Di . Gear / Motor Assembly HLNA1071 RDNA5115 HLNA1032 HLNA1033 HLNA1019 HLNA0997 HLNA0998 HLNA1071 HLNA1001 RDNA5115 HLNA1000 HLNA1019 HLNA0999 HLNA0985 HLNA0991 HLNA1037 HLNA1035 HLNA1024 RDNA0052 HLNA1076 HLNA1034 HLNA1076 HLNA1036 HLNA0975 HLNA1053 HLNA0973 HLNA1076 HLNA1021 HLNA0994...
  • Page 30 Rear End Installation HLNA1006 HLNA1041 HLNA1006 HLNA1027 HLNA1006 HLNA0971 HLNA1062 HLNA1062 HLNA1006 HLNA1006 HLNA1009 HLNA1027 HLNA1063 HLNA1017 HLNA1017 HLNA0970 HLNA0987 HLNA0986 HLNA0985 HLNA0986...
  • Page 31 Rear End Installation HLNA0980 RDNA5115 HLNA1012 HLNA1039 HLNA0974 HLNA1043 RDNA5115 HLNA1040 Shock Absorber HLNA1055 HLNA1061 HLNA1061 HLNA1070 Note: Friction shock shown - oil filled shocks supplied with the vehicle.
  • Page 32 Main Chassis Exploded View HLNA1001 HLNA1071 HLNA102 HLNA0998 RDNA5119 HLNA1001 HLNA0988 HLNA0983 HLNA1000 HLNA1071 HLNA1062 HLNA0997 HLNA0971 HLNA1062 HLNA1043 HLNA1001 HLNA1019 HLNA1063 HLNA0998 RDNA5115 HLNA1071 HLNA1032 HLNA0993 HLNA1001 HLNA1023 HLNA1043 HLNA1033 HLNA1061 HLNA1009 RDNA0052 HLNA1057 HLNA1017 HLNA1019 HLNA1006 HLNA1053 HLNA1037 HLNA1027 HLNA0991 HLNA0973...
  • Page 33 HLNA1022 RDNA5119 HLNA0981 HLNA0983 HLNA0981 HLNA0990 HLNA0990 HLNA0984 HLNA0981 HLNA0982 HLNA0981 HLNA0984 HLNA0992 HLNA1026 HLNA0971 HLNA1031 HLNA1042 HLNA1008 HLNA1016 HLNA1043 HLNA1045 HLNA0992 HLNA0992 HLNA0986 HLNA0986 HLNA1042 HLNA1005 HLNA1045 HLNA1043 HLNA1041 HLNA1031 RDNA5115 HLNA0986 HLNA1013 HLNA1056 HLNA1043 HLNA1016 HLNA1014 HLNA0985 HLNA1007 HLNA0991 HLNA1015 HLNA1026...

  • Page 34: Spare Parts List

    Spare Parts List HLNA0970 .....Rear Chassis Plate, B, ST, MT HLNA0971 .....R-Clip, B, ST, MT HLNA0972 .....Nuts(M4) HLNA0973 .....M3*8 Column Head Hex Screw HLNA0974....Wheel Hex HLNA0975 .....Nuts(M3) HLNA0976 .....Radio Tray Mount HLNA0978 .....Back Shock HLNA0979 .....Shock Ball Head C HLNA0980 .....Pin 2*10 HLNA0981 .....Diff Planetary Gear HLNA0982 .....Diff Shaft HLNA0983 .....Differential Outdrive...
  • Page 35 HLNA1008 .....Front Shock Tower B, ST, MT HLNA1009 .....Rear Shock Tower B, ST, MT HLNA1010 .....Steering Hub Carrier (L/R) HLNA1011 .....Front Hub Carrier (L/R) HLNA1012 .....Rear Upright HLNA1013 .....Front Bulk Head Brace HLNA1014 .....Front Shock Mount HLNA1015 .....Front Upper Link 58.5mm HLNA1016 .....Steering Link 55mm HLNA1017 .....Rear Upper Link 73mm HLNA1018 .....Servo Link 30.5mm...
  • Page 36 HLNA1056 .....Pin 3*26 HLNA1057 .....Pin 5*18 HLNA1059 .....Powder Steel Gear(20T-48P) HLNA1061 .....Rear Shock Absorber HLNA1062 .....Body Post, ST, MT HLNA1063 .....Post Mount, ST, MT HLNA1070 .....Cap Head Hex. Mechnical Screw 3*14 HLNA1071 ....Cap Head Hex. Mechnical Screw 3*16 HLNA1072 .....M3*3 Grub Hex Screws HLNA1073 .....Wheels, MT HLNA1074 ....Tires + Sponge, MT HLNA1075 .....Wheel Complete, MT...

  • Page 37: Warranties

    This warranty does not cover breakage due to abuse, improper break- in, improper setup, or improper operation. We at Helion RC have made every effort in component design, material selection and assembly to make our products as durable as possible. Helion products are covered under warranty only against manufacturer’s defect in materials,...
  • Page 38 Model Engines Warranty Information HELION RC 60 DAY WARRANTY Model Engines (Aust.) Pty. Ltd. warrants this product to be free from defects in materials or workmanship for 60 days from the date of purchase and will repair, replace or refund the purchase should the product prove to be defective.
  • Page 39 The place of purchase (retailer where you bought the product) will then contact Model Engines (Aust.) Pty. Ltd. for a Return Authority number and will return the item for warranty assessment to Model Engines (Aust.) Pty. Ltd.. Items delivered to Model Engines (Aust.) Pty. Ltd. for warranty assessment without a Return Authority number will be returned to sender.

  • Page 40: Declaration Of Conformity

    European directives. This product’s design fulfils the protective aims of the European Community relating to the safe operation of this equipment. For a copy of the Declaration of Conformity, please visit: www.helion-rc.com/support Disposal Electrical equipment marked with the crossed out wheelie bin symbol must not be disposed of in household waste, but must be taken to a specialist disposal or recycling system.
  • Page 41 Helion-RC.com...
