HLNA0602 (US)
HLNA0603 (UK)
HLNA0604 (EU)
HLNA0605 (AU)
LENGTH
235mm (9.25in)
WIDTH
172mm (6.8in)
HEIGHT
81mm (3.2in)
WHEELBASE
159mm (6.3in)
WHEEL DIAMETER
42mm (1.65in) X 23mm (0.91in)
TIRE DIAMETER
60mm (2.36in)
WEIGHT*
540g (1.2lb)
BATTERY
1,100mAh NiMH 6-CELL, 7.2v
MOTOR
370 SIZE
RADIO
2.4GHz 2-CHANNEL
CHARGER
AC WALL TRICKLE
*APPROXIMATE OUT-OF-THE-BOX WEIGHT
•
Entire contents ©2014 Helion RC
•
Before using your product, review all documentation and inspect the products carefully. If for some reason
you decide it is not what you wanted, then do not continue with unpacking, setup or operation of your
product. Your local hobby dealer cannot accept a product for return or exchange after partaking in actions
that produce wear and tear.
•
Read, understand and follow all instructions and accompanying material carefully before operating or as-
sembling your vehicle to prevent serious damage to your vehicle. Failure to complete these tasks properly
or intentional aversion to the content will be considered abuse and/or neglect.
•
Product specifications are subject to change without notice. Due to ongoing development, the actual prod-
uct may vary from images shown.
•
This product contains chemicals known to the State of California to cause cancer and birth defects or other
reproductive harm.
•
This product is not a toy! (14+) Recommended for ages 14 and up. Adult supervision required for ages
under 18 years old. Contains small parts, keep out of reach of children 3 years of age and younger.
OWNER'S MANUAL AND EXPLODED VIEW
1/18th SCALE 4x4
ELECTRIC TRUGGY
Advertisement
Related Manuals for Helion Animus 18TR HLNA0602
Summary of Contents for Helion Animus 18TR HLNA0602
- Page 1 AC WALL TRICKLE *APPROXIMATE OUT-OF-THE-BOX WEIGHT • Entire contents ©2014 Helion RC • Before using your product, review all documentation and inspect the products carefully. If for some reason you decide it is not what you wanted, then do not continue with unpacking, setup or operation of your product.
- Page 2 Visit your local hobby dealer for hobby grade chargers and batteries b. Patience while reading thoroughly through all of the instructions and guides that will help ensure you get the most out of your new Helion RC product RECOMMENDED TOOLS (NOT INCLUDED)...
- Page 3 1/18th SCALE 4x4 ELECTRIC TRUGGY GETTING STARTED... 1. Carefully remove the box contents using side cutting pliers to cut the tie straps 2. Remove body and battery battery from vehicle to prepare for charging a. Read charging instructions and understand all warnings and cautions before proceeding. This product is not a toy and should not be charged, operated, or maintained without supervision of an adult b.
- Page 4 UNDERSTANDING YOUR TRANSMITTER... Features: 1. Steering wheel: controls left/right motion (designed to be operated with right hand) 2. Throttle trigger: controls forward/reverse motion (designed to be operated with left index finger) 3. Handle: For holding the transmitter (designed to be held with left hand) 4.
- Page 5 1/18th SCALE 4x4 ELECTRIC TRUGGY ...TRANSMITTER CONTINUED... Standard operation: • Turning the transmitter wheel to the left from center makes the wheels on the vehicle turn LEFT • Turning the transmitter wheel to the right from center makes the wheels on the vehicle turn RIGHT •...
- Page 6 ...TRANSMITTER CONTINUED... Binding the radio system: The process of allowing communication to occur between a 2.4GHz transmitter and receiver is called “bind- ing” (sometimes referred to as “matching” or “pairing”). The radio system included with your product comes pre-configured and bound from the factory. In the event your system loses binding, or one of the compo- nents has been replaced, you will need to re-bind the transmitter and receiver.
- Page 7 Always use caution and common sense as failure to operate your Helion RC product in a safe and responsible manner can result in damage to the product or other properties. Therefore this product is not intended for use or maintenance by children without direct adult supervision.
- Page 8 CARE AND MAINTENANCE... General Care: • Always use clean, dry cloth or soft bristle brush to clean your equipment • Never use chemical cleansers to avoid damage to the sensitive electronics and plastics Maintenance: We want you to enjoy your product to its fullest potential. For this to happen it is important to keep your product clean and properly maintained.
- Page 9 1/18th SCALE 4x4 ELECTRIC TRUGGY ...MAINTENANCE CONTINUED... 3. Shocks: Periodically inspect the shocks for smooth/free motion, leaking oil and dirt residue build up around the shaft a. Do not allow dirt to build up around the shock shaft and bottom of the shock. Doing so will reduce the life of the shock and cause a shock to leak oil.
- Page 10 TROUBLESHOOTING GUIDE... Problem / Symptom Possible Cause Possible Solution Battery voltage too low Charge battery Vehicle will not turn on Battery not connected Re/connect battery Damaged battery Replace battery Battery voltage too low Charge or change batteries Transmitter will not turn on Battery/ies installed improperly Correct installation...
- Page 11 1/18th SCALE 4x4 ELECTRIC TRUGGY STORAGE AND DISPOSAL... Before contacting customer support, recall that this is a hobby grade product intended to be user serviceable. Please take the time to fully inspect your product for any obvi- ous causes to the issues you are experiencing. Below are some of the most common issues experienced.
- Page 12 HLNA0018..Axle Bearing Set (18-US) ....updated spare parts list and option parts list on the HLNA0161..AL Front Shocks, OR (18-US) ....Helion website: www.Helion-RC.com HLNA0162..AL Rear Shocks, OR (18-US) ....HLNA0163..Diff Outdrive Cups, Steel (18-US) ..HLNA0002..Main Chassis (18-US) ......
- Page 13 1/18th SCALE 4x4 ELECTRIC TRUGGY SHOCKS EXPLODED VIEW... DIFF EXPLODED VIEW... HLNA0665 HLNA0012 HLNA0026 fhps, M2x6mm HLNA0012 HLNA0716 HLNA0013 HLNA0019 ball bearing, 6x10x3mm HLNA0698 HLNA0012 HLNA0664 HLNA0013 HLNA0012 HLNA0014 HLNA0698 HLNA0012...
- Page 14 ...ANIMUS 18TR HLNA0050 HLNA0686 HLNA0008 HLNA0029 HLNA0043 HLNA0044 HLNA0006 HLNA0011 HLNA0715 HLNA0008 HLNA0044 HLNA0005 HLNA0012 HLNA0011 HLNA0015 HLNA0715 HLNA0015 HLNA0007 HLNA0002 HLNA0017 HLNA0003 HLNA0043...
- Page 15 1/18th SCALE 4x4 ELECTRIC TRUGGY EXPLODED VIEW... HLNA0010 HLNA0021 HLNA0666 HLNA0003 HLNA0044 HLNA0006 HLNA0715 HLNA0019 HLNA0019 HLNA0020 HLNA0019 HLNA0044 HLNA0012 HLNA0011 HLNA0015 HLNA0665 HLNA0005 HLNA0015 HLNA0015 HLNA0028 HLNA0019 RDNA0090 HLNA0717 HLNA0716 HLNA0007 HLNA0018 HLNA0017...
- Page 16 WARRANTY + CONFORMITY Limited Warranty Helion products are covered by the currently valid statutory warranty regulations. If you wish to make a claim under the limited warranty, please contact the model shop where you originally purchased the unit. The limited warranty does not cover: Damage due to commercial use, negligence, misuse, abuse, accident, or acts of God;...
