CONGRATULATIONS
Dear Customer,
Thank you for purchasing our Vogue Refrigerator. We are sure you will find your new appliance a
pleasure to use. Before you use the appliance, we recommend that you read through this entire user
manual, which provides the description of the appliance and its functions.
To avoid the risks that are always present when you use an electrical appliance, it is important that
the appliance is installed correctly and that you read the safety instructions carefully to avoid misuse
and hazards.
We recommend that you keep this instruction booklet for future reference and pass it on to any future
owners. After unpacking the appliance, please check that it is not damaged. If in doubt, do not use the
appliance but contact your local customer care centre.
AFTER POSITIONING THE REFRIGERATOR DO NOT PLUG IN FOR A MINIMUM OF
1.
IMPORTANT – CHECK FOR ANY DAMAGES OR MARKS
If you find the refrigerator is damaged or marked, you must report it within 7 days if you wish to claim
for damage/marks under the manufacturer's warranty. This does not affect your statutory rights.
2.
CORRECT USE OF YOUR APPLIANCE
•
Remove all packaging material before using the refrigerator. This includes the foam base and
all adhesive tape holding the accessories inside and outside.
•
Clean the inside and outside of the refrigerator with a wet cloth (a little detergent can be added
to the water) and then wipe again with a clean cloth.
•
The appliance needs to have an independent power socket.
•
Screw on bottom cover
FZ.411.SS
6 HOURS TO ALLOW THE GAS TO SETTLE
Page 1 of 16
Advertisement
Table of Contents
Related Manuals for Midea FZ.411.SS
Summary of Contents for Midea FZ.411.SS
- Page 1 CONGRATULATIONS FZ.411.SS Dear Customer, Thank you for purchasing our Vogue Refrigerator. We are sure you will find your new appliance a pleasure to use. Before you use the appliance, we recommend that you read through this entire user manual, which provides the description of the appliance and its functions.
- Page 2 TRANSPORTING • When moving do not tilt over more than 45 degrees. WARNING • Keep ventilation openings in the appliance or in the built-in-structure clear of obstruction. • Do not use mechanical devices or other means to accelerate the defrosting process. •...
- Page 3 Upright Freezer User’s Manual Model: FZ.411.SS Page 3 of 16...
- Page 4 This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.
- Page 5 PROPER USE OF REFRIGERATOR The coming of new fridge l Before the use of the fridge, remove all packages, including bottom cushion and foam pads and rubber belts in the fridge; l Clear the outside and inside of the fridge with a piece of warm wet rag (little detergent can be added into the warm water.
-
Page 6: Install The Door Handle
INSTALL THE DOOR HANDLE Note: Figures in the user manual are only for reference. The actual product may differ slightly. The refrigerator must be disconnected from the source of electrical supply before attempting the installation of accessory. ③ ② ① the hole the screw ③... -
Page 7: Parts List
PARTS LIST Note: Figures in the user manual are only for reference. The actual product may differ slightly. 1. lamp switch 2 lamp cover 3 temperature sensor gap 4 steel wire freezer shelf 6. inlet airflow gap 5 outlet airflow gap 7 steel wire drawer 8 door tray 9 steel wire door tray... - Page 8 INSTALL THE DECORATIVE COVER FOR BOTTOM BEAM The coming of new refrigerator l Open the door, take out the attachments (the bottom decorative cover), and three setscrews in the bag of the Instruction. And install it onto the bottom beam of the fridge.
-
Page 9: Safety Precaution
SAFETY PRECAUTION Page 9 of 16... - Page 10 POSITIONING Install this appliance in an area where the ambient temperature is between 110 ℉(43℃) and 32 ℉(0℃).If the temperature around the appliance is too low or high ,cooling ability may be affected ＞300mm Page 10 of 16...
-
Page 11: Operation Check
OPERATION CHECK 30 minutes later,open the freezer compartment door ,feel the cold air,that means the unit works properly. After a period of time to set the freezer temperature at the desired temperature. (Set the range from -14 ~-22 ( ℃ 7℉ ~ -8℉ ℃... -
Page 12: Food Storage
FOOD STORAGE back side air gap Page 12 of 16... -
Page 13: Introduction Of The Functions
INTRODUCTION OF THE FUNCTIONS 1、Alarm lamp 1.Hi-Temp(High temperature alarm) 2.Door Open(Door keep open for 60 seconds alarm ) 2、Button A.Quick Freeze button B.℃or ℉ temperature switch button C.Alarm Reset button D.Lock/Unlock button E.Temperature setting / Quick Freeze time setting ( ) down F.Temperature setting Quick Freeze time setting ( ) up... - Page 14 INTRODUCTION OF THE FUNCTIONS ●Quick Freeze Funtion setting Un-Quick freeze funtion mode :press button A to enter quick freeze mode,the temperature icon G show“ 24℃”or“ 11℉” ,quick freeze time acquiesce in 6 hours.Press button A again to exit. Quick freeze funtion will not work when the cabinet as the Refrigerator Quick freeze funtion mode :press button A for 3 seconds to enter the state of quick freeze time setting,quick freeze time icon G flickering;...
-
Page 15: Maintenance
MAINTENANCE LEAVING THE UNIT POWER OFF If the unit will be power off for a long time, the plug should be pulled out, then clean the unit thoroughly.Ensure that the door cannot be fully closed(leave a suitable gap), and place the unit in a well-ventilated area to avoid any odour. -
Page 16: Troubleshooting
TROUBLE SHOOTING Please contact the after-sales Service Department of the Company or professionals to deal with the trouble to avoid any risk. Before calling for the service ,please check the following issues first. PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION ●Check connection of power ●No power to unit.
