- Page 1 VC-B20D HD Camera Installation Guide - English [Important] To download the latest version of Quick Start Guide, multilingual user manual, software, or driver, etc., please visit Lumens http://www.Mylumens.com...
-
Page 2: Table Of Contents
Setting menu ..................16 Chapter 6 Descriptions of Major Functions ..........23 I would like to switch to VC-B20D ............ 23 I would like to save the current lens position data ......23 I would like to clear the saved position data ........23 I would like to turn on the back light compensation function .... - Page 3 I would like to adjust the AF speed ........... 24 I would like to set the image mode ........... 25 6.10 I would like to freeze images ............25 6.11 I would like to rotate the image ............25 6.12 I would like to change the camera direction ........25 6.13 I would like to display the current status ..........
-
Page 4: Copyright Information
Inc. Copying, reproducing or transmitting this file is not allowed if a license is not provided by Lumens Digital Optics Inc. unless copying this file is for the purpose of backup after purchasing this product. In order to keep improving the product, Lumens Digital Optics Inc. hereby reserves the right to make changes to product specifications without prior notice. -
Page 5: Chapter 1 Safety Instructions
Chapter 1 Safety Instructions Always follow these safety instructions when setting up and using the HD Camera: 1. Use attachments only as recommended. 2. Use the type of power source indicated on the HD Camera. If you are not sure of the type of power available, consult your dealer or local electricity company for advice. -
Page 6: Precautions
Precautions Warning: To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture. If HD Camera will not be used for an extended time, unplug it from the power socket. Note Risk of Electric Shock Please do not open it by yourself. -
Page 7: Chapter 2 Package Contents
Chapter 2 Package Contents Instruction for VC-B20D Remote control installation Power cord Power Adapter Appearance may vary depending on country/region English - 6... -
Page 8: Chapter 3 Product Overview
Chapter 3 Product Overview 3.1 Overview Front View Back View 1. Camera lens 2. Power LED indicator 3. Standby LED indicator 4. Power input 5. Camera Control(RS232 IN) 6. DVI-I output 7. Output Switch 8. -
Page 9: Description Of Led Indicator
3.2 Description of LED indicator 3.2.1 Power： 3.2.1.1 No light: Power off 3.2.1.2 Green light: In use 3.2.1.3 Flickering green: Signal from the remote control is received; the indicator flickers every 0.5 second 3.2.2 Standby： 3.2.2.1 Orange: In standby mode 3.2.2.2 No light: Power on English - 8... -
Page 10: Chapter 4 Instruction For Installation
Chapter 4 Instruction for installation 4.1 Preparation before installation Installation and connection of HD camera requires special skills. To install by yourself, please follow necessary steps, ensure steady and tight installation of the device, and pay attention to your safety to avoid any accident. 4.1.1 Ensure the safety of the installation environment. - Page 11 4.2.1.2 Installation steps 1. Install the camera on the wall with VC-AC03 <Remark> For the installation of VC-AC03, please refer to VC-AC03 Quick Installation Guide 4.2.1.3 Camera Size Length x Width x Height : 267.69 x 123 x 155.60 mm Weight : 1.3 Kg English - 10...
- Page 12 English - 11...
- Page 13 4.2.1.4 Precautions for installation 1. Before installation, please confirm the orientation of the machine relative to the object to be captured 2. It is recommended that the machine should be set at a distance of more than 1 meter away from the object to be captured. Please adjust for a best distance according to the magnification of the lens English - 12...
-
Page 14: Connecting The Device
4.3 Connecting the device 4.3.1 Image output Connecting to a HDTV/computer monitor (DVI) 4.3.1.1 DVI cable Monitor HDTV 4.3.2 Use control panel to control the Camera RS232 Cable Compact Camera Controller English - 13... - Page 15 4.3.3 IR Out IR Out includes IR Right and IR Left, use VISCA command to switch: 1. IR right and IR left ON 2. IR left OFF, IR right ON 3. IR left ON, IR right OFF 4. NA (no signal from IR receiver) IR Left IR Right English - 14...
-
Page 16: Chapter 5 Setting Menu Description
Chapter 5 Setting Menu Description 5.1 Functions of remote control <Remark> The below functions are listed alphabetically. Item Description Move the lens ,,, Turn on/off back light compensation Back Light Select 1 ~ 3 VC Camera select Turn on manual focus to adjust the Focus- focal length Manual /... -
Page 17: Setting Menu
5.2 Setting menu <Remark>The bold underlined values in the following table are defaults. 1st Level 3rd Level 2nd Level Major Adjustment Function Descriptions Minor Items Items Values 1. Full Auto 2. Shutter Pri Mode 3. Iris Pri Exposure mode setting 4. - Page 18 1/250 1/215 1/180 1/150 1/120 1/120 1/100 1/100 1/90 1/75 1/60 1/50 1/30 1/25 1/15 1/12 1. F2.8 2. F4 3. F5.6 Iris Pri IRIS priority setting 4. F8 5. F11 6. F16 1. 0dB 2. 2 dB 3. 4 dB 4.
- Page 19 60/30 50/25 mode mode 1/10000 1/10000 1/5000 1/5000 1/3000 1/3000 1/2500 1/2500 1/2000 1/1750 1/1500 1/1250 1/1000 1/1000 1/725 1/600 1/500 1/425 1/350 1/300 Manual Speed Manually set the shutter 1/250 1/215 1/180 1/150 1/120 1/120 1/100 1/100 1/90 1/75 1/60 1/50 1/30...
- Page 20 1. 8 dB 2. 10 dB 3. 12 dB 4. 14 dB 5. 16 dB 6. 18 dB Max. limit value of Gain Limit 7. 20 dB electron gain 8. 22dB 9. 24dB 10. 26 dB 11. 28 dB 12. 30dB 1.
- Page 21 Adjustable when the white Manual R balance mode is set to 0~ C~60 Gain Manual 1. Off Picture effect Set the picture effect 2. Neg 3. B&W Adjust the sharpness of Sharpness 1~A~16 the image 1. Auto 2. Off 3. 1 2D noise reduction 2D NR 4.
- Page 22 Adjustable in the Custom Gamma 0~ A ~3 Mode Skin tone setting, Skin Tone adjustable in the Custom 1~ A ~5 Mode Adjustable in the Custom Brightness 0~ A ~14 Mode Contrast adjustment, Contrast adjustable in the Custom 0~ A ~14 Mode 1.
- Page 23 AF frame setting, when central area was set as AF frame, focusing will be on Full Frame the center of the screen. AF Frame Center When full area was set as AF frame, focusing will be calculated based on the full screen.
-
Page 24: Chapter 6 Descriptions Of Major Functions
Chapter 6 Descriptions of Major Functions 6.1 I would like to switch to VC-B20D 1. Press [Camera 1 ~ 3] on the remote control to select VC-B20D. Camera 1 ~ 3 is selected with IR SELECT. 6.2 I would like to save the current lens position data 1. -
Page 25: I Would Like To Adjust The Focal Length
2. Press [Fast -] on the remote control to zoom out images. 6.6.2 Fine-tune image size 1. Press [Slow +] on the remote control to zoom in images. 2. Press [Slow -] on the remote control to zoom out images. 6.7 I would like to adjust the focal length 6.7.1 Auto tune... -
Page 26: I Would Like To Set The Image Mode
The focus speed upon triggering AF Sensitivity [Normal] (default): Image flickering may not occur [Fast]: Fast focus speed 1. Press [MENU] to activate the setting menu. 2. Press [] or [] to select [Auto Focus]. 3. Press [ENTER] to activate. 4. -
Page 27: Chapter 7 Dip Switch Setting
Chapter 7 DIP switch setting <Note> Please turn off the machine before changing DIP switch setting. 7.1 DIP SWITCH 7.1.1 OUTPUT Switch-----1、2Pin Setting Function Descriptions Infrared signal output switch DIP 1 OFF: Enable I ON : Disable Communication baud rate selector DIP 2 OFF: 9600 / ON : 38400 7.1.2 OUTPUT Switch-----3~6Pin... - Page 28 1920x1080/29.97p 1280x720/59.94p 1280x720/29.97p 7.1.3 IR SELECT Setting English - 27...
-
Page 29: Chapter 8 Troubleshooting
Chapter 8 Troubleshooting This chapter describes problems you may encounter while using VC-B20D. If you have questions, please refer to related chapters and follow all the suggested solutions. If the problem still occurred, please contact your distributor or the service center.
