- Page 1 VC-B20U HD Camera (PTZ Video Camera) Installation Guide - English [Important] To download the latest version of Quick Start Guide, multilingual user manual, software, or driver, etc., please visit Lumens http://www.MyLumens.com...
-
Page 2: Table Of Contents
Table of Contents Copyright Information ..................2 Chapter 1 Safety Instructions ................3 Chapter 2 Package Contents ................6 Chapter 3 Product Overview ................7 Overview ..................... 7 Description of LED indicator ............... 8 ... -
Page 3: Copyright Information
Inc. Copying, reproducing or transmitting this file is not allowed if a license is not provided by Lumens Digital Optics Inc. unless copying this file is for the purpose of backup after purchasing this product. In order to keep improving the product, Lumens Digital Optics Inc. hereby reserves the right to make changes to product specifications without prior notice. -
Page 4: Chapter 1 Safety Instructions
Chapter 1 Safety Instructions Please use the product following the safety instructions below: Operation Please use the product in the recommended operating environment. Do not place the product in tilted position. Do not place the product on an unstable trolley, stand or table. Do not use this product near water or source of heat. - Page 5 Cleaning Unplug all the cables before cleaning. Use a damp cloth for cleaning. Do not use liquid or aerosol cleaners. Remote control (if the accessories are equipped with remote control) Using an incorrect battery type in the remote control may result in breakdown.
- Page 6 EN55022 (CE Radiation) Warning This product is intended for use in a commercial, industrial, or educational environment. It is not intended for residential use. This is a Class A product. In a residential environment it may cause radio interference, in which case the user may be required to take adequate measures. The typical use is in a conference room, reception room or hall.
-
Page 7: Chapter 2 Package Contents
Chapter 2 Package Contents Instruction for VC-B20U Remote Control installation Power Cord Power Adapter USB cable (USB 3.0) Appearance may vary depending on country/region English - 6... -
Page 8: Chapter 3 Product Overview
Chapter 3 Product Overview 3.1 Overview Front View Back View 1. Camera lens 2. Power LED indicator 3. Standby LED indicator 4. Power input 5. Camera Control (RS232 IN) 6. USB 3.0 Host English - 7... -
Page 9: Description Of Led Indicator
3.2 Description of LED indicator 3.2.1 Power： No light: Power off 3.2.1.1 Green light: In use 3.2.1.2 Flickering green: Signal from the remote control is received; 3.2.1.3 the indicator flickers every 0.25 second 3.2.2 Standby: Orange: In standby mode 3.2.2.1 No light: Power on 3.2.2.2 English - 8... -
Page 10: Chapter 4 Instruction For Installation
Chapter 4 Instruction for Installation 4.1 Preparation before installation Installation and connection of HD camera requires special skills. To install by yourself, please follow necessary steps, ensure steady and tight installation of the device, and pay attention to your safety to avoid any accident. 4.1.1 Ensure the safety of the installation environment. - Page 11 Installation steps 4.2.1.2 1. Install the camera on the wall with VC-AC03 <Remark>For the installation of VC-AC03, please refer to VC-AC03 Quick Installation Guide 4.2.1.3 Camera size Length x Width x Height : 267.69 x 123 x 155.60 mm Weight : 1.3 Kg English - 10...
- Page 12 4.2.1.4 Precautions for installation 1. Before installation, please confirm the orientation of the machine relative to the object to be captured 2. It is recommended that the machine should be set at a distance of more than 1 meter away from the object to be captured. Please adjust for a best distance according to the magnification of the lens English - 11...
-
Page 13: Connecting The Device
4.3 Connecting the device 4.3.1 Image output Connecting to a computer 4.3.1.1 USB cable (USB 3.0) Computer 4.3.2 Use Compact Camera Controller to control the camera RS232 Cable Compact Camera Controller English - 12... - Page 14 4.3.3 IR Out IR Out includes IR Right and IR Left, use VISCA command to switch: 1. IR right and IR left ON 2. IR left OFF, IR right ON 3. IR left ON, IR right OFF 4. NA (no signal from IR receiver) IR Left IR Right English - 13...
-
Page 15: Chapter 5 Setting Menu Description
Chapter 5 Setting Menu Description 5.1 Functions of remote control <Remark>The below functions are listed alphabetically. Item Description ,,, Move the lens Back Light Turn on/off back light compensation Camera select Focus- Turn on manual focus to adjust the Manual / focal length Far/Near Focus-Auto... -
Page 16: Chapter 6 Descriptions Of Major Functions
Chapter 6 Descriptions of Major Functions 6.1 I would like to save the current lens position data 1. Press [Preset + ID] on the remote control to save the current position data. ID shall be a digit [0 ~ 9]. ... -
Page 17: I Would Like To Zoom In/Out Images
6.5 I would like to zoom in/out images 6.5.1 Adjust image size 1. Press [Fast +] on the remote control to zoom in images. 2. Press [Fast -] on the remote control to zoom out images. 6.5.2 Fine-tune image size 1. -
Page 18: Chapter 7 Troubleshooting
Chapter 7 Troubleshooting This chapter describes problems you may encounter while using VC-B20U. If you have questions, please refer to related chapters and follow all the suggested solutions. If the problem still occurred, please contact your distributor or the service center. -
Page 19: Appendix 1 Supported Resolutions
Appendix 1 Supported Resolutions Support Support Format Resolution Remark USB 3.0 USB 2.0 YUV2 1920x1080 1280x720 640x480 MJPEG 1920x1080 1280x720 640x480 English - 18...
