ALPATEC VT 23 User Manual page 11

notice VL-VP:notice VLP 16
1.- Front guard
2.- Lock nut
3.- Fan blade
4.- Rear guard lock nut
5.- Rear guard
6.- Motor shaft
7.- Oscillation control knob
8.- Speed control
9.- Base
10.- Screws supplied
VT 30 / VT 40
TECHNICAL DATA:
Model
Power
Air flow
Nb of speed
Dim. of the grille
Class
23/09/11 9:59 Page 11
DESCRIPTION VT 30 / VT 40
VT 30 VT 40
40 W 50 W
4,2 m/s 5 m/s
3 3
34 cm 45 cm
II II
