Technical Specifications

20
Video Inputs
Two Component (Y-Pb-Pr) inputs
on standard RCA connectors
Two S-Video (Y/C) inputs on standard
mini-DIN connectors
Two Composite video inputs on
standard RCA connector
Accepts standard NTSC/PAL/SECAM
interlaced scan video signals
Pass-Thru
Accepts RGB or Y-Pb-Pr
(Component)
Separate sync, Composite sync, or
Sync on Y
Can be used with PC sources
Video sources: 480p, 576p, 720p,
1080i
Video Outputs
15-pin VGA-type HD-15 connector
DVI digital output connector
User-selectable RGB or Y-Pb-Pr
(Component) output color space for
analog VGA output
RGB -0.7Vpp, Y-Pb-Pr (Component) -
0.7Vpp, Sync on Y -1.0Vpp
Separate H,V synchronization
standard; user-selectable composite
sync and sync on RGB
Outputs 480p/576p progressive scan
video, 31.5kHz/31.25kHz scan rate
525 total video lines per frame, 480
active lines (NTSC)
625 total video lines per frame,
576 active lines (PAL/SECAM)
12-bit video DAC, featuring 8X
Chroma Oversampling and 4X Luma
Oversampling at 108MHz
Controls
Input select controls (Channel 1 or 2
for each input type)
Pass Thru select
Aspect Ratio Control
Picture Controls: Brightness, Contrast,
Saturation, Hue, YC Delay, Sharpness,
Chroma Filter
Output signal Control
Color space select (RGB or Y-Pb-Pr
(Component))
H/V Sync, Csync, SOG/Y
Curtain control for 4:3 on
16:9 displays
DVI/Analog Select
DVI Resolution Select
Input Stage
High-performance multi-standard
video decoder
High quality adaptive comb filter
for 2D Y/C separation
