Displays and Controls (continued)
11

Alphanumeric Display

For all video inputs except 'Pass-Thru',
selecting 'Aspect Ratio', 'Picture Control',
or 'Output Control' turns on the
Alphanumeric Display.
The and Adjustment Controls
Pushing the and
through the available options or value for
the parameter selected. After selecting an
appropriate option or value for a chosen
video input, allow the display to turn off
to store it in memory.

Adjustment Lock

Once you have the Picture and Output
Control settings on the iScan Ultra to
your liking, you can lock these settings
to prevent accidentally changing them or
tampering by children. When you press
the and controls simultaneously,
a 'LCK' message will appear on the
alphanumeric display. This means that
the settings are locked and may not be
changed until unlocked.
To unlock the iScan Ultra, press both
the and controls again and a
'ULK' message will appear. The iScan
Ultra is now unlocked and Picture and
Output Control settings can be
changed.
Please note that the lock/unlock feature
is only accessible from the front panel of
the iScan Ultra. This feature will not
work with the remote control.
controls will cycle

Aspect Ratio Control

The iScan Ultra has a new Aspect Ratio
Control feature that can be used
whenever you are displaying 4:3 images
on a 16:9 TV. This includes standard
4:3 full-screen or letterboxed images
being played on a wide-screen TV.
The Aspect Ratio Control feature scales
4:3 images to fill as much of the 16:9 dis-
play area as possible. For 4:3 full-screen
images, activating the Aspect Ratio fea-
ture on the front panel will display the
correct aspect ratio in the middle of the
screen and add black or gray bars on the
sides (curtains) to maintain the aspect
ratio. Gray bar settings are recommended
for plasma or CRT-based displays.
When you activate the Aspect Ratio
feature, the center alphanumeric display
will turn on to allow you to choose one
of six options:
1) FF (Full Frame): No aspect ratio
conversion is performed. This setting
is appropriate when the input and
display aspect ratios are the same.
2) LBX (Letterbox): This setting is to be
used when the source is 4:3 letter-
boxed and the display is 16:9. It
vertically increases the image size by
a ratio of 4/3.
3) SQ0 (Squeeze0): This is to be used
when the source is 4:3 full-frame and
the display is 16:9. It horizontally
decreases the image size by a ratio of
3/4 and centers the resulting image
horizontally with black bars on
either side of the image.
