Pac123M Machine Torch Assembly (No Quick Disconnect) - Hypertherm powermax600 Service Manual

PARTS LIST - TORCH AND CONSUMABLES

PAC123M Machine Torch Assembly (No Quick Disconnect)

Item Part Number Description
086004* PAC123M Machine Torch Assembly with 15 ft / 4.5 m Lead (No Quick Disconnect)
086005* PAC123M Machine Torch Assembly with 25 ft / 7.5 m Lead (No Quick Disconnect)
086006* PAC123M Machine Torch Assembly with 50 ft / 15 m Lead (No Quick Disconnect)
1 120613
2 020620
3 128374
3 128375
3 128376
4 027599
5 120583
6 044016
7 028714
128061
128062
*
Top assembly includes the following consumables:
120573
120576
120600
120826
120827
6-6
10-99
Sleeve, Machine Torch
Sleeve, Torch Position
Replacement Torch Lead, 15 ft / 4.5 m
Replacement Torch Lead, 25 ft / 7.5 m
Replacement Torch Lead, 50 ft / 15 m
Snap Ring
Torch Main Body with Safety Switch
O-Ring: BUNA 90 Duro 0.614 X 0.070 inch
On/Off Pendant with Lead, 25 ft / 7.5 m
On/Off Pendant with Lead, 50 ft / 15 m
On/Off Pendant with Lead, 75 ft / 23 m
Electrode
Swirl Ring
Retaining Cap
Nozzle
Shield
Quantity
