DI-701 iShare Internet Gateway
User Manual
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DI-701 iShare and is the answer not in the manual?

Questions and answers

Related Manuals for D-Link DI-701 iShare

Summary of Contents for D-Link DI-701 iShare

  • Page 1 DI-701 iShare Internet Gateway User Manual - 1 -...
  • Page 2 FCC COMPLIANCE STATEMENTS FCC Part 15 Registration This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ......................6 ........................6 EATURES ......................6 PECIFICATIONS HOW DOES IT WORK....................8 HARDWARE INSTALLATION ..................9 ..................9 ARTS AMES AND UNCTIONS Color......................... 9 STATUS........................... 9 Indicator........................9 VDC IN ........................10 ...................10 ARDWARE EQUIREMENTS ....................11 ARDWARE ONNECTIONS SYSTEM ENVIRONMENT ..................13...
  • Page 4 Static Global Port Setting (TP) .................16 ..................17 ONFIGURING OMPUTER GUI M ..................18 ONFIGURING IN Getting Started (GUI) ....................18 Static Global Port Setting (GUI)................18 Modifying Local Port Setting (GUI)................19 Management......................20 .............21 ONFIGURATION IN ERMINAL ROGRAM Getting Started (TP) ....................21 Static Global Port Setting (TP) .................23 Modifying Local Port Setting (TP) ................24 SETUP DIAGNOSIS......................26 TCP/IP N...
  • Page 5 FIRMWARE UPGRADE....................37 ....................37 YSTEM EQUIREMENTS INDEX ..........................39 - 5 -...

  • Page 6: Introduction

    INTRODUCTION The DI-701 iShare Internet Gateway is a high-bandwidth router that connects a LAN to the Internet over any external DSL or cable modem. The DI-701 iShare Internet Gateway allows multiple users to share a single Internet Service Provider (ISP) account. The DI-701 iShare Internet Gateway acts a both a DHCP (Dynamic Host Configuration Protocol) server and a DHCP client simultaneously.
  • Page 7 RJ-45 connector for 10 Base-T Ethernet to an external Cable/xDSL Modem. Console DB-9 female connector for configuration and firmware upgrade LED Indicators Power, Local Link, Local Speed 10/100, Local Full/Half duplex, Global Link, Error Electricity Power Input Power 5V DC @2.4A - 7 -...

  • Page 8: How Does It Work

    HOW DOES IT WORK Internet Cable / XDSL Modem Small Office / Home Users 10Mbps Ethernet Single IP Address IP Sharing for 10/100Mbps Cable / XDSL Modem Ethernet Figure 1: Small Office/ Home Office Setup - 8 -...

  • Page 9: Hardware Installation

    HARDWARE INSTALLATION Parts Names and Functions LED Indicators on the Front Panel Ports on the Rear Panel Local VDC IN Console Global 1 2 3 4 5 6 7 Figure 2: LED Indicators and Ports Table 1: LED Indicators and Connections Color Status Indicator...

  • Page 10: Vdc In

    Table 2: Essential Hardware Item Included in Description Connections Standard package From UTP Ethernet Global Port RJ-45 port of cross-over cable DI-701 iShare modem Power adapter VDC IN Port Wall outlet Self-Prepared Items Description Connections From CAT3 or CAT5 Local Port...

  • Page 11: Hardware Connections

    Setup through Windows Graphic User Interface Figure 3: Hardware Connections 1. Make sure your DI-701 iShare is installed and connected properly. Use a UTP Ethernet cross-over cable to connect the Global port. See Figure 3. 2. Use a CAT3 or CAT5 UTP Ethernet straight cable to connect the Local port to a free port on your hub or switch.
  • Page 12 3. Connect the Power Adapter to the VDC IN port into a wall outlet. 4. Use an RS-232 cable to connect the Console port to the administrator computer’s COM port. (Optional - for terminal program configuration only.) The following sections explain how to configure the administrator computer. - 12 -...

  • Page 13: System Environment

    Gather and write down the following information before beginning: Factory Default Setting The LAN parameters of the DI-701 iShare are pre-set in the factory. The default values are shown in Table 3: Local and Global Port Addresses. Table 3: Local and Global Port Addresses...

  • Page 14: Information From Isp

    Information from ISP If your IP address is provided dynamically by your ISP (Internet Service Provider), skip this step. Gather the information shown in Table 4: Assigned Addresses and keep it for reference. Table 4: Assigned Addresses IP address Ex. 203.66.81.201 ISP-assigning IP address Ex.

  • Page 15: Configuration Settings

    CONFIGURATION SETTINGS Before Getting Started The DI-701 iShare can be configured through the setup program provided or through a terminal emulation program (TP), such as Windows HyperTerminal. The installation choices are described in the following sections. See Table 5: Configuration in Windows GUI Mode for a guide to port configuration.

  • Page 16: Static Global Port Setting (Tp)

    Table 6: Configuration in Terminal Program Mode Local port setting Global port setting Read through following sections (IP address distribution) (IP address distribution) configuration Dynamic Modified Dynamic Static Configuring Your Computer Getting Started (TP) Static Global Port Setting (TP) Getting Started (TP) Modifying Local Port Setting (TP) Getting Started (TP)

  • Page 17: Configuring Your Computer

    Configuring Your Computer 1. Start Windows 98. 2. Go to the Start menu. Point to Settings. Click Control Panel. 3. Double-click Network. 4. Select the binding of TCP/IP and your Ethernet adapter. Click the Property button. 5. Check the item of ”Obtain IP address automatically”. Click OK. Figure 4: TCP/IP Properties 6.

  • Page 18: Configuring In Gui Mode

    4. When the following dialog box appears, click Find. Figure 5: DI-701 iShare Setup Program 5. The setup program finds the active DI-701 iShare. The password dialog box prompts you to enter a password. The Configure tab is highlighted if the password is correct.

  • Page 19: Modifying Local Port Setting (Gui)

    3. IP addresses, Subnet mask IP address, Gateway, and DNS server should be noted and entered accordingly if you are assigned a static IP address by your ISP. See Table 7: IP Addresses and Figure 6. Table 7: IP Addresses For example: IP address: 202.178.230.113...

  • Page 20: Management

    Figure 7: Local Port 9. When finished, click the OK button to complete the setting. Management Select the Management tab to change the administrator password as shown in Figure 8. - 20 -...

  • Page 21: Configuration In Terminal Program Mode

    Figure 8: Management Configuration in Terminal Program Mode Use terminal emulation on your PC/workstation for the initial configuration of your DI-701. Windows HyperTerminal or other terminal emulation applications can be used. The following example was done with HyperTerminal. Getting Started (TP) 1.
  • Page 22 Figure 9: Connect To: 6. When the dialog box shown in Figure 9 appears, set the Bits per second rate at 38400, and Flow control at None. Click OK to complete the setting. See Figure 10. Figure 10: COM 1 Properties 7.

  • Page 23: Static Global Port Setting (Tp)

    IP Sharing for Cable Modem/ADSL Modem/Ethernet BIOS Version: 1.00 (1999/10/06) ©Copyrights 1999, all rights reserved. SRAM Test ..O WAN NIC Test ..O MAC Address: 00 E8 80 C8 20 93 LAN NIC Test ..O MAC Address: 00 E8 80 C8 00 12 Internet SOAR is ready System starts up Welcome to SOAR 1.01...

  • Page 24: Modifying Local Port Setting (Tp)

    Secondary DNS server [0.0.0.0]: 202.178.244.207 New configuration will be: Save this configuration, and reboot device? (Yes/No): <DEFAULT: No> Y Save configuration and reboot ... Modifying Local Port Setting (TP) Example: IP address for local [192.168.0.1]: IP netmask for local [255.255.255.0]: Distribute configuration for PCs on LAN? (Yes/No) [Yes]: Distribute IP address pool start at [192.168.0.2]: DHCP IP address pool numbers [32]:...
  • Page 25 Secondary DNS server: [202.178.244.207] Save this configuration, and reboot device? (Yes/No): <DEFAULT: No> Y Save configuration and reboot... - 25 -...

  • Page 26: Setup Diagnosis

    SETUP DIAGNOSIS TCP/IP Network Diagnosis Execute WINIPCFG.EXE or PING.EXE for TCP/IP network diagnosis. WINIPCFG The WINIPCFG program is used to gather information about the TCP/IP connections that are active on your system. It cannot be used to dynamically adjust TCP/IP connections. You can also renew leases (if allowed by the network), and get the current IP address assignments through this program.

  • Page 27: Ping.exe

    Figure 13: IP Configuration Figure 13 displays the advanced settings of your TCP/IP connection. The computer name and DNS server the computer is configured to call when it is looking for a named resource are on top. The gateway for Internet access via the network specifies which server processes the request.

  • Page 28: Cable Connectivity Checkup

    C:\>ping 168.95.192.1 PING can be executed in Windows as shown below: 1. Go to the Start menu. 2. Click Run. 3. Type 168.95.192.1. Click OK. 4. The server is online if the following message appears. Reply from 192.168.0.1: bytes=32 time=3ms TTL=100 5.

  • Page 29: Terminal Commands

    TERMINAL COMMANDS You may type ? or help to list the main menu commands as below. command>help Internet SOAR version 1.67 ======================================================= Command Description ------------------------------------------------------- help Show this message passwd Change administrator's password show Display active configuration Configure device in batch vserv Set internal virtual server mapping release...

  • Page 30: Show

    New password (4 characters or numbers at most): **** Re-type new password: **** show Displays the current configuration. For first-time login, the current configuration is the factory default settings. Refer to section titled “Factory Default Setting” for detail. Example: IP address of local port: [192.168.0.1] SubNetmask of local port: [255.255.255.0] Distribute IP addresses to local computers: [Yes] Continuous IP address pool starts at: [192.168.0.2]...
  • Page 31 Or <ESC> to escape. IP address of local port [192.168.0.1]: SubNetmask of local port [255.255.255.0]: Distribute IP address to local computers? (Yes/No) [Yes]: Continuous IP address pool start at [192.168.0.2]: Number of IP address in pool [32]: Obtain global port configuration from ISP? (Yes/No) [Yes]: n IP address of global port [202.178.230.149]: 203.66.99.252 SubNetmask of global port [255.255.255.0]: Device name (0 to 20 characters) [Untitled]: CABLE_ISP...

  • Page 32: Vserv

    Secondary DNS server : [203.66.81.252] Save and reboot ?(Yes/No) : [No] vserv Displays the internal virtual server mapping. You can set (including add, delete) the applications’ names and the corresponding IP addresses of the local servers. “Natural firewall” allows requests for Internet access from the Local network, but no requests from the Internet to the Intranet are allowed.

  • Page 33: Release

    Example Del: Input command : 1)Show 2)Add 3)Del 0)Quit 3 Item Port(Application) Local server ==== ================= ================ 1. 80 (www) 192.168.0.12 2. 23 (telnet) 192.168.0.3 Which item will be deleted : 2 Example Quit: Input command : 1)Show 2)Add 3)Del 0)Quit: 0 release Gives up the obtained global port configuration.

  • Page 34: User

    Note that if you choose NOT to obtain the global port configuration from your ISP, this command won’t be executed and the following message will appear. Example: command>renew Works only if 'Obtain global port configuration from ISP' is enabled user Displays the current active user(s), up to 128.

  • Page 35: Session

    Elapsed 2 days & 1:28:30 The displayed items are explained as the following: IP address the assigned IP address Node address physical address for the network adapter Remainder time the balance of leasing time for each lease. For “expired”, it means the computer is out of time and in logoff.
  • Page 36 Active: 8(Maximum: 128 ) The value meaning of Flag field is: 01 idle UDP session active UDP session idle TCP session 07 active TCP session idle FTP control session active FTP control session idle TCP session has been aborted by client idle TCP session has been aborted by server The displayed items are explained as the following: IP client...

  • Page 37: Firmware Upgrade

    DI-701. Getting Uploaded 1. Connect the RS-232 cable from the Console port of your DI-701 iShare to the PC COM port. 2. At the DOS prompt, run FWUPLOAD.EXE with COM port specified. You can type "FWUPLOAD -?"...
  • Page 38 OK: Firmware upload succeeded. If any error message appears, check the cable connectivity and make sure that you have selected the correct COM port, then go through the steps again. Restart the DI-701 iShare to activate the new firmware. - 38 -...

  • Page 39: Index

    INDEX Assigned Addresses......13 passwd ..........28 Cable........... 27 PING ..........26 COM........... 20 release..........32 computer ..........16 renew ..........32 Configuration........14 requirements ........10 Configuring GUI......... 17 session ..........34 connections ......... 11 set ............29 Device Alive ........27 show ...........
