USCutter SC User Manual page 9

Blade Set Up
1 2
Unscrew the cap from the Set Brass Ring on Blade
Blade Carriage. Carriage to the fully down
position.
5
Screw the cap back onto Adjust the carriage cap until the blade
the Blade Carriage. is protruding approximately 1/64
inch.
6 months
Blades should be replaced every . Your blade may need to be replaced
more often if you are cutting thicker material such as flock, glitter, or reflectives.
425.481.3555
3 4
Remove the protective cover Insert the blade into the
from a new blade. top of the Blade Carriage.
6 7
Adjust the Brass Ring until it fits snug
th of an against the Cap. This will help keep
the cap in place during operation.
14
16
www.uscutter.com
Setting the Origin for SC Cutter
To set the Origin of where the SC cutter will begin
cutting from press the "Enter" button on "Local" while on
the Home Screen using the "Select" button to highlight
it if needed. This will enter the cutter into "Jog Mode"
where the left and right arrows of the control pad adjust
the position of the carriage and the up and down arrows
advance and retreate the media via the feed rollers. Once
you have your media and carriage in position press the
"Select" button, while in the Local Screen, to move the
cursor to "Current" then press "Enter" and the origin is
set in the correct spot.
Home Screen
SPD: 0mm/s PRS: 10g
LOCAL TEST COPY
Model SC Plotter
Local Screen
SPD: 0mm/s PRS: 10g
ORIGIN CURRENT ON
Model SC Plotter
425.481.3555
Control Panel
Changing SC Cutter Speed
and Force
To set speed and force of the SC cutter, make sure you
are back in the "Home" screen with "Local" highlighted.
Press "Enter". Use the up and down arrows to adjust the
speed and the left and right arrows to adjust the cutting
force. A typical cutting speed is 500mm/s, and a typical
cutting force is 100g.
Select
Enter
Reset
Select
Enter
Reset
