Certificate Information
ATEX / IECEx Certificate No TRAC12ATEX0037X / IECEx TRC 12.0019X
•
ATEX / IECEx Certificate Types Ex ib IIC T4 Gb Tamb -10°C to +40°C (Vapor)
•
Ex ib IIIC T200°C Db Tamb -10°C to +40°C (Dust)
•
Ex ib I Mb (Mining)
Temperature Information
Measurement Range -4°F to 1112°F (-20°C to +600°C )
Accuracy ± 2°C or 2% of reading
Imaging
Image Frequency 9Hz
Detector 320 x 240 uncooled microbolometer
Thermal Sensitivity/NETD 50mK
Spectral Range 8μm to 14μm
Field of View (FOV) 25° x 20.5°
Spatial resolution (IFOV) 1.38 mrad
Minimum focus distance ≈ 4" (10cm)
Lens F 1.2
Image Capture
File Storage 8GB
File Formats CDX (Radiometric) JPEG (Non-radiometric)
Voice Annotation YES
•
RFID Tag Reader Operates with 13.54MHz passive tags
•
Detection range up to 5cm (1.9in)
•
SupportsISO/IEC15693-2,ISO/IEC18000-3 tag formats
General
Operating Temperature -4°F to 104°F (-20°C to +40°C)
Storage Temperature -40°F to +158°F (-40°C to +70°C)
Display 3.2" Backlit LCD
Software CorDEX CONNECT (Included)
Batteries Removable and Rechargeable
Battery Life Upto 8 hours
RUGGED AUTHORITY
T7000 – Intrinsically Safe Thermal Imaging Camera
