ToughPIX 2304XP Series

USER GUIDE

Class 1 Div 1 B, C, & D T4
Email: sales@cord-ex.com
www.cordexinstruments.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ToughPIX 2304XP Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cordex Instruments ToughPIX 2304XP Series

Summary of Contents for Cordex Instruments ToughPIX 2304XP Series

  • Page 1: User Guide

    ToughPIX 2304XP Series USER GUIDE Class 1 Div 1 B, C, & D T4 Email: sales@cord-ex.com www.cordexinstruments.com...

  • Page 2: Table Of Contents

    CONTENTS 1. INTRODUCTION 1. INTRODUCTION 7. M ENU OPTIONS OVERVIEW Capture Menu Overview Congratulations on your purchase of the ToughPIX 2304XP digital camera. The Package Contents Scene Mode ToughPIX 2304XP is flameproof for use in Ex (potentially explosive environments. Size Equipped with a 5.0 megapixel sensor, this camera is capable of capturing images with 2.

  • Page 3: Getting To Know Your Camera

    2. GETTING TO KNOW YOUR CAMERA REAR VIEW FRONT VIEW LCD Monitor Screen Shutter Button Power Button OK button Digital Zoom button Flash 4-Way control button Lens Up button Menu button Self-timer LED Right button Battery Flash button Compartment Down button USB Connector Mode button Compartment...

  • Page 4: Lcd Monitor Display

    LCD MONITOR DISPLAY Video mode 1. Flash mode 2. Battery condition 3. Storage media 4. Main focus area 5. Video quality 6. Video Resolution 7. Available recording time/Elapsed time 8. Self-timer icon 9. Focus setting 10. Mode icon Playback mode - still image playback 1.

  • Page 5: Preparation

    3. GETTING STARTING PREPARATION CHOOSING THE LANGUAGE Specify in which language menus and messages are to be displayed on the LCD NEVER OPEN THE BATTERY OR USB COMPARTMENTS monitor. IN A HAZARDOUS ENVIRONMENT. 1. Press the MENU button. 1. Open the camera’s battery compartment. 2.

  • Page 6: Taking Pictures

    4. TAKING PICTURES CAPTURING IMAGES SETTING THE SCENE MODE The camera has six scene mode settings for the following 1. Switch the camera on. Press the Power button to turn the power on. Auto: Let the camera choose the settings. 2.

  • Page 7: Adjusting The Exposure (Ev Compensation)

    5. TAKING VIDEOS ADJUSTING THE EXPOSURE (EV COMPENSATION) RECORDING VIDEO CLIPS This mode allows you to record video clips at a You can manually adjust the exposure used by the digital camera. Use this mode resolution of VGA (640 x 480) or QVGA (320 x 240) when the proper exposure cannot be obtained, for example, when the contrast pixels.

  • Page 8: Viewing Photos And Videos

    6. VIEWING PHOTOS AND VIDEOS PLAYING BACK STILL IMAGES PLAYING BACK VIDEO CLIPS You can play back the still images on the LCD You can play back recorded video clips on the monitor. camera. 1. Press the button. 1. Press the button.

  • Page 9: Slideshow Display

    SLIDESHOW DISPLAY PROTECTING IMAGES The slideshow function enables you to playback Set the data to read-only to prevent images from your still images automatically in order one being erased by mistake. image at a time. 1. Press the button. 1. Press the button.

  • Page 10: Erasing Images

    7. MENU OPTIONS ERASING IMAGES CAPTURE MENU Erasing a single image / Erasing all images This menu is for the basic settings used by the camera to capture still images. 1. Press the button. The last image is displayed on the screen. 2.

  • Page 11: Iso

    SHARPNESS Refer to section in this manual titled “Adjusting the Exposure (EV Compensation)” for Sets the sharpness of the image. further details. * Hard / Normal / Soft COLOR Sets the color of the image. Sets the sensitivity for capturing images. When the sensitivity is raised *Standard/Vivid/Sepia/B&W (and the ISO figure is increased), photography will become possible even in dark locations, but the image will appear more pixelated (grainier).

  • Page 12: Video Menu

    PLAYBACK MENU VIDEO MENU In the mode, choose which settings are This menu is for the basic settings to be used to be used for playback. when recording video clips. 1. Press the button. 1. Press the MODE button to set the camera mode to 2.

  • Page 13: Setup Menu

    8. DOWNLOADING FILES SETUP MENU NEVER OPEN THE BATTERY OR USB COMPARTMENTS Set your camera’s operating environment. IN A HAZARDOUS ENVIRONMENT. 1. Press the MENU button. 2. Select the Setup menu with the u button. SYSTEM REQUIREMENT 3. Select the desired option item with the p buttons, and press the OK button to enter its Windows Macintosh...

  • Page 14: Technical Information

    Auto, Daylight, Cloudy, Tungsten, Fluorescent (two settings) Auto, 50, 100, 200 Interface USB connector Power 1 x ATEX Certifed CorDEX Instruments battery pack part number CDX2341-801 Dimensions (excluding battery) 165mm (W) x 105mm (H) x 70mm (D) Weight 1.5kg Ref. ID 2320, Rev. A...

  • Page 15: Ref. Id 2320, Rev. A

    UK Headquarters: Cordex Instruments Ltd No. 6 Farfield Main Road Wykeham Scarborough YO13 9QD Copyright © 2011, CorDEX Instruments Limited. All other brand and product names are trademarks of CorDEX Instruments Limited. Ref. ID 2320, Rev. A...
