  • Page 1 Always there to help you Register your product and get support at www.philips.com/welcome CED780/12 Question? Contact Philips EN User manual IT Manuale utente DE Benutzerhandbuch NL Gebruiksaanwijzing FR Mode d’emploi...

  • Page 2: Table Of Contents

    Contents Select program type RDS program types 1 Important Activate AF/TA functions Safety Notice 7 Use navigation system Insert map card 2 Your in-car entertainment system Use map Introduction What's in the box 8 Play with Bluetooth device Overview of the main unit Overview of the remote control Pair the Bluetooth-enabled devices Make a call...
  • Page 3 Set rear view camera Adjust display design Listen to other devices Detach the front panel Reset Replace fuse 13 Product information Playability information 14 Troubleshooting About the Bluetooth device...

  • Page 4: Important

    Bluetooth SIG, Inc. and any use of such Recycling marks by Philips is under license. Windows Media and the Windows logo are trademarks, or registered trademarks Your product is designed and manufactured with...

  • Page 5: Your In-Car Entertainment System

    Remote control Trademarks are the property of Koninklijke Philips Electronics Trim plate N.V. or their respective owners. Philips reserves the right to Carrying case for front panel change products at any time without being obliged to adjust earlier supplies accordingly.

  • Page 6: Overview Of The Main Unit

    Overview of the main unit a b c d a b c d • Adjust dimmer settings. OPEN • Press and hold to turn off TFT display. • Open/Close TFT screen. TILT • Adjust position of the screen. • Press to answer a call. •...

  • Page 7: Overview Of The Remote Control

    • Select DVD or DivX subtitle language. • Press to terminate call. • Turn maximizing sound on or off. • Tune for radio station. DVD MENU • • Skip/search for track. Access DVD main menu. • Fast backward/forward playback. • RESET Turn full sound on or off.

  • Page 8: Get Started

    Connector Connect to adjustment. If you have any questions regarding installation Yellow wire The +12V car battery which is live at kits, consult your Philips car audio dealer. all times. Blue/White The electric antenna control lead or Caution wire power supply lead of the antenna booster.

  • Page 9: Mount Into The Dashboard

    Connector/Object Connect to/with Caution Pink wire Extension wire • To avoid any accident, the driver must not watch video Extension wire (not Parking brake (-) while driving. This unit is designed to not allow watching included) moving video while driving. Park your car in a safe place and Brake switch engage the parking brake before watching moving video.

  • Page 10: Attach The Front Panel

    Note • If the unit is fixed by the supplied screws instead of the sleeve, skip this step. Attach the front panel Attach the trim plate. • Since the unit cannot be used if the slant angle of dashboard opening is above 20 degrees, ensure that the horizontal slant of the dashboard opening is between 0 and 20 degrees.

  • Page 11: Turn On

    Insert one CR2025 battery with correct polarity (+/-) as indicated. to display the full menu. Close the battery compartment. Turn on Caution • Risk of road accidents! Never watch videos or adjust settings while you drive. Press to turn the unit on. The setup menu is displayed.

  • Page 12: Connect Usb Device

    When USB device is disconnected, it plays the » previous source. Insert SD card Note • This device supports Secure Digital High Capacity To remove the disc, press the button. (SDHC) card. » When the disc is ejected, the unit switches to the previous source, if connected.

  • Page 13: Select Audio Track

    to display the second menu. to select: • [Rep: chapter]: play the current chapter repeatedly. • [Rep: title]: play all chapters in the title repeatedly. • [Rep: disc]: cancel repeat play. For VCD karaoke: to select: Drag along the search bar to display the alphabet •...

  • Page 14: Listen To Radio

    Zoom You can zoom in pictures for a close view. During view pictures, tap anywhere except for the upper left corner to display the control bar. repeatedly to zoom in/out the picture. Rotate pictures Store radio stations in memory During view pictures, tap anywhere except for the upper left corner to display the control bar.

  • Page 15: Turn On Rds

    TRAVEL Travel LEISURE Leisure JAZZ Jazz Music COUNTRY Country Music NATION M National Music OLDIES Oldies Music FOLK M Folk Music DOCUMENT Documentary Select program type TEST Alarm Test Before tuning to RDS stations, you can select program type and ALARM Alarm let the unit search only for programs of the selected category.

  • Page 16: Use Navigation System

    Pairing with unit to display home menu. The setting menu is displayed. » to display Bluetooth setting menu. Tap [New Pairing] to search for Bluetooth device with your device. Select the name of desired device in the pairing list. Enter default password "0000" in your device. iI the pairing succeeds.

  • Page 17: Make A Call

    When conversation ends, tap (red) to terminate Make a call the call. You can make phone call with the unit under any mode. Note • You can also press on front panel to answer/ terminate the call. • Ensure that the phone is connected to the unit via Bluetooth. Switch phone call to mobile phone on top of the screen.

  • Page 18: Bluetooth Phone Book Settings

    Play iPod Compatible iPod/iPhone The car audio system supports below iPod/iPhone models: Made for. • iPod touch (4th generation) • Tap on desired number to start calling. iPod touch (3rd generation) • iPod touch (2nd generation) Adjust Bluetooth settings • iPod touch (1st generation) •...

  • Page 19: Search For A Track

    • Unit control mode: tap screen on car audio to control the music. Search for a track During play from iPod/iPhone, you can search through the music/video files to select preferred file for listening/watching. During playing, tap Search list is displayed. » to select a preset EQ: •...

  • Page 20: Switch Music Listening Zone

    Tap on the screen to adjust music listening zone setting. Turn FullSound on/off Philips FullSound restores the audio details that is lost in music compression. It enriches the music signal, so what you hear is the full sound with every nuance of emotion and every detail of musical genius.

  • Page 21: Adjust General Settings

    General settings Options Description [Navigation Access the Navigation Program Path] Program Path mode. [Radio Region] Select one that matches your location. [Navigation [On] Turn the navigation voice on. Voice] [Beep] [On] Turn the beep sound on. Each time you press a button, [Off] Turn the navigation voice off.

  • Page 22: 12 Others

    12 Others Adjust brightness AV IN Press DISP on front panel repeatedly to adjust the dimmer settings. Press and hold DISP to turn off the display, press again or tap on TFT screen to switch on. to display home menu. Set rear view camera [AV-IN1].

  • Page 23: Replace Fuse

    Usable sensitivity - AM (MW) 25 uV • If the fuse breaks immediately after it has been replaced, there may be an internal malfunction. In this Screen size 7.0 inches case, consult your Philips dealer. Display resolution 800 x 480 dots Contrast ratio Brightness 450 cd/m2...

  • Page 24: Playability Information

    If you encounter problems when using this device, check the Bluetooth following points before requesting service. If the problem remains unsolved, go to the Philips web site Communication system Bluetooth Standard version 2.0 (www.philips.com/welcome). When you contact Philips, Output Bluetooth Standard Power Class 2...

  • Page 25: About The Bluetooth Device

    About the Bluetooth device Music playback is unavailable on the system even after successful Bluetooth connection. • The device cannot be used with the system to play music. The audio quality is poor after connection with a Bluetooth-enabled device. • The Bluetooth reception is poor.
  • Page 26 Specifications are subject to change without notice © 2012 Koninklijke Philips Electronics N.V. All rights reserved. CED780_12_UM_V2.2...
