Page 1
Please use this service manual with referring to the ● 修理の際は、必ず取扱説明書を参照の上、作業を行っ ● operating instructions without fail. てください。 Some illustrations using in this service manual are ● 本文中に使用しているイラストは、説明の都合上現物 ● slightly different from the actual set. と多少異なる場合があります。 Denon Brand Company, D&M Holdings lnc. X0378 V.05 DE/CDM 0903...
Page 5
り移動させた場合には、それらの作業が完了した時点でワ they were originally bundled or placed afterward. イヤーの整形をおこなってください。正しく整形されてい Otherwise, incorrect arrangement can be a cause of noise ないとノイズ発生の原因となることがあります。 generation. Wire arrangement viewed from the top 上面からみたワイヤー整形 Back Panel side Front Panel side RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 6
Note: All user settings will be lost and this factory setting 注意 : 初期化を行うとお客様が設定した内容が工場出荷 will be recovered when this initialization mode. 状態に戻りますので、あらかじめ設定内容を控え So make sure to memorize your setting for restor- ておき初期化後再設定してください。 ing after the initialization. RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 7
"EXPLODED VIEW" TRANS (Ref. No. of EXPLODED VIEW : C11) The viewpoint of each photograph Picture A (photography direction) Front side 各図の視点(撮影方向) Top view Picture C Picture D Picture B Picture E RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 8
( 手順 ) : TOP CABINET → LOADER PANEL → FRONT PANEL SUB ASSY (1) Disconnect the connector wire, FFC Cable and screws. (コネクターワイヤー、FFC ケーブルとねじをはずす。 ) Picture D FFC CABLE AMP PCB ASSY CX932 Picture C RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 9
シーをはずす。 ) CN53 Picture A Please refer to "EXPLODED VIEW " for the disassembly method of each P.W.B included in FRONT PANEL SUB ASSY. FRONT PANEL SUB ASSY の各基板のはずしかたは "EXPLODED VIEW " を参照してください。 RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 10
TOP CABINET → LOADER PANEL → FRONT PANEL SUB ASSY → CD MECHA (1) Remove the screws. (ねじをはずす。) Top View (2) Disconnect the connector wires and FFC cable.(コネクタワイヤーと FFC ケーブルをはずす。 ) Picture A FFC CABLE CN25 CN26 RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 11
( 手順 ) : TOP CABINET → LOADER PANEL → FRONT PANEL SUB ASSY → CD MECHA → HEAT SINK SUB ASSY (1) Disconnect the connecter wires. ( コネクタワイヤーをはずす。 ) CN95 CN72 Picture C RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 12
(3) Disconnect the connecter wires.(コネクタワイヤーをはずす。 ) CN97 CN73 Picture C Please refer to "EXPLODED VIEW " for the disassembly method of each P.W.B included in HEAT SINK SUB ASSY. HEAT SINK SUB ASSY の各基板のはずしかたは "EXPLODED VIEW " を参照してください。 RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 13
(2) Remove the screws.( ねじをはずす。 ) Bottom view Picture B Please refer to "EXPLODED VIEW " for the disassembly method of each P.W.B included in REAR PANEL SUB ASSY. REAR PANEL SUB ASSY の各基板のはずしかたは "EXPLODED VIEW " を参照してください。 RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 14
Picture E CN92 CN97 CN99 8. GUIDE UNIT proceeding ( 手順 ) : TOP CABINET → REAR PANEL SUB ASSY → SPK UNIT → GUIDE UNIT (1) Remove the screws.(ねじをはずす。 ) Bottom view RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 15
Picture B 9. TRANS proceeding ( 手順 ) : TOP CABINET → REAR PANEL SUB ASSY → SPK UNIT → GUIDE UNIT → TRANS (1) Remove the screws.(ねじをはずす。 ) Bottom View Picture B RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 16
(2) Open the CD tray by turning the Drive gear clockwise. す。 (3) Open the Stopper as shown in the fig., then detach CD (3) ストッパーを矢印方向に開き、CD トレーをはずす。 tray. Stopper Drive gear Stopper Sw pin CD tray RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 17
• The laser pick-up is OK if the amplitude level of the mea- sured RFO waveform is between 0.4 and 1.1 Vp-p, defec- tive otherwise. LD 破壊防止用ショートパターン Protective soldering place for laser diode. (コネクタを接続し、APC 回路通電前に外す事) RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 18
3.1 ディスク装着 ・スライドを初期設定位置(最内周から外側 3.1 Disc loading mounted automatically. 10mm の位置)に移動し、その状態でストップ ・ Move the slide to the initially set position (10 mm する. towards the outside from the innermost position) and stop in this status. RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 21
No. heat run repetitions displayed on 示する。 time display section. ・ヒートラン回数はローダーを OPEN し終えたところで ・ Increment the heat run repetition no. (increase インクリメント (increment:ヒートラン回数を 1 つ増やす ) by 1) at the point when the loader has finished opening. する. RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 22
The track no. and time when the error occurred is displayed for 5 seconds, then error display Error display reappears. switching (2) ・5 秒後にエラー表示に戻る.S6.3 参照 ・ Error display reappears after 5 seconds. See 6.3. RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 23
・ MCU_CD_USB B'D WN81 4,5,6pin, MCU_CD_USB B'D WN81 4,5,6pin, VFD_CE,VFD_CLK,VFD_DI VFD_CE,VFD_CLK,VFD_DI ・ IC24 on MCU_CD_USB B'D IC24 on MCU_CD_USB B'D 部品確認 Check Parts ・ FRONT B'D Q801,802,803 OK? FRONT B'D Q801,802,803 OK? 終了 RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 24
・ IC24 on MCU_CD_USB B'D ・ [IC15]:6,7,8 pin AKCS,AKCLK,AKCON ・ WN12 6,7,8pin on MCU_CD_USB B'D [IC15]:6,7,8 pin AKCS,AKCLK,AKCON WN12 6,7,8pin on MCU_CD_USB B'D AK_CDTI,AK_CLK,AK_CS AK_CDTI,AK_CLK,AK_CS ・ WF12 on INPUT B'D WF12 on INPUT B'D O.K. O.K. RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 26
Check Analog Audio Data output from FUNCTION IC ファンクションICからのオーディオデータの確認 INPUT B'D Check Soldering. INPUT B'D 半田付けを確認 [I11]:49.50pin LOUT,ROUT [IC11] on INPUT B'DMAIN UNIT. ・ [I11]:49.50pin LOUT,ROUT ・ [IC11] on INPUT B'DMAIN UNIT. O.K. O.K. to CD PLAY * Mark CD再生の*マークへ RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 27
Check Analog Audio Data output from FUNCTION IC INPUT B'D Check Soldering. INPUT B'D 半田付けを確認 ・ [I11]:49.50pin LOUT,ROUT ・ [IC11] on INPUT B'D [I11]:49.50pin LOUT,ROUT [IC11] on INPUT B'D O.K. O.K. to CD PLAY * Mark CD再生の*マークへ RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 28
Check Analog signal output from FUNCTION IC Check Soldering. ファンクションICからに出力信号を確認 半田付けを確認 INPUT B'D IC11 on INPUT B'D INPUT B'D ・ IC11 on INPUT B'D [IC11]:49,50pin LOUT,ROUT ・ [IC11]:49,50pin LOUT,ROUT O.K. O.K. to CD PLAY * Mark CD再生の*マークへ RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 31
SEMICONDUCTORS Only major semiconductors are shown, general semiconductors etc. are omitted to list. 主な半導体を記載しています。汎用の半導体は記載を省略しています。 1. IC’s TMP92FD28AFG (IC21) RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 36
Input pin for system clock oscillator X'tal Circuit (External Rfb=1M ) 3AI/F Output pin for system clock oscillator X'tal 3AI/F circuit Power supply pin for 3.3 V system clock XVDD3 oscillator circuit RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 37
Power supply pin for 3.3 V digital I/O circuit. SBSY Sub code block sync output pin CMOS PORT 3I/F CRCC check result output pin for sub code SBOK CMOS PORT Q data. 3I/F RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 38
Output impedance =2.5k both of according with servo 3AI/F analog/digital slice mode. frequency band. RF signal input pin Zin 20k 3AI/F Zin is selectable by command. RFRPi RF ripple signal input pin 3AI/F RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 39
To prevent the undefined pin states from affecting the servo circuitry or any other mechanical blocks in the system, appropriate measures should be taken, such as using a driver IC supporting a standby feature to place the system in standby mode while either of the above conditions is satisfied. RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 40
MCU power P70/TA0IN OPEN P71/TA1OUT OPEN P72/TA3OUT PORTABLE_IN Portable_input P73/TA4IN LED_ST ST LED Control P74/TA5OUT LED_PON Power LED Control P75/TA7OUT P_DOWN P_down port P80/TB0IN0/INT5 PROTECT_IN AMP protect detect P81/TB0IN1/INT6 HEADPHONE_IN headphone in detect RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 41
CD DSP reset P15/AD13/A13 MT_STBY motor stanby P16/AD14/A14 CD_CLOSE_M cd close motor P17/AD15/A15 CD_OPEN_M cd open motor P20/A0/A16 OPEN P21/A1/A17 CD_OPEN_SW cd open switch DVSS MCU +3.3V external interrupt, DVCC MCU +3.3V MCU power RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 55
Units: pF. 220pF (0 or 1) Indicates number of zeros after effective number. 2-digit effective number. Units: pF. When the dielectric strength is indicated in AC, "AC" is included after the dieelectric strength value. RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 68
EXPLODED VIEWS for EK model for JP model for EK model for EK model WARNING: Parts marked with this symbol have critical characteristics. Use ONLY replacement parts recommended by the manufacturer. z印の部分は安全を維持するために重要 な部品です。従って交換時は必ず指定の 部品を使用してください。 RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 69
M1 412010015015D VOLUME KNOB ASSY for Premium silver model CGK1A134YA M1 412010015008D VOLUME KNOB ASSY for Black model CGK1A134ZA M2 421410005018D BADGE, DENON for Premium silver model CGB1A205Z M2 421410005001D BADGE, DENON for Black model CGB1A205Y RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 70
CHD1A023R SCREW(CTW3+18JR) CTW3+18JR SCREW(CTB3+8JFZR) CTB3+8JFZR SCREW(CTB3+10JFZR) CTB3+10JFZR SCREW(CTBD3+8JFN) for Premium silver model CTBD3+8JFN SCREW(CTBD3+8JFZR) for Black model CTBD3+8JFZR SCREW(CTWD4+6FFN) for Premium silver model CTWD4+6FFN SCREW(CTWD4+6FFZR) for Black model CTWD4+6FFZR SCREW(CTB3+6FFZR) CTB3+6FFZR SCREW(CTS3+8JFZR) CTS3+8JFZR RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 71
EXPLODED VIEW OF CD MECHANISM UNIT 12-1 12-2 RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 73
7-7 90M-ZA000230R FM 1 POL ANT(UL) for RCDM37JP,DE500JP CSA1A019Z 7-8 00D3950030004 ANT, DAB T for RCDM37DABEK CSA272 943611000190S CORD, POWER EUR for RCDM37E2 CJA2B108ZV 943611000210S CORD, POWER UK for RCDM37DABEK CJA2E106ZV 943611000280S CORD, POWER JPN for RCDM37JP,DE500JP CJA2J091Z RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 74
Premium silver model 10 998545000090D LABEL, POS for DE500JP CQB1A880T LABEL, CONTROL for RCDM37E2/DABEK CQB1A627 00D5139111030 LABEL, COLOR for Premium silver model CQB1A882Z LABEL, CAUTION for RCDM37E2/DABEK CQB1A661Z 14 00D5150920307 CARD, WARRANTY for RCDM37JP,DE500JP CQE1A194W RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 75
Premium silver model CQB1A882Z 943531000240D BOX, MASTR CARTON CPG1A864Z SPEAKER ASSY for Premium silver model SCM37CWE3 SPEAKER ASSY for Black model SCM37BKE3 CD RECEIVER for Premium silver model RCDM37SPE3 CD RECEIVER for Black model RCDM37BKE3 RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 76
Ref. No. Part No. Part Name Remarks Q'ty New 943533000250D PAD(A) CPS1A819 943533000260D PAD(B) CPS1A820 LABEL, FCC CQB1A634Z LABEL, CAUTION CQB1A661Z RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 77
MEASURING POINT AND WAVEFORMS 各部の波形と測定ポイント MEASURING POINT CUP12092Z MCU UNIT (Foil side) Detail A RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 78
CUP12092Z MCU UNIT (Component side) Detail B Detail C Detail D RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 79
② FEI ③ FOO ③ FOO ⑥ FMO ⑥ FMO TCD-784 TCD-W082L (3) DISC detection ② FEI(5pin) ② FEI(5pin) ③ FOO ③ FOO ④ TEI ④ TEI ⑤ DMO ⑤ DMO TCD-784 TCD-W082L RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 82
ALL RESISTANCE VALUES IN OHM. k=1,000 OHM M=1,000,000 OHM ALL CAPACITANCE VALUES IN MICRO FARAD. P=MICRO-MICRO FARAD EACH VOLTAGE AND CURRENT ARE MEASURED AT NO SIGNAL INPUT CONDITION. CIRCUIT AND PARTS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE. RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 83
TUNER IN y e w GRND CD/USB INPUT B'D Lch SIGNAL LINE Rch SIGNAL LINE SCHEMATIC DIAGRAMS (1/3) Lch and Rch common SIGNAL LINE MCU CD USB UNIT RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 84
CD/USB AMP B'D Lch SIGNAL LINE Rch SIGNAL LINE Lch and Rch common SIGNAL LINE SCHEMATIC DIAGRAMS (2/3) INPUT UNIT RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
Page 85
PORTABLE H/P OUT USB IN SP OUT Lch SIGNAL LINE Rch SIGNAL LINE Lch and Rch common SIGNAL LINE SCHEMATIC DIAGRAMS (3/3) MAIN UNIT RCD-M37 / RCD-M37DAB / D-E500 / D-M37...
