FOR VEHICLE USE
Instructions for Installation & Use
IMPORTANT:
KEEP THIS BOOK IN THE PLACE PROVIDED ON THE CHILD RESTRAINT
To be used with either a lap-sash seat belt or
an add-on accessory child harness by children
whose shoulders are above the lower shoulder
height marker with head restraint in lowest
position (approximately 4 years of age) until
child's shoulders reach the upper shoulder
height marker with head restraint in highest
position (approximately 6 to 8 years of age).
Suitable for use only with the Safe-n-Sound™
Protecta PLUS™ Harness Series 220/2010 or
Babylove™EzyGo Harness™Series BL220/2010.
BOOSTER SEAT
Series No. 20/B/2010
