Summary of Contents for Next generation 4050/A/2013
- Page 1 CHILD BOOSTER SEAT Instructions for Installation & Use Series No. 4050/A/2013 IMPORTANT: KEEP THIS BOOK IN THE PLACE PROVIDED ON THE CHILD RESTRAINT...
-
Page 2: Table Of Contents
INDEX PAGE INTRODUCTION WARNINGS SHOULDER HEIGHT MARKERS AND A GROWING CHILD SHOULDER HEIGHT MARKERS AND THE NEXT STEP FEATURES HOW TO SETUP HOW TO USE CARE AND MAINTENANCE ACCESSORIES IN CASE OF CRASH... -
Page 3: Introduction
Use a larger booster seat. Carefully read all the instructions for installation. If in doubt about the method of installation, consult Next Generation Nursery Products Pty. Ltd. or agent or a child restraint fitter or, in New Zealand, consult the agent for the vehicle. -
Page 4: Warnings
• Use the restraint exactly as shown in the instructions. • Supervision of children is needed because they may be able to undo the buckles. • DO NOT LEAVE CHILDREN UNATTENDED IN THE CAR. • Do not alter or modify this restraint. •... - Page 5 IMPORTANT : • The restraint should not be purchased or sold as a second hand item. It is recommended not to use child restraints older than 10 years as the protection in an accident may be reduced. • Seatbelt extenders are not recommended to be used if the seatbelt is not long enough to secure the child restraint.
-
Page 6: Shoulder Height Markers And A Growing Child
SHOULDER HEIGHT MARKERS AND A GROWING CHILD Label B Label A Height label will be behind the child’s neck. SMALLER CHILD Shoulders must not be below the Lower Label A Shoulder Height Marker. From approximately 4 years of age. Front of Vehicle TALLER CHILD Label B Shoulders must not be above the Upper... -
Page 7: Shoulder Height Markers And The Next Step
SHOULDER HEIGHT MARKERS AND THE NEXT STEP IMPORTANT: Follow this advice. LOWER SHOULDER HEIGHT MARKER : Label A The child’s shoulders must be in-line or above this marker. Approximately 4 years of age. If the child’s shoulders are below then the child should remain in their previous child restraint. - Page 8 SHOULDER HEIGHT MARKERS AND THE NEXT STEP Next type of restraint that can be used in the car for your child. When your child has outgrown the seat, you can then use either restraint methods as follows: Just the car's lap-sash seatbelt. Lower leg must hang over the edge of the seat cushion.
-
Page 9: Features
FEATURES 1. Shoulder Height Markers Front of Vehicle 2. Car Seatbelt 3. Padded Cover for Comfort BOOSTER SEATBELT PATH label (each side, for lap belt) 5. KeepSafe™guide 6. Sash guide BOOSTER SEATBELT PATH label (each side, for sash belt) -
Page 10: How To Setup
HOW TO SETUP UNFOLDING THE BOOSTER SEAT If the seat is in a folded position, grip the Booster seat back and seat base and unfold till you hear it lock into position. CAUTION: DO NOT PLACE FINGERS IN BETWEEN SEAT BACK & SEAT BASE WHEN FOLDING OR UNFOLDING. - Page 11 HOW TO SETUP ADJUSTING THE KEEPSAFE™GUIDE The crotch strap can be adjusted so that it fits the seatbelt correctly to the child. The crotch strap length adjuster can be found under the seat. A. Adjust the crotch straps for the KeepSafe™guide so that the Lap portion of the seatbelt is sitting on the child's thighs and the clip prevents the lap belt rising on the abdomen.
- Page 12 HOW TO SETUP ADJUSTING THE SASH GUIDE POSITION A. The sash guide needs to be positioned in-line with or just above the child's shoulders. Sash B. Remove trim at the top rear of the guide restraint, then pull the cover forward to reveal the Sash guide which is attached to a strap at the back of the seat cover.
- Page 13 HOW TO SETUP The sash guide should be used to correctly To Lengthen position the sash portion of the lap-sash seatbelt across the child's shoulder and Hold the strap, chest. rotate and pull Feed the adjusting strap into the slot on the the sash guide to lengthen cover that is just below the child's shoulder.
- Page 14 HOW TO USE WITH LAP-SASH SEATBELT A. Place the booster seat in the desired seating position. B. Seat the child in the seat. The child's shoulders must be between the lower and upper shoulder height markers. C. Pull the seatbelt out fully and place the lap belt over the child's hips and thighs, BOOSTER SEATBELT PATH across the red label, engage seatbelt buckle and...
- Page 15 HOW TO USE D. Feed the sash-belt across the child's chest and through the sash guide. The sash guide should be used to correctly position the sash portion of the lap-sash seat over the child’s shoulder and across the chest. Continue to adjust the height of the sash guide so that the guide is above the child’s shoulder as the child grows.
- Page 16 HOW TO USE E. Hook the KeepSafe™guide over the lap part of the seatbelt with the lap belt positing logo facing forward. The KeepSafe™guide must be used at all times to prevent the child slumping (sliding forward at base of seat) as the lap belt on the abdomen is dangerous in the event of a crash.
- Page 17 HOW TO USE G. The seatbelt must fit firmly but comfortably across the lap and chest. If needed, adjust the vehicle seat to improve the position of the sash on the child’s chest. It should pull to the rear of the child. H.
-
Page 18: To Remove Child
HOW TO USE WARNING: A SASH BELT UNDER THE ARM OR BEHIND THE BACK IS DANGEROUS SEATBELT UNDER SEATBELT BEHIND THE THE ARM BACK IS DANGEROUS IS DANGEROUS Seatbelt fitting closely NOTE: Seatbelt extenders should across the chest and not be used if the seatbelt is through the sash guide not long enough to fit around and over the top of the... -
Page 19: How To Clean
Washing and care instructions are on the care label attached to the cover. Refer to the following pages for instructions on how to remove and replace the cover. VERY IMPORTANT: Only replace the cover with Next Generation Nursery Products supplied replacement cover with identical shoulder height markers or a replacement cover meeting AS/NZS 8005. - Page 20 CARE & MAINTENANCE TO REMOVE COVER 1. To remove the main cover unclip clips (B and C) located at the lower back of the seat. Lift and peel away A from seat. 2. To remove the base cover unclip clips (D) and feed KeepSafe™guide (E) through the cover and peel away from seat.
-
Page 21: Accessories
ACCESSORIES MESSY MAT™ (IF SUPPLIED) Place ribbed or pocket end of the Messy Mat seat protector on edge of car seat, smooth back toward seat join (’A’) and fit in any excess Messy Mat into the join of the car seat (’A’). Hook and loop attachment referred in some Short Messy Mat instruction books, are no longer required to fit this... -
Page 22: In Case Of Crash
IN CASE OF CRASH If your restraint has been involved in a severe crash, you should destroy the restraint even if no damage is obvious. Some insurance companies offer vehicle insurance which covers or partially covers the replacement of your child restraint. Contact your insurance company for further details. - Page 23 VERY IMPORTANT: Only use this child restraint with the cover supplied or a manufacturer-authorised replacement cover with identical shoulder height markers. Next Generation Nursery Products Pty. Ltd. A.C.N. 113 490 949 Australia 6 Thorpe Street, Sunshine, Victoria 3020. Phone No. 1300 363 358 New Zealand Phone No.
- Page 24 Hipod trademark is the property of Next Generation Nursery Products Pty. Ltd. © 2013 Next Generation Nursery Products Pty Ltd. P/No. 2201575/A...
