MANUAL
K3 CD DI PLAYER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the K3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Roksan Audio K3

Summary of Contents for Roksan Audio K3

  • Page 1 MANUAL K3 CD DI PLAYER...
  • Page 2 NOTE: Laser Safety This unit employs a laser. Only qualified persons should remove the cover or attempt to service this unit due to the risk of eye injury.
  • Page 3 Congratulations on the purchase of your Roksan K3 CD Di PLAYER. Your audio component is designed and manufactured to the highest specifications and rigorously tested to offer many years of reliable and high quality musical enjoyment. Correct installation and operation of the product will have a significant influence on the performance of your audio sys- tem and ensure many years of trouble-free listening.
  • Page 4 CAUTIONS AC MAINS SUPPLY Your K3 CD Di Player is set to operate from a fixed supply voltage which is marked on a label next to the mains input plug. Before connecting the mains lead please check that your mains...

  • Page 5: General Cautions

    Location Your K3 CD Di Player should be located in a well ventilated area and kept away from sources of heat, dust and humidity and out of direct sunlight. The CD Player may be positioned either as a free standing unit or alongside another audio/ video product.

  • Page 6: Installation

    ROKSAN K3 MANUAL INSTALLATION K3 CD Di Player- Front Panel View 1 2 3 1 Open / Close Button 2 Stop Button 3 Play/Pause Button 4 Fluorescent Display 5 CD Disc Tray 6 Track Back Button 7 Track Forward Button...
  • Page 7 ROKSAN K3 MANUAL K3 CD Di Player - Rear Panel View 1 6 17 1 8 12 Analogue Output (Left & Right) 13 Digital Outputs (Optical: Toslink; Balanced: AES/EBU; Coaxial: RCA) 14 Digital Coaxial Input 15 Digital Optical Input 16 IEC Mains Inlet Socket 17 AC Mains Fuse Holder 18 Voltage &...

  • Page 8: Analogue Output

    • 1 x Toslink Optical (14) Any device with a digital output can be connected to the K3 CD Di and the signal will be fed to the analogue outputs of the player into the relevant amplification. If the digital source device you wish to connect has either optical, coaxial (or both) digital output(s) it can be connected to the CD Di to utilise the player’s circuit for superior sound performance.
  • Page 9 (display will indicate: no disc). When a disc has been loaded, your K3 CD Di Player will briefly spin the disc while it studies the data encoded on it. The disc will then stop and the display will indicate the number of tracks on the disc and the total play time.
  • Page 10 OPERATING THE DIGITAL INPUT If you wish to use an external digital source, it should be connected to the K3 CD Di by either the coaxial (14) or optical (15) digital input options on the rear of the K3 CD Di. Now select the correct input via the rocker switch located on the underside right of the unit (10).

  • Page 11: Troubleshooting

    MANUAL TROUBLESHOOTING If you suspect your ROKSAN K3 CD Di Player is not operating properly, first check all the connections carefully. Pay particular attention to input and output connections. Phono plugs should be fully inserted- a frequent cause of problems is that Phono plug surrounds do not make proper contact.
  • Page 12 ROKSAN K3 MANUAL GUARANTEE Your ROKSAN Product is guaranteed against any defect in materials and workmanship for a period of five years from the date of purchase. This guarantee only becomes effective once your product has been registered within fourteen days of purchase.

  • Page 13: Specifications

    ROKSAN K3 MANUAL SPECIFICATIONS Operating System CD Digital Audio System (CD, CD-R, CD-RW) Frequency Response 20Hz – 20kHz (± 0.2dB) Harmonic Distortion < 0.002% @ 0dB, 1kHz < 0.006% @ -30dB, 1kHz < 0.002% @ 0dB, 20Hz < 0.008% @ 0dB, 20kHz Intermodulation Distortion <...
  • Page 14 ROKSAN AUDIO LIMITED +44 (0)20 8900 6801 www.roksan.co.uk Jubliee Close Townsend Lane London, NW9 8TR United Kingdom All specifications are liable to change without notice. E&OE...

This manual is also suitable for:

K3 cd di
