Specifications
• Input impedance: greater than 1MOhm
• Output impedance: less than 10KOhm
• Controls: depth and rate
• Features: Stagger-tuned capacitors
with a unique 'golden ratio'
• Pink LED: pulsates with modulation speed
for visual song tempo matching
• L.F.O.: 0.1-10Hz (smoothed triangle)
• Power requirements: 12VDC @ 1.2A
• Dimensions: width 6.8" depth 4.8" height 2"
• Weight: 2lb (on Earth); 0.3lbs (on Europa)
• Construction: solid die-cast aluminum box
• Finish: high-gloss Cadillac pink powder coat
Warning: High D.C. voltages
of over 300 volts are present in
the circuit: disconnect power
before opening the unit. There
are no user serviceable parts
inside
Effectrode regarding warranty
or servicing.
Serial #
VC-1A
Copyright © 2009 Effectrode
this
pedal.
Contact
®
Audiophile Pedals
Owner's Manual
33866 SE Eastgate Circle, Corvallis, OR 97333
www.effectrode.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Effectrode vibra chorus
Summary of Contents for Effectrode vibra chorus
-
Page 1: Specifications
There are no user serviceable parts inside this pedal. Contact Effectrode regarding warranty or servicing. Serial # VC-1A 33866 SE Eastgate Circle, Corvallis, OR 97333 ® Copyright © 2009 Effectrode Audiophile Pedals www.effectrode.com... - Page 2 The 12AX7 tube in the Vibra Chorus can be swapped used, other than the appreciating the outstanding with many 9-pin double triode tubes, including tone your guitar has.
- Page 3 Controls space In the scheme of things the Vibra Chorus sits somewhere between Leslie/Fender Vibratone rotating speaker systems and the first electronic devices like the Uni-Vibe. So, in a way it's something that was missed along the evolutionary path of the chorusing effect. Its phase-shifting...
- Page 4 Phase delay chorus - Early chorusing and vibrato effects, which tend to sound ‘darker’ on lower was achieved by means of a mechanical rotating intensity settings, the Vibra Chorus maintains a speaker assembly - acoustically adding doppler much lighter tone on all depth settings. When used...
