Vari Lite VL2000 Service Manual page 113

No. Item
19 62.3009.0473
20 62.4000.0105
21 62.4000.0200
22 62.4205.0107
23 62.4225.0107
24 62.4228.0106
25 64.4016.0506
26 68.4566.0001
27 82.5325.0001
28 83.3163.0001
29 83.3173.0005
30 84.0068.0812
31 84.4234.0002
32 84.4263.0001
33 84.4270.0001
34 84.4285.0001
35 85.3773.0001
36 87.7247.0001
37 87.7302.00XX
38 88.8130.0001
02.9 673.00 10 D
Qty. UM. Description
12 EA CAP, .047UF 50V 10% MONO CER CHIP SUR MT
14 EA CAP, .1UF 50V 20% CER CHIP SUR MT Z5U EIA0805 C4, C10,
2 EA CAP, 20PF 50V 5% CER CHIP SUR MT COG EIA0805
1 EA CAP, 100UF 10V 20% SUR MT
1 EA CAP, 100UF 35V 20% ALUM ELECTRO SUR MT
4 EA CAP, 10UF 50V 20% ALUM ELECTRO SUR MT
1 EA CRYSTAL, 16MHZ SUR MT
1 EA INDUCTOR, 173UH PE-53819S LCI-37 SUR MT
1 EA DIODE, MBRS130LT3 SCHOTTKY SUR MT
1 EA IC, MC34164D-5 SENSING CIRCUIT
UNDERVOLTAGE SURFACE MOUNT
1 EA IC, LM2594M-5 150KHZ 0.5A STEP-DOWN
VOLTAGE REGULATOR
1 EA IC , MC68HC812A4PV8 (UNPRGMMD) 16BIT
MICROCONTROLLER
1 EA IC, RS485 TRANSCEIVER SUR MT SOIC PKG
1 EA IC, AD7302BR 8-BIT DAC 2.7-5.5V PARALLEL
INPUT DUAL VOLTAGE OUTPUT
1 EA IC, NC7S08M5 SINGLE AND GATE SUR MT
1 EA IC, NC7S04M5 HS INVERTER
4 EA IC, STEPMOTOR DRIVER
1 EA IC, AM29F200BT FLASH MEMORY 5V
1 EA INSTALLER DISK SET, BURNER VL2000
LUMINAIRES
1 EA LED, GREEN SUR MT WATER CLEAR LENS
(REEL)
24-March-2004
I P B
L L U S T R A T E D A R T S R E A K D O W N
3
: Y
O K E
Ref.
C3, C6, C7,
C9, C12,
C14, C15,
C19, C25,
C28, C29,
C30
C13, C17,
C24, C26,
C31-C38
C20, C21
C22
C23
C1, C2, C8,
C16
Y1
L1
D1
U5
VR1
U8
U2
U9
U12
U6
U1, U3, U4,
U7
U11
D2
