290A Installation Guide
1. Unpacking
In your box with the 290A housing you will find a small plas-
tic bag containing:
1
2
3
4
2. Fitting your camera inside the housing
Recommendation: Fit the camera in indoor conditions.
2.1. Open the housing by releasing the two clips on the side.
2.2. Undo the two screws (6) on the camera mounting board
(7) and keep them safe (see Picture 1). Slide the board
backwards and lift it out.
6
Picture 1
2.3. Attach the lens to the camera (refer to the Axis Installa-
tion Guide provided with the Axis camera).
290A Outdoor Housing
No.
1. One large allen key
2. One small allen key
3. Two locking screws
4. Four M8 wall fixings
5
5. Four plugs (11x50
mm) for use in solid
walls
7
2.4. Attach the camera to the camera mounting board (7)
using the screw attached to the board. You will find a
screw hole (8) at the bottom of the camera (see Picture
2). Before tightening the screw, position the camera
with the board inside the housing (with the lens to the
front) (see Picture 1) and determine the camera's cor-
rect position.
Recommendation: The lens should be as close to the
window as possible.
Caution: Allow sufficient space between the lens and
window to accommodate the lens' zoom function. Once
the correct position has been established, lift out the
camera with the board while keeping it in the correct
position. Tighten the screw at the bottom to securely
affix the camera to the board.
Caution: The heater at the front of the housing unit be-
comes hot when in operation. Position the cable con-
nected from the DC IRIS socket to the lens so that it does
not touch the heater.
Caution: Do not over-tighten the screw as you may
damage the camera.
2.5. Position the camera with the board inside the housing
as before (see Picture 1). Make sure the board is inserted
under the lugs beneath the window in its most forward
position. Use the two screws (6) undone under 2.2 to
mount the board with the camera and lens back into the
housing.
2.6.Close the housing with the two clips on the side.
Your housing is now ready for installation outdoors.
290A
Picture 2
8
1/4
