Specifications

Pow er requirements Class 2, 16.5 VAC, 40 VA, 60 Hz (600-1023 or
600-1024)
Rechargeable battery: 12 VDC, 4.5 or 5.0 Ah
lead-acid (60-681) or 12 VDC, 7 Ah (60-680).
The battery w ill last 24 hours w ith no AC and
specified stand-by load.
Auxiliary pow er 1.0 A at 9 to 14 VDC (12 VDC typical)
output
Radio frequency 319.5 MHz
Nominal RF range 1,000 feet (305 m) typical open air
Storage temperature -30 to 140ºF (-34 to 60ºC)
Operating 32 to 120ºF (0 to 49ºC)
temperature
Maximum humidity 85% relative humidity, noncondensing
Dimensions (H x W x 14 x 12 x 3 in. (35.6 x 30.5 x 7.6 cm)
D)

Regulatory information

UL listed installations
This section describes the requirements for UL listed
installations.
Basic system:
•
Control panel (600-1021-95R Concord 4 RF, 600-1022-
95R Concord Express V4, 600-1040 Concord Commercial
V4, or 600-1042 Concord 4 Hybrid).
•
Standard class 2 16.5 VAC, 40 VA power transformer 22-
145 or 22-156 (600-1023), 22-156-CN, or 22-145-CN
(600-1023-CN), or power line carrier class 2 16.5 VAC, 40
VA power transformer 22-149 (600-1024) or 22-149-CN
(600-1024-CN). You must order these transformers
separately from UTC Fire & Security.
•
Backup battery 12 V 4.5 or 5.0 Ah (60-681) or 12 V 7 AH
(60-680).
•
SuperBus 2000 fixed display touchpad (60-820), FTP
1000 (600-1020), 2x16 LCD touchpad (60-746-01), ATP
1000 (60-983), ATP 2100 (60-985), ATP 2600 (60-984),
2x20 LCD touchpad (60-803), or 2x20 VFD touchpad (60-
804).
•
Interior speaker siren (60-528), hardwired interior siren
(13-949), or speaker siren (13-060).
•
Basic system but also include a SuperBus 2000 RF
receiver (60-764-95R-01) or a SuperBus transceiver (600-
1025-01-95R).
Household burglary alarm system unit (UL 1023)
Basic system plus the following:
Concord 4 Installation Guide
•
Hardwired magnetic contact (13-068 or 13-071) or
wireless learn mode door/window sensor (60-362)
•
Immediate beeps set to on.
•
UL 98 options set to on.
•
Receiver failure set to on (if wireless devices are used).
•
Siren verify set to on.
•
Exit delay set to 60 seconds.
•
Quick exit set to off.
•
Siren timeout set to 4 minutes or more.
•
Entry delay set to 45 seconds or less.
•
RF TX timeout set to 24 hours (if sys tem includes built in
receiver or SuperBus 2000 RF receiver or SuperBus 2000
RF transceiver and wireless burglary sensors).
•
Extended delay set to off.
•
Sleep time set to off.
•
Two trip error set to off.
•
Alarm verify set to off.
•
Disable trouble beeps set to off.
Household fire warning system (UL 985)
Basic system plus the following:
•
Wireless smoke sensor 60-506-319.5, 60-848-02-95, or
TX-6010-01-1 learned into sensor group 26.
•
Immediate beeps set to on.
•
UL 98 options set to on.
•
Receiver failure set to on (if wireless devices are used).
•
Siren verify set to on.
•
Sleep time set to off.
•
Siren timeout set to 4 minutes or more.
•
Two-trip error set to off.
•
Disable trouble beeps set to off.
•
RF TX timeout set to 4 hours (if system includes built in
receiver or SuperBus 2000 RF transceiver and wireless
smoke sensors).
UL 1023 and 985 24-hour backup
For 24-hour backup, the total current draw for all
connected devices is limited to 90 mA (during normal
standby conditions) using a 4.5 or 5.0 Ah battery, or 190
mA (during normal standby conditions) using a 7.0 Ah
battery.
SIA system requirements
SIA system requirements are the same as those
described for a UL-listed basic system. If multiple
annunciation is required, use additional touchpads. This
applies to model numbers 60-746-01, 60-803, 60-804,
60-820, 60-983, 60-984, 60-985, and 600-1020. UL
requirements take priority over SIA requirements.
Table 11 on page 10 describes programming
requirements to meet ANSI-SIA CP-01.
