Eight Supervised Inputs For Various Hardwired Detectors. Zone - Interlogix Concord 4 RF Installation Manual

Num ber Nam e Application
19 Delayed Interior doors that initiate a delay
interior before going into alarm
20 Delayed PIR motion sensors that initiate a
interior delay before going into alarm
21 Local instant 24-hour local alarm zone protecting
interior anything that opens and closes
22 Local Same as group 21, plus activation
delayed initiates a delay before going into
interior alarm
23 Local instant 24-hour local alarm zone protecting
auxiliary anything that opens and closes
24 Local instant 24-hour local alarm zone protecting
auxiliary anything that opens and closes,
sirens shut off at restoral
25 Local Notify the user w hen a door is
special opened, sounds emit from a local
chime annunciator
26 Fire 24-hour fire, rate-of-rise heat, and
smoke sensors
27 Output Hardw ired output module (HOM)
module lamp control or other customer
features
28 Output HOM, PIR motion sensor, sound
module sensor, or pressure mat
29 Auxiliary Freeze sensor
32 Output HOM, PIR motion sensor, sound
module sensor, or pressure mat
33 Siren Wireless siren supervision
34 Gas Carbon monoxide (CO) gas
detectors
35 Local instant Local alarm levels 1 and 2, report to
police (day CS in level
zone)
38 Auxiliary Water sensor
1. This group is not certified as a primary protection circuit for UL-listed systems and is for supplementary use only.
2. Sound instant police siren if tw o or more sensors are tripped w ithin 4 minutes. Otherw ise sensors are followers to delayed sensors. If
Alarm Verification is on, group 18 functions like group 17.
3. This group has not been investigated by UL.
4. This group is required for UL-listed residential fire alarm applications.
5. Does not satisfy Auto Stay Arming exit requirement.
8
Alarm
Police
1
Police
1
Police
Police
Auxiliary Instant
3
Auxiliary Instant
1
Special
chime
1
Fire
Silent
3
Silent
3
Auxiliary Instant
Silent
3
Silent
Auxiliary Instant
3
Police
3
3
Auxiliary Instant
Delay Restoral Supervisor
y
Interior X
Standard
Instant X
Standard X
X
X
Instant
Instant X
Instant X
Instant
X
Instant
Instant
X
Instant X
X
CS Chim e
report (level)
X X
X X
X
X
X
X
X
X X
X
X
X X
X X
X X
X X (level 3
only)
X X
Concord 4 Installation Guide
Active
(level)
3
3
1, 2, 3
1, 2, 3
1, 2, 3
1, 2, 3
1, 2, 3
1, 2, 3
1, 2, 3
1, 2, 3
1, 2, 3
1, 2, 3
1, 2, 3
1, 2, 3
1, 2, 3
1, 2, 3
