User Guide
Connec-
tions
Earphones/Headphones
1. Connect earphones or headphones to the earphones port.
Balanced Earphones/Headphones
1. Connect supported earphones or headphones to the
balanced port.
Balanced Audio Device
1. Connect to an external audio device by using the Earphones
port and Balanced port in conjunction.
Astell & Kern balanced cable (PEF12, PEF21) is not supported.
OR
OR
Earphones Port
Balanced Port (LR)
(Ground)
Getting Started
06
