Summary of Contents for mundoclima CL23190
- Page 1 Duct 100% fresh air Installation manual CL23190 to CL23194 English www.mundoclima.com...
-
Page 2: Table Of Contents
Installation manual Duct 100% fresh air The appliance shall not be installed in the laundry. CONTENTS PAGE If the supply cord is damaged, it must be replaced by the INSTALLATION PRECAUTION..............1 manufacturer or its service agent or a similarly qualified person INSTALLATION PLACE................1 in order to avoid a hazard. -
Page 3: Accessories
Installation manual Duct 100% fresh air ● There is combustible gas or materials. The following are selectable accessories Remote controller & Its Frame ● There is much evaporating acid or alkaline gas. 1. Remote controller........1 ● Other special areas. Notes Before Installation Select the correct carry-in path. - Page 4 Installation manual Duct 100% fresh air Wooden construction Take out the air-in grill. Put the square timber traversely overthe roof beam, then Dismantle the air filter install the hanging screw bolts. (Refer to Fig.4-1) Clean the air filter (Vacuum cleaner or pure water may be Timber over the beam used to clean the air filter.
- Page 5 Installation manual Duct 100% fresh air The positioning of ceiling hole and indoor unit and hanging screw bolts routine method of installation: the size of installation for indoor unit following the Fig.4--9 and Fig.4-10 12.5~14kW Unit: mm PLASTIC COVER ELECTRICAL CONTROL AIR INTAKE 4-12*25 OBLONG SUSPENTION BOLT HOLES...
- Page 6 Installation manual Duct 100% fresh air Fig.4-10 Position A Water Tray Position B 12 Screw For fixing the safety drain tray Safety Drain Tray Fig.4-11 1. The whole unit status show as Fig.4-10. 2. Remove the all 11 screw from fixed Safety Drain Tray, and then take off the tray as figure showed in Fig.4-11. 3.Take off the tray along the direction of the arrow show in Fig.4-11.
- Page 7 Installation manual Duct 100% fresh air The method of installation: Adopt following method if the air-conditioning’s size of installationsite is limited and the indoor unit can’t put into the installtionsite. Fig.4-12 Position A Water Tray Position B 11-Screw Safety Drain Tray Fig.4-13 1.
- Page 8 Installation manual Duct 100% fresh air maintenance of motor 4 Bolts For fixing the fan assembly Filter Motor Assembly Safety Drain Tray 12-Screw For fixing the satety drain tray Fig.4-14 Inside of structure Front view of fan assembly installation state Side view of fan assembly installation state Pothook...
- Page 9 Installation manual Duct 100% fresh air maintenance of motor 4 Bolts For fixing the fan assembly FIiler Fortified panel Motor Asseembly 4 Screw For fixing the reinforced panel Safety Drain Tray 11-Screw For fixing the satety drain tray Fig.4-16 Inside of structure Front view of fan assembly installation state Side view of fan assembly installation state...
- Page 10 Installation manual Duct 100% fresh air 20kW 25kW 1121 28kW Entrances and exits for communication lines of indoor and outdoor Air outlet 4-12*25 oblong 1443 suspention bolt holes Electrical parts box 4-Φ10 hanging screw Air outlet (configure on spot) duct flange Connecting point Refrigerant-pipe flared of drain pipe...
-
Page 11: Installation Space
Installation manual Duct 100% fresh air The indoor unit show as Fig.4-19 NOTE Following Fig.4-20 twist-off the screws, along the direction of A During teardown and installation, the scroll was allowed direct get off the cover plate A and cover plate B. support by hand Dismounting bolt A Fan subassembly is more weightiness, please take careful... -
Page 12: High Static Pressure Type
Installation manual Duct 100% fresh air 7. DUCT DESIGN 6. HIGH STATIC PRESSURE TYP Cover the pipe before connecting to keep rubbish, dust or other impurities out. 12/14KW As there is no dust filter on the indoor unit, other places which are easy to maintaining such as inhalant duct should be installed with dust filter. -
Page 13: Throtting Components Maaintenance
Installation manual Duct 100% fresh air Total connected capacity of standard indoor units and fresh air The air filter is not the standard accessory, but please must be treatment unit does not exceed 100%. system capacity of 20 HP = installed air filter in the air intake side of the fan duct system. -
Page 14: Refrigerant Pipe Connection
Installation manual Duct 100% fresh air 12. REFRIGERANT PIPE CONNECTION ● Expel the air (refer to the “Expel The Air”) after connecting the refrigerant pipe with the indoor unit and the outdoor unit.Then fasten the nuts at the repair-points. 12.1 Expel The Air Notices For Benable pipe. -
Page 15: Connect The Drain Pipe
Installation manual Duct 100% fresh air When the pumping has finished, close the Lo-lever of the manifold Table.12-1 ● valve completely and turn off the vacuum pump. A(mm) Outside diameter When you have pumped for over 15 minutes, please confirm ●... -
Page 16: Wiring
Installation manual Duct 100% fresh air 14. WIRING With the connection part to the indoor unit, please be noted not to impose pressure on the side of indoor unit pipes. When the declivity of the drain pipe downwards is over 1/100, there should not be any win ding. -
Page 17: Control
Installation manual Duct 100% fresh air OUTDOOR UNIT INDOOR UNIT INDOOR UNIT INDOOR UNIT INDOOR UNIT CENTRAL CONTROL MONITOR COMPUTER INDOOR UNIT Fig.14-1 OUTDOOR UNIT TO INDOOR POWER SUPPLY INDOOR UNIT INDOOR UNIT INDOOR UNIT INDOOR UNIT XT2 XT3 XT2 XT3 Please use 3-core shielding wire, and ground the shielding layer. - Page 18 Installation manual Duct 100% fresh air Table.15-1 Mainboard codes indication label For set horsepower ENC1 Toggle switch SW 1 Definition Capacity(Horsepower) 1 means factory test mode Code 0 means auto addressing mode 2200W(0.8HP) (default setting) 1234 2800W(1.0HP) 1 means DC fan is chosen 0 means AC fan is chosen 3600W(1.2HP) 1234...
-
Page 19: Trouble Shooting
Installation manual Duct 100% fresh air 16. TROUBLE SHOOTING SW 5 Definition 00 means temp. compensation value Table.16-1 is 6 under heat mode (reserved) NO. Type Contents Digital LED display Remarks 01 means temp. compensation value The evaporator is 2 under heat mode (reserved) sensor check Error code... -
Page 20: Install Branch Pipe
Installation manual Duct 100% fresh air 18. INSTALL BRANCH PIPE Hi-pressure pipe Low-pressure pipe For 12.5KW~14KW models Φ9.5 Liquid branch pipe Gas branch pipe Φ15.9 Fig.18-1 Hi-pressure pipe Low-pressure pipe For 20KW~28KW models Electric throttle part ≤10m Φ9.5 Liquid branch pipe Φ9.5 Φ15.9 Gas branch pipe... -
Page 21: Test Operation
Installation manual Duct 100% fresh air 19. TEST OPERATION CAUTION Protection function will delay the startup of compressor for 3 minutes The test operation must be carried out after the entire installation in case the unit is turned on immediately after power on or restarted has been completed. - Page 22 ASK FOR MORE INFORMATION Phone: (+34) 93 446 27 80 eMail: info@mundoclima.com TECHNICAL ASSISTANCE Phone: (+34) 93 652 53 57 www.mundoclima.com...
