AVR 3500 Audio/Video Receiver
SERVICE MANUAL
®
Power for the Digital Revolution.
™

Advertisement

loading
Need help?

Need help?

Do you have a question about the AVR 3500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Harman Kardon AVR 3500

Summary of Contents for Harman Kardon AVR 3500

  • Page 1 AVR 3500 Audio/Video Receiver SERVICE MANUAL ® Power for the Digital Revolution. ™...

  • Page 2: Technical Specifications

    Height measurement includes feet and chassis. All features and specifications are subject to change without notice. Harman Kardon is a registered trademark, and Power for the Digital Revolution is a trademark, of Harman International Industries, Inc. is a trademark of Harman International Industries, Inc. (Patent No. 5,386,478).
  • Page 5 AVR 2500 AVR 3500 AVR 4500 AVR 5500 Remote Control 55242980 55242990 55262320/55178550 55262330/55178550 Power Transformer 230V 55201720 55201720 55274640 55163910 St-By Transformer 230V 55155650 55155650 55155650 55155650 Carton Box 55243010XX 55243020XX 5524300XX 5524310XX Micro controller Main IC201 55267250 55267250...
  • Page 6 PART NO :55245900 TITEL : AC EMBD IMA DSP BD AVR3500 Tocom# Pkg M/B St Qty Unit SName 55245970 1 PCE AC ESABD IAU DSP BD AVR3500 20290150 0.3 KG SOLDER BAR 52SN/45PB/3SB BAR 55148120 0.3 PCE AC ART SILKSCREEN CDRW1211 20290240 0.005 KG SOLDER ALPHA RELIA.
  • Page 7 C151 20269020 30 1 PCE CE 100U0F +20% 16.0V 85C C152 20269020 30 1 PCE CE 100U0F +20% 16.0V 85C C155 10121000 39 1 PCE CE 10U0F +20% 16.0V 85C C156 10121000 39 1 PCE CE 10U0F +20% 16.0V 85C C157 10121000 39 1 PCE...
  • Page 8 C106 11058670 91 1 PCE CCCFMIN 100P0F +5% -5% 50.0V NP0 C107 11058670 91 1 PCE CCCFMIN 100P0F +5% -5% 50.0V NP0 C108 11058670 91 1 PCE CCCFMIN 100P0F +5% -5% 50.0V NP0 C109 11058670 91 1 PCE CCCFMIN 100P0F +5% -5% 50.0V NP0 C120 20267290 91 1 PCE...
  • Page 9 R019 50886550 91 1 PCE RMGCFMIN 560R0 OHM +5% 100MI0W R020 11066390 91 1 PCE RMGCFMIN 75R0 OHM +5% 100MI0W R022 11066480 91 1 PCE RMGCFMIN 47K0 OHM +5% 100MI0W R023 90574400 91 1 PCE RMGCFMIN 470R0 OHM +5% 100MI0W R027 80440390 91 1 PCE...
  • Page 10 R100 80440370 91 1 PCE RMGCFMIN 150R0 OHM +5% 100MI0W R101 30944330 91 1 PCE RMGCFMIN 20K0 OHM +5% 100MI0W R102 30944330 91 1 PCE RMGCFMIN 20K0 OHM +5% 100MI0W R105 50886630 91 1 PCE RMGCFMIN 100K0 OHM +5% 100MI0W R106 50886630 91 1 PCE...
  • Page 11 BD25 55126690 50 1 PCE FBEAD SURFACE MT 2500OHM FCM2012H-252T02 BD26 55126690 50 1 PCE FBEAD SURFACE MT 2500OHM FCM2012H-252T02 BD27 55126690 50 1 PCE FBEAD SURFACE MT 2500OHM FCM2012H-252T02 BD28 55126690 50 1 PCE FBEAD SURFACE MT 2500OHM FCM2012H-252T02 BD29 55126690 50 1 PCE...
  • Page 12 C130 20267290 91 1 PCE CCCFMIN 100N0F +80% -20% 50.0V Y5V C131 20267290 91 1 PCE CCCFMIN 100N0F +80% -20% 50.0V Y5V C132 20267290 91 1 PCE CCCFMIN 100N0F +80% -20% 50.0V Y5V C133 20267290 91 1 PCE CCCFMIN 100N0F +80% -20% 50.0V Y5V C134 20267290 91 1 PCE...
  • Page 13 PART NO : 55245850 TITEL : AC EMBD IMA FRONT BD AVR3500 Tocom# Pkg M/B St Qty Unit SName 55245920 1 PCE AC ESABD IAU FRONT BD AVR3500 20290150 0.3 KG SOLDER BAR 52SN/45PB/3SB BAR 15481260 0.3 L SLDC FLUX LRES FOAM SM32DHT-2 20290240 0.005 KG SOLDER ALPHA RELIA.
  • Page 14 D221 55199400 NR 1 PCE D-LEM CT-3SGTA GN RND 3.0 CL 20.0CD D222 55179290 NR 0 PCE D-LEM LTL-1CHGEC P-GN RND CL D222 55199400 NR 1 PCE D-LEM CT-3SGTA GN RND 3.0 CL 20.0CD D223 55179290 NR 0 PCE D-LEM LTL-1CHGEC P-GN RND CL D223 55199400 NR 1 PCE...
  • Page 15 IC201 55267250 HE 1 PCE IC-MICROCONT CXP82860-351Q AVR2500/3500 IC205 55142240 NR 1 PCE IC-OPERAMP NJM2068DD DUAL OP JA201 55113740 1 PCE CON PHONO SCKT RCA-307 3 PINS JA202 55113960 1 PCE CON DIN SCKT SOCKET CONNECTOR SVHS EST-S408J L201 55179380 16 1 PCE LF 4U7H +10% 1.7 OHM 190.0A L202...
  • Page 16 Q233 55133350 56 1 PCE TR-SLPLF MPSA56 Y P -500MI0A -300V Q235 55133210 56 1 PCE TR-SLPLF DTC114YSA N 100MI0A Q235 55179230 56 0 PCE TR-SLPSWA KRC107M N PART NO : 55246010 TITEL : AC ESABD SMD FRONT BD AVR3500 Tocom# Pkg M/B St Qty Unit SName...
  • Page 17 J248 80440510 91 1 PCE RMGCFMIN 0 OHM +0% 100MI0W J288 80440510 91 1 PCE RMGCFMIN 0 OHM +0% 100MI0W J294 80440510 91 1 PCE RMGCFMIN 0 OHM +0% 100MI0W J297 80440510 91 1 PCE RMGCFMIN 0 OHM +0% 100MI0W J298 80440510 91 1 PCE...
  • Page 18 R225 60444350 91 1 PCE RMGCFMIN 47R0 OHM +5% 100MI0W R226 80440370 91 1 PCE RMGCFMIN 150R0 OHM +5% 100MI0W R227 80440370 91 1 PCE RMGCFMIN 150R0 OHM +5% 100MI0W R228 80440370 91 1 PCE RMGCFMIN 150R0 OHM +5% 100MI0W R229 80440370 91 1 PCE...
  • Page 19 R289 11066480 91 1 PCE RMGCFMIN 47K0 OHM +5% 100MI0W R290 30944310 91 1 PCE RMGCFMIN 4K7 OHM +5% 100MI0W R291 30944250 91 1 PCE RMGCFMIN 10R0 OHM +5% 100MI0W R292 50886630 91 1 PCE RMGCFMIN 100K0 OHM +5% 100MI0W R293 11066460 91 1 PCE...
  • Page 20 PART NO : 55245840 TITEL : AC EMBD IMA MAIN BD AVR3500 Tocom# Pkg M/B St Qty Unit SName 55245910 1 PCE AC ESABD IAU MAIN BD AVR3500 20290150 0.3 KG SOLDER BAR 52SN/45PB/3SB BAR 15481260 0.3 L SLDC FLUX LRES FOAM SM32DHT-2 20290240 0.005 KG SOLDER ALPHA RELIA.
  • Page 21 L501 55179560 NR 1 PCE LFA 1MM 10MM 5 LEFT P551 55179640 NR 1 PCE POS 100R0 OHM 16.0V Q425 55133270 NR 1 PCE TR-SHPLF 2SC4137 N 100MI0A 20V Q426 55133270 NR 1 PCE TR-SHPLF 2SC4137 N 100MI0A 20V Q437 55127360 NR 1 PCE TR-SHPLF 2SD2390 DARLINGTON N 10.0A...
  • Page 22 C412 60439150 71 1 PCE CC 33P0F +5% -5% 50.0V NP0 C413 20268880 30 1 PCE CE 10U0F +20% 50.0V 85C C414 20268880 30 1 PCE CE 10U0F +20% 50.0V 85C C417 55180340 71 1 PCE CPM 100N0F +10% 63.0V C418 55180340 71 1 PCE...
  • Page 23 D405 70436540 16 1 PCE D-SLP 1N4148 100.0V 150E-3A D406 70436540 16 1 PCE D-SLP 1N4148 100.0V 150E-3A D501 70436540 16 1 PCE D-SLP 1N4148 100.0V 150E-3A D502 70436540 16 1 PCE D-SLP 1N4148 100.0V 150E-3A D551 70436540 16 1 PCE D-SLP 1N4148 100.0V 150E-3A D552 70436540 16...
  • Page 24 R121 50882970 16 1 PCE RCF 470R0 OHM +5% 250MI0W R122 50882970 16 1 PCE RCF 470R0 OHM +5% 250MI0W R123 30939510 16 1 PCE RCF 100K0 OHM +5% 250MI0W R124 30939510 16 1 PCE RCF 100K0 OHM +5% 250MI0W R125 50882970 16 1 PCE...
  • Page 25 R474 30939360 16 1 PCE RCF 10R0 OHM +5% 250MI0W R477 30939360 16 1 PCE RCF 10R0 OHM +5% 250MI0W R478 30939360 16 1 PCE RCF 10R0 OHM +5% 250MI0W R489 20469450 16 1 PCE RCF 220R0 OHM +5% 250MI0W R490 11059630 16 1 PCE...
  • Page 26 R593 50882970 16 1 PCE RCF 470R0 OHM +5% 250MI0W R594 50882970 16 1 PCE RCF 470R0 OHM +5% 250MI0W R595 50882970 16 1 PCE RCF 470R0 OHM +5% 250MI0W R596 50882950 16 1 PCE RCF 100R0 OHM +5% 250MI0W R597 50882950 16 1 PCE...
  • Page 27 PART NO: 55245820 TITLE : AC MECH BOM AVR3500 OEM Tocom# Pkg M/B St Qty Unit SName 0050 55170390 25 PCE CABLE-FIX WIRE-TIE MELLERMAI NYLON6 0 0 0060 55227740 1 PCE AC MSA ASY KST-M1114MW1-60 TU MODULE AVR2500 0070 55242850 1 PCE AC DEC CABINET PANEL FRONT 0080...
  • Page 28 0640 20289870 0.04 KG GLUE CEMENDINE 575 0650 20190880 0.02 KG WAX ZOPHAR 1340 120 82C YE 0.906 0660 20290210 0.09 KG SOLDER RELIACORE II 60/40 SOLDER WIRE 0.63 MM 0670 20289720 0.08 KG GLUE THREE BOND 1401C 0680 55039910 0.07 KG GLUE HOT MELT 0690...
  • Page 29 PART NO : 55245830 TITEL : AC BOM PKG AVR3500 Tocom# Pkg M/B St Qty Unit SName 0050 55127490 1 PCE ANTENNA WIRE ANTENNA LOOP CT01-AM 0 0 0060 55242990 1 PCE AC MSA ASY RMC CONTROLER AVR3500 0070 55020220 NR 3 PCE BATNCALK 1.5V AAA 1.15 AH 0080...
  • Page 30 PART NO : 55245860 TITEL : AC EMBD IMA AVR2500 PROCESS BD Tocom# Pkg M/B St Qty Unit SName 55245930 1 PCE AC ESABD IAU AVR2500 PROCESS BD 20290150 0.3 KG SOLDER BAR 52SN/45PB/3SB BAR 15481260 0.3 L SLDC FLUX LRES FOAM SM32DHT-2 20290240 0.005 KG SOLDER ALPHA RELIA.
  • Page 31 C797 20342060 39 1 PCE CE 47U0F +20% 16.0V 85C C798 20342060 39 1 PCE CE 47U0F +20% 16.0V 85C C799 20342060 39 1 PCE CE 47U0F +20% 16.0V 85C C800 10121000 39 1 PCE CE 10U0F +20% 16.0V 85C C801 10121000 39 1 PCE...
  • Page 32 Q729 55133290 56 1 PCE TR-SLPLF KTD1302 B N 300MI0A 20V Q730 55133220 56 1 PCE TR-SLPLF DTA114YSA P 100MI0A Q731 55133340 56 1 PCE TR-SLPLF DTC114TS N 600MI0A Q732 55112030 56 1 PCE TR-M FET RA/TAD 2SK117Y N 300MI0W 14MI0A PART NO : 55246020 TITEL : AC ESABD SMD AVR2500 PROCESS BD Tocom#...
  • Page 33 C860 80436820 91 1 PCE CCCFMIN 680P0F +10% -10% 50.0V X7R C863 80436820 91 1 PCE CCCFMIN 680P0F +10% -10% 50.0V X7R C865 80436820 91 1 PCE CCCFMIN 680P0F +10% -10% 50.0V X7R IC704 55142710 NR 1 PCE IC-SWITCH KIC9162AF ANALOG SWITCH IC705 55142680 NR 1 PCE...
  • Page 34 Q734 55133180 92 1 PCE TR-SSD DTC114YKA N 10K0 OHM 47K0 OHM Q735 55133190 92 1 PCE TR-SSD DTA114YKA P 10K0 OHM 47K0 OHM Q736 55133190 92 1 PCE TR-SSD DTA114YKA P 10K0 OHM 47K0 OHM R701 90574400 91 1 PCE RMGCFMIN 470R0 OHM +5% 100MI0W R702 40438350 91...
  • Page 35 R802 70434200 91 1 PCE RMGCFMIN 100R0 OHM +5% 100MI0W R803 20471950 91 1 PCE RMGCFMIN 1K0 OHM +5% 100MI0W R804 20471950 91 1 PCE RMGCFMIN 1K0 OHM +5% 100MI0W R805 20471950 91 1 PCE RMGCFMIN 1K0 OHM +5% 100MI0W R806 70434200 91 1 PCE...
  • Page 36 R869 70434200 91 1 PCE RMGCFMIN 100R0 OHM +5% 100MI0W R870 70434200 91 1 PCE RMGCFMIN 100R0 OHM +5% 100MI0W R871 70434200 91 1 PCE RMGCFMIN 100R0 OHM +5% 100MI0W R872 70434200 91 1 PCE RMGCFMIN 100R0 OHM +5% 100MI0W R873 70434200 91 1 PCE...
  • Page 37 R933 20471920 91 1 PCE RMGCFMIN 220R0 OHM +5% 100MI0W R934 90574400 91 1 PCE RMGCFMIN 470R0 OHM +5% 100MI0W R935 30944340 91 1 PCE RMGCFMIN 27K0 OHM +5% 100MI0W R936 50886630 91 1 PCE RMGCFMIN 100K0 OHM +5% 100MI0W R937 20471950 91 1 PCE...
  • Page 38 PART NO : 55245870 TITEL : AC EMBD IMA SURROUND BD AVR3500 Tocom# Pkg M/B St Qty Unit SName 55245940 M SO 1 PCE AC ESABD IAU SURROUND BD AVR3500 20290150 X so 0.3 KG SOLDER BAR 52SN/45PB/3SB BAR 15481260 B so 0.3 L SLDC FLUX LRES FOAM SM32DHT-2...
  • Page 39 PART NO : 55245940 TITEL : AC ESABD IAU SURROUND BD AVR3500 Tocom# Pkg M/B St Qty Unit SName 55155720 B ud 1 PCE AC PCB SURR AVR120 SINGLE LAYER C601 20268880 30 B so 1 PCE CE 10U0F +20% 50.0V 85C C602 20268880 30 B so 1 PCE CE 10U0F +20% 50.0V 85C...
  • Page 40 FH981 55170330 CM B so 1 PCE TERMFUSEHLDR FUSE-HOLDER FH982 55170330 CM B so 1 PCE TERMFUSEHLDR FUSE-HOLDER Q601 20556600 56 B so 1 PCE TR-SHPLF KTC3200BL N 100MI0A 120V Q602 20556600 56 B so 1 PCE TR-SHPLF KTC3200BL N 100MI0A 120V Q603 20556600 56 B so 1 PCE TR-SHPLF KTC3200BL N 100MI0A 120V...
  • Page 41 R637 60441580 16 B so 1 PCE RCF 22K0 OHM +5% 250MI0W R638 60441580 16 B so 1 PCE RCF 22K0 OHM +5% 250MI0W R639 60441580 16 B so 1 PCE RCF 22K0 OHM +5% 250MI0W R640 60441580 16 B so 1 PCE RCF 22K0 OHM +5% 250MI0W R641 70434970 16 B so...
  • Page 42 PART NO : 55245890 TITEL : AC EMBD IMA VIDEO BD AVR3500 Tocom# Pkg M/B St Qty Unit SName 55245960 1 PCE AC ESABD IAU VIDEO BD AVR3500 20290150 0.3 KG SOLDER BAR 52SN/45PB/3SB BAR 15481260 0.3 L SLDC FLUX LRES FOAM SM32DHT-2 20290240 0.005 KG SOLDER ALPHA RELIA.
  • Page 43 C651 20252670 30 1 PCE CE 470U0F +20% 10.0V 85C C652 20252670 30 1 PCE CE 470U0F +20% 10.0V 85C C653 20252670 30 1 PCE CE 470U0F +20% 10.0V 85C C664 20252670 30 1 PCE CE 470U0F +20% 10.0V 85C C665 20252670 30 1 PCE...
  • Page 44 C611 11058670 91 1 PCE CCCFMIN 100P0F +5% -5% 50.0V NP0 C612 11058670 91 1 PCE CCCFMIN 100P0F +5% -5% 50.0V NP0 C619 11058670 91 1 PCE CCCFMIN 100P0F +5% -5% 50.0V NP0 C620 11058670 91 1 PCE CCCFMIN 100P0F +5% -5% 50.0V NP0 C629 11059340 91 1 PCE...
  • Page 45 J073 80440510 91 1 PCE RMGCFMIN 0 OHM +0% 100MI0W J074 80440510 91 1 PCE RMGCFMIN 0 OHM +0% 100MI0W J076 80440510 91 1 PCE RMGCFMIN 0 OHM +0% 100MI0W J077 80440510 91 1 PCE RMGCFMIN 0 OHM +0% 100MI0W J079 80440510 91 1 PCE...
  • Page 46 R688 50886670 91 1 PCE RMGCFMIN 1M0 OHM +5% 100MI0W R689 60444370 91 1 PCE RMGCFMIN 180R0 OHM +5% 100MI0W R690 30944270 91 1 PCE RMGCFMIN 68R0 OHM +5% 100MI0W R691 30944250 91 1 PCE RMGCFMIN 10R0 OHM +5% 100MI0W R692 80440510 91 1 PCE...
  • Page 47 AVR120DSP-MP.sch-1 - Wed Oct 31 15:25:00 2001...
  • Page 48 AVR120F-HMS-1.sch-1 - Wed Oct 31 15:27:28 2001...
  • Page 51 AVR120S-HMS-1.sch-1 - Wed Jan 30 09:54:40 2002...
  • Page 52 AVR120M-HMS-2.sch-1 - Wed Jan 30 09:49:27 2002...
