- Page 1 INSTALLATION, USE AND MAINTENANCE GUIDE ECO THERM 1000 THERM 1000 THERM 1000 THERM 1000 THERM 1000 www.thermorossi.com...
- Page 2 Smoke outlet ..................................ALARMS ......................................ELECTRICAL WIRING ..................................INFORMATION FOR THE SKILLED TECHNICIAN ..........................12.1 Main components and their operation ..........................12.2 Useful advice for installation and operation ........................12.3 Troubleshooting cause-solution ............................ECOTHERM 1000 SPARE PARTS ..............................pg. 2...
- Page 3 92/31/EEC 93/97/EEC Thermorossi S.p.A., Via Grumolo 4 - ARSIERO (VI), declares that the heaters of the ECOTHERM series have been designed and manufactured in compliance with the safety requirements of the standards for EC marking. This declaration refers to the entire range of the specified series.
- Page 4 °If the appliance is sold or transferred to another user ensure that the guide is handed over with it. Thermorossi S.p.A. maintains the author’s rights on these service instructions. The information in this booklet may not be reproduced or given to third parties or used for competitive purposes without the appropriate authorization.
- Page 5 2 2 2 2 2 TECHNICAL CHARACTERISTICS TECHNICAL CHARACTERISTICS TECHNICAL CHARACTERISTICS TECHNICAL CHARACTERISTICS TECHNICAL CHARACTERISTICS ECOTHERM 1000 Power min / max 2.5 Kw - 7 Kw Smoke temperature ~220°C Average smoke flow rate 9,3 g/s Minimum draft 0.09 mbar Smoke exhaust pressure switch...
- Page 6 3 3 3 3 3 GENERAL GENERAL DESCRIPTION DESCRIPTION GENERAL GENERAL GENERAL DESCRIPTION DESCRIPTION DESCRIPTION 3 . 1 3 . 1 OPERA OPERA TING TING TECHNOL TECHNOL 3 . 1 3 . 1 3 . 1 OPERA OPERA OPERATING TING TING TECHNOL TECHNOLOGY...
- Page 7 FIGURA 2 5 5 5 5 5 DESCRIPTIONS OF CONTROLS 5 . 1 5 . 1 5 . 1 5 . 1 5 . 1 DESCRIPTION OF CONTR DESCRIPTION OF CONTR DESCRIPTION OF CONTR DESCRIPTION OF CONTR DESCRIPTION OF CONTROL P OL P OL P OL PANEL...
- Page 8 DA A A A A Y Y Y Y Y AND AND TIME SETTING TIME SETTING TIME SETTING TIME SETTING TIME SETTING The heater must be fed and the rear switch in position “1”.”Display (7) may show the inscriptions On , OFF or Star. To set the time and the day of the week carry out the procedures described below.
- Page 9 When the programming is enabled (temporary inscription on cr on the display and, at the same time, a fixed point is present on the right side at the bottom of the display) any additional chronothermostat (see para.7.2) is deactivated. Programming can be reset by keeping key (5) pressed for 8 seconds until the inscription rESt is displayed: this operation can be carried out when the inscriptions On or OFF or StAr are shown on the display.
- Page 10 “Perry”. CAUTION: In the event of connections to the chronothermostat Thermorossi shall not be held responsible for the insert not starting up, smoke leaks, breakage of the lighting component. In the event of a programmed cycle on always ensure that the brazier is clean and seated correctly in its lodging.
- Page 11 8 8 8 8 8 CLEANING AND MAINTENANCE CLEANING AND MAINTENANCE CLEANING AND MAINTENANCE CLEANING AND MAINTENANCE CLEANING AND MAINTENANCE 8 . 1 8 . 1 8 . 1 8 . 1 8 . 1 F O R E W O R D F O R E W O R D F O R E W O R D F O R E W O R D...
- Page 12 8.3 REPLACEMENT OF THE REMOTE CONTROL BATTERY When the infrared remote control does not send out the transmission signal (led on), the battery must be replaced. Use a Phillips screwdriver of proper size, to separate the half shells and replace the battery. When the dead battery is removed, it must be safely disposed of. 8.4 CONTROL PANEL BUFFER BATTERY REPLACEMENT Inside the control panel there is a buffer battery type CR2032 .
- Page 13 9 . 2 9 . 2 9 . 2 SMOKE OUTLET SMOKE OUTLET SMOKE OUTLET 9 . 2 9 . 2 SMOKE OUTLET SMOKE OUTLET •The smoke exhaust shown in the following figures is the best solution to ensure the discharge of smoke even when the fan is not operational, such as for example if there is an electrical power failure.
- Page 14 ALARMS ALARMS ALARMS ALARMS ALARMS The heater is programmed to communicate 3 fundamental alarms. The alarms are listed below: PE OF : is communicated when the temperature during the On mode drops below 42 °C. This indicates that the heater is switching off due to lack of pellets. AL AC : is communicated if after the start up phase the temperature does not rise above 42°C.
- Page 15 INFORMA INFORMA TION FOR TION FOR THE SKILLED THE SKILLED TECHNICIAN TECHNICIAN INFORMA INFORMATION FOR INFORMA TION FOR TION FOR THE SKILLED THE SKILLED THE SKILLED TECHNICIAN TECHNICIAN TECHNICIAN 12.1 MAIN COMPONENTS AND THEIR OPERATION SMOKE PRESSURE SWITCH This is a safety switch that stops the screw feeder motor whenever necessary. The main cause for the pressure switch tripping is a blocked flue outlet or smoke exhaust pipe.
- Page 16 12.3 TROUBLESHOOTING CAUSE-SOLUTION PROBLEM CAUSE SOLUTION PELLETS DO NOT DROP PELLET TANK IS EMPTY FILL UP THE TANK (THE INSCRIPTION PE OF IS PRESENT IN THE INTO THE BURNER DISPLAY) FOREIGN BODY SUCH AS NAIL, NYLON, REMOVE THE FOREIGN BODY PIECE OF WOOD ON THE FEEDER SCREW ON THE BOTTOM OF THE TANK (THE...
- Page 17 THE GLASS IS COVERED IN THE APPLIANCE ACCUMULATES PELLETS SEE POINT “PROBLEM-CAUSE-SOLUTION” BLACK SOOT IN THE BRAZIER “THE APPLIANCE ACCUMULATES PELLETS IN THE BRAZIER WHILE OPERATING” NO CAUSE CLEAN THE GLASS MORE OFTEN STEEL BLADE NOT PLACED CORRECTLY OR PLACE THE BLADE CORRECTLY OR MISSING INSTALL IT ABSENCE OF FLOW OF...
- Page 18 THERM 1000 SPARE P ARE P ARE PAR ARTS FOR ECO TS FOR ECO TS FOR ECOTHERM 1000 THERM 1000 THERM 1000 7001 2903 (com pleto) 6001 2690 B E IG E 6001 2688 C U O IO 6001 2689 R O S S O...
- Page 19 6001 1 75 0 7001 293 3 P an n e llo 6000663 7 60 01 2695 T arg h e tta 60 01 1 656 6001 2787 B atte ria C R 203 2 70 01 293 2 7001 2969 6000753 4 G u arn izio n e p o rta 6000921 8 G u arn izion e v etro 60006693 V e tro...
- Page 20 LEGENDA Complete fan Ventilatore completo Ventilatore Grate Griglia Condenser Condensatore...
