HP Ethernet 1Gb 4-port 366T Adapter

User Guide

Abstract
This document is for the person who installs, administers, and troubleshoots servers and storage systems. HP assumes you are qualified in the
servicing of computer equipment and trained in recognizing hazards in products with hazardous energy levels.
Part Number: 826574-001
September 2015
Edition: 1

Advertisement

loading

  Related Manuals for HP 366T

  Summary of Contents for HP 366T

  • Page 1: User Guide

    User Guide Abstract This document is for the person who installs, administers, and troubleshoots servers and storage systems. HP assumes you are qualified in the servicing of computer equipment and trained in recognizing hazards in products with hazardous energy levels.
  • Page 2 © Copyright 2015 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
  • Page 3: Table Of Contents

    Electrostatic discharge ......................... 15 Preventing electrostatic discharge ......................15 Grounding methods to prevent electrostatic discharge .................. 15 Support and other resources ......................16 Before you contact HP ..........................16 HP contact information ..........................16 Acronyms and abbreviations ......................17 Documentation feedback ......................18...
  • Page 4: Technician Notes

    Warnings, cautions, and notes WARNING: Only authorized technicians trained by HP should attempt to repair this equipment. All troubleshooting and repair procedures are detailed to allow only subassembly/module-level repair. Because of the complexity of the individual boards and subassemblies, no one should attempt to make repairs at the component level or to make modifications to any printed wiring board.
  • Page 5 Select Download drivers and software (and firmware). Type the adapter name in the For product box and then click Go. For example, type HP Ethernet 1Gb 4-port 366T. Download the drivers, firmware, or documentation as needed. Technician notes 5...
  • Page 6: Introduction

    (http://www.hp.com/go/proliantnics). LED indicators The HP Ethernet 1Gb 4-port 366T Adapter has four ports with LED indicators for Link (L) and Activity (A) for each port. A standard-height bracket is shown in the following figure with RJ-45 ports and LED indicators.
  • Page 7 Item LED indicator Status Description On (Amber/Orange) Link to the adapter is established at 1 Gb/s. The adapter is receiving power and the cable connection is good. Introduction 7...
  • Page 8: Installing An Adapter

    NOTE: Before removing the cover of your server, refer to the HP documentation for the proper methods for installing a PCI Express card and avoiding electric shock hazards.
  • Page 9: Installing An Adapter In A Server

    Installing an adapter in a server For additional information on how to safely install a PCI Express card in the server, see the HP ProLiant server documentation. CAUTION: If the server is not PCI Hot Plug compliant, power it down and disconnect the power cord from the power outlet before removing the server access panel.
  • Page 10: Connecting The Network Cable

    Using a correctly sized slotted screwdriver, carefully remove the two board lock screws located at the top and bottom of the connector. Remove the standard profile bracket and place the low profile bracket over the connector. Be careful not to damage the connector or bind the low profile bracket to the connector. Connecting the network cable To secure the cable, plug the cable connector into the RJ-45 port.
  • Page 11: Specifications

    Specifications UTP cable specifications The HP Ethernet 1Gb 4-port 366T adapter can use existing UTP CAT5 (or better) cable to deliver Gigabit Ethernet over copper, according to the IEEE 802.3ab specifications. For new installations, CAT5e (enhanced CAT5) cable is recommended.
  • Page 12: Power And Environmental Specifications

    Power and environmental specifications Specification Value Temperature—0° to 55° C (0° to 131° F) Operating Humidity—15 to 80% relative humidity, non-condensing Temperature—40° to 70° C (0° to 158° F) Non-operating Humidity—10 to 90% relative humidity, non-condensing 4 W typical, 5 W maximum Power Specifications 12...
  • Page 13: Regulatory Compliance Notices

    Compliance with these directives is assessed using applicable European Harmonised Standards. The full Declaration of Conformity can be found at the following HP website (http://www.hp.eu/certificates). (Search with the product model name or its Regulatory Model Number (RMN), which may be found on the regulatory label.)
  • Page 14: Canadian Notice (Avis Canadien)

    Canadian notice (Avis Canadien) This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations, CAN ICES-3(A)/NMB-3(A). Cet appareil numérique de la class A respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. Korean class A notice Japanese class A notice Disposal of waste equipment by users in private households in the European Union...
  • Page 15: Electrostatic Discharge

    Electrostatic discharge Preventing electrostatic discharge To prevent damaging the system, be aware of the precautions you need to follow when setting up the system or handling parts. A discharge of static electricity from a finger or other conductor may damage system boards or other static-sensitive devices.
  • Page 16: Support And Other Resources

    Active Health System log (HP ProLiant Gen8 or later products) Download and have available an Active Health System log for 7 days before the failure was detected. For more information, see the HP iLO 4 User Guide or HP Intelligent Provisioning User Guide on the HP website (http://www.hp.com/go/ilo/docs).
  • Page 17: Acronyms And Abbreviations

    Acronyms and abbreviations Canadian Standards Association IPv4 Internet Protocol version 4 IPv6 Internet Protocol version 6 PCI-X peripheral component interconnect extended unshielded twisted pair Acronyms and abbreviations 17...
  • Page 18: Documentation Feedback

    Documentation feedback HP is committed to providing documentation that meets your needs. To help us improve the documentation, send any errors, suggestions, or comments to Documentation Feedback (mailto:docsfeedback@hp.com). Include the document title and part number, version number, or the URL when submitting your feedback.
