SERVICE MANUAL
Ver 1.2 2004. 04

SPECIFICATIONS

System
Compact disc digital audio system
Laser diode properties
Material: GaAlAs
Wavelength: λ = 780 nm
Emission duration: Continuous
Laser output: Less than 44.6 µW (This output is the value measured at a
distance of 200 mm from the objective lens surface on the optical pick-up
block with 7 mm aperture.)
Power requirements
• Two Sony NH-7WMAA rechargeable batteries: 1.2 V DC x 2
• Two LR6 (size AA) batteries: 1.5 V DC x 2
• AC power adaptor (DC IN 4.5 V jack): 100-240 V, 50/60 Hz
Dimensions (w/h/d) (without projecting parts and controls)
Approx. 135.8 x 22.6 x 135.8 mm (5
Mass (excluding accessories)
Approx. 182 g (6.5 oz)
Operating temperature
5°C - 35°C (41°F - 95°F)
Design and specifications are subject to change without notice.
Sony Corporation
9-961-979-03
Parsonal Audio Company
2004D02-1
Published by Sony Engineering Corporation
© 2004.04
3
29
3
x
x 5
in.)
8
32
8
D-EJ250
Canadian Model
Model Name Using Similar Mechanism New
CD Mechanism Type
Optical Pick-up Type
Supplied Accessories
AC power adaptor (1)
Headphones/earphones with remote control (1)
Note on the remote control
Use only the supplied remote control. You cannot operate this CD player
with the remote control supplied with other CD players.
PORTABLE CD PLAYER
AEP Model
UK Model
E Model
CDM-3325ER
DAX-25E

Advertisement

Table of Contents
loading

Summary of Contents for Sony D-EJ250

  • Page 1: Specifications

    7 mm aperture.) Power requirements • Two Sony NH-7WMAA rechargeable batteries: 1.2 V DC x 2 • Two LR6 (size AA) batteries: 1.5 V DC x 2 • AC power adaptor (DC IN 4.5 V jack): 100-240 V, 50/60 Hz Dimensions (w/h/d) (without projecting parts and controls) Approx.
  • Page 2: Table Of Contents

    DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE REMPLACER CES COMPOSANTS QUE PAR DES PIÈSES SONY DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU DANS LES SUPPÉMENTS PUBLIÉS PAR SONY.
  • Page 3 D-EJ250 SECTION 3 DISASSEMBLY The equipment can be removed using the following procedure. Upper lid ASSY, Cabinet (upper) ASSY MD ASSY Motor ASSY (Sled) (M902), Optical pick-up (DAX-25E), Turn table motor ASSY(spindle) (M901) Cabinet (lower) ASSY Main board Note : Follow the disassembly procedure in the numerical order given.
  • Page 4: Servicing Notes

    D-EJ250 SECTION 1 SERVICING NOTES Laser Diode Checking Methods NOTES ON HANDLING THE OPTICAL PICK-UP BLOCK OR During normal operation of the equipment, emission of the laser diode BASE UNIT is prohibited unless the upper panel is closed while turning ON the S809(push switch type).
  • Page 5: Md Assy (Cdm-3325Er), Main Board

    D-EJ250 3-2. MD ASSY (CDM-3325ER), MAIN BOARD MD assy (CDM-3325ER) 1 CN501 2 CN401 3 CN402 6 MAIN board HOW TO SET THE HARNESS IN ASSEMBLING CN401 CN402 harness...
  • Page 6: Motor Assy (Sled) (M902), Optical Pick-Up (Dax-25E), Turn Table Motor Assy(Spindle) (M901)

    D-EJ250 3-3. MOTOR ASSY (SLED) (M902), OPTICAL PICK-UP (DAX-25E), TURN TABLE MOTOR ASSY (SPINDLE) (M901) 1 three screws (B1.7x4) 3 gear cover 8 three screws (B1.7x4) 5 motor assy (sled) (M902) 7 optical pick-up (DAX-25E) q; turn table motor assy...
  • Page 7: Electrical Adjustmens

    D-EJ250 SECTION 4 ELECTRICAL ADJUSTMENTS Focus bias Check The CD section adjustments are done automatically in this set. Condition: Precautions for Check • Hold the set in horizontal state. 1. Perform check in the order given. 2. Use YEDS-18 disc (Part No.: 3-702-101-01) unless otherwise...
  • Page 8: Diagrams

    D-EJ250 SECTION 5 DIAGRAMS 5-1. BLOCK DIAGRAM IC603 D-RAM(16M) D0-3 A0-10 2,3,24,25 9-12,15-19,21,8 5 23 4 IC302 OPTICAL HEADPHONE AMP PICK-UP BLOCK 87,88,84,85 97-100,96-91,82 90 83 89 (DAX-25E) LDACO LOUT VCC1_2.2V SUB CODE DEMODULATOR PROCESSOR OP IC ROUT RDACO IC601...
  • Page 9: Printed Wiring Boards -Main Section (Side A)

    D-EJ250 5-2. PRINTED WIRING BOARDS – MAIN SECTION (SIDE A) – : Uses unleaded solder. MAIN BOARD (SIDE A) L602 C625 R616 • Semiconductor R617 Location C637 C635 R618 C630 Ref. No. Location C815 X601 R620 R609 D101 C629 R619...
  • Page 10: Printed Wiring Boards -Main Section (Side B)

    D-EJ250 PRINTED WIRING BOARDS – MAIN SECTION (SIDE B) – : Uses unleaded solder. MAIN BOARD (SIDE B) • Semiconductor OPTICAL PICK-UP CN802 Location BLOCK Ref. No. Location DAX-25E R810 D304 CN601 D308 D805 D402 Q301 D404 D407 TP601 C304...
  • Page 11: Schematic Diagram -Main Section (1/3)

    D-EJ250 5-3. SCHEMATIC DIAGRAM – MAIN SECTION (1/3) –...
  • Page 12: Schematic Diagram -Main Section (2/3)

    D-EJ250 Ver 1.2 5-4. SCHEMATIC DIAGRAM – MAIN SECTION (2/3) – • See page 16 for IC Pin Function Description.
  • Page 13: Schematic Diagram -Main Section (3/3)

    D-EJ250 5-5. SCHEMATIC DIAGRAM – MAIN SECTION (3/3) –...
  • Page 14 D-EJ250 Ver 1.2 For Schematic Diagrams: For Printed Wiring Boards: • IC BLOCK DIAGRAM Note: • X : parts extracted from the component side. • All capacitors are in µF unless otherwise noted. pF µµF 50 WV or • : Through hole.
  • Page 15 D-EJ250 IC403 BH6580KV 59 58 57 56 55 H BRIDGE H BRIDGE H BRIDGE 40 LATCH DCIN HVPROT 39 DATA REGB LEVEL CONTROLLER SHIFTER 38 CLOXK 37 WAKEUP DCIN_S XRST CHGB CHARGE VMMNT RESET_O SYNC CHGMNT PREGND BATM1 SOFT 10msec...
  • Page 16: Ic Pin Function Description

    D-EJ250 5-6. IC PIN FUNCTION DESCRINTION • IC801 (SYSTEM CONTROL) T5AW5-04CD Pin No. Pin Name Description – Ground terminal System clock input XOUT Not used (OPEN) TEST Test mode terminal VCPU_2.0V – Power supply FOK_I Focus OK signal input XBUSY_I...
  • Page 17 D-EJ250 Pin No. Pin Name Description PGM_SDTO – PGM serial data output PGM_SDTI PGM serial data input PGM_SCK_O PGM clock output CD_ON Not used (OPEN) GFS_I Guard Frame Synchronous signal input from BU9354CKV FG_I FG signal input from BH6580KV <PGMSEL_O>/SC_SEL_O...
  • Page 18: Exploded Views

    D-EJ250 Ver 1.2 SECTION 6 EXPLODED VIEWS NOTE : • -XX, -X mean standardized parts, so they may • The mechanical parts with no reference number The components identified by mark 0 have some difference from the original one. in the exploded views are not supplied.
  • Page 19: Cabinet Section

    D-EJ250 Ver 1.2 6-2. CABINET SECTION CDM-3325ER Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 3-261-238-21 KNOB (HOLD) (SILVER) 3-266-051-01 SPRING (R) 3-261-238-31 KNOB (HOLD) (BLUE) 3-261-236-22 CABINET (LOWER) (SILVER) X-3384-386-1 CABINET (UPPER) SUB ASSY (S) (SILVER)
  • Page 20: Optical Pick-Up Section (Cdm-3325Er)

    D-EJ250 Ver 1.2 6-3. OPTICAL PICK-UP SECTION (CDM-3325ER) M902 M901 The components identified by Les composants identifiés par une mark 0 or dotted line with mark marque 0 sont critiques pour 0 are critical for safety. la sécurité. Replace only with part number Ne les remplacer que par une pièce...
  • Page 21: Electrical Parts List

    D-EJ250 Ver 1.2 SECTION 7 MAIN ELECTRICAL PARTS LIST NOTE: • RESISTORS • Due to standardization, replacements in the All resistors are in ohms. parts list may be different from the parts METAL: metal-film resistor The components identified by mark 0...
  • Page 22 D-EJ250 MAIN Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks C801 1-164-156-11 CERAMIC CHIP 0.1uF IC601 6-803-922-01 IC BU9354CKV C802 1-164-156-11 CERAMIC CHIP 0.1uF IC603 6-702-737-01 IC MSM51X17400F-10TFSR1 C803 1-164-156-11 CERAMIC CHIP 0.1uF IC801 6-803-923-01 IC T5AW5-04CD...
  • Page 23 D-EJ250 Ver 1.2 MAIN Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks R316 1-216-837-11 METAL CHIP 1/10W R805 1-216-821-11 METAL CHIP 1/10W R320 1-216-845-11 METAL CHIP 100K 1/10W R807 1-414-760-21 FERRITE R322 1-216-797-11 METAL CHIP 1/10W...
  • Page 24 D-EJ250 Ver 1.2 Ref. No. Part No. Description Remarks MISCELLANEOUS ************* 0107 X-3380-950-1 OPTICAL PICK-UP (DAX-25E RP ASSY) LCD801 1-805-462-11 DISPLAY PANEL, LIQUID CRYSTAL M901 A-3180-965-A MOTOR ASSY, TURN TABLE (SPINDLE) M902 A-3180-966-A MOTOR ASSY, SLED (including GEAR) ****************************************************** ACCESSORIES...
  • Page 25 D-EJ250 MEMO...
  • Page 26: Revision History

    D-EJ250 REVISION HISTORY Clicking the version allows you to jump to the revised page. Also, clicking the version at the upper right on the revised page allows you to jump to the next revised page. Ver. Date Description of Revision 2004.01...
