D-E777/EJ721/EJ725
SERVICE MANUAL
Ver 1.0 2001.01
System
Compact disc digital audio system
Laser diode properties
Material: GaAIAs
Wavelength : λ= 780 nm
Emission duration: Continuous
Laser output : Less than 44.6 µW
(This output is the value measured at a distance
of 200 mm from the objective lens surface on
the optical pick-up block with 7 mm aperture. )
D-A conversion
1-bit quartz time-axis control
Frequency response
+1
20 - 20,000 Hz
dB (measured by EIAJ CP-
–2
307)
Output (at 4.5 V input level)
Line output (stereo minijack)
Output level 0.7 V rms at 47 kΩ
Recommended load impedance over 10 kΩ
Headphones (stereo minijack)
Approx. 5 mW + Approx. 5 mW at 16 Ω
(Approx. 1 mW + Approx. 1 mW at 16 Ω)*
*For the customers in France
Optical digital output (optical output connector)
Output level: –21 - –15 dBm
Wavelength: 630 - 690 nm at peak level
Sony Corporation
9-873-052-11
2001A0200-1
Audio Entertainment Group
© 2001.1
General Engineering Dept.
Photo : D-EJ725

SPECIFICATIONS

Power requirements
For the area code of the model you purchased,
check the upper left side of the bar code on the
package.
• Two Sony NC-WMAA rechargeable
batteries: 2.4 V DC,
• Sony NH-WM2AA rechargeable batteries:
2.4 V DC,
• Two LR6 (size AA) batteries: 3 V DC
• AC power adaptor (DC IN 4.5 V jack):
US, Canadian, MX model:
120 V, 60 Hz
AEP, FR, EE, G, E13 model:
220 - 230 V, 50/60 Hz
UK model: 230 - 240 V, 50 Hz
AUS model: 240 V, 50 Hz
JEW, E33 model: 100 - 240 V, 50/60 Hz
HK model: 220 V, 50/60 Hz
CH model: 220 V, 50 Hz
• Sony DCC-E345 car battery cord for use on
car battery : 4.5V DC
Canadian Model
Australian Model
Chinese Model
Tourist Model
Model Name Using Similar Mechanism D-EJ621
CD Mechanism Type
Optical Pick-up Type
Battery life* (approx. hours)
(When you use the CD player on a flat and
stable surface.)
Playing time varies depending on how the CD
player is used.
When using
G-PROTECTION function
Tow NC-WMAA
(charged for about 3 hours**)
NH-WM2AA
(charged for about 5 hours**)
Two Sony alkaline batteries
LR6 (SG)
Four Sony alkaline batteries
LR6 (SG)
Two rechargeable batteries
NC-WMAA and two Sony
alkaline batteries LR6 (SG)
Rechargeable batteries
NH-WM2AA and two Sony
alkaline batteries LR6 (SG)
*
Measured value by the standard of EIAJ
(Electronic Industries Association of Japan).
** Charging time varies depending on how the
rechargeable battery is used.
PORTABLE CD PLAYER
US Model
D-EJ721/EJ725
AEP Model
UK Model
E Model
D-EJ725
D-E777
CDM-3123EBA
DAX-23E
on
off
10
8
22
20
38
34
86
76
50
44
64
54
– Continued on page 2 –

Advertisement

Table of Contents
loading

Summary of Contents for Sony Walkman D-E777

  • Page 1: Specifications

    HK model: 220 V, 50/60 Hz alkaline batteries LR6 (SG) CH model: 220 V, 50 Hz Rechargeable batteries • Sony DCC-E345 car battery cord for use on Output (at 4.5 V input level) NH-WM2AA and two Sony car battery : 4.5V DC...
  • Page 2: Table Of Contents

    (within 3 times). NE REMPLACER CES COMPOSANTS QUE PAR DES PIÈCES • Be careful not to apply force on the conductor when soldering or SONY DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL unsoldering. OU DANS LES SUPPLÉMENTS PUBLIÉS PAR SONY.
  • Page 3: Servicing Notes

    D-E777/EJ721/EJ725 SECTION 1 SERVICING NOTES Laser Diode Checking Methods NOTES ON HANDLING THE OPTICAL PICK-UP BLOCK OR During normal operation of the equipment, emission of the laser diode BASE UNIT is prohibited unless the upper panel is closed while turning ON the S801 (push switch type).
  • Page 4: General

    D-E777/EJ721/EJ725 SECTION 2 This section is extracted from GENERAL instruction manual. LOCATING THE CONTROLS CD player (front) 1 Display 8 ./> (AMS/search) buttons 2 REPEAT/ENTER button 9 u (play/pause) 3 PLAY MODE button button 4 SOUND button q; x (stop)/CHG (charge) button 5 HOLD switch qa EXT BATT...
  • Page 5 D-E777/EJ721/EJ725 Remote control (for the models supplied with the RM-CD15L/CD16EL remote control) qj Display wa N > (play•AMS/search) buttons qk HOLD switch ql x (stop) button ws . (AMS/search) buttons w; VOL (volume) +/– buttons wd Clip (rear)
  • Page 6: Disassembly

    D-E777/EJ721/EJ725 SECTION 3 DISASSEMBLY The equipment can be removed using the following procedure. “Motor ASSY, Turn table (Spindle) (M901)” Cabinet (rear) MD ASSY, Main board “Motor ASSY (Sled) (M902)”, Optical pick-up (DAX-23E) Cabinet (front) “Lid, upper”, Switch unit Note : Follow the disassembly procedure in the numerical order given. 3-1.
  • Page 7: Motor Assy, Turn Table (Spindle) (M901)

    D-E777/EJ721/EJ725 3-3. “MOTOR ASSY, TURN TABLE 3-4. “MOTOR ASSY (SLED) (M902)”, (SPINDLE) (M901)” OPTICAL PICK-UP (DAX-23E) 1 Screws 1 Screw (B 1.7x5) (B1.7x5) Cover, Gear Gear B Screw ASSY, Feed Motor ASSY (Sled) (M902) 4 Screw (P 1.4x3.5) Retainer, shaft Motor ASSY, Turn table (Spindle) (M901) Optical pick-up...
  • Page 8: Electrical Adjustments

    D-E777/EJ721/EJ725 SECTION 4 ELECTRICAL ADJUSTMENTS The CD section adjustments are done automatically in this set. Focus bias Check Condition: Precautions for Check • Hold the set in horizontal state. 1. Perform check in the order given. 2. Use YEDS-18 disc (Part No.: 3-702-101-01) unless otherwise Connection: indicated.
  • Page 9: Diagrams

    D-E777/EJ721/EJ725 SECTION 5 DIAGRAMS 5-1. EXPLANATION OF IC TERMINALS IC801 (SYSTEM CONTROLLER) T5U87-05 Pin No. Pin name Description — Ground terminal. RESERVE — Not used (OPEN). FOKI Focus OK signal input from the digital servo processor (IC601). “L”: NG, “H”: OK AGCPWM AGC control pulse signal output terminal.
  • Page 10 D-E777/EJ721/EJ725 Pin No. Pin name Description BATDET Battery detection input. XHGOM Optical pick-up power ON/OFF control signal output terminal. “L”: ON XLAT Serial data latch pulse signal output to IC601. XSOE Serial data output enable signal output terminal. RESERVE — Not used (OPEN).
  • Page 11: Block Diagram

    D-E777/EJ721/EJ725 5-2. BLOCK DIAGRAM • Signal path. : CD...
  • Page 12: Printed Wiring Boards - Main Section (Side A)

    D-E777/EJ721/EJ725 5-3. PRINTED WIRING BOARDS – MAIN BOARD (SIDE A) – Semiconductor DRY BATTERY RECHAGEABLE Location SIZE "AA" BATTERY (IEC DESIGNATION LR6) NC-WMAA/NH-WM2AA Ref. No. Location MAIN BOARD (SIDE A) 2PCS, 3V 2.4V D312 D401 D402 D403 D405 D406 D411 D601 D804 J401...
  • Page 13: Printed Wiring Boards - Main Section (Side B)

    D-E777/EJ721/EJ725 5-4. PRINTED WIRING BOARDS – MAIN BOARD (SIDE B) – Semiconductor MAIN BOARD (SIDE B) Location Ref. No. Location D311 D404 D461 D602 D603 D803 AVLS OFF t ON IC351 IC401 IC402 IC501 IC602 IC603 IC604 J301 LINE OUT Q302 (OPTICAL) Q402...
  • Page 14: Schematic Diagram - Main Section (1/2)

    D-E777/EJ721/EJ725 5-5. SCHEMATIC DIAGRAM – MAIN SECTION (1/2) – Refer to page 16 to 17 for IC Block Diagrams. Refer to page 16 for Waveforms Refer to page 16 for Notes. IC B/D IC B/D...
  • Page 15: Schematic Diagram - Main Section (2/2)

    D-E777/EJ721/EJ725 5-6. SCHEMATIC DIAGRAM – MAIN SECTION (2/2) – Refer to page 16 to 17 for IC Block Diagrams. Refer to page 16 for Waveforms Refer to page 16 for Notes. IC B/D IC B/D...
  • Page 16 D-E777/EJ721/EJ725 IC Block Diagrams IC351 TA2120FN (EL) IC501 BA6779BFV-E2 Waveforms BIAS MUTE MUTE BIAS BEEP PLAY MODE AVDD BEEP BIAS OUT B OUT A 2.1 Vp-p 450 – 600 mVp-p IN2+ IV2- 1.9 µsec – – IC601 wg VOLT/DIV : 0.5 V AC IC601 ua VOLT/DIV : 0.1 V AC CLOCK...
  • Page 17 D-E777/EJ721/EJ725 IC601 CXD3028R 120 119 118 117 116 115 114 113 112 111 110 109 108 107 106 105 104 103 102 101 100 99 98 97 96 95 94 93 92 91 ERROR CLOCK PCMD CORRECTOR GENERATOR SELECTOR LRCK RFAC INTERFACE DEMODULATOR...
  • Page 18: Exploded Views

    D-E777/EJ721/EJ725 SECTION 6 EXPLODED VIEWS NOTE : • Hardware (# mark) list and accessories and • -XX, -X mean standardized parts, so they packing materials are given in the last of this The components identified by mark 0 may have some difference from the original parts list.
  • Page 19 D-E777/EJ721/EJ725 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 4-982-491-11 SCREW (2X8), TAPPING 3-222-740-01 BUTTON (MODE) 3-222-733-01 CABINET (REAR) (US) 3-222-733-11 CABINET (REAR) (EXCEPT US) 3-223-134-01 SHEET (LCD WINDOW), ADHESIVE 4-993-131-31 KNOB (HOLD) (EXCEPT US) 3-224-568-01 RING, COVER 4-993-131-51 KNOB (HOLD) (US) 3-222-738-01 WINDOW, LCD 3-222-744-01 SPRING (FULL OPEN)
  • Page 20: Optical Pick-Up Section (Cdm-3123Eba)

    D-E777/EJ721/EJ725 6-2. OPTICAL PICK-UP SECTION (CDM-3123EBA) M901 M902 The components identified by Les composants identifiés par une mark 0 or dotted line with mark marque 0 sont critiques pour 0 are critical for safety. la sécurité. Replace only with part number Ne les remplacer que par une pièce specified.
  • Page 21: Electrical Parts List

    D-E777/EJ721/EJ725 SECTION 7 ELECTRICAL PARTS LIST MAIN NOTE : • Due to standardization, replacements in the • SEMICONDUCTORS In each case, u : µ , for example : The components identified by mark 0 parts list may be different from the parts uA..
  • Page 22 D-E777/EJ721/EJ725 MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark C453 1-115-467-11 CERAMIC CHIP 0.22uF C651 1-162-967-11 CERAMIC CHIP 0.0033uF 10% C454 1-164-156-11 CERAMIC CHIP 0.1uF (EXCEPT US) C455 1-115-467-11 CERAMIC CHIP 0.22uF C801 1-164-156-11 CERAMIC CHIP 0.1uF C456 1-164-156-11 CERAMIC CHIP...
  • Page 23 D-E777/EJ721/EJ725 MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark IC601 8-752-409-05 IC CXD3028R R105 1-216-821-11 METAL CHIP 1/16W IC602 8-759-594-56 IC MSM51X17400D-10TFSR1 (US) R106 1-216-845-11 METAL CHIP 100K 1/16W IC603 8-759-653-36 IC GLT441M04-70TC (EXCEPT US) R107 1-216-849-11 METAL CHIP 220K...
  • Page 24 D-E777/EJ721/EJ725 MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R415 1-218-965-11 RES-CHIP 1/16W R509 1-218-983-11 RES-CHIP 330K 1/16W R416 1-218-989-11 RES-CHIP 1/16W (US) R418 1-218-895-11 METAL CHIP 100K 0.5% 1/16W R419 1-218-903-11 METAL CHIP 220K 0.5% 1/16W R602...
  • Page 25 D-E777/EJ721/EJ725 MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R813 1-218-969-11 RES-CHIP 1/16W 1-467-550-25 ADAPTOR, AC (AC-E455A) (E777/EJ725:E33) (US) 1-473-115-11 ADAPTOR, AC (AC-E455F) (EJ725:UK) R813 1-218-971-11 RES-CHIP 1/16W 1-475-623-12 ADAPTOR, AC (AC-E455) (EJ725:HK) (E777/EJ725: EXCEPT US, FR) 1-476-373-21 REMOTE CONTROL UNIT R813 1-218-979-11 RES-CHIP...
  • Page 26 D-E777/EJ721/EJ725 REVISION HISTORY Clicking the version allows you to jump to the revised page. Also, clicking the version at the upper right on the revised page allows you to jump to the next revised page. Ver. Date Description of Revision 2001.01...
