EVENT
WIRELESS ZONE LOW
Wireless PIR
BATTERY
Zone 1-8
REMOTE CONTROL
Remote Control Button
LOW BATTERY
PANIC BUTTON Keypad Panic
(BUTTONS 1&3
PRESSED TOGETHER)
Keypad Fire
FIRE ALARM
(BUTTONS 4&6
PRESSED TOGETHER)
MEDICAL ALARM Keypad Medical
(BUTTONS 7&9
PRESSED TOGETHER
PENDANT PANIC Radio Key
User 1-8
Area A Armed
ARMED A
ARMED B Area B Armed
Area A Stay Mode ON
STAY MODE A
STAY MODE B Area B Stay Mode ON
DURESS ALARM Duress Alarm

Installation Notes:

INSTALLTION COMPANY:
Company________________________________________
Technician___________________
Installation Date__________
PDF created with FinePrint pdfFactory trial version
DEVICE INDICATOR STATUS
LED's 1-8 Flashing
TROUBLE On Steady
1-8 LED's 1-8 Flashing
SYSTEM Flashing
SYSTEM Flashing
AREA A Flashing
SYSTEM Flashing
AREA B Flashing
SYSTEM Flashing
LED's 1-8 Flashing
AREA A LED On Steady
AREA B LED On Steady
AREA A LED Flashing
AREA B LED Flashing
TROUBLE On Steady
AREA A & B Flashing
Phone_________________
http://www.fineprint.com
To add a new user code:
By default only the master code has access to change add or remove
codes. Any new codes added will be able to arm, disarm and put either
area of the panel into 'Stay' mode. User codes can be limited in their
levels of access if required. See your installer.
Making sure the panel is not armed, key in the following sequence:
[PROGRAM] mastercode [ENTER]
The program light will come on steady, indicating readiness to accept new
programming.
To load, for example, user code 3 with a code 4321, key in the following
sequence: Add further user codes from 2 up to 10 if required.
[PROGRAM] 3 [ENTER]
If there is an existing code already in that address it will be flashed back
on the key pads LED display. Entering the new code will delete the old
and the new code will be flashed back to you.
4321 [ENTER]
The panel will give 3 short beeps to indicate correct entry or 1 long tone if
not accepted.
To remove or clear a user code number e.g. user 3, key in the following
sequence
[PROGRAM] 3 [ENTER] [BYPASS] [ENTER]
To exit out of program mode key
[PROGRAM] [ENTER]
Note: on the LED display 0 is indicated by LED 'A' and 9 by LED 'B'.
Event Memory
Your PW-8 alarm panel has an event memory which stores, the 127 most
recent events including all alarm events and system events such as mains
failure etc as well as sets.
The System LED will flash when an event occurs e.g. "mains failure".
When the event is cleared "mains returns", the system LED will remain
steady. To clear this indicator press [MEMORY] or it will simply clear next
time you arm the panel.
