Samsung SL-M4580FX Service Manual page 65

Description
AC Output
-
AC Output Connector (CON4)
Description
AC OUTPUT
(to Lamp)
-
Signal Connector (CON1)
Description
Power
Lamp1 Control Signal
Lamp2 Control Signal
Phase_Control
Signal
FDB ON_OFF
Ground
Copyright© 1995-2013 SAMSUNG. All rights reserved.
2. Product Specifications and Description
PIN NAME
AC_N
PIN NAME
LAMP1
LAMP2
COMMON
PIN NAME
24VS1
Heater_ON1
Heater_ON2
Zero_Crossing
Relay_ON/OFF
GND
PIN ASSIGN
2
PIN ASSIGN
1
2
3
PIN ASSIGN
1
2
3
4
5
6
2-52
