Panasonic AM1 (NZ BASIC) Specification Sheet page 8

4. Oil tight types
The pushbutton part is sealed with the rubber cap and the connected part between the cap and body is also coated with resin so that
these parts are kept away from foreign matters. This type has resistance to oil.
Rigid lever
AM1511KF (Solder terminal)
AM1711KF (Screw terminal)
Rigid short roller lever
AM1514KF (Solder terminal)
AM1714KF (Screw terminal)
Rigid roller lever
AM1513KF (Solder terminal)
AM1713KF (Screw terminal)
Plunger seal
26.1
20.1±0.5
Plunger seal
26.1
R26.7
20.1±0.5
16.9±0.8
Plunger seal
20.1±0.5
16.9±0.8
All Rights Reserved © COPYRIGHT Panasonic Electric Works Co., Ltd.
Lever: Stainless steel
R63.5
F.P.
O.P.
Roller 9.5 dia.×4:
Plastic
F.P.
O.P.
Roller 9.5 dia.×4:
Plastic
26.1
R48.3
F.P.
O.P.
mm General tolerance: ±0.4
Operating force,
max.
Release force,
min.
Pretravel,
4.8
max. mm
Movement differential,
max. mm
Overtravel,
min. mm
Operating position,
mm
Operating force,
max.
Release force,
min.
Pretravel, max.
mm
Movement differential,
max. mm
Overtravel,
min. mm
Operating position,
mm
Operating force,
max.
Release force,
min.
Pretravel,
max. mm
Movement differential,
max. mm
Overtravel,
min. mm
Operating position,
mm
AM1
0.69 N
0.14 N
10
1.5
5.6
19.1±0.7
1.67 N
0.42 N
4.5
0.7
2.4
30.2±0.4
0.98 N
0.20 N
7.5
1.3
3.6
30.2±0.7
