Panasonic AM1 (NZ BASIC) Specification Sheet page 6

Rigid lever
AM1501KF (Solder terminal)
AM1701KF (Screw terminal)
Rigid short roller lever
AM1504KF (Solder terminal)
AM1704KF (Screw terminal)
Rigid roller lever
AM1503KF (Solder terminal)
AM1703KF (Screw terminal)
2. One way types
This type is operated only to one direction, not to the reversed direction by the construction of the roller lever, pivoting away from the
cam on the return stroke.
Rigid short roller lever
AM1544KF (Solder terminal)
AM1744KF (Screw terminal)
26.1
20.1±0.5
26.1
R26.7
20.1±0.5
26.1
20.1±0.5
26.1
R21.1
27.8 max.
20.1±0.5
All Rights Reserved © COPYRIGHT Panasonic Electric Works Co., Ltd.
Lever: Stainless steel
R63.5
4.8
F.P.
O.P.
Roller 9.5 dia.×4:
Plastic
F.P.
O.P.
Roller 9.5 dia.×4:
Plastic
R48.3
F.P.
O.P.
Roller 4.75 dia.×4.75:
Plastic
F.P.
O.P.
AM1
mm General tolerance: ±0.4
Operating force,
0.69 N
max.
Release force,
0.14 N
min.
Pretravel,
10
max. mm
Movement differential,
1.3
max. mm
Overtravel,
5.6
min. mm
Operating position,
19.1±0.7
mm
Operating force,
1.57 N
max.
Release force,
0.42 N
min.
Pretravel,
4.5
max. mm
Movement differential,
0.7
max. mm
Overtravel,
2.4
min. mm
Operating position,
30.2±0.4
mm
Operating force,
0.98 N
max.
Release force,
0.2 N
min.
Pretravel,
7.5
max. mm
Movement differential,
1.3
max. mm
Overtravel,
3.6
min. mm
Operating position,
30.2±0.7
mm
Operating force,
2.23 N
max.
Release force,
0.42 N
min.
Pretravel,
3.5
max. mm
Movement differential,
0.4
max. mm
Overtravel,
1.5
min. mm
Operating position,
30.2±0.4
mm
