Panasonic AM1 (NZ BASIC) Specification Sheet page 5

AM1
Panel mount roller plunger
AM110811KF (Solder terminal)
AM130811KF (Screw terminal)
Panel mount cross roller plunger
AM110812KF (Solder terminal)
AM130812KF (Screw terminal)
Dimensions and Operating characteristics are the same as those of Panel mount roller plunger type. However, the roller joins the switch body at an angle of 90°.
Flexible leaf lever
AM1101KF (Solder terminal)
AM1301KF (Screw terminal)
Flexible roller leaf lever
AM1103KF (Solder terminal)
AM1303KF (Screw terminal)
P.T.
0.4 max.
±0.3
23.3
O.P.
±1.2
33.3
15.5
+0.10
±0.5 4.2
16
–0.05
P.T.
0.4 max.
±0.3
23.3
O.P.
±1.2
33.3
15.5
+0.10
4.2
±0.5
16
–0.05
49.6±0.8
Leaf: Stainless steel
F.P.
O.P.
46±0.8
Leaf: Stainless steel
F.P. O.P.
All Rights Reserved © COPYRIGHT Panasonic Electric Works Co., Ltd.
Roller 12.7 dia. × 4.6
: Plastic
M12 × P1
Nut (2 thick)
14.3
4.2 +0.10 dia.
–0.05
Roller 12.7 dia. × 4.6
: Plastic
M12 × P1
Nut (2 thick)
14.3
4.2 +0.10 dia.
–0.05
4.8
14.6
Roller 9.5 dia.×4:
Plastic
14.6
mm General tolerance: ±0.4
Operating force,
3.63 N
max.
Release force,
1.12 N
min.
Pretravel,
0.4
max. mm
Movement differential,
0.05
max. mm
Overtravel,
3.6
min. mm
Operating position,
33.3±1.2
mm
Operating force,
3.63 N
max.
Release force,
1.12 N
min.
Pretravel,
0.4
max. mm
Movement differential,
0.05
max. mm
Overtravel,
3.6
min. mm
Operating position,
33.3±1.2
mm
Operating force,
1.47 N
max.
Release force,
0.14 N
min.
Pretravel,
max. mm
Movement differential,
1.3
max. mm
Overtravel,
1.6
min. mm
Operating position,
17.5±0.8
mm
Operating force,
1.47 N
max.
Release force,
0.14 N
min.
Pretravel,
max. mm
Movement differential,
1.3
max. mm
Overtravel,
1.6
min. mm
Operating position,
28.6±0.8
mm
