UNI-ID7C3 / UNI-ID7T3
Indoor Recessed Dome Housings
Installation and Operation Instructions for the following model:
UNI-ID7C3
Indoor recessed housing, clear lower dome
UNI-ID7T3
Indoor recessed housing, tinted dome
Note: AC 24V power supply for the camera, ethernet cables and other interface
wiring are installer provided items.
Note: Please note that to achieve the increased depth with the aspheric design for optimal camera
lens to capsule orientation, the capsule is slightly angled around the highest section. This creates
a "line', visible to the naked eye, around the upper most section of the capsule. This "line" serves
as the geometric center line used to insure proper camera placement. It is not typically seen by
the camera. However, Sony RZ series PTZ cameras are able to tilt up above the horizon to 25°,
this wide range of tilt motion at a wide angle view may cause this line to be captured in the image.
Mounting Instructions for:
SNC-RH124
SNC-RZ25
SNC-RZ30
SNC-RZ50
SNC-RX530
SNC-RX550
SNC-RX570
Quick Reference:
SNC-RZ25N............................Go to Step 1
SNC-RZ25N............................Go to Step 2
SNC-RZ50N............................Go to Step 3
SNC-RX Series........................Go to Step 4
SNC-RH/RS.............................Go to Step 5
Camera Installation Steps
81-IN6568
10-15-2009
Advertisement
Table of Contents
Related Manuals for Sony UNI-ID7T3
Summary of Contents for Sony UNI-ID7T3
- Page 1 It is not typically seen by the camera. However, Sony RZ series PTZ cameras are able to tilt up above the horizon to 25°, this wide range of tilt motion at a wide angle view may cause this line to be captured in the image.
-
Page 2: Important Safeguards
These Installation and Operating Instructions. support structure and falling, with resultant damages or injury to anyone or anything struck by the falling unit. SERVICE If technical support or service is needed, contact Sony at the following number: TECHNICAL SUPPORT 8:15AM to 7:30PM (Eastern Time) -
Page 3: Contents Of Box
Contents of Box Details Contents of Box (1) Quick Release Plate (1) Spacer Packet (4) M3 x 6mm Machine Screw (4) M3 lock washers (1) 1/4 x 20 Bolt (1) 1/4 flat washer (1) 1/4 lock washer (3) 8 x 32 x 3/8" bolt (3) Cable ties... -
Page 4: Electrical Specifications
Electrical Specifications UNI-ID7C3 UNI-ID7T3 No power options provided. Power required for camera only. Power 24VAC Class 2 Power Supply Only English Tools Required: Phillips Head Screwdriver Ceiling Support Wires(18-24 Gauge Wire) Ningunas opciones de la energía proporcionaron. Energía requerida para la cámara fotográfica solamente. -
Page 5: Sony Snc-Rz30
Camera Installation: SNC-RZ25N Sony SNC-RZ25N Mounting Hole 1" 3391 Mounting Plate Attach bracket with (1) 1/4x20 bolt, washer and lock washer and (2) 3mm x 8mm Phillip head screws and lockwashers. Attach the 3 screws loosely on the spacers as shown. Slide on the plate and camera then tighten the 3 screws. - Page 6 Camera Installation: SNC-RZ50N Sony SNC-RZ50N 2" Mounting Hole 3391 Mounting Plate Attach bracket with 3mm x 8mm bolts and lock washers. Attach (3) 8x32x3/8”screws loosely on the spacers. Slide on the plate and camera then tighten the 3 screws. (Go to step 6) •...
- Page 7 Camera Installation: SNC-RH124 Sony SNC-RH124 Mounting Hole (12.7 1/2" 3391 Mounting Plate Attach mount base with (3) #8 x 3/8 bolts and star washers. Attach camera to base. (See camera manual for additional details.) • Adjuntar base de montaje con (3) # 8 x 3 / 8 tornillos y arandelas de estrella. Conecte la cámara a la base. (Ver manual de la cámara para obtener detalles adicionales.)
-
Page 8: Installation
Installation: (2) locations for the conduit Remove the desired conduit knock-out Fit the ½˝ flex conduit or ‘L’ counduit into from the top of the housing. the desired hole. • Quite la maravilla deseada del conducto de la • Quepa el conducto ½˝ o el ` L ' counduit de la tapa de la cubierta. - Page 9 Base Bracket If required, secure housing by running bolts in the bottom flange and support wires from a solid structure. (Support wires are an installer provided item). • Si está requerido, asegure los pernos del funcionamiento de la cubierta The camera may be mounted on either side of the en el reborde inferior y apoye los alambres de una estructura sólida.
-
Page 10: Replacement Parts List
Replacement Parts List Part Number Description RPMR7010 MR7 TOP HOUSING ASSEMBLY UNI-ID7C3 RPMR7020 MR7 SUPPORT ARMS KIT (SET OF 3) UNI-ID7T3 RP3390 BASE BRACKET REPLACEMENT CAPSULE FOR MR7T RCMR7T HOUSING REPLACEMENT CAPSULE FOR MR7CL RCMR7C HOUSING, NO SILKSCREEN, LINER RPMR7050... - Page 11 How - to Clean a Dome Bubble To effectively clean your video surveillance dome bubble (acrylic or polycarbonate) from debris, follow these simple step-by-step instructions. Materials Needed • Clean, dry, pressurized air • Water • High quality soft paper towel •...
- Page 12 Warranty For warranty information on this and other Sony Security Systems Products, please visit: http://pro.sony.com/bbsccms/services/files/servicesprograms/SecurityWarranty.pdf...
