Important Safety Instructions This symbol, wherever used, alerts you to the presence of un-insulated and dangerous voltages within the product enclosure. These are voltages that may be sufficient to constitute the risk of electric shock or death. This symbol, wherever used, alerts you to important operating and maintenance instructions. POWER SUPPLY Ensure that the insource voltage (AC outlet) matches the voltage rating of the product.
3.7 kg in one unit rack. PX 500 offers 3 different modes. STEREO mode is a stereo amplification who can provide 2 x 180 W / 8 Ohms or 2 x 250 W / 4 Ohms. BRIDGE mode provides 500 W / 8 Ohms. PARALLEL mode amplifies a mono source, using resources from 2 channels.
Controls and Settings Front Panel 1 – POWER ON When the power switch is activated the soft start mode operates, muting the outputs to prevent damages to the speakers. The delay times before switching on is 7 s. 2 – CHANNEL 1 Channel 1 level control.
Page 6
Controls and Settings Rear Panel 9 – BAL INPUT XLR balanced inputs 1 & 2. 10 – UNBAL INPUTS RCA unbalanced inputs 1 & 2. 11 – MODE Mode selector : PARALLEL – STEREO – BRIDGE (see Chapter 4) Please turn off the device before any actions. 12 –...
Operating Modes STEREO Mode This is the standard mode: both channels functioning independently, the attenuators (2) and (3) respectively controlling each channel input levels. The recommended nominal load impedance is 8 or 4 Ohms per channel. The speakers are connected to the terminals as shown in the figure below. BRIDGE Mode It is a monophonic mode, both channels work with the same signal input, but in phase opposition.
Operating Modes PARALLEL Mode In this mode both channels of the amplifier receive the same signal connected to the input 1, both attenuators (2) and (3) remaining active. The speaker outputs wiring is identical to Stereo mode. Installations Hints In case of installation in cabinet or rack, ensure the ventilation requirements. The depth of the device is 277 mm, the height is 1 unit rack (44 mm).
Connectors PX 500 input connectors are balanced (XLR) and unbalanced (RCA). Cables related to connecting to other equipment must therefore be of the same nature. Are listed below types of different cords with their electrical connection diagram. Balanced Unbalanced Impedance load When connecting multiple speakers or speakers on the same channel, various types of connection are possible.
Impedance load The table below gives the value of the total impedance depending on the connection modes. It only includes the most frequently encountered cases. Speaker impedance Speaker quantity (*) Equivalent impedance of Equivalent impedance of PARALLEL Mode SERIAL Mode 16 Ohms 8 Ohms 32 Ohms (not recommended)
Malfunctions Some occasional problems are very often linked to handling errors. By checking the points listed below, it will be possible to find without difficulty, solutions to potential malfunctions. If problems persist, consult a dealer or an authorized AUDIOPOLE service center. Symptom Cause Solution...
