Page 1: Installation Instructions
111140E-11 2016-11 Spirit K2 Installation instructions Air handling unit with kitchen hood and control panel... -
Page 2: Table Of Contents
Contents Installation/Preliminaries Inspection/Maintenance Space Required Location requirements Installation of Flexit SPIRIT K2 R Installing the volume hood Encasing Connection of unit and electrical work Connection of unit Electrical work Automatic Control External components Sizes/Physical Dimensions Dimensioned sketch Flexit SPIRIT K2 R... -
Page 3: Symbols Used
• There shall be adequate ventilation of the room when the Important Safety Instructions: range hood is used at the same time as appliances burning gas or other fuels. It is the installer's responsibility to carry out a full safety and •... -
Page 4: Installation/Preliminaries
Installation/Preliminaries See separate documentation for installation of ducts, valves, 1.3 Location requirements etc. The unit has been designed for location in the kitchen over the cooker as it contains an integrated kitchen hood. The The unit is designed for indoor installation. unit is available in left or right versions (exhaust air nipple to the left or right), depending on what is the most favourable in relation to the duct location. - Page 5 Recommended sound attenuation for wall-mounting For wall mounting, the (included) wall bracket fixed to the unit is used. The unit must not be placed on a wall with rooms on the other side which are sensitive to noise. The wall must be sound-insulated.
-
Page 6: Installation Of Flexit Spirit K2 R
2 Installation of Flexit SPIRIT K2 R Flexit SPIRIT K2 R is designed for installation in the kitchen above the cooker, see Fig. 2. The unit is supplied in left and right-hand versions depending on what suits duct locations best (Chap. 4.1). -
Page 7: Encasing
Fig. 5 2.2 Encasing The casing must not be deeper than dimension A. B=2mm B=2mm 596 mm Fig. 7 Fig. 6 min 600 mm *min. req. 650mm for gas cookers... -
Page 8: Connection Of Unit And Electrical Work
Connection of unit and electrical work 3.1 Connection of unit 3.3 Automatic Control • Ensure that the ducts arrive at the right muff coupling. See The control pack is included in the unit package. The the marking on the unit (top/bottom and behind door). low-voltage cable must be laid between the unit and the The symbols are explained on page 3 and the location is switch unit. -
Page 9: Sizes/Physical Dimensions
4 Sizes/Physical Dimensions 4.1 Dimensioned sketch Flexit SPIRIT K2 R (Shown as left-hand model) (Shown as right-hand model) -
Page 10: General Drawings And System Drawings
5 General Drawings and System Drawings (Shown as left-hand model. The right-hand version is a mirror image.) Outdoor Supply Extract Exhaust General Diagram (Rotary Wheel-type Heat Exchanger) (FI2) Extract filter F 7 2 (FI1) Supply air filter F 7 3 (EB1) Heating element (F10-20) Overheating thermostat (heating) (Reset) -
Page 11: Capacity And Sound Data
6 Capacity and sound data 6.1 Capacity diagram, sound data, specifications - K2 R EC Supply air side (with F7 filter) Air flow rate [l/s] < 0,75 100% 100% 40dB(A) 45dB(A) 50dB(A) 55dB(A) 60dB(A) 63dB(A) Air flow rate [m³/h] Extract air side (with F7 filter) Air flow rate [l/s] <... -
Page 12: Technical Data
Technical data 7.1 Technical data Flexit SPIRIT K2 R 700W 350W Rated voltage 230 V/50 Hz 230 V/50 Hz Fuse size 10 A 10 A Rated current, total 3,91 A 2,1 A Rated power, total 870 W 495 W Rated power, electric batteries... -
Page 13: Installation Of Control Panel Ci 60/600
8 Installation of control panel CI 60/600 8.1 Content Control panel Back piece for concealed installation Back piece for surface installation Installation instructions Cable for control panel 8.2 Installation of CI60/600 Fig. 8 CAUTION! The control panel must be connected to the ventilation unit before the ventilation unit is connected to mains. -
Page 14: Concealed Installation
8.3 Concealed installation 8.5 Finishing off – CI60 Lay the cable between the wall box and the ventilation unit in Slide the panel off as shown by arrow no. 1 (see Fig. 11) and the preinstalled conduit pipe. Fit the back piece (item no. 2), fit the control panel straight into the back piece as shown over the wall box and click the cable in directly from behind by arrow no. -
Page 15: Adjusting Ec Units
9 Adjusting EC units 9.1 Adjustment with CI60 Fig. 14 The unit's air supply MUST be adjusted before the unit is used for the first time. This should be done in accordance with the projection documents. Adjust the values based on the projected values. 9.1.1 Adjustment Only stage 2 (NORMAL) needs to be adjusted. -
Page 16: Adjustment With Ci600
9.2 Adjustment with CI600 The unit's air supply MUST be adjusted before This dialog is identical for the supply air and extract air fans. The fans are adjusted individually to the desired capacity for the unit is used for the first time. This should be done in accordance with the projection the respective speed. -
Page 17: Adjusting The Kitchen Hood
11 Adjustment Curves If basic ventilation is desired via the kitchen hood, the 11.1 Forced ventilation Flexit SPIRIT K2 R damper from the factory must be replaced. Replace it with a damper with adjustment options. This is not supplied with the unit. -
Page 18: Final Checks/First Use
• The unit has filters for both outdoor air and extract air. • Tumble dryers must not be connected to the unit. The installer may be held liable for any incorrect or defective installation. Flexit SPIRIT K2 R, Left-hand model Flexit SPIRIT K2 R, Right-hand model... -
Page 19: Ec Declaration Of Conformity
EN 55014-2:1997 + A1 + A2 Our products have been tested in accordance with parts of: 2006/42/EC Machinery Directive (Safety) The product has been CE-marked: 2011 Manufacturer: FLEXIT AS, Televeien 15, 1870 Ørje, Norway FLEXIT AS 16.02.2011 Type: K2 R... - Page 20 Flexit AS, Televeien 15, N-1870 Ørje www.flexit.no...
