INSTALLATION, AND MAINTENANCE MANUAL FOR GAS FIRED, WALL-HUNG BOILERS RSF 30 E Model TYPE C ROOM SEALED SEDBUK BAND D 0694 TA01A011.B1003 Technical Specification RADIANT BRUCIATORI S.p.A. Montelabbate (PU) ITALY ENGLISH...
INDEX INSTALLATION INSTRUCTIONS AND WARNINGS page TECHNICAL DATA page OVERALL DIMENSIONS - EXHAUST FLUE SYSTEM page GENERAL INSTALLATION REQUIREMENTS page BOILER INSTALLATION page ELECTRICAL CONNECTIONS page 8;13 BOILER CONTROL PANEL page STARTING UP THE BOILER FOR THE FIRST TIME page MULTIGAS OPERATION page MAIN COMPONENTS...
Page 4
RADIANT BRUCIATORI S.p.A. products are type tested EC. All RADIANT boilers are constructed according to UNI - CIG (EC) norms. The materials used, such as copper, brass, and stainless steel form a compact, homogeneous, highly functional unit that is easy to install and simple to operate. The wall-mounted boiler is equipped with all of the approved accessories required to make it a true, independent heating plant for home heating and for the production of hot water for domestic needs.
CENTRAL HEATING - DOMESTIC HOT WATER sealed combustion circuit type RSF 30 E - electronic ignition Coaxial vertical C52 Double Coaxial horizontal Technical data...
Installation Manual GENERAL INSTALLATION REQUIREMENTS GAS SAFETY It is the law that all gas appliances are installed by a CORGI registered installer (you can check this by contacting corgi on 01256.372200) in accordance with the regulations listed below. Failure to install appliances correctly could lead to prosecution. It is in your own interest and that of safety to ensure that the law is complied with.
Page 8
Installation Manual FLUE POSITION IMPORTANT: THE FLUE SYSTEM SHALL BE INSTALLED IN ACCORDANCE WITH THE RECOMMENDATIONS CONTAINED IN BS 5440:1. The boiler MUST be installed so that the terminal is exposed to the external air. It is important that the position of the terminal allows free passage of air across it at all times. If the terminal discharges into a pathway or passageway check that combustion products will not cause nuisance and that the terminal will not obstruct the passageway.
Page 9
Installation Manual MINIMUM DISTANCES FOR FIXING TO WALL KIT A To allow access in the boiler for MOD. 1 KIT H MOD. 2 maintenance operations, MOD. 2 minimum distances shown below MOD. 1 must be respected (fig. 1): CON STAFFA MOD. 1 WITH BRACKET MOD.
Page 10
Available head with by-pass partially (50%) on. ANTI-FROST SYSTEM Radiant boilers are equipped with an Anti- Freeze system which comes into operation when the temperature falls to 5° C (Heating sensor) and 4° C (Hot water sensor) and protects the boiler down to –10°C external temperature.
Installation Manual ELECTRICAL CONNECTIONS For qualified personell only: the boiler works with 230 V 50 Hz AC current and has maximum input of 170 W. Connection to the electrical mains must be performed with a device having an omnipolar opening of at least 3 mm. Make sure the live and neutral connections conform to the diagram.
Page 12
Installation Manual CONTROL PANEL ELECTRONIC WATER PRESSURE GAUGE LEGEND (see fig. 1) 14 13 ON / OFF POWER SWITCH HEATING TEMPERATURE ADJUSTMENT KNOB DOMESTIC HOT WATER TEMPERATURE ADJUSTMENT KNOB OUTSIDE TEMPERATURE DISPLAY PAD (ONLY WITH OPTIONAL OUTSIDE TEMPERATURE SENSOR FITTED) CHIMNEY-SWEEPER SELECTION PAD / PARAMETER SETTING SERVICE PAD MODE SELECTION PAD (SUMMER...
Page 13
Installation Manual • set ON/OFF switch in ON position (see fig.1), after a few seconds the pump will come into operation; • once the boiler is working, if any noises are heard in the system, repeat the above air purging procedures until there is no air left in the system;...
Page 14
GAS DATA TABLE Models: RSF 30 E NATURAL GAS G 20 LIQUID BUTAN GAS G 30 LIQUID PROPANE GAS G 31 Lower Wobbe index (15°C;...
Installation Manual ELECTRICAL CONNECTION PRINTED CIRCUIT BOARD CVI-M SM20015 (cod. 76655LA) DISPLAY DIGITAL BOARD 2000 SKO6206 (COD. 76654LA) - LINE - NEUTRAL - AIR PRESSURE SWITCH - WATER PRESSURE SWITCH - ELECTRONIC FLOWSWITCH - MAIN SWITCH - D.H. WATER SENSOR ELECTRONIC IGNITION BOARD - HEATING SENSOR 1,5bar...
Page 17
Installation Manual WIRING DIAGRAM FOR REMOTE CONTROL INSTALLATION (no zone valves) Fig. 3 Interfaccia grey orange Fig. 2 P.B.C. INTERFACE REMOTE Fig. 4 EXTERNAL SENSOR M1 1 REMOTO Fig. 5 Fig. 1 Fit the interface (fig. 2) on the circuit board (fig. 1) into the holes A and B provided (see fig. 1). Connect plug M1 on the interface circuit board (fig.
Installation Manual MAINTENANCE To keep the boiler in efficient and safe operating condition, we recommend you perform the following checks at least once a year: • Check all seals on the gas side and replace gaskets to restore perfect seal as required. •...
Page 19
Installation Manual SPARE PARTS SHORT LIST CODE DESCRIPTION RSF 30 E 20046LA 24 PLATE EXCHANGER 17B1902406 21032LA GAS BURNER 17 R. 1,20 NATURAL GAS 21033LA GAS BURNER 17 R. 0,75 L.P.G. 24040LA CIRCULATING PUMP GOLD 50V1 SHUL CLF6 15/6 W/ AIR VENT...
Page 20
Via Pantanelli, 164/166 - 61025 Loc. Montelabbate (PU) Tel. +39 0721 9079.1 • fax. +39 0721 9079279 e-mail: tecnico@radiant • Internet: http://www.radiant.it UK – Radiant Helpline – 01329.828555 ALL DESCRIPTIONS AND ILLUSTRATIONS CONTAINED IN THIS LEAFLET HAVE BEEN CAREFULLY PREPARED BUT WE RESERVE THE RIGHT TO MAKE CHANGES AND IMPROVEMENTS IN OUR PRODUCTS WHITCH MAY AFFECT THE ACCURANCY OF THE INFORMATION CONTAINED IN THIS LEAFLET.
