PLEASE READ CAREFULLY AND KEEP
THIS MANUAL FOR FUTURE REFERENCE
Instruction Manual
GRIZZLY FURNACE
Certified and tested according
to CAN/CSA B415.1 norms
CAN/CSA B366.1 norms
490, rue de l'Argon, Quebec Qc. Canada G2N 2C9
Phone: 418-849-8095
Fax.: 418-849-0077
www.jaroby.com
September 13, 2016
Printed in Canada
Advertisement
Table of Contents
Related Manuals for J. A. Roby GRIZZLY FURNACE
Summary of Contents for J. A. Roby GRIZZLY FURNACE
- Page 1 PLEASE READ CAREFULLY AND KEEP THIS MANUAL FOR FUTURE REFERENCE Instruction Manual GRIZZLY FURNACE Certified and tested according to CAN/CSA B415.1 norms CAN/CSA B366.1 norms 490, rue de l'Argon, Quebec Qc. Canada G2N 2C9 Phone: 418-849-8095 Fax.: 418-849-0077 www.jaroby.com September 13, 2016...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SPECIFICATIONS – GRIZZLY FURNACE ............3 DIMENSIONS ....................... 3 CLEARANCES ..................... 4 WARNING ......................4 NOTICE ........................ 6 CREOSOTE ........................... 6 CHIMNEY ......................7 INSTALLATION ....................7 VERTICAL INSTALLATION INSIDE A MASONRY CHIMNEY ..........8 EXTERIOR VERTICAL INSTALLATION ................8 VERTICAL INSTALLATION ON A CATHEDRAL ROOF ............ -
Page 3: Specifications - Grizzly Furnace
SPECIFICATIONS – GRIZZLY FURNACE Combustible Wood Recommended surface 1500 to 3700 ft² (139 to 347m²) Result based on the amount of heat produced in the plenum Particulate emission 0.07g/MJ Minimum heating capacity 11 300 BTU/h Maximum heating capacity 44070 BTU/h... -
Page 4: Clearances
CLEARANCES Back 1 in (2.54cm) Lateral 6 in (15.2cm) Roof 84 in (2.14m) WARNING Read this manual before installing and/or using this appliance and keep it in a safe place within reach for future references. If this appliance is not properly installed, it could result in fire, property damage, injuries and loss of life. - Page 5 Wood should not be stocked within the minimums clearances or in the necessary space for loading and ash disposal. Always use dried wood. Do not burn green or wet wood. Do not use construction debris such as pieces of 2x4, plywood. If the appliance starts to turn red, it is too charged.
-
Page 6: Notice
NOTICE The GRIZZLY Furnace was designed to operate safely when the doors closed and burning only firewood. Any change, modification or unauthorized installation will automatically cancel the certification of the appliance, the guarantee and the homologation, and in addition, the appliance might become dangerous. -
Page 7: Chimney
Use only approved chimney of the same dimensions as the appliance exit, which means you should use a 6 inch diameter chimney for your GRIZZLY Furnace. A Chimney must be tested upon the ULC S629 CSA, UL103 norms. The GRIZZLY Furnace wood appliance can be connected to a masonry chimney following the ULC S635, ULC S640 and the UL 1777 norms. -
Page 8: Vertical Installation Inside A Masonry Chimney
ERTICAL INSTALLATION INSIDE A MASONRY CHIMNEY The GRIZZLY Furnace wood appliance must be installed in accordance with the applicable local laws or the CAN/CSA-B365, ULC S635, ULC S640, UL 1777 norms. Install the chimney following the manufacturer’s instructions. XTERIOR VERTICAL INSTALLATION... -
Page 9: Vertical Installation On A Cathedral Roof
CAN/CSA- B365 norm. Install the chimney following the manufacturer’s instructions. ROSS STYLE INSTALLATION The GRIZZLY Furnace wood appliance must be installed in accordance with the applicable local laws or the CAN/CSA-B365 norm. Install chimney following manufacturer’s instructions. -
Page 10: Vertical Installation
ERTICAL INSTALLATION The GRIZZLY Furnace wood appliance must be installed in accordance with the applicable local laws or the CAN/CSA-B365 norm. Install the chimney following the manufacturer’s instructions. September 13, 2016... -
Page 11: Clearances
CLEARANCES Due to its reduced clearances, this appliance occupies a minimum of space in the room. No matter where you install it, this appliance will perfectly complete your decoration by its originality and its heat. This appliance only needs 1 inch clearance at its back, 6 inches at the lateral wall. -
Page 12: Installation Of The Firebricks
INSTALLATION OF THE FIREBRICKS Installation of the firebricks Use the round bricks support and the hex head screw to secure the bricks on the interior wall of the furnace. 1. Install the bricks in the bottom of the stove (horizontal) 12 x Bricks A, 2 x Bricks F, 1 x Bricks E 2. - Page 13 FIGURE 1 6. Fix the support pipes in the stove using the hexagonal head screw provided. (See figure 2) FIGURE 2 September 13, 2016...
- Page 14 7. Insert the 2 other pipes in the stove passing through the hook of the pipes. 8. Insert the 4 bricks on the pipes (4 x bricks E) and the wool, then put the steel plate over the wool. ***IMPORTANT*** Make sure that the wool don't obstruct the remaining space between the deflector and the wool.
-
Page 15: Fan And Thermodisc
FAN AND THERMODISC The 115 volt fan must be screwed at the place provided for this purpose at the back of the appliance. The F120 thermodisc must be fixed beside the junction box in the holes made for the installation. When the appliance is in function, the heat reaching a temperature of 120 °F activates the F120 thermodisc. -
Page 16: L160 And F120 Thermodisc Location
MUST BE INSTALLED BY CERTIFIED INSTALLER To plug the thermostat, unscrew the junction box on the side of the furnace. Join the black wire of the thermostat with another one of the junction box, and then insulate them with a wire nut. Join the white wire of the junction box and another one of the thermostat, and then insulate them with a wire nut. - Page 17 INSTALLATION OF THE APPLIANCE 1- Fix the plenum to the appliance with 12 screws. 2- Fix the trapdoor in front of the furnace, on the rectangular box with 2 screws. 3- Fix the front cover at the front of the furnace with 4 screws.
- Page 18 6- Fix the electrical box, the thermostat junction box, the F120 thermodisc with the 1/2 inch long screws. Verify that no electrical wire touches the hot surface of furnace. 7- Install the chain linking the electrical box with the air intake damper. Just hook the chain of the damper to the hole of the electrical box rod.
- Page 19 8- Follow the next step to attach the wires with the nylon bushings (See the pictures below). 1- Insert the wire in the bushing. 2- Close the bushing 3- Insert the bushing in the hole of the protection plate. WARNING: Be sure that the electrical wire do not touch the appliance. September 13, 2016...
-
Page 20: Direct Vent Door
DIRECT VENT DOOR The appliance is equipped with a direct vent door which gives access to the heat exchanger. When the door is open, the heat accumulated in the heat exchanger directly comes out from there. Even if there is a power outage, the furnace keeps heating the room. -
Page 21: Seating
SEATING You must install a fireproof plate under the appliance, which must exceed it by 18 inches at the front and 8 inches on all other sides. **** Use only non-combustible materials such as ceramics, marble or granite. LIGHTING Now that you have completed the installation of the appliance according to the recommendations, you are ready for the lighting! Place papers and small wood in the appliance. -
Page 22: Air Circulation Of The Heating System
AIR CIRCULATION OF THE HEATING SYSTEM Always refer to the applicable national building code before installing the hot air conduct. It is recommended to FLOOR GRILLE FLOOR GRILLE install floor grilles order to balance the air pressure between floors where appliance is installed and the upper floor. -
Page 23: Combustion Air Supply
COMBUSTION AIR SUPPLY Combustion air supply can be done by either of following methods: Indirect method: In the case of an appliance not certified for a direct connection with a source of new air supply, the new air is brought in a duct at a maximum of 300 mm (12 in) of the appliance, in order not to compromise its operation. -
Page 24: Preventive Measures And Maintenance
PREVENTIVE MEASURES AND MAINTENANCE Verify the accumulation of creosote every week that you use the appliance until you know at which frequency it must be cleaned (minimum once per year). Remove every creosote deposit in order to prevent chimney fires. ... -
Page 25: Interchangeable Parts List
INTERCHANGEABLE PARTS LIST BRICK INTERIOR PIPE GLASS BRICK’ S SUPPORT DOOR HANDLE APPLIANCE’ S DOOR FANS SEALANT CORDS FAN CONTROL MODULE DAMPER MOTOR TRANSFORMATOR THERMOSTAT BUTTERFLY VALVE AIR ENTRY STALK O ORDER PARTS PLEASE CONTACT YOUR AUTHORIZED RETAILER September 13, 2016... -
Page 26: Warranty
J. A. ROBY. Failure of any components which is attributed to poor maintenance, is not warrantable and will not be covered by this policy. J.A. ROBY neither assumes, nor authorizes any third party to assume, on its behalf, any other liabilities with respect to the sale of this product.
