ABBREVIATIONS

2WD

4WD

A/C

ABS

ACC

ALR

AUTO LSD

AVG

CRS

DAC

DISP

ECU

EDR

ELR

EPS

GAWR

GCWR

GVWR

I/M

LATCH

LED

MMT

M+S

MTBE

OBD

RFT

SRS

548

2 Wheel Drive

4 Wheel Drive

Air Conditioning

Anti-lock Brake System

Accessory

Automatic Locking Retractor

Automatic Limited Slip Differential

Average

Child Restraint System

Downhill Assist Control

Display

Electronic Control Unit

Event Data Recorder

Emergency Locking Retractor

Electric Power Steering

Gross Axle Weight Rating

Gross Combination Weight Rating

Gross Vehicle Weight Rating

Emission Inspection and Maintenance

Lower Anchors and Tethers for Children

Light Emitting Diode

Methylcyclopentadienyl Manganese Tricarbonyl

Mud and Snow

Methyl Tertiary Butyl Ether

On Board Diagnostics

Run-Flat Tire

Supplemental Restraint System

MEANING

Table of Contents

Need help?

Do you have a question about the 2012 Rav4 and is the answer not in the manual?

Questions and answers

Jim Dempsey

March 14, 2025

Is there a reset button for low tire pressure on 2012 Toyota Rav4

Summary of Contents for Toyota 2012 Rav4

Page 1 Abbreviation list Abbreviation/Acronym list ABBREVIATIONS MEANING 2 Wheel Drive 4 Wheel Drive Air Conditioning Anti-lock Brake System Accessory Automatic Locking Retractor AUTO LSD Automatic Limited Slip Differential Average Child Restraint System Downhill Assist Control DISP Display Electronic Control Unit Event Data Recorder Emergency Locking Retractor Electric Power Steering GAWR...
Page 2 Abbreviation list ABBREVIATIONS MEANING Tire Identification Number TPMS Tire Pressure Warning System TRAC Traction Control Trailer Weight Rating Vehicle Identification Number Vehicle Stability Control...
Page 3: For Your Information
A wide variety of non-genuine spare parts and accessories for Toyota vehicles are currently available on the market. You should know that these parts are not covered by Toyota warranty and that Toyota is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.
Page 4 ● Anti-lock brake system ● SRS airbag system ● Seat belt pretensioner system Be sure to check with your Toyota dealer for precautionary measures or spe- cial instructions regarding installation of a mobile two-way radio system. Vehicle data recordings Your Toyota is equipped with several sophisticated computers that will record certain data, such as: •...
Page 5 Event data recorder This vehicle is equipped with an event data recorder (EDR). The main pur- pose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems performed.
Page 6 ● Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the lessee for a leased vehicle) is obtained • In response to an official request by the police, a court of law or a govern- ment agency •...
Page 7 CAUTION ■ General precautions while driving Driving under the influence: Never drive your vehicle when under the influ- ence of alcohol or drugs that have impaired your ability to operate your vehi- cle. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordination, which could lead to an accident that could result in death or serious injury.
Page 8 This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.
Page 10 TABLE OF CONTENTS Adjusting and operating features such as door locks, Before driving mirrors, and steering column. When driving Driving, stopping and safe-driving information. Interior Air conditioning and audio systems, as well as other features interior features for a comfortable driving experience. Maintenance Cleaning and protecting your vehicle, performing do-it- and care...
Page 11 1-1. Key information Keys The following keys are provided with the vehicle. Vehicles without smart key system Master keys Operating the wireless remote control function (→P. 40) Valet key Key number plate Vehicles with smart key system Electronic keys • Operating the smart key system (→P.
Page 12 Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a key is lost, a new key can be made by your Toyota dealer using the key number plate. (→P. 488) ■...
Page 13 1-2. Opening, closing and locking the doors ∗ Smart key system The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. (The driver should always carry the electronic key.) Electronic key Electronic key Electronic key Locks and unlocks the doors (→P.
Page 14 1-2. Opening, closing and locking the doors Unlocking and locking the doors and back door (front and back door handles only) Grip the handle to unlock the doors. Make sure to touch the sensor on the back of the handle. The doors cannot be unlocked for 3 seconds after the doors are locked.
Page 15 1-2. Opening, closing and locking the doors Antenna location and effective range ■ Antenna location Antennas outside the cabin Antennas inside the cabin Antenna outside the luggage compartment...
Page 16 1-2. Opening, closing and locking the doors ■ Effective range (areas within which the electronic key is detected) When locking or unlocking the doors The system can be operated when the electronic key is within about 2.3 ft. (0.7 m) of either of the outside front door handles and back door handle.
Page 17 1-2. Opening, closing and locking the doors ■ Operation signals A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice) ■ Conditions affecting operation The smart key system uses weak radio waves. In the following situations, the communication between the electronic key and the vehicle may be affected, preventing the smart key system and wireless remote control from operating properly.
Page 18 1-2. Opening, closing and locking the doors The setting changes each time an operation is performed, as shown below. (When changing the setting continuously, release the buttons, wait for at least 5 seconds, and repeat step 2.) Mode Unlocking doors Beep Hold the driver's door han- dle to unlock only the...
Page 19 1-2. Opening, closing and locking the doors ■ Electronic key battery depletion ● The standard battery life is 1 to 2 years. (The battery becomes depleted even if the electronic key is not used.) If the smart key system or the wireless remote control function does not operate, or the detection area becomes smaller, the battery may be depleted.
Page 20 1-2. Opening, closing and locking the doors ● As long as the electronic key is within the effective range, the doors may be locked or unlocked by anyone. ● Even if the electronic key is not inside the vehicle, it may be possible to start the engine if the electronic key is near the window.
Page 21 1-2. Opening, closing and locking the doors ● When an alarm sounds: Take appropriate measures according to the following table. Alarm Situation Correction procedure Tried to lock the doors Retrieve the elec- Exterior alarm using the entry function tronic key from the sounds once for while the electronic key is passenger compart-...
Page 22 1-2. Opening, closing and locking the doors Alarm Situation Correction procedure Tried to close the driver’s door after carrying the key Shift the shift lever to outside the vehicle with the Interior and exte- P, turn the “ENGINE “ENGINE START STOP” rior alarms sound START STOP”...
Page 23 1-2. Opening, closing and locking the doors ■ Customization that can be configured at Toyota dealer It is possible to deactivate the smart key system etc. (Customizable features →P. 528) ■ Certification for the smart key system For vehicles sold in the U.S.A.
Page 24 (→P. 30) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of emitting the radio waves. Then, consult your doctor to see if you should disable the entry function.
Page 25 1-2. Opening, closing and locking the doors Wireless remote control The wireless remote control can be used to lock and unlock the vehi- cle from outside the vehicle. Vehicles without smart key system Locks all doors Pushing holding: Sounds alarm Unlocks all doors Pressing the button unlocks the driver’s door.
Page 26 1-2. Opening, closing and locking the doors ■ Panic mode Vehicles without smart key system When is pushed for longer than about one second, an alarm will sound for about 60 seconds and the vehicle lights will flash to deter any person from trying to break into or damage your vehicle.
Page 27 When the wireless key has been left near an electrical appliance such as a personal computer Vehicles with smart key system →P. 32 ■ Customization that can be configured at Toyota dealer Settings (e.g. wireless remote control) can be changed. (Customizable features →P. 528)
Page 28 1-2. Opening, closing and locking the doors ■ Certification for wireless remote control (vehicles without smart key system) For vehicles sold in the U.S.A. FCC ID: HYQ12BDC FCC ID: HYQ13BDC NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 29 1-2. Opening, closing and locking the doors Side doors The vehicle can be locked and unlocked using the entry function, wireless remote control, key or door lock switch. ■ Entry function (vehicles with smart key system) →P. 28 ■ Wireless remote control →P.
Page 30 1-2. Opening, closing and locking the doors ■ Door lock switch Locks all doors Unlocks all doors ■ Inside lock button Locks the door Unlocks the door Pulling the door handle can open the front door even if the lock button is in the lock posi- tion.
Page 31 1-2. Opening, closing and locking the doors Locking the front doors from the outside without the wireless remote control or key Move the inside lock button to the lock position. STEP Close the door. STEP Rear door child-protector locks The door cannot be opened from inside the vehicle when the child- protector lock is set.
Page 32 Depending on the position of the electronic key, the key may not be detected correctly and the door may be locked. ■ Customization that can be configured at Toyota dealer Settings (e.g. door unlocking function) can be changed. (Customizable features →P. 528) CAUTION ■...
Page 33 Door lock switch →P. 45 Rear step bumper rear step bumper intended for rear end protection and easier step-up loading. ■ Customization that can be configured at Toyota dealer Settings (e.g. wireless remote control) can be changed. (Customizable features →P. 528)
Page 34 1-2. Opening, closing and locking the doors CAUTION ■ Caution while driving ● Keep the back door closed while driving. If the back door is left open, it may hit near-by objects while driving or lug- gage may be unexpectedly thrown out, causing an accident. In addition, exhaust gases may enter the vehicle, causing death or a seri- ous health hazard.
Page 35 ● Do not attach any accessories other than genuine Toyota parts to the back door. Such additional weight on the back door may interfere with the safety opening and closing operation of the back door.
Page 36 1-2. Opening, closing and locking the doors NOTICE ■ To prevent damage to the back door components Do not allow more than one person to get on the rear step bumper at a time.
Page 37 1-3. Adjustable components (seats, mirrors, steering wheel) Front seats Manual seat Seat position adjustment lever Seatback angle adjustment lever Vertical height adjustment lever (driver’s side only)
Page 38 1-3. Adjustable components (seats, mirrors, steering wheel) Power seat (driver’s side only) Seat position adjustment switch Seatback angle adjustment switch Seat cushion (front) angle adjustment switch Vertical height adjustment switch Seat lumbar support adjust- ment switch...
Page 39 1-3. Adjustable components (seats, mirrors, steering wheel) Flattening front seatbacks The front seats can be moved into a flat seat arrangement. Manual seat STEP Slide the second seats as far back as possible. (→P. 57) STEP Remove the front head restraint. (→P. 68) Slide the front seat further for- STEP ward than the front-most lock...
Page 40 1-3. Adjustable components (seats, mirrors, steering wheel) Power seat STEP Slide the second seats as far back as possible. (→P. 57) STEP Remove the front head restraint. (→P. 68) Push the seat position adjusting STEP switch forward to slide the seat to the front-most position.
Page 41 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Active head restraints Even small forces applied to the seatback may cause the head restraint to move. Pushing up a locked head restraint forcibly may appear the head restraint inner structure. These do not indicate problems. During rear-end collision...
Page 42 1-3. Adjustable components (seats, mirrors, steering wheel) Rear seats ■ Second seats Vehicles with third seat Seat position adjustment levers Seatback angle adjustment levers When a person sits in the rear center position, adjust both seat cushions to the same position and align all seat- backs at the same angle.
Page 43 1-3. Adjustable components (seats, mirrors, steering wheel) Vehicles without third seat Seat position adjustment levers Seatback angle adjustment levers When a person sits in the rear center position, adjust both seat cushions to the same position and align all seat- backs at the same angle.
Page 44 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Third seats (if equipped) The third seats do not have a seat adjustment function. Moving a second seats for third seats entry (vehicles with third seats) ■ Getting in the vehicle (right side only) Pull the lever forward and fold down the seatback.
Page 45 1-3. Adjustable components (seats, mirrors, steering wheel) Folding second seats Folding down the second seats will enlarge the luggage compart- ment. ■ Before folding the second seats STEP Stow the second center seat belt. (→P. 74) Make sure the outside seat belt STEP passes through the hanger when folding the second seat.
Page 46 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Folding second seats STEP Slide the second seats as far back as possible. (→P. 57) From inside Pull down the seatback angle STEP adjustment lever and fold down the seatback. From outside (vehicles without third seats) Open the back door and pull the STEP lock release lever to fold down...
Page 47 1-3. Adjustable components (seats, mirrors, steering wheel) Stowing third seats (vehicles with third seats) ■ Before stowing the third seats Stow the third seat belt buckles. STEP Pass the seat belts through the STEP seat belt hangers. This prevents the shoulder belt from being damaged.
Page 48 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Stowing third seats Pull and hold the seat lock STEP release strap and lift up the seat rearward and then push the seat down. Push the seat on the front side STEP against the floor and push the seat on rear side against the floor.
Page 49 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Returning third seats Pull the seat lock release strap, STEP lift the seat up and move the seat forward. Lock the seat into place. Make sure it is locked securely. Pull the seatback lock release STEP strap and raise the seatback.
Page 50 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ Seat adjustment Observe the following precautions. Failure to do so may result in death or serious injuries. ● The seat belts provide maximum protection in a frontal or rear collision when the driver and the front passenger are sitting up straight and well back in the seats.
Page 51 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ When folding second seats ● Stop the vehicle on level ground, set the parking brake and shift the shift lever to P. ● Do not fold the second seatback when passengers sit or luggage is placed on the seat.
Page 52 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ After adjusting a seat ● After adjusting the seat position, try sliding it forward and backward to make sure it is locked in position. ● After adjusting the seatback, push your body adjust the seatback to make sure it is locked in position.
Page 53 1-3. Adjustable components (seats, mirrors, steering wheel) Head restraints Head restraints are provided for all seats. Front seats Pull the head restraints up. Down Push the head restraint down while pushing the lock release button. Lock release button Second seats Pull the head restraints up.
Page 54 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Removing the head restraints Front seats Pull the head restraint up while pushing the lock release button. Second seats Pull the head restraint up while pushing the lock release button. Third seats (if equipped) Pull the head restraint up while pushing the lock release button.
Page 55 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Installing the head restraints Front seats Align the head restraint with the installa- tion holes and push it down while press- ing the lock release button. Second seats Align the head restraint with the installa- tion holes and push it down while press- ing the lock release button.
Page 56 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Adjusting the height of the head restraints Make sure that the head restraints are adjusted so that the center of the head restraint is closest to the top of your ears. ■ Adjusting the rear seat head restraints (except second outside head restraints) Always raise the head restraint one level from the stowed position when...
Page 57 1-3. Adjustable components (seats, mirrors, steering wheel) Seat belts Make sure that all occupants are wearing their seat belts before driv- ing the vehicle. ■ Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, does come into contact with the...
Page 58 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Adjusting the height of the belt (front seats) Down Move the height adjuster up and down as needed until you hear a click. Second center seat belt The second center seat belt is a 3-point type restraint with 2 buckles. Both seat belt buckles must be correctly located and securely latched for proper operation.
Page 59 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Releasing method The second center seat belt can be completely released only when necessary such as when folding down the second seats. To release the tab “A”, insert the STEP tab “B”, key (vehicles without a smart key system) or mechanical key (vehicles with a smart key system) (→P.
Page 60 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Emergency locking retractor (ELR) The retractor will lock the belt during a sudden stop or on impact. It may also lock if you lean forward too quickly. A slow, easy motion will allow the belt to extend so that you can move around fully.
Page 61 1-3. Adjustable components (seats, mirrors, steering wheel) ■ When not using the outer rear seat belts Second seats Pass the outer rear seat belts through the seat belt hangers and secure the seat belt plates to prevent the shoulder belts from being damaged.
Page 62 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ●...
Page 63 ● Ensure that the belt and tab are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. ● Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there is no obvious damage.
Page 64 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ When using the second center seat belt Do not use the second center seat belt with either buckle released. Fastening only one of the buckles may result in death or serious injury in case of sudden braking or a collision.
Page 65 1-3. Adjustable components (seats, mirrors, steering wheel) Steering wheel The steering wheel can be adjusted to a comfortable position. Hold the steering wheel and STEP press the lever down. Adjust to the ideal position by STEP moving the steering wheel horizontally and vertically.
Page 66 1-3. Adjustable components (seats, mirrors, steering wheel) Anti-glare inside rear view mirror Glare from the headlights of vehicles behind can be reduced by using the following functions. Manual anti-glare inside rear view mirror Normal position Anti-glare position Auto anti-glare inside rear view mirror In automatic mode, sensors are used to detect the headlights of vehicles behind and the reflected light is automatically reduced.
Page 67 1-3. Adjustable components (seats, mirrors, steering wheel) Adjusting the height of rear view mirror Adjust the height of the rear view mirror by moving it up and down. ■ To prevent sensor error (vehicles with auto anti-glare inside rear view mirror) To ensure that the sensors operate prop- erly, do not touch or cover them.
Page 68 1-3. Adjustable components (seats, mirrors, steering wheel) Outside rear view mirrors Vehicles without smart key system Mirror angle can be adjusted using the switch when the engine switch is in the “ACC” or “ON” position. Vehicles with smart key system Mirror angle can be adjusted using the switch when the “ENGINE START STOP”...
Page 69 1-3. Adjustable components (seats, mirrors, steering wheel) Folding back the mirrors Push backward to fold the mir- rors. ■ When the mirrors are fogged up (vehicles with outside rear view mirror defoggers) Turn on the mirror defoggers to defog the mirrors. (→P. 258) CAUTION ■...
Page 70 1-4. Opening and closing the windows and moon roof Power windows The power windows can be opened and closed using the following switches. Closing One-touch closing (driver’s window only) Opening One-touch opening (driver’s window only) Pressing the switch in the opposite direction will stop win- dow travel partway.
Page 71 1-4. Opening and closing the windows and moon roof ■ The power windows can be operated when Vehicles without smart key system The engine switch is in the “ON” position. Vehicles with smart key system The “ENGINE START STOP” switch is in IGNITION ON mode. ■...
Page 72 If you release the switch while the window is moving, start again from the beginning. If the window continues to close but then re-open slightly even after perform- ing the above procedure correctly, have the vehicle inspected by your Toyota dealer.
Page 73 1-4. Opening and closing the windows and moon roof CAUTION ■ Closing the windows Observe the following precautions. Failing to do so may result in death or serious injury. ● Check to make sure that all passengers do not have any part of their body in a position where it could be caught when a window is being operated.
Page 74 1-4. Opening and closing the windows and moon roof ∗ Moon roof Use the overhead switches to open, close, and tilt the moon roof up and down. ■ Opening and closing Open The moon roof stops slightly before the fully open position to reduce wind noise.
Page 75 1-4. Opening and closing the windows and moon roof ■ Operating the moon roof after turning the engine off Vehicles without smart key system The moon roof can be operated for approximately 45 seconds after the engine switch is turned to the “ACC” or “LOCK” position. They cannot, how- ever, be operated once either front door is opened.
Page 76 Check to make sure that the moon roof is completely closed and then release the switch. If the moon roof does not fully close even after performing the above proce- dure correctly, have the vehicle inspected by your Toyota dealer.
Page 77 1-4. Opening and closing the windows and moon roof CAUTION ■ Opening the moon roof Observe the following precautions. Failing to do so may cause death or serious injury. ● Do not allow any passengers to put their hands or heads outside the vehi- cle while it is moving.
Page 78 1-5. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap. ■ Before refueling the vehicle Vehicles without smart key system Turn the engine switch to the “LOCK” position and ensure that all the doors and windows are closed. Vehicles with smart key system Turn the “ENGINE START STOP”...
Page 79 1-5. Refueling Hang the fuel tank cap on the STEP back of the fuel filler door. Closing the fuel tank cap When replacing the fuel tank cap, turn it until a clicking sound is heard. After releasing your hand, the cap will turn slightly to the opposite direction.
Page 80 This may cause static electricity to build up, resulting in a possible ignition hazard. ■ When replacing the fuel cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 81 1-5. Refueling NOTICE ■ Refueling Do not spill fuel during refueling. Doing so may damage the vehicle, such as causing the exhaust systems to operate abnormally or damaging fuel system components or the vehicle's painted surface.
Page 82 1-6. Theft deterrent system Engine immobilizer system The vehicle's keys have built-in transponder chips that prevent the engine from starting if the key has not been previously registered in the vehicle's on-board computer. Never leave the keys inside the vehicle when you leave the vehicle. Vehicles without smart key system: The indicator light flashes after the key has been...
Page 83 1-6. Theft deterrent system ■ System maintenance The vehicle has a maintenance-free type engine immobilizer system. ■ Conditions that may cause the system to malfunction ● If the key is in contact with a metallic object ● If the key is in close proximity to or touching a key to the security system (key with a built-in transponder chip) of another vehicle ■...
Page 84 1-6. Theft deterrent system NOTICE ■ To ensure the system operates correctly Do not modify or remove the system. If modified or removed, the proper operation of the system cannot be guaranteed.
Page 85 1-6. Theft deterrent system Theft prevention labels (U.S.A.) These labels are attached to the vehicle to reduce vehicle theft by facilitating the tracing and recovery of parts from sto- len vehicles. Do not remove under penalty of law.
Page 86 1-7. Safety information Correct driving posture Drive in a good posture as follows: Sit upright and well back in the seat. (→P. 52) Adjust the position of the seat forward or backward to ensure the pedals can be reached easily depressed to the extent required.
Page 87 1-7. Safety information CAUTION ■ While driving ● Do not adjust the position of the driver's seat while driving. Doing so could cause the driver to lose control of the vehicle. ● Do not place a cushion between the driver or passenger and the seatback. A cushion may prevent correct posture from being achieved, and reduce the effectiveness of the seat belt and head restraint, increasing the risk of death or serious injury to the driver or passenger.
Page 88 1-7. Safety information SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. Front airbags Driver airbag/front passenger airbag Can help protect the head and chest of the driver and front pas-...
Page 89 1-7. Safety information Airbag system components Curtain shield airbags SRS warning light Side airbags Driver airbag Front passenger airbag Driver’s seat position sen- Side and curtain shield air- bag sensors Driver’s seat belt buckle switch Front airbag sensors Airbag sensor assembly Front passenger’s seat belt buckle switch Front passenger occupant...
Page 90 1-7. Safety information Your vehicle is equipped with ADVANCED AIRBAGS designed based on the US motor vehicle safety standards (FMVSS208). The airbag sensor assembly (ECU) controls airbag deployment based on infor- mation obtained from the sensors etc. shown in the system compo- nents diagram above.
Page 91 1-7. Safety information ■ SRS airbag deployment conditions Front airbags ● The SRS front airbags will deploy in the event of an impact that exceeds the set threshold level (the level of force corresponding to an approxi- mately 12 - 18 mph [20 - 30 km/h] frontal collision with a fixed wall that does not move or deform).
Page 92 1-7. Safety information ■ Conditions under which the SRS airbags may deploy (inflate), other than a collision The SRS front airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration. ●...
Page 93 1-7. Safety information ■ Types of collisions that may not deploy the SRS side airbags and cur- tain shield airbags The SRS side airbag and curtain shield airbag system may not activate if the vehicle is subjected to a collision from the side at certain angles, or a colli- sion to the side of the vehicle body other than the passenger compartment.
Page 94 1-7. Safety information ■ When to contact your Toyota dealer In the following cases, contact your Toyota dealer as soon as possible. ● Any of the SRS airbags have been inflated. ● The front of the vehicle is damaged or...
Page 95 1-7. Safety information CAUTION ■ SRS airbag precautions Observe the following precautions regarding the airbags. Failure to do so may cause death or serious injury. ● The driver and all passengers in the vehicle must wear their seat belts properly. The SRS airbags are supplemental devices to be used with the seat belts.
Page 96 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are...
Page 97 1-7. Safety information CAUTION ■ SRS airbag precautions ● Do not sit on the edge of the seat or lean against the dashboard. ● Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger.
Page 98 1-7. Safety information CAUTION ■ SRS airbag precautions ● Do not attach anything to or lean any- thing against areas such as the dash- board or steering wheel pad. These items can become projectiles when SRS driver and front passenger airbags deploy.
Page 99 If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillar garnishes, are damaged or cracked, have them replaced by your Toyota dealer. ■ Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer.
Page 100 1-7. Safety information Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classifica- tion system. This system detects the conditions of the front passen- ger seat and activates or deactivates the devices for front passenger. SRS warning light Front passenger's seat belt reminder light “AIR BAG OFF”...
Page 101 1-7. Safety information Conditions and operation of the front passenger occupant classification system ■ Adult* “AIR BAG ON” and “AIR BAG OFF” “AIR BAG indicator lights ON” Indicator/ SRS warning light warning light Front passenger's seat belt reminder Flashing* light Front passenger airbag Side airbag on the front passenger seat Devices...
Page 102 1-7. Safety information ■ Unoccupied “AIR BAG ON” and “AIR BAG OFF” Not illumi- indicator lights nated Indicator/ SRS warning light warning light Front passenger's seat belt reminder light Front passenger airbag Deactivated Side airbag on the front passenger seat Devices Curtain shield airbag in the front Activated...
Page 103 1-7. Safety information : Never install a rear-facing child restraint system on the front pas- senger seat. A forward-facing child restraint system should only be installed on the front passenger seat when it is unavoidable. (→P. 122) : In case the indicator is not illuminated, consult this manual as for installing the child restraint system properly.
Page 104 1-7. Safety information CAUTION ■ Front passenger occupant classification system precautions Observe the following precautions regarding front passenger occupant clas- sification system. Failure to do so may cause death or serious injury. ● Wear the seat belt properly. ● Make sure the front passenger's seat belt tab has not been left inserted into the buckle before someone sits in the front passenger seat.
Page 105 Do not kick the front passenger seat or subject it to severe impact. Other- wise, the SRS warning light may come on to indicate a malfunction of the detection system. In this case, contact your Toyota dealer immediately. ● Child restraint systems installed on the second seat should not contact the front seatbacks.
Page 106 1-7. Safety information Child restraint systems A child restraint system for a small child or baby must itself be prop- erly restrained on the seat with the lap portion of the lap/shoulder belt. The laws of all 50 states of the U.S.A. and Canada now require the use of child restraint systems.
Page 107 1-7. Safety information Types of child restraint Child restraint systems are classified into the following 3 types according to the age and size of the child. Rear facing ⎯ Infant seat/convertible seat Forward facing ⎯ Convertible seat Booster seat...
Page 108 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 109 1-7. Safety information CAUTION ■ Child restraint precautions ● Do not use the seat belt extender when installing a child restraint system on the front or rear passenger seat. If installing a child restraint system with the seat belt extender connected to the seat belt, the seat belt will not securely hold the child restraint system, which could cause death or seri- ous injury to the child or other passengers in the event of a sudden stop, sudden swerve or accident.
Page 110 1-7. Safety information Installing child restraints Follow the child restraint system manufacturer's instructions. Firmly secure child restraints to the outside rear seats using the LATCH anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compatible with the LATCH (Lower Anchors and Tethers for Chil- dren) system.
Page 111 1-7. Safety information Second outside seats: Anchor brackets (for top tether strap) Anchor brackets are provided for the second outside seats. Second center seat: Anchor brackets (for top tether strap) An anchor bracket is provided for the second center seat.
Page 112 1-7. Safety information Installation with LATCH system (second outside seats only) Fold the seatback while pulling STEP the lever. Return the seatback and secure it at the 1st lock posi- tion (most upright position). Adjust the seatback to the 7th lock position.
Page 113 1-7. Safety information Type B Latch the buckles onto the STEP LATCH anchors. The bars are installed in the clearance between the seat cush- ion and seatback. If the child restraint has a top tether strap, the top tether strap should be latched onto the top tether strap anchor.
Page 114 1-7. Safety information Installing child restraints using a seat belt (child restraint lock function belt) Rear facing ⎯ Infant seat/convertible seat ■ Place the child seat on the rear STEP seat facing the rear of the vehi- cle. Run the seat belt through the STEP child seat and insert the plate into the buckle.
Page 115 1-7. Safety information While pushing the child seat STEP down into the rear seat, allow the shoulder belt to retract until the child seat is securely in place. After shoulder belt retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
Page 116 1-7. Safety information While pushing the child seat into STEP the rear seat, allow the shoulder belt to retract until the child seat is securely in place. After shoulder belt retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
Page 117 1-7. Safety information Removing a child restraint installed with a seat belt Push the buckle release button and fully retract the seat belt. Child restraint systems with a top tether strap (second seats only) ■ Outside seats Remove the head restraint. STEP Slide the seats forward slightly if STEP...
Page 118 1-7. Safety information Secure the child restraint using STEP Front of vehicle the seat belt. Latch the hook onto the anchor bracket and tighten the top tether strap. Make sure the top tether strap is securely latched. Replace the head restraint. STEP Move the seats to the rear-most STEP...
Page 119 1-7. Safety information ■ Center seat Open the anchor bracket cover. Secure the child restraint using the seat belt. Latch the hook onto the anchor bracket and tighten the top tether strap. Make sure the top tether strap is securely latched. ■...
Page 120 1-7. Safety information CAUTION ■ When installing a booster seat Do not fully extend the shoulder belt to prevent the belt from going to ALR lock mode. (→P. 75) ALR mode causes the belt to tighten only which could cause injury or dis- comfort to the child.
Page 121 1-7. Safety information CAUTION ■ When installing a child restraint system ● When installing a child restraint system in the rear center seat, adjust both seat cushions to the same position and align seatbacks at the same angle. Otherwise, the child restraint system cannot be securely restrained and this may cause death or serious injuries in the event of sudden braking, sudden swerving or an accident.
Page 122 2-1. Driving procedures Driving the vehicle The following procedures should be observed to ensure safe driv- ing. ■ Starting the engine →P. 147, 151 ■ Driving STEP With the brake pedal depressed, shift the shift lever to D. (→P. 154) STEP Release the parking brake.
Page 123 The vehicle is judged to be driving uphill or downhill ● When the accelerator pedal is released ■ Breaking in your new Toyota To extend the life of the vehicle, the following precautions are recommended to observe: ● For the first 200 miles (300 km): Avoid sudden stops.
Page 124 Your vehicle has a drum-in-disc type parking brake system. This type of brake system needs bedding-down of the brake shoes periodi- cally or whenever the parking brake shoes and/or drums are replaced. Have your Toyota dealer perform the bedding-down. ■ Operating your vehicle in a foreign country Comply with the relevant vehicle registration laws and confirm the availability of the correct fuel.
Page 125 Large amounts of exhaust in the vehi- cle can cause driver drowsiness and an accident, resulting in death or a serious health hazard. Have the vehicle inspected by your Toyota dealer immediately. ●...
Page 126 2-1. Driving procedures CAUTION ● Do not drive the vehicle off-road. This vehicle is not designed for real off-road driving. Proceed with all due caution if it becomes unavoidable to drive off-road. ● Do not drive across river crossings or through other bodies of water. This may cause electric/electronic components to short circuit, damage the engine or cause other serious damage to the vehicle.
Page 127 2-1. Driving procedures CAUTION ● In order to prevent accidents due to the vehicle rolling away, always keep depressing the brake pedal while the engine is running, and apply the parking brake as necessary. ● If the vehicle is stopped on an incline, in order to prevent accidents caused by the vehicle rolling forward or backward, always depress the brake pedal and securely apply the parking brake as needed.
Page 128 The exhaust should be checked occasionally. If there is a hole or crack caused by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle inspected and repaired by your Toyota dealer. Failure to do so may allow exhaust gases to enter the vehicle, resulting in death or a serious health hazard.
Page 129 2-1. Driving procedures CAUTION ● The brake system consists of 2 individual hydraulic systems: If one of the systems fails, the other will still operate. In this case, the brake pedal should be depressed more firmly than usual and braking distance becomes longer.
Page 130 If you hear a squealing or scraping noise (brake pad wear limit indica- tors) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. The rotor damage can result if the pads are not replaced when needed.
Page 131 2-1. Driving procedures Engine (ignition) switch (vehicles with smart key system) Performing the following operations when carrying the electronic key on your person starts the engine or changes “ENGINE START STOP” switch modes. ■ Starting the engine The engine can be started in any mode by operating the “ENGINE START STOP”...
Page 132 2-1. Driving procedures ■ Changing “ENGINE START STOP” switch mode Modes can be changed by pressing the “ENGINE START STOP” switch with the brake pedal released. (The mode changes each time the switch is pressed.) OFF* The emergency flashers can be used.
Page 133 ■ When the “ENGINE START STOP” switch indicator flashes in amber The system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. ■ Auto power off function If the vehicle is left in ACCESSORY mode for more than an hour with the shift lever in P, the “ENGINE START STOP”...
Page 134 2-1. Driving procedures CAUTION ■ When starting the engine Always start the engine while sitting in the driver's seat. Do not depress the accelerator pedal while starting the engine under any circumstances. Doing so may cause an accident resulting in death or serious injury. ■...
Page 135 2-1. Driving procedures Engine (ignition) switch (vehicles without smart key system) ■ Starting the engine STEP Check that the parking brake is set. STEP Check that the shift lever is set in P. STEP Sit in the driver’s seat and firmly depress the brake pedal. STEP Turn the engine switch to the “START”...
Page 136 2-1. Driving procedures ■ Turning the key from “ACC” to “LOCK” STEP Shift the shift lever to P. (→P. 154) STEP Push in the key and turn to the “LOCK” position. ■ Steering lock release When starting the engine, the engine switch may seem stuck in the “LOCK”...
Page 137 2-1. Driving procedures NOTICE ■ To prevent battery discharge Do not leave the key in the “ACC” or “ON” position for a long period if the engine is not running. ■ When starting the engine ● Do not crank for more than 30 seconds at a time. This may overheat the starter and wiring systems.
Page 138 2-1. Driving procedures Automatic transmission Select a shift position appropriate for the driving conditions. ■ Shifting the shift lever 4-speed models 5-speed models...
Page 139 2-1. Driving procedures Vehicles without smart key system: While the engine switch is in the “ON” position, depress the brake pedal and move the shift lever. Vehicles with smart key system: While the “ENGINE START STOP” switch is in IGNITION ON mode, depress the brake pedal and move the shift lever.
Page 140 2-1. Driving procedures ■ Downshifting restrictions The shift lever cannot be downshifted if the following speeds are exceeded. 4-speed models (2WD) mph (km/h) Downshifting Maximum speed 3 → 2 75 (121) 2 → L 37 (60) 4-speed models (4WD) mph (km/h) Downshifting Maximum speed 3 →...
Page 141 2-1. Driving procedures ■ When driving with cruise control activated 4-speed models Even when performing the following actions with the intent of enabling engine braking, engine braking will not activate while downshifting to 3 because cruise control will not be canceled. (→P. 182) 5-speed models Even when performing the following actions with the intent of enabling engine braking, engine braking will not activate while downshifting to 4...
Page 142 2-1. Driving procedures Turn signal lever Right turn Left turn Move and hold the lever partway to signal a lane change. The right hand signal will flash until you release the lever. Move and hold the lever partway to signal a lane change.
Page 143 2-1. Driving procedures Parking brake Canada U.S.A. Sets the parking brake Fully apply the parking brake while depressing the brake pedal. Releases the parking brake Slightly raise the lever and lower it completely while pressing the but- ton. ■ Usage in winter time See “Winter driving tips”...
Page 144 2-1. Driving procedures Horn To sound the horn, press on or close to the mark. ■ After adjusting the steering wheel Make sure that the steering wheel is securely locked. The horn may not sound if the steering wheel is not securely locked. (→P.
Page 145 2-2. Instrument cluster Gauges and meters Vehicles without smart key system The following gauges, meters and displays illuminate when the engine switch is in the “ON” position. Vehicles with smart key system The following gauges, meters and displays illuminate when the “ENGINE START STOP”...
Page 146 2-2. Instrument cluster Trip information display →P. 167 Automatic transmission shift position indicator lights →P. 154 Odometer/trip meter Odometer Displays the total distance the vehicle has been driven. Trip meter Displays the distance the vehicle has been driven since the meter was last reset.
Page 147 2-2. Instrument cluster NOTICE ■ To prevent damage to the engine and its components ● Do not let the indicator needle of the tachometer enter the red zone, which indicates the maximum engine speed. ● The engine may be overheating if the temperature gauge is in the red zone (H).
Page 148 2-2. Instrument cluster Indicators and warning lights The indicator and warning lights on the instrument cluster and cen- ter panel inform the driver of the status of the vehicle’s various sys- tems. ■ Instrument cluster ■ Center panel...
Page 149 They will turn off after the engine is started, or after a few seconds. There may be a malfunction in a system if a light does not come on, or if the lights do not turn off. Have the vehicle inspected by your Toyota dealer for details.
Page 150 Have the vehicle inspected by your Toyota dealer immediately if this occurs.
Page 151 2-2. Instrument cluster Trip information display The trip information display presents the driver with a variety of driv- ing-related data, including the current outside temperature. Trip information (→P. 168) Displays outside temperature and fuel consumption.
Page 152 2-2. Instrument cluster Trip information Without Display Audio system Push the “DISP” button to dis- play trip information. Display items can be switched by pressing the “DISP” button. With Display Audio system Push the “DISP” button to dis- play trip information. Display items can be switched by pressing the “DISP”...
Page 153 2-2. Instrument cluster ■ Average fuel consumption Displays the average fuel consumption since the function was reset. • To reset the calculations, return the mode to “AVG” and push and hold the “DISP” button until the display shows “0”. • Use the displayed average fuel consumption as a reference.
Page 154 2-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. Type A Vehicles with day- time running light system: The daytime running lights turn side marker, parking, tail, license plate, daytime run- ning lights instrument panel lights turn on.
Page 155 2-3. Operating the lights and wipers Type B Vehicles with day- time running light system: The daytime running lights turn side marker, parking, tail, license plate, daytime run- ning lights instrument panel lights turn on. The headlights and all lights listed above (except daytime run- ning lights) turn on.
Page 156 2-3. Operating the lights and wipers Turning on the high beam headlights With the headlights on, push the lever forward to turn on the high beams. Pull the lever back to the center position to turn the high beams off. Pull the lever toward you to turn on the high beams.
Page 157 To turn the lights on again, turn the “ENGINE START STOP” switch to IGNI- TION ON mode, or turn the headlight switch off and then back to ■ Customization that can be configured at Toyota dealer Settings (e.g. light sensor sensitivity) can be deactivated. (Customizable features →P. 528) NOTICE ■...
Page 158 2-3. Operating the lights and wipers ∗ Fog light switch The fog lights improve visibility in difficult driving conditions, such as in rain or fog. They can be turned on only when the headlights are on low beam. Type A Front fog lights on ∗...
Page 159 2-3. Operating the lights and wipers Type B Front fog lights on...
Page 160 2-3. Operating the lights and wipers Windshield wipers and washer Wiper intervals can be adjusted for intermittent operation. Type A Intermittent wind- shield wiper opera- tion speed wind- shield wiper opera- tion High speed wind- shield wiper opera- tion Temporary operation Increases the intermittent windshield wiper frequency Decreases the intermittent...
Page 161 2-3. Operating the lights and wipers Wash/wipe operation The wipers will automatically operate a couple of times after the washer squirts. (After operating several times, the wipers operate one more time after a short delay to pre- vent dripping.) Type B Intermittent wind- shield wiper opera-...
Page 162 2-3. Operating the lights and wipers Increases the intermittent windshield wiper frequency Decreases the intermittent windshield wiper frequency Wash/wipe operation The wipers will automatically operate a couple of times after the washer squirts. (After operating several times, the wipers operate one more time after a short delay to pre- vent dripping.) ■...
Page 163 2-3. Operating the lights and wipers NOTICE ■ When the windshield is dry Do not use the wipers, as they may damage the windshield. ■ When there is no washer fluid spray from the nozzle Damage to the washer fluid pump may be caused if the lever is pulled toward you and held continually.
Page 164 2-3. Operating the lights and wipers Rear window wiper and washer Type A Intermittent window wiper operation Normal window wiper operation Washer/wiper dual operation Washer/wiper dual operation...
Page 165 2-3. Operating the lights and wipers Type B Intermittent window wiper operation Normal window wiper operation Washer/wiper dual operation Washer/wiper dual operation ■ The rear window wiper and washer can be operated when Vehicles without smart key system The engine switch is in the “ON” position. Vehicles with smart key system The “ENGINE START STOP”...
Page 166 2-4. Using other driving systems Cruise control Use the cruise control to maintain a set speed without depressing the accelerator pedal. Indicator Cruise control switch ■ Setting the vehicle speed Press the “ON-OFF” button to STEP activate the cruise control. Cruise control indicator will come on.
Page 167 2-4. Using other driving systems ■ Adjusting the set speed To change the set speed, operate the lever until the desired set speed is obtained. Increase the speed Decrease the speed Hold the lever until the desired speed setting is obtained. Fine adjustment: Momentarily move the lever in the desired direction.
Page 168 If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer.
Page 169 2-4. Using other driving systems CAUTION ■ To avoid operating the cruise control by mistake Switch the cruise control off using the “ON-OFF” button when not in use. ■ Situations unsuitable for cruise control Do not use cruise control in any of the following situations. Doing so may result in loss of control and could cause an accident resulting in death or serious injury.
Page 170 2-4. Using other driving systems Rear view monitor system (vehicles with auto anti-glare inside rear view mirror) The rear view monitor system assists the driver by displaying an image of the area behind the vehicle. The image is displayed in reverse on the screen.
Page 171 2-4. Using other driving systems ■ The rear view monitor system can be operated when Vehicles without smart key system The shift lever is in R, the back door is fully closed and the engine switch is in the “ON” position. Vehicles with smart key system The shift lever is in R, the back door is fully closed and the “ENGINE START STOP”...
Page 172 2-4. Using other driving systems ● To constantly disable the rear view monitor system Push and hold the “AUTO” button for 12 to 15 seconds. The screen will turn off and on after 6 seconds. Keep pushing the button until the screen turns back off.
Page 173 2-4. Using other driving systems ■ Displayed area Vehicles without spare tire The area covered by the camera is lim- ited. Objects that are close to either corner of the bumper or under the bumper cannot be seen on the screen. The area displayed on the screen may vary according to vehicle orientation or road conditions.
Page 174 2-4. Using other driving systems ■ Rear view monitor system camera Vehicles without spare tire In the following cases, it may become difficult to see images on the screen even if the system functions correctly. ● The vehicle is in a dark area, such as at night.
Page 175 2-4. Using other driving systems Vehicles with spare tire In the following cases, it may become difficult to see images on the screen even if the system functions correctly. ● The vehicle is in a dark area, such as at night. ●...
Page 176 2-4. Using other driving systems ■ Smear effect If a bright light, such as sunlight reflected off the vehicle body, is picked up by the camera, a smear effect* char- acteristic to the camera may occur. *: Smear effect: A phenomenon that occurs when a bright light is picked up by the camera;...
Page 177 If the camera lens is extremely dirty, wash with a mild cleanser and rinse. ● When replacing tires, please consult your Toyota dealer. If you replace the tires, the area displayed on the screen may change. NOTICE ■...
Page 178 2-4. Using other driving systems Driving assist systems To help enhance driving safety and performance, the following sys- tems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle. ■...
Page 179 2-4. Using other driving systems ■ Enhanced VSC (Enhanced Vehicle Stability Control) Provides cooperative control of the ABS, TRC, VSC and EPS. Helps to maintain directional stability when swerving on slippery road surface by controlling steering performance. ■ Hill-start assist control (if equipped) →P.
Page 180 2-4. Using other driving systems To disable TRAC and/or VSC (2WD models) If the vehicle gets stuck in fresh snow or mud, TRAC and VSC may reduce power from the engine to the wheels. You may need to turn the system off to enable you to rock the vehicle in order to free it. The AUTO LSD function is activated when the system is in TRAC off mode.
Page 181 2-4. Using other driving systems To disable TRAC and/or VSC (4WD models) If the vehicle gets stuck in fresh snow or mud, TRAC and VSC may reduce power from the engine to the wheels. You may need to turn the system off to enable you to rock the vehicle in order to free it. ■...
Page 182 When the “AUTO LSD” indicator light flashes even if the VSC OFF switch has not been pressed (2WD models) TRAC, AUTO LSD, hill-start assist control and downhill assist control cannot be operated. Contact your Toyota dealer. ■ When the “TRAC OFF” indicator light comes on even if the VSC OFF...
Page 183 The EPS system should return to normal within 10 minutes. ■ If the slip indicator comes on It may indicate a malfunction in the VSC, TRAC and AUTO LSD function. Contact your Toyota dealer. CAUTION ■ The ABS does not operate effectively when ●...
Page 184 The ABS and VSC systems will not function correctly if different tires are fit- ted on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. ■ Handling of tires and suspension Using tires with any kind of problem or modifying the suspension will affect the driving assist systems, and may cause the system to malfunction.
Page 185 2-4. Using other driving systems ∗ Hill-start assist control Hill-start assist control helps to prevent the vehicle from rolling backwards when starting on an incline or slippery slope. To engage hill-start assist con- trol, further depress the brake pedal when the vehicle is stopped completely.
Page 186 Use the slip indicator status (flashing or off) to confirm if hill-start assist control is operating. ■ If the slip indicator comes on It may indicate a malfunction in the system. Contact your Toyota dealer. CAUTION ■ Hill-start assist control ●...
Page 187 2-4. Using other driving systems ∗ Downhill assist control system With the downhill assist control system, the vehicle is able to descend a steep hill while maintaining a constant low speed of about 3 mph (5 km/h) without brake pedal operation. ■...
Page 188 Refrain from using the system until the downhill assist control system indicator stays on. (There is no problem with continuing driving normally.) ■ If the slip indicator comes on It may indicate a malfunction in the system. Contact your Toyota dealer.
Page 189 2-4. Using other driving systems CAUTION ■ Conditions which may affect the downhill assist control system opera- tion ● Do not rely too heavily on the downhill assist control system. On extremely steep inclines, icy surfaces or muddy roads, the vehicle may slip and the system may not be able to maintain the constant low vehicle speed of about 3 mph (5 km/h), leading to an accident causing death or serious injury.
Page 190 2-4. Using other driving systems Four-wheel drive lock switch (4WD models) Four-wheel drive lock mode can be used when a large amount of drive power needs to be applied to all the wheels, such as when the vehicle gets stuck in mud and you need to free it. Press the switch.
Page 191 2-5. Driving information Utility vehicle precautions This vehicle belongs to the utility vehicle class, which has higher ground clearance and narrower tread in relation to the height of its center of gravity to make it capable of performing in a wide variety of off-road applications.
Page 192 2-5. Driving information CAUTION ■ Off-road vehicle precautions Always observe the following precautions to minimize the risk of serious per- sonal injury or damage to your vehicle: ● In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a seat belt.
Page 193 2-5. Driving information Off-road driving When driving your vehicle off-road, please observe the following pre- cautions to ensure your driving enjoyment and to help prevent the closure of areas to off-road vehicles. ● Drive your vehicle only in areas where off-road vehicles are permit- ted to travel.
Page 194 2-5. Driving information CAUTION ■ Off-road driving precautions Always observe the following precautions to minimize the risk of death or serious personal injury or damage to your vehicle: ● Drive carefully when off the road. Do not take unnecessary risks by driving in dangerous places.
Page 195 2-5. Driving information NOTICE ■ When you drive through water If driving through water, such as when crossing shallow streams, first check the depth of the water and the bottom of the stream for firmness. Drive slowly and avoid deep water. ■...
Page 196 2-5. Driving information Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load. ● Stow cargo and luggage in the luggage compartment whenever possible. Be sure all items are secured in place. ● Be careful to keep the vehicle level. Placing the weight as far for- ward as possible helps maintain vehicle balance.
Page 197 2-5. Driving information Slide the cross rails to the appro- STEP priate position for loading lug- gage turn knobs clockwise to tighten the cross rails securely. Capacity and distribution Cargo capacity depends on the total weight of the occupants. (Cargo capacity) = (Total load capacity) - (Total weight of occupants) Steps for Determining Correct Load Limit⎯...
Page 198 2-5. Driving information (6)If your vehicle will be towing a trailer, load from your trailer will be transferred to your vehicle. Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. Example on your vehicle Cargo capacity Total load capacity When 2 people with the combined weight of 366 lb.
Page 199 2-5. Driving information As shown in the above example, if the number of occupants increases, the cargo and luggage load will be reduced by an amount that equals the increased weight due to the additional occupants. In other words, if an increase in the number of occupants causes an excess of the total load capacity (combined weight of occupants plus cargo and luggage load), you must reduce the cargo and luggage on your vehicle.
Page 200 2-5. Driving information CAUTION ■ Capacity and distribution ● Do not exceed the maximum axle weight rating or the total vehicle weight rating. ● Even if the total load of occupant's weight and the cargo load is less than the total load capacity, do not apply the load unevenly. Improper loading may cause deterioration of steering or braking con- trol which may cause death or serious injury.
Page 201 2-5. Driving information NOTICE ■ When loading luggage (vehicles with moon roof) Be careful not to scratch the surface of the moon roof.
Page 202 2-5. Driving information Vehicle load limits Vehicle load limits include total load capacity, seating capacity, towing capacity and cargo capacity. ■ Total load capacity: Without third seat 825 lb. (375 kg) With third seat 1155 lb. (525 kg) Total load capacity means the combined weight of occupants, cargo and luggage.
Page 203 2-5. Driving information CAUTION ■ Overloading the vehicle Do not overload the vehicle. It may not only cause damage to the tires, but also degrade steering and braking ability, resulting in an accident.
Page 204 2-5. Driving information Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a manner appropri- ate to the prevailing weather conditions. ■ Pre-winter preparations ● Use fluids that are appropriate to the prevailing outside tem- peratures.
Page 205 2-5. Driving information ■ When driving the vehicle Accelerate the vehicle slowly and drive at a reduced speed suit- able to road conditions. ■ When parking the vehicle Park the vehicle and move the shift lever to P without setting the parking brake.
Page 206 2-5. Driving information ■ Tire chain installation Observe the following precautions when installing and removing chains. ● Install and remove tire chains in a safe location. ● Install tire chains on the front tires. ● Install tire chains following the instructions provided in the accompanying manual.
Page 207 Vehicles with a tire pressure warning system: ■ Repairing or replacing snow tires Request repairs of and obtain replacement snow tires from Toyota dealers or legitimate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
Page 208 To tow a trailer safely, use extreme care and drive the vehicle in accordance with your trailer’s characteristics and operating condi- tions. Toyota warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. Contact your Toyota dealer for further information about additional...
Page 209 2-5. Driving information Towing related terms ■ GCWR (Gross Combination Weight Rating) The maximum allowable gross combination weight. The gross combination weight is the sum of the total vehicle weight (including the occupants, cargo and any optional equipment installed on the vehicle) and the weight of the trailer being towed (including the cargo in the trailer).
Page 210 2-5. Driving information ■ GAWR (Gross Axle Weight Rating) The maximum allowable gross Front GAWR axle weight. The gross axle weight is the load placed on each axle (front and rear). Rear GAWR ■ TWR (Trailer Weight Rating) The maximum allowable gross (With brakes) trailer weight.
Page 211 2-5. Driving information ■ Unbraked TWR (Unbraked Trailer Weight Rating) The trailer weight rating for tow- (Without brakes) ing a trailer without a trailer ser- vice brake system. ■ Tongue Weight The load placed on the trailer hitch ball. (→P. 230)
Page 212 2-5. Driving information Weight limits ● The gross trailer weight must never exceed the TWR described in the table. (→P. 229) ● The gross combination weight must never exceed the GCWR described in the table. (→P. 229) ● The gross vehicle weight must never exceed the GVWR indi- cated Certification...
Page 213 2-5. Driving information GCWR, TWR and Unbraked TWR Confirm that the gross trailer weight, gross combination weight, gross vehicle weight, gross axle weight and tongue weight are all within the limits. ■ GCWR and TWR Driving Trailer Weight Engine GCWR system Rating 5350 lb.
Page 214 2-5. Driving information Trailer Tongue Weight ● A recommended tongue weight varies in accordance with the types of trailers or towing as described below. ● To ensure the recommended values shown below, the trailer must be loaded by referring to the following instructions. •...
Page 215: Hitch
Toyota hitch/bracket for your vehicle. For details, contact your Toyota dealer. ● If you wish to install a trailer hitch, contact your Toyota dealer. ● Use only a hitch that conforms to the gross trailer weight require- ment of your vehicle.
Page 216 2-5. Driving information Selecting trailer ball Use the correct trailer ball for your application. Trailer ball load rating Matches or exceeds the gross trailer weight rating of the trailer. Ball diameter Matches the size of the trailer coupler. Most couplers stamped with the required trailer ball size.
Page 217 2-5. Driving information Positions for towing hitch receiver and hitch ball Weight carrying ball position: 41.4 in. (1051.1 mm) Hitch receiver pin hole posi- tion: 32.4 in. (821.8 mm) Connecting trailer lights Please consult your dealer when installing trailer lights, as incorrect installation may cause damage to the vehicle’s lights.
Page 218 ● Speed limits for towing a trailer vary by state or province. Do not exceed the posted towing speed limit. ● Toyota recommends that the vehicle-trailer speed limit is 65 mph (104 km/h) on a flat, straight, dry road. Do not exceed this limit, the posted towing speed limit or the speed limit for your trailer as set forth in your trailer owner’s manual, whichever is lowest.
Page 219 2-5. Driving information ● Avoid jerky starts or sudden acceleration. ● Avoid jerky steering and sharp turns, and slow down before mak- ing turn. ● Note that when making a turn, the trailer wheels will be closer than the vehicle wheels to the inside of the turn. Compensate by making a wider than normal turning radius.
Page 220 2-5. Driving information ● Always place wheel blocks under both the vehicle’s and the trailer’s wheels when parking. Apply the parking brake firmly, and put the transmission in P. Avoid parking on a slope, but if unavoid- able, do so only after performing the following: STEP Apply the brakes and keep them applied.
Page 221 2-5. Driving information ■ Matching trailer ball height to trailer coupler height No matter which class of tow hitch applies, for a more safe trailer hookup, the trailer ball setup must be the proper height for the coupler on the trailer. Coupler Trailer ball ■...
Page 222 Break-in schedule If your vehicle is new or equipped with any new power train components (such as an engine, transmission, differential or wheel bearing), Toyota rec- ommends that you do not tow a trailer until the vehicle has been driven for over 500 miles (800 km).
Page 223 2-5. Driving information ● After the trailer swaying has stopped: • Stop in a safe place. Get all occupants out of the vehicle. • Check the tires of the vehicle and the trailer. • Check the load in the trailer. Make sure the load has not shifted.
Page 224 2-5. Driving information CAUTION ● Do not apply the brakes suddenly as you may skid, resulting in jackknifing and loss of vehicle control. This is especially true on wet or slippery sur- faces. ● Do not exceed the trailer hitch assembly weight, gross vehicle weight, gross axle weight and trailer tongue weight capacities.
Page 225 NOTICE ■ When installing a trailer hitch Use only the position recommended by your Toyota dealer. Do not install the trailer hitch on the bumper; this may cause body damage. ■ Do not directly splice trailer lights Do not directly splice trailer lights.
Page 226 2-5. Driving information Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE ■ To avoid serious damage to your vehicle Do not tow your vehicle with 4 wheels on the ground.
Page 227 3-1. Using the air conditioning system and defogger ∗ Manual air conditioning system Air outlet selection dial Temperature control dial Outside air or recirculated air mode Air conditioning on/off switch Fan speed control dial Adjusting the settings ■ Adjusting the temperature setting Turn the temperature control dial clockwise (warm) or counter- clockwise (cool).
Page 228 3-1. Using the air conditioning system and defogger ■ Changing the air outlets Set the air outlet selection dial to an appropriate position. The positions between the air outlet selections shown below can be also selected for more detailed adjustment. Air flows to the upper body.
Page 229 3-1. Using the air conditioning system and defogger Air flows to the feet and the windshield defogger operates. The air intake is automatically switched to outside air mode. It is not possible to return to recircu- lated air mode when the dial is set at this position.
Page 230 3-1. Using the air conditioning system and defogger Adjusting the position of the air outlets Front outlets (center) Direct air flow to the left or right, up or down. Front outlets (right and left sides) Direct air flow to the left or right, up or down.
Page 231 There may be a problem in the air conditioning system if the indicator light keeps flashing. Turn the air conditioning system off and have it inspected by your Toyota dealer. ■ When...
Page 232 3-1. Using the air conditioning system and defogger NOTICE ■ To prevent battery discharge Do not leave the air conditioning system on longer than necessary when the engine is off.
Page 233 3-1. Using the air conditioning system and defogger ∗ Automatic air conditioning system Airflow and outlets are automatically adjusted according to the tem- perature setting. Driver's side Changes the air outlets used temperature control Air flow display Outside air or recirculated air mode Air conditioning on/off switch...
Page 234 3-1. Using the air conditioning system and defogger Adjusting the settings ■ Adjusting the temperature setting Press “∧” on to increase the temperature and “∨” to decrease the temperature. The air conditioning system switches between individual and simulta- neous modes each time is pressed.
Page 235 3-1. Using the air conditioning system and defogger ■ Changing the air outlets Press the desired button, The air flow shown on the display indicates the following. Air flows to the upper body. Air flows to the upper body and feet.
Page 236 3-1. Using the air conditioning system and defogger Air flows to the feet and the windshield defogger operates. : Vehicles with third seats ■ Switching between outside air and recirculated air modes Press The mode switches between outside air mode (indicator off) and recircu- lated air mode (indicator on) each time is pressed.
Page 237 3-1. Using the air conditioning system and defogger Micro dust and pollen filter Press Outside air mode will be switched to recirculated air mode. Pollen is removed from the air and the air flows to the upper part of the body.
Page 238 3-1. Using the air conditioning system and defogger Front outlets (right and left sides) Direct air flow to the left or right, up or down. Opening and closing the side outlets Open the vent. Close the vent. ■ Using the automatic mode Fan speed is adjusted automatically in accordance with the temperature set- ting and ambient conditions.
Page 239 There may be a problem in the air conditioning system if the indicator light keep flashing. Turn the air conditioning system off and have it inspected by your Toyota dealer. ■ Air conditioning odors ●...
Page 240 3-1. Using the air conditioning system and defogger CAUTION ■ To prevent the windshield from fogging up Do not use during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the wind- shield can cause the outer surface of the windshield to fog up, blocking your vision.
Page 241 3-1. Using the air conditioning system and defogger Rear window and outside rear view mirror defoggers The rear window defogger is used to defog the rear window. The out- side rear view mirror defoggers are used to remove frost, dew or raindrops from the outside rear view mirrors.
Page 242 3-1. Using the air conditioning system and defogger ■ The defogger can be operated when Vehicles without smart key system The engine switch is in the “ON” position. Vehicles with smart key system The “ENGINE START STOP” switch is in IGNITION ON mode. ■...
Page 243 3-1. Using the air conditioning system and defogger ∗ Windshield wiper de-icer This feature is used to prevent ice from building up on the wind- shield and wiper blades. On/off The de-icer will automatically turn off after approximately 15 minutes. ■...
Page 244: Table Of Contents
3-2. Using the audio system Audio system types Without Display Audio system CD player and AM/FM radio Title Page Using the radio P. 270 Using the CD player P. 273 Playing back MP3 and WMA discs P. 278 Operating an iPod P.
Page 245 3-2. Using the audio system With Display Audio system Owners of models equipped with a Display Audio system should refer to the “Display Audio System Owner's Manual”. ■ Using cellular phones Interference may be heard through the audio system's speakers if a cellular phone is being used inside or close to the vehicle while the audio system is operating.
Page 246 3-2. Using the audio system ■ Trademark owned by SRS Labs, Inc. (with Display Audio system) ® ® The audio systems utilize SRS FOCUS and SRS TruBass audio enhancement technologies, under license from SRS Labs, Inc., in all modes except AM radio mode. FOCUS, TruBass, SRS and symbol are trademarks of SRS Labs, Inc.
Page 247 3-2. Using the audio system CAUTION ● Laser products • Do not take this unit apart or attempt to make any changes yourself. This is an intricate unit that uses a laser pickup to retrieve information from the surface of compact discs. The laser is carefully shielded so that its rays remain inside the cabinet.
Page 248 3-2. Using the audio system CAUTION Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité...
Page 249 3-2. Using the audio system CAUTION FCC Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Expo- sure Guidelines in Supplement C to OET65 and RSS-102 of the IC radio fre- quency (RF) Exposure rules.
Page 250 3-2. Using the audio system CAUTION ■ Canada (with Display Audio system) IC ID: 775E-K032 This device complies with Part 15 of FCC Rules and Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of this device.
Page 251 3-2. Using the audio system CAUTION FCC Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Expo- sure Guidelines in Supplement C to OET65 and RSS-102 of the IC radio fre- quency (RF) Exposure rules.
Page 252 3-2. Using the audio system CAUTION If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna.
Page 253: Using The Radio
3-2. Using the audio system Using the radio Power Volume Adjusting the frequency or Station selector selecting items Seeking the frequency Displays text message Scanning for AM/FM mode receivable stations button Setting station presets ∧ STEP Search for desired stations by turning or pressing “...
Page 254 3-2. Using the audio system Scanning radio stations ■ Scanning the preset radio stations STEP Press and hold until you hear a beep. Preset stations will be played for 5 seconds each. STEP When the desired station is reached, press once again.
Page 255 3-2. Using the audio system ■ Certifications for the radio tuner This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 256: Using The Cd Player
3-2. Using the audio system Using the CD player Power Volume CD eject Random playback Reverse Selecting a Repeat play track or displays track list Fast-forward Selecting a track Playback Search playback Displays text message Loading CDs Insert a CD. Ejecting CDs Press and remove the CD.
Page 257 3-2. Using the audio system Fast-forwarding and reversing tracks To fast-forward or reverse, press ) or Selecting a track from a track list STEP Press The track list will be displayed. STEP Turn and press to select a track. To return to the previous display, press (BACK).
Page 258 Operation has stopped due to a high temperature inside the player. Wait for a while and then press . If the CD still cannot be played back, contact your Toyota dealer. ■ Discs that can be used Discs with the marks shown below can be used.
Page 259 3-2. Using the audio system ■ CD player protection feature To protect the internal components, playback is automatically stopped when a problem is detected while the CD player is being used. ■ If a CD is left inside the CD player or in the ejected position for extended periods CDs may be damaged and may not play properly.
Page 260 3-2. Using the audio system NOTICE ● Low-quality and deformed CDs ● CDs with a transparent or translucent recording area ● CDs that have had tape, stickers or CD- R labels attached to them, or that have had the label peeled off ■...
Page 261: Playing Back Mp3 And Wma Discs
3-2. Using the audio system Playing back MP3 and WMA discs Power Volume Disc eject Random playback Selecting a file Repeat play or displays folder list Selecting a file Playback Search playback Selecting a folder, fast-forwarding Displays text message or reversing Loading and ejecting MP3 and WMA discs →P.
Page 262 3-2. Using the audio system ■ Returning to the first folder Press and hold ) until you hear a beep. ■ Scanning a folder STEP Press and hold until you hear a beep. The first 10 seconds of the first file in the each folder will be played. STEP When the desired folder is reached, press again.
Page 263 3-2. Using the audio system Repeat play Pressing (RPT) changes modes in the following order: File repeat → Folder repeat* → Off *: Available except when RDM (random playback) is selected Switching the display Press Track title, Artist name and Album title (MP3 only) are shown on the dis- play.
Page 264 3-2. Using the audio system ■ If a CDs are left inside the CD player or in the ejected position for extended periods →P. 276 ■ Lens cleaners →P. 276 ■ MP3 and WMA files MP3 (MPEG Audio LAYER3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 compression.
Page 265 3-2. Using the audio system ● Compatible media Media that can be used for MP3 and WMA playback are CD-Rs and CD- RWs. Playback in some instances may not be possible, depending on the status of the CD-R or CD-RW. Playback may not be possible or the audio may jump if the disc is scratched or marked with fingerprints.
Page 266 3-2. Using the audio system ● MP3 and WMA playback When a disc containing MP3 or WMA files is inserted, all files on the disc are first checked. Once the file check is finished, the first MP3 or WMA file is played.
Page 267: Operating An Ipod
3-2. Using the audio system Operating an iPod Connecting an iPod enables you to enjoy music from the vehicle speakers. ■ Connecting an iPod Open the cover and connect STEP an iPod using an iPod cable. Turn on the power of the iPod if it is not turned on.
Page 268 3-2. Using the audio system ■ Control panel Adjusting sound quality and volume balance Power Volume Shuffle playback Selecting an iPod Repeat play iPod menu menu/song or mode displays song list Fast-forward Reverse Selecting a song Playback Displays text message...
Page 269 3-2. Using the audio system Selecting a play mode STEP Press (MENU) to select iPod menu mode. STEP Turning clockwise changes the play mode in the fol- lowing order: “Playlists”→“Artists”→“Albums”→“Songs”→“Podcasts”→“Genres” →“Composers”→“Audiobooks” STEP Press to select the desired play mode. ■ Play mode list First Second...
Page 270 3-2. Using the audio system ■ Selecting a list STEP Turn to display the first selection list. STEP Press to select the desired item. Pressing the knob changes to the second selection list. STEP Repeat the same procedure to select the desired item. To return to the previous selection list, press (BACK).
Page 271 3-2. Using the audio system Fast-forwarding and reversing songs To fast-forward or reverse, press ) or Shuffle playback Pressing (RDM) changes modes in the following order: Track shuffle → Album shuffle → Off Repeat play Press (RPT) To cancel, press (RPT) again.
Page 272 3-2. Using the audio system ■ About iPod ● “Made for iPod” and “Made for iPhone” mean that an electronic acces- sory has been designed to connect specifically to iPod, or iPhone, respectively, and has been certified by the developer to meet Apple per- formance standards.
Page 273 3-2. Using the audio system ■ Error messages “iPod ERROR”: This indicates that the data in the iPod cannot be read. “ERROR 3”: This indicates that the iPod may be malfunctioning. “ERROR 4”: This indicates that an over current error has occurred. “ERROR 5”: This indicates that an iPod communication error has occurred.
Page 274 3-2. Using the audio system Items related to standards and limitations are as follows: ● Maximum number of lists in device: 9999 ● Maximum number of songs in device: 65535 ● Maximum number of songs per list: 65535 CAUTION ■ Caution while driving Do not connect iPod or operate the controls.
Page 275: Operating A Usb Memory
3-2. Using the audio system Operating a USB memory Connecting a USB memory enables you to enjoy music from the vehicle speakers. ■ Connecting a USB memory Open the cover and connect a STEP USB memory. Turn on the power of the USB memory if it is not turned on.
Page 276 3-2. Using the audio system ■ Control panel Power Volume Random playback Selecting a file Repeat play or displays folder list Selecting a file Playback Search playback Selecting a folder, fast-forwarding or reversing Displays text message...
Page 277 3-2. Using the audio system Selecting a folder ■ Selecting folders one at a time To select the desired folder, press ) or ■ Selecting a folder and file from folder list STEP Press The folder list will be displayed. STEP Turn and press to select a folder and a file.
Page 278 3-2. Using the audio system Scanning files STEP Press The first 10 seconds of all files in the folder will be played. STEP When the desired folder is reached, press again. Fast-forwarding and reversing files →P. 288 Random playback Pressing (RDM) changes modes in the following order: Folder random →...
Page 279 3-2. Using the audio system ■ USB memory functions ● Depending on the USB memory that is connected to the system, the device itself may not be operable and certain functions may not be avail- able. If the device is inoperable or a function is unavailable due to a mal- function (as opposed to a system specification), disconnecting the device and reconnecting it once again may resolve the problem.
Page 280 3-2. Using the audio system ● MP3 and WMA files MP3 (MPEG Audio LAYER 3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size using MP3 compression. WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 format.
Page 281 3-2. Using the audio system ● ID3 and WMA tags ID3 tags can be added to MP3 files, making it possible to record the track title, artist name, etc. The system is compatible with ID3 Ver. 1.0, 1.1, and Ver. 2.2, 2.3, 2.4 ID3 tags.
Page 282 3-2. Using the audio system NOTICE ■ To prevent damage to USB memory ● Do not leave USB memory in the vehicle. The temperature inside the vehi- cle may become high, resulting in damage to the player. ● Do not push down on or apply unnecessary pressure to the USB memory while it is connected as this may damage the USB memory or its terminal.
Page 283: Optimal Use Of The Audio System
3-2. Using the audio system Optimal use of the audio system Menu button Adjusting the sound quality and ASL...
Page 284 3-2. Using the audio system Using the audio control function ■ Changing sound quality modes STEP Press STEP Turn to select “Sound Setting”. STEP Press STEP Turn to select the desired mode. “BASS”, “TREBLE”, “FADER”, “BALANCE”, or “ASL” STEP Press ■...
Page 285 3-2. Using the audio system ■ Adjusting the Automatic Sound Levelizer (ASL) When ASL is selected, turning to the right changes the amount of “ASL” in the order of “LOW”, “MID” and “HIGH”. Turning to the left turns “ASL” off. ASL automatically adjusts the volume and tone quality according to vehi- cle speed.
Page 286: Using The Aux Port
3-2. Using the audio system Using the AUX port This port can be used to connect a portable audio device and listen to it through the vehicle’s speakers. Open the cover and connect STEP the portable audio device. Press STEP ■...
Page 287: Using The Steering Wheel Audio Switches
3-2. Using the audio system Using the steering wheel audio switches Some audio features can be controlled using the switches on the steering wheel. Volume Radio mode: Select radio stations CD mode: Selects tracks and files (MP3 and WMA) iPod mode: Selects songs memory mode: Selects folders and files...
Page 288 3-2. Using the audio system Adjusting the volume Press “+” on to increase the volume and “-” to decrease the vol- ume. Press and hold to continue increasing or decreasing the volume. Silencing a sound Press and hold To cancel, press and hold again.
Page 289 3-2. Using the audio system Selecting a folder or album ® STEP Press to select CD, USB memory or Bluetooth audio mode. STEP Press and hold “∧” or “∨” on until you hear a beep. CAUTION ■ To reduce the risk of an accident Exercise care when operating the audio switches on the steering wheel.
Page 290 3-2. Using the audio system ® Bluetooth audio/phone ■ ® Bluetooth audio ® The Bluetooth audio system enables you to enjoy music played on a portable digital audio player (portable player) from the vehi- cle speakers via wireless communication. ® This audio system supports Bluetooth , a wireless data system capable of playing portable audio music without cables.
Page 291 3-2. Using the audio system ■ Conditions affecting operation ® The Bluetooth audio/phone may not operate normally in the following situa- tions: ● ® The portable player does not support Bluetooth ● The cellular phone is located outside the service area ®...
Page 292 3-2. Using the audio system ■ Compatible models ● ® Bluetooth specifications: Ver. 1.1, or higher (recommended: Ver. 2.1 + EDR or higher) ● Following Profiles: • A2DP (Advanced Audio Distribution Profile) Ver. 1.0, or higher (recom- mended: Ver. 1.2 or higher) •...
Page 293: Using The Bluetooth ® Audio/Phone
3-2. Using the audio system ® Using the Bluetooth audio/phone ■ Audio unit ® Bluetooth connection con- dition If “BT” is not displayed, the ® Bluetooth audio/phone cannot be used. Display A message, name, number, etc. is displayed. Lower-case characters and special characters cannot be displayed.
Page 294 3-2. Using the audio system ■ Steering wheel switches →P. 304 ■ Microphone...
Page 295 3-2. Using the audio system ® Using the Bluetooth audio/phone for the first time ® Before using the Bluetooth audio/phone, it is necessary to register a ® Bluetooth device in the system. Follow the procedure below to reg- ister (pair) a device: STEP Press and select “Bluetooth”...
Page 296 3-2. Using the audio system ® Menu list of the Bluetooth audio/phone First menu Second menu Third menu Operation details Registering a “BT Pairing” ® Bluetooth device Listing the registered “List Phone” cellular phones Listing the registered “List Audio” portable players “Passkey”...
Page 297 3-2. Using the audio system First menu Second menu Third menu Operation details “Add contacts” Adding a new number Registering a speed “Add SD” dial “Delete Call Deleting a number History” stored in the call history “Phonebook” Deleting a number “Delete stored in the contacts”...
Page 298 3-2. Using the audio system ® Operating a Bluetooth enabled portable player Selecting an album, fast-forwarding or reversing Power Volume Repeat play Random playback Selecting items Selecting a track Playback Search playback Playback/Pause Displays text message Selecting an album Press ) or ) to select the desired album.
Page 299 3-2. Using the audio system Scanning tracks STEP Press The first 10 seconds of all tracks in the album will be played. STEP When the desired track is reached, press again. Playing and pausing tracks Press ) to play or pause a track. Fast-forwarding and reversing tracks →P.
Page 300 3-2. Using the audio system ® ■ Bluetooth audio system functions Depending on the portable player that is connected to the system, certain functions may not be available.
Page 301 3-2. Using the audio system Making a phone call To enter the “PHONE” mode, press the off-hook switch. ■ Making a phone call ● Dialing by selecting a name ● Speed dialing ● Dialing by entering the number ● Dialing from call histories ■...
Page 302 3-2. Using the audio system Dialing by selecting a name STEP Select “Phonebook” using STEP Select the desired name using and press the off-hook switch. By pressing (Add S. Dial) and one of the speed dial buttons (from ) while the desired name is selected, it can be registered as a speed dial.
Page 303 3-2. Using the audio system Dialing from call histories STEP Select “All calls”, “Missed calls”, “Incoming calls” or “Outgoing calls” using STEP Select a desired number using and press the off-hook switch. The following operations can be performed: ● Registering a number as a speed dial Press (Add S.
Page 304 3-2. Using the audio system Operations during a call ● Transferring a call A call can be transferred between the cellular phone and system while dialing, receiving a call, or during a call. Use one of the fol- lowing methods: a.
Page 305 3-2. Using the audio system Adjusting the ringtone volume when receiving a call Change the ringtone volume using To decrease the volume: Turn counterclockwise. To increase the volume: Turn clockwise. ■ When talking on the phone ● Do not talk simultaneously with the other party. ●...
Page 306 3-2. Using the audio system Using the “SET UP” menu (“Bluetooth” menu) ® Registering a Bluetooth device in the system allows the system to function. The following functions can be used for registered devices: ■ Functions and operation procedures STEP Press and select “Bluetooth”...
Page 307 3-2. Using the audio system Registering a portable player Select “BT Pairing” using , and perform the procedure for reg- istering a portable player. (→P. 312) Listing the registered cellular phones Select “List Phone” using . The list of registered cellular phones will be displayed.
Page 308 3-2. Using the audio system Listing the registered portable players Select “List Audio” using . The list of registered portable play- ers will be displayed. ● Connecting the registered portable player to the audio system STEP Select the name of the portable player to be connected using STEP Select “Select”...
Page 309 3-2. Using the audio system Changing the passkey STEP Select “Passkey” using STEP Select a 4 to 8-digit passkey using Input the number 1 digit at a time. STEP When the entire number to be registered as a passkey has been input, press again.
Page 310 3-2. Using the audio system Displaying the device status Select “Bluetooth info” using ● Displaying the device name Select “Device Name” using ● Displaying the device address Select “Device Address” using Setting the automatic connection confirmation display to on or off If the “Display Setting”...
Page 311 3-2. Using the audio system Initialization Select “Initialize” using ● Initializing the sound settings Select “Sound setting” using and press (YES). For details about sound settings (→P. 300) ● Initializing the device information Select “Car Device Info” using and press (YES).
Page 312 3-2. Using the audio system Using the “SET UP” menu (“Phone” menu) ■ Functions and operation procedures To enter the menu of each function, press and follow the steps below using ● Adding a new phone number 1. “Phone” → 2. “Phonebook” → 3. “Add contacts” ●...
Page 313 3-2. Using the audio system Adding a new phone number Select “Add contacts” using ● Transferring all contacts from the cellular phone Select “Overwrite all contacts” using and press (YES). ● Transferring one contact from the cellular phone Select “Add one contact” using and press (YES).
Page 314 3-2. Using the audio system Deleting call histories Select “Delete Call History” using ● Deleting outgoing call history STEP Select “Outgoing Calls” using STEP Select the desired phone number using and press (YES). To delete all outgoing call history data, press (ALL) and then press (YES).
Page 315 3-2. Using the audio system ● Deleting missed call history STEP Select “Missed Calls” using STEP Select the desired phone number using and press (YES). To delete all missed call history data, press (ALL) and then press (YES). ● Deleting a number from all call histories (Outgoing calls, Incoming calls and Missed calls) STEP Select “All Calls”...
Page 316 3-2. Using the audio system Deleting a registered phone number STEP Select “Delete contacts” using STEP Select the desired phone number using and press (YES). To delete all of the registered phone numbers, select “All delete” using and press (YES). Deleting another cellular phone’s phonebook STEP Select “Delete other PB”...
Page 317 3-2. Using the audio system Setting ringtone volume STEP Select “Ringtone Volume” using STEP Change the ringtone volume. To decrease the volume: Turn counterclockwise. To increase the volume: Turn clockwise. Setting ringtone STEP Select “Ringtone” using STEP Using , select a ringtone (1 - 3). To set the selected ringtone, press Transferring call histories Select “Transfer Histories”...
Page 318 3-3. Using the interior lights Interior lights list Your Toyota is equipped with the illuminated entry system to assist in entering the vehicle. Owing to the function of the system, the lights shown in the following illustration (except the luggage com-...
Page 319 3-3. Using the interior lights Personal/interior light main switch and personal/interior lights Personal/interior light main switch Type A Door position The personal lights and interior light come on when a door is opened. They go off when the doors are closed. The personal lights and interior light can be individually turned on or off.
Page 320 3-3. Using the interior lights Personal/interior lights and interior light and luggage compartment light Type B On/off Interior light Door position Luggage compartment light...
Page 321 20 minutes. ■ Customization that can be configured at Toyota dealer Settings (e.g. the time elapsed before lights turn off) can be changed. (Customizable features →P. 528)
Page 322 3-4. Using the storage features List of storage features Cup holders Bottle holders Auxiliary box Glove box Overhead console Console box CAUTION ■ Items that should not be left in the storage spaces Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the following when cabin temperature becomes high: ●...
Page 323 3-4. Using the storage features Glove box Glove box Unlock with the master key (vehicles without smart key system) or mechanical key (vehicles with smart key sys- tem) Lock with the master key (vehicles without smart key system) or mechanical key (vehicles with smart key sys- tem) Open (pull lever)
Page 324 3-4. Using the storage features Console box Console box Upper tray Lift the lid. Lower box Pull the lever up and lift the lid. CAUTION ■ Caution while driving Keep the console box closed. Injuries may result in the event of an accident or sudden braking.
Page 325 3-4. Using the storage features Overhead console Overhead console The overhead console is useful for temporarily storing sunglasses and similar small items. Press the lid. CAUTION ■ Caution while driving Keep the overhead console closed. Injuries may result in the event of an accident or sudden braking. ■...
Page 326 3-4. Using the storage features Cup holders Cup holders Type A Removing the adapters changes the size. (→P. 343) Type B To use the cup holders, pull the strap forward and fold down the center seatback. ■ Adjusting size of the cup holders (type A only) Remove the adapters.
Page 327 3-4. Using the storage features Cup holders and bottle holders CAUTION ■ Items unsuitable for the cup holder Do not place anything other than cups or aluminum cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
Page 328 3-4. Using the storage features Bottle holders Third seat CAUTION ■ Items unsuitable for the bottle holder Do not place anything other than a bottle in the bottle holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
Page 329 3-4. Using the storage features Auxiliary box Auxiliary box To open and close the auxiliary box, press the button. CAUTION ■ Caution while driving Keep the auxiliary box closed. Injuries may result in the event of an accident or sudden braking. NOTICE ■...
Page 330 3-5. Other interior features Sun visors Forward position: Flip down. Side position: Flip down, unhook, and swing to the side. Side extender: Place in side position then slide backwards.
Page 331 3-5. Other interior features Vanity mirrors Slide the cover. The light turns on when the cover is opened.
Page 332 3-5. Other interior features Clock Vehicles with a manual air conditioning system Adjusts the hours. Adjusts the minutes. Rounds nearest hour.* *: e.g. 1:00 to 1:29 → 1:00 1:30 to 1:59 → 2:00 Vehicles with an automatic air conditioning system Adjusts the hours.
Page 333 3-5. Other interior features Power outlets The power outlet can be used for a following component. 12 V: Accessories that use less than 10 A. 120 VAC: Accessories that use less than 100 W. ■ 12 V Type A Type B Type C...
Page 334 3-5. Other interior features ■ 120 VAC (if equipped) ■ The power outlet can be used when 12 V ● Vehicles without smart key system The engine switch is in the “ACC” or “ON” position. ● Vehicles with smart key system The “ENGINE START STOP”...
Page 335 Do not modify, disassemble or repair the power outlet or its inverter in any way. Doing so may result in unexpected malfunctions or accidents, which could cause serious damage or injuries. Contact your Toyota dealer for any necessary repairs. ■...
Page 336 3-5. Other interior features NOTICE ■ To avoid damaging the power outlet and the plug ● Close the power outlet lid when not in use. ● Do not allow foreign objects or liquids to enter the power outlet, as this may cause a short circuit.
Page 337 ■ If the power outlet is loose when an electrical appliance plug is con- nected Replace the outlet. Contact your Toyota dealer for any necessary replace- ments. ■ If the power outlet gets dirty Use a soft, clean cloth to wipe it gently.
Page 338 3-5. Other interior features ∗ Seat heaters Heats the driver’s seat Heats the front passenger’s seat The indicator light is on while the seat heater is operating. Push the switch once again to turn off the seat heater. ■ The seat heaters can be used when Vehicles without smart key system The engine switch is in the “ON”...
Page 339 3-5. Other interior features NOTICE ■ To prevent seat heater damage Do not put unevenly weighted objects on the seat and do not stick sharp objects (needles, nails, etc.) into the seat. ■ To prevent battery discharge Turn the switches off when the engine is not running.
Page 340 3-5. Other interior features Armrest To use the armrest, pull the strap forward and fold down the center seatback. NOTICE ■ To prevent damage to the armrest Do not place too much strain on the armrest.
Page 341 3-5. Other interior features Coat hooks CAUTION ■ Items that must not be hung on the hook Do not hang a coat hanger or other hard or sharp objects on the hook. If the SRS curtain shield airbags deploy, these items may become projectiles that cause death or serious injury.
Page 342 When installing the driver's floor mat ● Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver's seat. ●...
Page 343 3-5. Other interior features Luggage compartment features ■ Cargo hooks Cargo hooks are provided for securing loose items. ■ Grocery bag hooks ■ Storage box (vehicles without third seats) Type A The rear deck board can be folded up into two positions. Lift the rear deck board.
Page 344 3-5. Other interior features Fold up the deck board. STEP The lid can be removed. Type B Lift the front deck board.
Page 345 3-5. Other interior features ■ Luggage cover (if equipped) Attach the hooks to the head STEP restraints. If necessary, move the second seats to enable the hook engagement. Pull out the luggage cover and STEP hook onto the anchors. Removing the luggage cover (if equipped) The luggage cover can be removed by following the procedure below.
Page 346 3-5. Other interior features Stowing the luggage cover (if equipped) Open the rear deck board and STEP remove the deck side cover. Insert the right end of the lug- STEP gage cover into the recess, then compress the left end of the lug- gage cover and insert it into the recess.
Page 347 3-5. Other interior features CAUTION ■ When the cargo hooks are not in use To avoid injury, always return the cargo hooks to their stowed positions. ■ Caution while driving ● Do not drive with any of the deck boards opened. Items may fall out and cause injury.
Page 348 4-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition. ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 349 4-1. Maintenance and care ■ Aluminum wheels ● Remove any dirt immediately by using a neutral detergent. Do not use hard brushes or abrasive cleaners. Do not use strong or harsh chemical cleaners. Use the same mild detergent and wax as used on the paint. ●...
Page 350 4-1. Maintenance and care NOTICE ■ To prevent paint deterioration and corrosion on the body and compo- nents (aluminum wheels etc.) ● Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
Page 351 4-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle's interior and keep it in top condition: ■ Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty sur- faces with a cloth dampened with lukewarm water.
Page 352 4-1. Maintenance and care ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle's interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 353 4-1. Maintenance and care NOTICE ■ Cleaning detergents ● Do not use organic substances such as benzene or gasoline, acidic or alkaline solutions, dye, bleach or other detergent. Doing so may discolor the vehicle interior or cause streaks or damage to painted surfaces. ●...
Page 354 It is recommended that genuine Toyota parts be used for repair to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than a Toyota dealer performs repairs, confirm the war- ranty coverage.
Page 355 STEP Press and hold the button until the trip meter displays “000000”. ■ Allow inspection and repairs to be performed by a Toyota dealer ● Toyota technicians are well-trained specialists and are kept up to date with the latest service information. They are well informed about the operations of all systems on your vehicle.
Page 356 4-2. Maintenance CAUTION ■ Warning in handling of battery ● Engine exhaust, some of its constituents, and a wide variety of automobile components contain or emit chemicals known to the State of California to cause cancer and birth defects and other reproductive harm. Work in a well ventilated area.
Page 357 “Scheduled Maintenance Guide” or “Owner’s Manual Supplement”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment Items...
Page 358 4-2. Maintenance Vehicle interior Items Check points • Moves smoothly (without uneven Accelerator pedal pedal effort or catching)? • Can the vehicle be held securely Automatic transmission “Park” on an incline with the shift lever in mechanism • Moves smoothly? •...
Page 359 4-2. Maintenance Vehicle exterior Items Check points Doors • Operate smoothly? Engine hood • The lock system works properly? • Is there any leakage after park- Fluid leaks ing? • Inflation pressure is correct? • Tire surfaces not worn or dam- aged? Tires •...
Page 360 If the malfunction indicator lamp comes on The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/ M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. ■...
Page 361 Brake fluid level (→P. 395) • Rag or paper towel • Funnel (used only for adding brake fluid) • “Toyota Super Long Life Coolant” or similar high quality ethylene glycol based non-silicate, non- amine, non-nitrite and non-borate coolant with long-life hybrid organic acid technology.
Page 362 4-3. Do-it-yourself maintenance Items Parts and tools • Fuse with same amperage rating Fuses (→P. 421) as original Radiator and condenser ⎯ (→P. 395) • Tire pressure gauge Tire inflation pressure (→P. 408) • Compressed air source • Water washer fluid containing Washer fluid (→P.
Page 363 4-3. Do-it-yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury, observe the following precautions. ■ When working on the engine compartment ● Keep hands, clothing, and tools away from the moving fans and engine drive belt.
Page 364 4-3. Do-it-yourself maintenance NOTICE ■ If you remove the air cleaner filter Driving with the air cleaner removed may cause excessive engine wear due to dirt in the air. Also a backfire could cause a fire in the engine compart- ment.
Page 365 4-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood release lever. STEP The hood will pop up slightly. Lift the auxiliary catch lever STEP and lift the hood. Hold the hood open by insert- STEP ing the supporting rod into the slot.
Page 366 4-3. Do-it-yourself maintenance CAUTION ■ Pre-driving check Check that the hood is fully closed and locked. If the hood is not locked properly, it may open while the vehicle is in motion and cause an accident, which may result in death or serious injury. ■...
Page 367 4-3. Do-it-yourself maintenance Positioning a floor jack When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement may damage your vehicle or cause injury. ■ Front ■ Rear...
Page 368 4-3. Do-it-yourself maintenance CAUTION ■ When raising your vehicle Make sure to observe the following to reduce the possibility of death or seri- ous injury. ● Lift up the vehicle using a floor jack such as the one shown in the illustra- tion.
Page 369 4-3. Do-it-yourself maintenance Engine compartment 2.5 L 4-cylinder (2AR-FE) engine Fuse boxes (→P. 421) Radiator (→P. 395) Engine coolant reservoir Condenser (→P. 395) (→P. 393) Electric cooling fans Engine oil filler cap Engine oil level dipstick (→P. 391) (→P. 390) Battery (→P.
Page 370 4-3. Do-it-yourself maintenance 3.5 L V6 (2GR-FE) engine Fuse boxes (→P. 421) Radiator (→P. 395) Engine coolant reservoir Condenser (→P. 395) (→P. 393) Electric cooling fans Engine oil filler cap Engine oil level dipstick (→P. 391) (→P. 390) Battery (→P. 397) Washer fluid tank (→P.
Page 371 4-3. Do-it-yourself maintenance Engine compartment cover ■ Removing the engine compartment cover ■ Installing the clips NOTICE ■ After installing an engine compartment cover Make sure that the cover is securely installed in its original position.
Page 372 4-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. ■ Checking the engine oil STEP Park the vehicle on level ground. After warming up the engine and turning it off, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
Page 373 4-3. Do-it-yourself maintenance 3.5 L V6 (2GR-FE) engine Full ■ Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 374 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal.
Page 375 4-3. Do-it-yourself maintenance NOTICE ■ To prevent serious engine damage Check the oil level on a regular basis. ■ When replacing the engine oil ● Be careful not to spill engine oil on the vehicle components. ● Avoid overfilling, as the engine could be damaged. ●...
Page 376 If the coolant level drops within a short time after replenishing Visually check the radiator, hoses, engine coolant reservoir cap, drain cock and water pump. If you cannot find a leak, have your Toyota dealer test the cap and check for leaks in the cooling system. ■...
Page 377 Radiator and condenser Check the radiator and condenser, and clear any foreign objects. If either of the above parts are extremely dirty or you are not sure of their condition, have your vehicle checked by your Toyota dealer. CAUTION ■...
Page 378 4-3. Do-it-yourself maintenance CAUTION ■ When filling the reservoir Take care because brake fluid can harm your hands or eyes and damage painted surfaces. If fluid gets on your hands or in your eyes, flush the affected area with clean water immediately.
Page 379 4-3. Do-it-yourself maintenance Battery ■ Battery exterior Make sure that the battery terminals are not corroded and that there are no loose connections, cracks, or loose clamps. Terminals Hold-down clamp ■ Before recharging When recharging, the battery produces hydrogen gas which is flammable and explosive.
Page 380 4-3. Do-it-yourself maintenance CAUTION ■ Chemicals in the battery A battery contains poisonous and corrosive sulfuric acid and may produce hydrogen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near the battery: ●...
Page 381 4-3. Do-it-yourself maintenance CAUTION ■ Emergency measures regarding electrolyte ● If electrolyte gets in your eyes Flush your eyes with clean water for at least 15 minutes and get immedi- ate medical attention. If possible, continue to apply water with a sponge or cloth while traveling to the nearest medical facility.
Page 382 4-3. Do-it-yourself maintenance Washer fluid For vehicles sold in U.S.A. Add washer fluid in the following situations. ● Any washer does not work. ● The low washer fluid warning light comes on. For vehicles sold in Canada If any washer does not work or the low windshield washer fluid warn- ing light comes on, the washer tank may be empty.
Page 383 Vehicles with a spare tire of the same wheel type as the installed tires Rotate the tires in the order shown. To equalize tire wear and extend tire life, Toyota recom- mends that tire rotation is Front carried out at the same inter- val as tire inspection.
Page 384 ■ The tire pressure warning system (if equipped) Your Toyota is equipped with a tire pressure warning system that uses tire pressure warning valves and transmitters to detect low tire inflation pressure before serious problems arise. (→P. 456)
Page 385 Have tire pressure warning valve and transmitter ID codes registered by your Toyota dealer. (→P. 403) Registering ID codes (vehicles with a tire pressure warning...
Page 386 A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage. If you are not sure, consult with your Toyota dealer. ■ Replacing tires and wheels (vehicles with a tire pressure warning...
Page 387 4-3. Do-it-yourself maintenance ■ Tire types 1 Summer tires Summer tires are high-speed performance tires best suited to highway driving under dry conditions. Since summer tires do not have the same traction performance as snow tires, summer tires are inadequate for driving on snow-covered or icy roads.
Page 388 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 389 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
Page 390 4-3. Do-it-yourself maintenance Tire inflation pressure ■ Tire inflation pressure The recommended cold tire inflation pressure and tire size is dis- played on the tire and loading information label. (→P. 517)
Page 391 4-3. Do-it-yourself maintenance ■ Inspection and adjustment procedure Tire valve Tire pressure gauge STEP Remove the tire valve cap. STEP Press the tip of the tire pressure gauge onto the tire valve. STEP Read the pressure using the graduations of the gauge. STEP If the tire inflation pressure is not within the recommended levels, adjust the pressure.
Page 392 Reduced driving comfort and tire life ● Reduced safety ● Damage to the drive train If a tire needs frequent refilling, have it checked by your Toyota dealer. ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: ●...
Page 393 4-3. Do-it-yourself maintenance CAUTION ■ Proper inflation is critical to save tire performance Keep your tires properly inflated. Otherwise, the following conditions may occur and result in an accident causing death or serious injury. ● Excessive wear ● Uneven wear ●...
Page 394 ● Bent wheels that have been straightened ■ Aluminum wheel precautions ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
Page 395 When replacing wheels (vehicles with a tire pressure warning sys- tem) The wheels of your Toyota are equipped with tire pressure warning valves and transmitters that allow the tire pressure warning system to provide advanced warning in the event of a loss in tire inflation pressure.
Page 396 Because tire repair or replacement may affect the tire pressure warning valves and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.
Page 397 4-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. ■ Removal method STEP Vehicles without smart key system: Turn the engine switch off. Vehicles with smart key system: Turn the “ENGINE START STOP”...
Page 398 4-3. Do-it-yourself maintenance ■ Replacement method Remove the air conditioning filter and replace it with a new one. The “UP↑” marks shown on the filter should be pointing up. ■ Checking interval Inspect and replace the air conditioning filter according to the maintenance schedule.
Page 399 4-3. Do-it-yourself maintenance Key battery Replace the battery with a new one if it is discharged. ■ You will need the following items: ● Flathead screwdriver (To prevent damage to the key, cover the tip of the screwdriver with a rag.) ●...
Page 400 4-3. Do-it-yourself maintenance Open the case cover using a STEP coin protected with tape etc. and remove the depleted bat- tery. Insert a new battery with the “+” terminal facing up. ■ Replacing the battery (vehicles with smart key system) Take out the mechanical key.
Page 401 Use a CR2016 (vehicles without smart key system) or CR1632 (vehicles with smart key system) lithium battery ● Batteries can be purchased at your Toyota dealer, jewelers, or camera stores. ● Replace only with the same or equivalent type recommended by your Toyota dealer.
Page 402 4-3. Do-it-yourself maintenance NOTICE ■ For normal operation after replacing the battery Observe the following precautions to prevent accidents. ● Always work with dry hands. Moisture may cause the battery to rust. ● Do not touch or move any other components inside the remote control. ●...
Page 403 4-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. STEP Vehicles without smart key system: Turn the engine switch off.
Page 404 4-3. Do-it-yourself maintenance Under the instrument panel Remove the lid. STEP After a system failure, see “Fuse layout and amperage rat- ings” (→P. 425) for details about which fuse to check. Remove the fuse with the pull- STEP out tool. STEP Check if the fuse has blown.
Page 405 Type B Normal fuse Blown fuse Replace it with one of an appropriate amperage rating. The amperage rating can be found on the fuse box lid. Type C Normal fuse Blown fuse Contact your Toyota dealer.
Page 406 4-3. Do-it-yourself maintenance Type D Normal fuse Blown fuse Contact your Toyota dealer. Type E Normal fuse Blown fuse Contact your Toyota dealer.
Page 407 4-3. Do-it-yourself maintenance Fuse layout and amperage ratings ■ Engine compartment Type A (driver’s side) Fuse Ampere Circuit SPARE 30 A Spare fuse SPARE 20 A Spare fuse SPARE 10 A Spare fuse Air conditioning system, power win- ECU-B2 7.5 A dows, smart key system ALT-S 7.5 A...
Page 408 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Gauges and meters, clock, main body ECU, wireless remote control, smart key system, audio system, front passenger occupant classifi- ECU-B 10 A cation system, ABS, TRAC, VSC, AUTO LSD, downhill assist control system, hill-start assist control sys- tem, Active Torque Control 4WD system Vanity lights, personal/interior...
Page 409 4-3. Do-it-yourself maintenance Fuse Ampere Circuit CDS* 30 A Electric cooling fan FAN 1* 50 A H-LP CLN 30 A No circuit : Vehicles with towing package : Vehicles with 2.5 L 4-cylinder (2AR-FE) engine : Vehicles with 3.5 L V6 (2GR-FE) engine Type B (passenger’s side) Fuse Ampere...
Page 410 4-3. Do-it-yourself maintenance Fuse Ampere Circuit AM2-2 7.5 A Starting system Multiport fuel injection system/ EFI NO.1 10 A sequential multiport fuel injection system Multiport fuel injection system/ EFI NO.2 10 A sequential multiport fuel injection system EFI NO.3 7.5 A No circuit GROW 80 A...
Page 411 4-3. Do-it-yourself maintenance Fuse Ampere Circuit 20 A A/F sensor, fuel pump* : Vehicles without towing package : Vehicles with towing package : Vehicles with 2.5 L 4-cylinder (2AR-FE) engine : Vehicles with 3.5 L V6 (2GR-FE) engine ■ Under the instrument panel Fuse Ampere Circuit...
Page 412 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Audio system, power outlets, power rear view mirror control, 7.5 A automatic transmission shift lock system, main body ECU, clock, smart key system MIR HTR 10 A Outside rear view mirror defoggers PWR OUTLET 15 A Power outlet RR FOG...
Page 413 4-3. Do-it-yourself maintenance Fuse Ampere Circuit 7.5 A On-board diagnosis system Stop/tail lights, high mounted stop- light, automatic transmission shift lock system, multiport fuel injection system/sequential multiport fuel STOP 10 A injection system, ABS, TRAC, VSC, AUTO LSD function, downhill assist control system, hill-start assist control system Main body ECU, power door lock...
Page 414 Never use a fuse of a higher amperage rating than indicated, or use any other object in place of a fuse. ● Always use a genuine Toyota fuse or equivalent. Never replace a fuse with a wire, even as a temporary fix. This can cause extensive damage or even fire.
Page 415 You may replace the following bulbs yourself. The difficulty level of replacement varies depending on the bulb. If necessary bulb replacement seems difficult to perform, contact your Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer.
Page 416 4-3. Do-it-yourself maintenance ■ Rear bulb locations Vehicles without a spare tire Rear side marker lights License plate Rear turn signal and back-up lights lights Vehicles with a spare tire Rear side marker lights License plate light Rear turn signal and back-up lights...
Page 417 4-3. Do-it-yourself maintenance Replacing light bulbs ■ Headlights Right side only: Remove the clip STEP and move it aside to allow easy access to the light bulbs. Turn the bulb base counterclock- STEP wise. Headlight (low beam) Headlight (high beam) Unplug connector while...
Page 418 4-3. Do-it-yourself maintenance Reinstalling the clip ■ Front turn signal, parking and front side marker lights Right side only: Remove the clip STEP and move it aside to allow easy access to the light bulbs. Turn the bulb base counterclock- STEP wise.
Page 419 4-3. Do-it-yourself maintenance Reinstalling the clip ■ Front fog lights (if equipped) Turn the steering wheel in the STEP opposite direction of the front fog light that you wish to replace. For example, if you wish to replace the front fog light on the right side, turn the steering wheel to the left.
Page 420 4-3. Do-it-yourself maintenance Unplug connector while STEP depressing the lock release. Turn the bulb base counterclock- STEP wise. ■ Back-up lights, rear turn signal and rear side marker lights Open the back door (→P. 48) STEP and remove the cover. Turn the bulb base counterclock- STEP wise.
Page 421 4-3. Do-it-yourself maintenance Remove the light bulb. STEP Rear side marker light Rear turn signal light Back-up light ■ License plate lights Vehicles without a spare tire Remove the cover as shown in STEP the illustration. Turn the bulb base counterclock- STEP wise.
Page 422 Remove the light bulb. STEP ■ Light other than the above If any of the lights listed below has burnt out, have it replaced by your Toyota dealer. ● High mounted stoplight ● Stop/tail lights ● Side turn signal lights (if equipped)
Page 423 4-3. Do-it-yourself maintenance ■ Condensation build-up on the inside of the lens Contact your Toyota dealer for more information in the following situations. Temporary condensation build-up on the inside of the headlight lens does not indicate a malfunction. ● Large drops of water are built up on the inside of the lens.
Page 424 4-3. Do-it-yourself maintenance CAUTION ■ Replacing light bulbs ● Turn off the lights. Do not attempt to replace the bulb immediately after turning off the lights. The bulbs become very hot and may cause burns. ● Do not touch the glass portion of the light bulb with bare hands. Hold the bulb by the plastic or metal portion.
Page 425 5-1. Essential information Emergency flashers Use the emergency flashers if the vehicle malfunctions or is involved in an accident. Press the switch to flash all the turn signal lights. To turn them off, press the switch once again. NOTICE ■ To prevent battery discharge Do not leave the emergency flashers on longer than necessary when the engine is not running.
Page 426 If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or a commercial towing service, using a wheel-lift type truck or a flat bed truck. Use a safety chain system for all towing, and abide by all state/pro- vincial and local laws.
Page 427 5-1. Essential information Emergency towing If a tow truck is not available, in an emergency your vehicle may be temporarily towed using a cable or chain secured to the emergency towing eyelet. This should only be attempted on hard surfaced roads for short distances at low speeds.
Page 428 5-1. Essential information Installing towing eyelet Remove the eyelet cover using a STEP flathead screwdriver. To protect the bodywork, place a rag between the screwdriver and the vehicle body, as shown in the illustration. Insert the towing eyelet into the STEP hole and tighten partially by hand.
Page 429 5-1. Essential information Towing with a sling-type truck Do not tow with a sling-type truck to prevent body damage. Towing with a wheel-lift type truck From the front (2WD models) Release the parking brake. From the front (4WD models) Use a towing dolly under the rear wheels.
Page 430 5-1. Essential information From the rear Use a towing dolly under the front wheels. Using a flat bed truck If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45°. Do not overly tighten the tie downs or the vehicle may be damaged.
Page 431 5-1. Essential information CAUTION ■ Caution while towing ● Use extreme caution when towing the vehicle. Avoid sudden starts or erratic driving maneuvers which place excessive stress on the emergency towing eyelet and the cables or chains. Always be cautious of the surroundings and other vehicles while towing. ●...
Page 432 5-1. Essential information NOTICE ■ To prevent body damage when towing with a sling-type truck Do not tow with a sling-type truck, either from the front or rear. ■ To prevent causing serious damage to the transmission and Active Torque Control 4WD system (4WD models) when towing using a wheel- lift type truck 2WD models: Never tow this vehicle from the rear with the front wheels on the...
Page 433 5-1. Essential information If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Toyota dealer as soon as possible. ■ Visible symptoms ● Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)
Page 434 5-1. Essential information Fuel pump shut off system To minimize the risk of fuel leakage when the engine stalls or an air- bag inflates upon collision, the fuel pump shut off system stops sup- plying fuel to the engine. Follow the procedure below to restart the engine after the system is activated.
Page 435 Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous. The following warning indicates a possible problem in the brake sys- tem. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Warning light Warning light/Details Brake system warning light (warning buzzer)* •...
Page 436 Have the vehicle inspected immediately. Failing to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident. Have the vehicle inspected by your Toyota dealer immediately. Warning light Warning light/Details Malfunction indicator lamp Indicates a malfunction in: (U.S.A.)
Page 437 5-2. Steps to take in an emergency Warning light Warning light/Details “ABS” warning light (U.S.A.) Indicates a malfunction in: • The ABS; • The brake assist system. (Canada) Electric power steering system warning light Indicates a malfunction in the EPS system. Cruise control indicator light Indicates a malfunction in the cruise control system.
Page 438 (if equipped) lever to P. Indicates that the auto- If the light does not go off, matic transmission fluid contact your Toyota dealer. temperature is too high. Low washer fluid warning light Fill the tank. Low level of washer fluid...
Page 439 • Flat tire (→P. 467, 485) even if the tire inflation pressure is adjusted, have the system checked by your Toyota dealer. When the light comes on after blinking for 1 minute: Have the system checked Malfunction in the tire by your Toyota dealer.
Page 440 5-2. Steps to take in an emergency Warning light Warning light/Details Correction procedure Maintenance required reminder light Indicates that mainte- nance is required accord- ing to the driven distance on the maintenance schedule.* Illuminates for about 3 sec- onds and then flashes for about 15 seconds approxi- If necessary, perform main- mately 4500 miles (7200...
Page 441 5-2. Steps to take in an emergency Follow the correction procedures. (vehicles with smart key system) After taking the specified steps to correct the suspected problem, check that the warning light turns off. Interior Exterior Warning Correction Warning light/Details buzzer buzzer light procedure...
Page 442 The malfunction indicator lamp will go off after taking several driving trips. If the malfunction indicator lamp does not go off even after several trips, con- tact your Toyota dealer as soon as possible. ■ Front passenger detection sensor and passenger seat belt reminder ●...
Page 443 5-2. Steps to take in an emergency ■ The tire pressure warning light may turn on due to natural causes The tire pressure warning light may turn on due to natural causes such as natural air leaks or tire inflation pressure changes caused by temper- ature.
Page 444 5-2. Steps to take in an emergency ● If non-genuine Toyota wheels are used. (Even if you use Toyota wheels, the tire pressure warning system may not work properly with some types of tires.) ● If tire chains are used.
Page 445 • If the tire pressure warning light comes on even after tire inflation pressure adjustment, it is probable that you have a flat tire. Have the tire replaced by the nearest Toyota dealer. • Avoid abrupt maneuvering and braking. If the vehicle tires deterio- rate, you could lose control of the steering wheel or the brakes.
Page 446 5-2. Steps to take in an emergency CAUTION ■ Maintenance of the tires Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label (tire and load information label).
Page 447 5-2. Steps to take in an emergency CAUTION Your vehicle has also been equipped with a TPMS (tire pressure warning system) malfunction indicator to indicate when the system is not operat- ing properly. The TPMS (tire pressure warning system) malfunction indi- cator is combined with the low tire pressure telltale (tire pressure warning light).
Page 448 5-2. Steps to take in an emergency If you have a flat tire (vehicles with standard tires) Remove the flat tire and replace it with the spare provided. ■ Before jacking up the vehicle ● Stop the vehicle on a hard, flat surface. ●...
Page 449 5-2. Steps to take in an emergency Taking out the jack Disengage claws STEP remove the cover. Loosen STEP Tighten Loosen and take out the jack.
Page 450 5-2. Steps to take in an emergency Taking out the tool bag Disengage claws STEP remove the cover. Take out the tool bag. STEP...
Page 451 5-2. Steps to take in an emergency Taking out the spare tire (vehicles with the spare tire cover) Open the back door. Unlock the STEP latch handle which is on the bot- tom of the spare tire cover. STEP Close the back door. Remove the spare tire cover by STEP holding the bottom and lifting it...
Page 452 5-2. Steps to take in an emergency Taking out the spare tire (vehicles without the spare tire cover) Using the wheel nut wrench, STEP loosen the hold-down nuts by turning them counterclockwise until they can be loosened by hand. Follow the order shown in the illustration.
Page 453 5-2. Steps to take in an emergency Replacing a flat tire Chock the tires. STEP Wheel Flat tire chock posi- tions Behind the Left- rear right- hand hand side side tire Front Behind the Right- rear left- hand hand side side tire In front of...
Page 454 5-2. Steps to take in an emergency STEP Remove the wheel ornament using the wheel nut wrench as shown below. 16-inch wheel To protect the wheel ornament, place a rag between the wrench and the wheel ornament, as shown in the illustration. 17-inch and 18-inch wheels Slightly loosen the wheel nuts STEP...
Page 455 5-2. Steps to take in an emergency Turn the tire jack portion “A” by STEP hand until the notch of the jack is in contact with the jack point. Type A: Assemble the jack han- STEP dle extension. Type B: Assemble the jack han- STEP dle extension.
Page 456 5-2. Steps to take in an emergency STEP Raise the vehicle until the tire is slightly raised off the ground. Type A Type B Type C...
Page 457 5-2. Steps to take in an emergency Remove all the wheel nuts and STEP the tire. When resting the tire on the ground, place the tire so that the wheel design faces up to avoid scratching the wheel surface. Installing the tire Remove any dirt or foreign mat- STEP ter from the wheel contact sur-...
Page 458 5-2. Steps to take in an emergency STEP Install the tire and loosely tighten each wheel nut by hand by approximately the same amount. Replacing a steel wheel with a steel wheel Tighten the nuts until the tapered Tapered portion portion comes into loose contact with the disc wheel seat.
Page 459 5-2. Steps to take in an emergency STEP Lower the vehicle. Type A Type B Type C...
Page 460 5-2. Steps to take in an emergency Firmly tighten each nut two or STEP three times in the order shown in the illustration. Tightening torque: 76 ft•lbf (103 N•m, 10.5 kgf•m) STEP Reinstall the wheel ornament. 16-inch wheel 17-inch and 18-inch wheels...
Page 461 5-2. Steps to take in an emergency Stowing the flat tire STEP Remove any dirt or foreign matter from the disc wheel seat and the wheel contact surface. Vehicles with aluminum wheels STEP and a steel wheel for the spare: Remove the plastic rings from the wheel nuts of the spare tire carrier.
Page 462 5-2. Steps to take in an emergency Insert the hooks into the upper STEP slots and lower the cover to install the spare tire cover. Upper slots Hooks Attach the cover by hooking the STEP 2 inner protrusions. Check that the cover is securely attached.
Page 463 5-2. Steps to take in an emergency STEP Stow the jack and all tools securely, and replace all the cov- ers. ■ When reinstalling the wheel ornament (vehicles with 16-inch wheels) Align the cutout of the wheel ornament with the valve stem as shown. ■...
Page 464 5-2. Steps to take in an emergency CAUTION ■ Using the tire jack Improper use of the tire jack may lead to death or serious injuries due to the vehicle suddenly falling off the jack. ● Do not use the tire jack for any purpose other than replacing tires or installing and removing tire chains.
Page 465 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and...
Page 466 5-2. Steps to take in an emergency If you have a flat tire (vehicles with run-flat tires) Take your vehicle to the nearest Toyota dealer or authorized tire dealer as soon as possible. ■ Run-flat tires (A “RFT” or “DSST” mark is molded on the...
Page 467 ● The battery may be discharged. (→P. 491) ● There may be a malfunction in the steering lock system (vehi- cles with smart key system). Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown.
Page 468 (a system to prevent accidental operation of the shift lever). Have the vehicle inspected by your Toyota dealer. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted.
Page 469 5-2. Steps to take in an emergency If you lose your keys New genuine keys can be made by your Toyota dealer. For vehicles with the smart key system, bring the other key and the key number stamped on the key number plate.
Page 470 Starting the engine STEP Shift the shift lever to P and apply the brakes. Touch the Toyota emblem side of STEP electronic “ENGINE START STOP” switch. If any of the doors is opened and...
Page 471 Press the “ENGINE START STOP” switch within 5 seconds after the buzzer sounds, keeping the brake pedal depressed. In the event that the “ENGINE START STOP” switch still cannot be operated, contact your Toyota dealer. ■ Stopping the engine Shift the shift lever to P and press the “ENGINE START STOP” switch as you normally do when stopping the engine.
Page 472 You can call your Toyota dealer or qualified repair shop. If you have a set of jumper (or booster) cables and a second vehi- cle with a 12-volt battery, you can jump start your Toyota following the steps below. STEP...
Page 473 Once the vehicle’s engine has started, remove the jumper cables in the exact reverse order in which they were con- nected. Once the engine starts, have the vehicle checked at your Toyota dealer as soon as possible. ■ Starting the engine when the battery is discharged The engine cannot be started by push-starting.
Page 474 5-2. Steps to take in an emergency CAUTION ■ Avoiding battery fires or explosions Observe the following precautions to prevent accidentally igniting the flam- mable gas that may be emitted from the battery. ● Make sure the jumper cable is connected to the correct terminal and that it is not unintentionally in contact with any part other than the intended termi- nal.
Page 475 Wait until the temperature of the engine (shown on the instrument cluster) begins to fall and then stop the engine. If the fans are not operating: Stop the engine and call your Toyota dealer. After the engine has cooled STEP...
Page 476 5-2. Steps to take in an emergency Have the vehicle checked at the nearest Toyota dealer as soon as possible. ■ Overheating If you observe the following, your vehicle may be overheating. ● The engine coolant temperature gauge enters the red zone or a loss of power is experienced.
Page 477 5-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt, or snow. STEP Stop the engine. Set the parking brake and put the shift lever in P.
Page 478 5-2. Steps to take in an emergency NOTICE ■ To avoid damaging the transmission and other components ● Avoid spinning the wheels and do not rev the engine. ● If the vehicle remains stuck after trying these procedures, the vehicle may require towing to be freed.
Page 479 5-2. Steps to take in an emergency If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the following pro- cedure: STEP Steadily step on the brake pedal with both feet and firmly...
Page 480 5-2. Steps to take in an emergency Vehicles with a smart key sys- STEP tem: Stop the engine by press- ing and holding the “ENGINE START STOP” switch for 3 consecutive seconds or more. Press and hold for 3 seconds or more STEP Stop the vehicle in a safe place by the road.
Page 481 5-2. Steps to take in an emergency...
Page 482 6-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weights 178.7 in. (4540 mm)* 180.7 in. (4590 mm)* Overall length 180.9 in. (4595 mm)* 181.1 in. (4600 mm)* 181.9 in. (4620 mm)* Without over fender 71.5 in. (1815 mm) Overall width With over fender 73.0 in.
Page 483 6-1. Specifications 2.5 L 4-cylinder (2AR-FE) engine 1500 lb. (680 kg) Trailer Weight Rating 3.5 L V6 (2GR-FE) engine (Trailer weight + cargo weight) 2000 lb. (905 kg) 3500 lb. (1585 kg)* : Without spare tire : 215/70R16 tires : 225/65R17 tires : 235/55R18 tires : With spare tire cover : Unladen vehicle...
Page 484 Vehicle identification number The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
Page 485 6-1. Specifications ■ Engine number The engine number is stamped on the engine block as shown. 2.5 L 4-cylinder (2AR-FE) engine 3.5 L V6 (2GR-FE) engine Engine Model 2AR-FE 2GR-FE 4-cylinder in line, 6-cylinder V type, Type 4-cycle, gasoline 4-cycle, gasoline 3.54 ×...
Page 486 ■ Engine oil selection “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: ILSAC multigrade engine oil...
Page 487 6-1. Specifications Recommended viscosity: 2.5 L 4-cylinder (2AR-FE) engine SAE 5W-20 or 0W-20 SAE 5W-20 or 0W-20 engine oil may be used. However, SAE 0W-20 is the best choice for good fuel economy and good starting in cold weather. Outside temperature Oil viscosity (0W-20 is explained here as an example): ●...
Page 488 6-1. Specifications 3.5 L V6 (2GR-FE) engine SAE 5W-30 SAE 5W-30 is the best choice for good fuel economy and good starting in cold weather. If SAE 5W-30 is not available, SAE 10W-30 oil may be used. However, it should be replaced with SAE 5W-30 at the next oil Outside temperature change.
Page 489 3.5 L V6 (2GR-FE) engine 9.4 qt. (8.9 L, 7.8 Imp. qt.) 9.8 qt. (9.3 L, 8.2 Imp. qt.)* Use either of the following. • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based Coolant type non-silicate, non-amine, non-nitrite, and...
Page 490 NOTICE ■ Automatic transmission fluid type Using automatic transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of your transmission accompanied by vibration, and ultimately damage the automatic transmis- sion of your vehicle.
Page 491 6-1. Specifications Transfer (4WD models) Oil capacity 0.48 qt. (0.45 L, 0.40 Imp. qt.) Oil type Hypoid gear oil API GL-5 Above 0°F (-18°C): SAE 90 Recommended oil viscosity Below 0°F (-18°C): SAE 80W or SAE 80W-90 Brakes Pedal clearance* Without third seats 3.7 in.
Page 492 6-1. Specifications Tires and wheels Type A 215/70R16 99H, 225/65R17 101H, Tire size 235/55R18 99H Tire inflation pressure Front: 32 psi (220 kPa, 2.2 kgf/cm or bar) (Recommended cold tire Rear: 32 psi (220 kPa, 2.2 kgf/cm or bar) inflation pressure) Spare: 32 psi (220 kPa, 2.2 kgf/cm or bar) 16 ×...
Page 493 6-1. Specifications Light bulbs Light Bulbs Bulb No. Type Headlights High beam 9005 Low beam 9006 ⎯ Front fog lights* Front turn signal/parking, front 7443 21/5 Exterior side marker lights ⎯ Rear side marker lights Rear turn signal lights 7440 Back-up lights License plate lights ⎯...
Page 494 ASTM D4814 in the U.S.A. and CGSB3.5-M93 in Canada. ■ Fuel tank opening for unleaded gasoline To help prevent incorrect fueling, your Toyota has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps. ■...
Page 495 Toyota allows the use of oxygenate blended gasoline where the oxygen- ate content is up to 10% ethanol or 15% MTBE. ● If you use gasohol in your Toyota, be sure that it has an octane rating no lower than 87. ●...
Page 496 6-1. Specifications NOTICE ■ Notice on fuel quality ● Do not use improper fuels. If improper fuels are used the engine will be damaged. ● Do not use leaded gasoline. Leaded gasoline can cause damage to your vehicle's three-way catalytic converters causing the emission control system to malfunction and the emission control system to function improperly.
Page 497 6-1. Specifications Tire information Typical tire symbols Tire size (→P. 519) DOT and Tire Identification Number (TIN) (→P. 518) Uniform tire quality grading For details, see “Uniform tire quality grading” that follows. Location of treadwear indicators (→P. 401) Run-flat tire (RFT) or standard tire (→P.
Page 498 6-1. Specifications Load limit at maximum cold tire inflation pressure (→P. 404) Maximum cold tire inflation pressure (→P. 512) This means the pressure to which a tire may be inflated. Summer tire or all season tire (→P. 405) An all season tire has “M+S” on the sidewall. A tire not marked “M+S”...
Page 499 6-1. Specifications Tire size ■ Typical tire size information The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 digits or 3 digits) Speed symbol...
Page 500 U.S. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. ■ DOT quality grades All passenger vehicle tires must conform to Federal Safety Requirements in addition to these grades.
Page 501 6-1. Specifications ■ Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a speci- fied government test course. For example, a tire graded 150 would wear one and a half (1 - 1/2) times as well on the government course as a tire graded 100.
Page 502 6-1. Specifications Warning: The temperature grades for this tire are established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either sepa- rately or in combination, can cause heat buildup and possible tire fail- ure.
Page 503 6-1. Specifications Tire related term Meaning 150 lb. (68 kg) times the number of occupants Normal occupant specified in the second column of Table 1 that weight follows Distribution of occupants in a vehicle as speci- Occupant distribution fied in the third column of Table 1 below The combined weight of installed regular pro- duction options weighing over 5 lb.
Page 504 6-1. Specifications Tire related term Meaning The surface area of the rim not covered by the Weather side inflated tire The part of the tire that is made of steel wires, Bead wrapped or reinforced by ply cords and that is shaped to fit the rim A breakdown of the bond between components Bead separation...
Page 505 6-1. Specifications Tire related term Meaning The parting of the innerliner from cord material Innerliner separation in the carcass (a) The sidewall that contains a whitewall, bears white lettering, or bears manufac- turer, brand, and/or model name molding that is higher or deeper than the same Intended outboard molding on the other sidewall of the tire, or sidewall...
Page 506 6-1. Specifications Tire related term Meaning A layer of rubber-coated parallel cords A parting of rubber compound between adja- Ply separation cent plies A mechanical device made of rubber, chemi- cals, fabric and steel or other materials, that, Pneumatic tire when mounted on an automotive wheel, pro- vides the traction and contains the gas or fluid that sustains the load...
Page 507 6-1. Specifications Tire related term Meaning That portion of a tire that comes into contact Tread with the road A tread section running circumferentially Tread rib around a tire Tread separation Pulling away of the tread from the tire carcass The projections within the principal grooves Treadwear indicators designed to give a visual indication of the...
Page 508 Your vehicle includes a variety of electronic features that can be personalized to your preferences. Programming these preferences requires specialized equipment and may be performed by your Toyota dealer. Some function settings are changed simultaneously with other functions being customized. Contact your Toyota dealer. Customized Item Function Default setting...
Page 509 6-2. Customization Customized Item Function Default setting setting Wireless Operation signal remote con- (Buzzer) trol → P. 40) Panic function Driver's door Door lock unlocked in one All doors → P. 44, Unlocking using a key step, all doors unlocked in one 489) unlocked in two step...
Page 510 6-2. Customization Customized Item Function Default setting setting Seat belt Vehicle speed linked reminder seat belt reminder → P. 456) buzzer...
Page 511 6-3. Initialization Items to initialize The following items must be initialized for normal system operation in cases such as after the battery is reconnected, or maintenance is performed on the vehicle. Item When to initialize Reference After reconnecting or changing the Power window P.
Page 512 6-3. Initialization...
Page 513 If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800-331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 514 Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English. Utilisation correcte des ceintures de sécurité...
Page 515 ATTENTION ■ Lorsque vous utilisez la ceinture de sécurité du siège central de la deuxième rangée N'utilisez pas la ceinture de sécurité du siège central de deuxième rangée si l'une des 2 boucles est déverrouillée. Si une seule des boucles est verrouillée, ceci peut entraîner des blessures graves, voire mortelles en cas de freinage brusque ou de collision.
Page 516 SRS airbag instructions for Canadian owners (in French) The following is a French explanation of SRS airbag instructions extracted from the SRS airbag section in this manual. See the SRS airbag section for more detailed SRS airbag instruc- tions in English. Sacs de sécurité...
Page 517 Sacs de sécurité gonflables latéraux et rideau Sacs de sécurité gonflables latéraux Participent à la protection du thorax des occupants des sièges avant. Sacs de sécurité gonflables rideau Participent principalement à la protection de la tête des occupants assis aux places extérieures.
Page 518 Composition du système de sacs de sécurité gonflables Sacs de sécurité gonflables Voyant SRS rideau Sac de sécurité gonflable Sacs de sécurité gonflables conducteur latéraux Capteur de la position du Sac de sécurité gonflable siège conducteur passager avant Contacteur de boucle de Capteurs sacs ceinture...
Page 519 Votre véhicule est équipé de ADVANCED AIRBAGS conçus selon les normes de sécurité américaines applicables aux véhicules à moteur (FMVSS208). Le boîtier électronique (ECU) des sacs de sécurité gonflables régule le déploiement de ces derniers sur la base des informations qu'il reçoit des capteurs, etc. indiqués ci-dessus dans le schéma illustrant composants...
Page 520 ATTENTION ■ Précautions à observer avec les sacs de sécurité gonflables SRS Respectez les précautions suivantes avec les sacs de sécurité gonflables. À défaut, des blessures graves, voire mortelles, pourraient s'ensuivre. ● Le conducteur et tous les passagers à bord du véhicule doivent porter leur ceinture de sécurité...
Page 521 être grièvement blessés ou tués par le déploiement d'un sac de sécurité gonflable. Installez les enfants trop jeunes pour pouvoir utiliser la ceinture de sécurité dans un siège de sécurité enfant. Toyota recommande vivement que les nourrissons et les jeunes enfants soient installés sur le siège arrière du véhicule et convenablement attachés.
Page 522 ATTENTION ■ Précautions à observer avec les sacs de sécurité gonflables SRS ●Ne vous asseyez pas sur le bord du siège et ne vous appuyez pas contre la planche de bord. ●Ne laissez pas un enfant rester debout devant le sac de sécurité gonflable SRS passager avant ou bien s'asseoir sur les genoux du passager avant.
Page 523 ATTENTION ■ Précautions à observer avec les sacs de sécurité gonflables SRS ● Ne fixez ni ne posez aucun objet sur la planche de bord ou la garniture centrale du volant de direction. Au déploiement des sacs de sécurité gonflables SRS conducteur et passager avant, tout objet...
Page 524 ● Si les parties renfermant les sacs de sécurité gonflables SRS, telles que la garniture du moyeu de volant et les garnitures de montants avant et arrière, apparaissent abîmées ou craquelées, faites-les remplacer par votre concessionnaire Toyota.
Page 525 ■ Modification et mise au rebut des éléments du système de sacs de sécurité gonflables SRS Consultez impérativement votre concessionnaire Toyota si vous avez besoin d'intervenir sur votre véhicule ou de procéder à l'une des modifications suivantes. Les sacs de sécurité gonflables SRS risquent de ne pas fonctionner correctement ou de se déployer (gonfler) accidentellement, provoquant ainsi...
Page 526 What to do if... What to do if... If you have a flat tire A tire punctures P. 467 P. 486 If the engine will not start The engine does not start P. 97 Engine immobilizer system P. 491 If the battery is discharged If the shift lever cannot be shifted The shift lever cannot be P.
Page 527: Warning Lights
What to do if... ■Warning lights Brake system warning Electric power steering sys- light tem warning light P. 455 Active Torque Control 4WD sys- tem warning light P. 454 P. 455 Low fuel level warning Charging system warn- light ing light P.
Page 528 What to do if... “ABS” warning light Tire pressure warning light P. 456 Smart key system warn- ing light P. 455 P. 460 Slip indicator light Cruise control indicator light* P. 455 P. 455 : The light flashes to indicate a malfunction.
Page 529: Gas Station Information
P. 512 pressure Engine oil capacity (Drain and refill ⎯ P. 506 reference) Toyota Genuine Motor Oil or equivalent Oil grade: P. 506 ILSAC multigrade engine oil Engine oil type Recommended oil viscosity: SAE 5W-20 or 0W-20 (2.5 L 4-cylinder [2AR-FE] engine) SAE 5W-30 (3.5 L V6...

This manual is also suitable for:

Rav4 2012

Toyota 2012 Rav4 Owner's Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Toyota 2012 Rav4

Summary of Contents for Toyota 2012 Rav4

This manual is also suitable for:

Table of Contents
