TABLE OF CONTENTS

AUTO

1

ACCESS SEAT

Maintenance

2

When trouble

3

arises

Index

This manual contains information about the AUTO

ACCESS SEAT. Refer to the "Owner's Manual" for other

information regarding your vehicle.

SIENNA AAS_U (OM45471U)

Information regarding the AUTO ACCESS SEAT,

including usage procedure

Checking fuses and replacing the battery of the

wireless remote control

Points to check when you think a malfunction has

occurred

Alphabetical listing of information contained in this

manual

1

Table of Contents

Advertisement

Table of Contents

Need help?

Need help?

Do you have a question about the 2012 Sienna and is the answer not in the manual?

Questions and answers

Summary of Contents for Toyota 2012 Sienna

Page 1 TABLE OF CONTENTS AUTO Information regarding the AUTO ACCESS SEAT, ACCESS SEAT including usage procedure Checking fuses and replacing the battery of the Maintenance wireless remote control When trouble Points to check when you think a malfunction has arises occurred Alphabetical listing of information contained in this Index manual...
Page 2: Table Of Contents
TABLE OF CONTENTS Index AUTO ACCESS SEAT When trouble arises 1-1. AUTO ACCESS SEAT 3-1. When you think a malfunction has occurred AUTO ACCESS SEAT ... 6 AUTO ACCESS SEAT ..44 Head restraint......9 If the AUTO ACCESS SEAT Armrests .......
Page 3 Pictorial index AUTO ACCESS SEAT Seatback angle Head restraint P. 9 adjustment switch P. 6 Armrests P. 11 Seat position adjustment switch P. 6 Footrest P. 13 Seat position Wireless remote control adjustment switch P. 16 P. 6 Seat raise/lower switch P.
Page 4 This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.
Page 5: Auto Access Seat
1-1. AUTO ACCESS SEAT AUTO ACCESS SEAT Seat position adjustment switch Seatback angle adjustment switch Operating condition ■ The seat position and seatback angle cannot be adjusted if the AUTO ACCESS SEAT is not stowed correctly inside the vehicle. Seat movement amount ■...
Page 6 1-1. AUTO ACCESS SEAT Disconnecting the battery ■ Do not disconnect the battery while operating the AUTO ACCESS SEAT. The AUTO ACCESS SEAT will become inoperable. If the battery is disconnected during operation and the AUTO ACCESS SEAT becomes inoperable, reconnect the battery and refer to P. 47. CAUTION Wearing a seat belt ■...
Page 7 1-1. AUTO ACCESS SEAT CAUTION Seatback angle adjustment ■ Do not recline the seat more than necessary when the vehicle is in motion to reduce the risk of sliding under the lap belt. If the seat is too reclined, the lap belt may slide past the hips and apply restraint forces directly to the abdomen or your neck may contact the shoul- der belt, increasing the risk of death or serious injury in the event of an acci- dent.
Page 8: Head Restraint
1-1. AUTO ACCESS SEAT Head restraint Head restraint is provided for the AUTO ACCESS SEAT. Pull the head restraint up. Down Lock release Push the head restraint down button while pressing the lock release button. Adjusting the height of the head restraint ■...
Page 9 1-1. AUTO ACCESS SEAT Installing the head restraint ■ Align the head restraint with the installa- tion holes and push it down to the lock position. Press and hold the lock release button when lowering the head restraint. CAUTION Head restraint precautions ■...
Page 10: Armrests
1-1. AUTO ACCESS SEAT Armrests Lower the armrests as far as they will go when rotating or raising/ lowering the AUTO ACCESS SEAT. Raise Lower Wearing the seat belt ■ Wearing the seat belt is easier with the armrest raised. SIENNA AAS_U (OM45471U)
Page 11 1-1. AUTO ACCESS SEAT CAUTION When wearing the seat belt ■ Wear the seat belt correctly, passing it underneath the armrest. If the seat belt is caught on the armrest, it may not be fully effective, which could cause death or serious injury in the event of a sudden braking, sudden swerving or an accident.
Page 12: Footrest
1-1. AUTO ACCESS SEAT Footrest Lower the footrest as far as it will go when rotating or raising/lower- ing the AUTO ACCESS SEAT. Raise Lower CAUTION When operating the footrest ■ Operate the footrest by holding the front edge. You may be injured if your fingers get caught in the rotating parts. SIENNA AAS_U (OM45471U)
Page 13: Correct Riding Posture
1-1. AUTO ACCESS SEAT Correct riding posture Maintain the correct posture while sitting in the seat, as follows: while keeping both knees aligned and inside the AUTO ACCESS SEAT. Lower the armrests and keep both arms inside the armrests and inside the AUTO ACCESS SEAT.
Page 14 1-1. AUTO ACCESS SEAT CAUTION When sitting in the seat ■ When the seat is being used by a person who is unable to bend his/her ● knees or neck, or by a person that is unable to sit far back in the seat, be careful as their head, feet etc.
Page 15: Wireless Remote Control
1-1. AUTO ACCESS SEAT Wireless remote control The wireless remote control can be used to rotate and raise or lower the AUTO ACCESS SEAT. Indicator light Seat raise switch Seat lower switch Effective range Approximately 3.3 ft. (1 m) from the AUTO ACCESS SEAT SIENNA AAS_U (OM45471U)
Page 16 1-1. AUTO ACCESS SEAT Operating conditions ■ The effective range of the wireless remote control changes in accor- ● dance with surroundings. Interference from other radio waves may cause the AUTO ACCESS ● SEAT to stop moving temporarily even when pressing the wireless remote control switches.
Page 17: The Auto Access Seat
When replacing either the transmitter or the receiver of the wireless ■ remote control It is necessary to replace both the transmitter and the receiver. Contact your Toyota dealer. Certification for the wireless remote control ■ U.S.A. FCC ID: HYQ12BDF...
Page 18: The Auto Access Seat
1-1. AUTO ACCESS SEAT CAUTION Wireless remote control precautions ■ Observe the following precautions to reduce the risk of injury. Operate the AUTO ACCESS SEAT from a position from which you can ● see the occupant of the seat. Make sure that the occupant’s head, arms and legs will not get caught ●...
Page 19: 1-2. Operating The Auto Access Seat
1-2. Operating the AUTO ACCESS SEAT Before operating the AUTO ACCESS SEAT The AUTO ACCESS SEAT (right-hand second seat) can be rotated, raised and lowered electrically to help the seat occupant easily enter and exit the vehicle. Have all operations carried out by an assistant. Park the vehicle on a flat surface and leave the engine run- STEP ning.
Page 20 1-2. Operating the AUTO ACCESS SEAT Fold the front passenger seat- STEP back while pulling the seat- back angle lever. Unfasten the seat belt on the AUTO ACCESS SEAT. STEP Adjust the armrest and foot STEP restraint AUTO ACCESS SEAT to the down- most position.
Page 21 1-2. Operating the AUTO ACCESS SEAT Beep sounds ■ The beep makes the following sounds in response to operating procedures and conditions. Beep Operation/Condition When the wireless remote control switches or the seat raise/lower switch is pressed and the AUTO ACCESS SEAT Once operates.
Page 22 1-2. Operating the AUTO ACCESS SEAT CAUTION When operating the AUTO ACCESS SEAT ■ Do not operate while parked on an ● incline or on uneven ground. The occu- pant may fall from the seat or from their wheelchair, or you may be hit by the wheelchair while putting it away, possi- bly causing an injury.
Page 23 1-2. Operating the AUTO ACCESS SEAT CAUTION When operating the AUTO ACCESS SEAT ■ Do not place luggage or hands and feet ● underneath around AUTO ACCESS SEAT. Hands and feet could get caught, possi- bly resulting in an injury. Make sure that the seat belt is unbuckled.
Page 24 1-2. Operating the AUTO ACCESS SEAT NOTICE To prevent seat damage ■ Before operating the AUTO ACCESS SEAT, make sure that there are no ● luggage items or other obstacles around the moving parts of the seat. The AUTO ACCESS SEAT may be damaged if it hits an obstacle. The load capacity of the AUTO ACCESS SEAT is 330 lb.
Page 25: Moving The Auto Access Seat Outside The Vehicle
1-2. Operating the AUTO ACCESS SEAT Moving the AUTO ACCESS SEAT outside the vehicle Park the vehicle on a flat surface and leave the engine run- STEP ning. Shift the shift lever to P and set the parking brake. STEP Confirm the following: STEP •...
Page 26 1-2. Operating the AUTO ACCESS SEAT The beep will sound once, and the AUTO ACCESS SEAT will begin to move automatically. The indicator light on the wire- less remote control will flash. The AUTO ACCESS SEAT will rotate while the seat- back reclines and while moving towards the front of the vehicle.
Page 27 1-2. Operating the AUTO ACCESS SEAT Operating conditions ■ Under the following conditions, the seat will not rotate or lower even if the seat lower switch is pressed. The right-hand sliding door is not opened completely. ● The seat belt is caught up in the AUTO ACCESS SEAT. ●...
Page 28 1-2. Operating the AUTO ACCESS SEAT CAUTION Before moving the AUTO ACCESS SEAT outside the vehicle ■ Check that the right-hand third seat occupant is safe. ● Do not try to close the right-hand sliding ● door while operating AUTO ACCESS SEAT.
Page 29: Returning The Auto Access Seat To The Vehicle
1-2. Operating the AUTO ACCESS SEAT Returning the AUTO ACCESS SEAT to the vehicle Park the vehicle on a flat surface and leave the engine run- STEP ning. Shift the shift lever to P and set the parking brake. STEP Confirm the following: STEP •...
Page 30 1-2. Operating the AUTO ACCESS SEAT The beep will sound once, and the AUTO ACCESS SEAT will begin to move automatically while seatback reclines. The indicator light on the wire- less remote control will flash. The AUTO ACCESS SEAT will rotate while the seat- back raises and while mov- ing towards the rear of the vehicle.
Page 31 1-2. Operating the AUTO ACCESS SEAT Jam protection function ■ If the operation of the AUTO ACCESS SEAT is interrupted by collision with an obstacle etc., the beep will sound twice and the seat will retreat slightly and then stop. If this happens, make sure that the hands, feet etc. of the occupant will not hit the body of the vehicle, and operate the seat once again after removing the obstacle.
Page 32 1-2. Operating the AUTO ACCESS SEAT CAUTION When the AUTO ACCESS SEAT has been returned to the vehicle ■ Shake the AUTO ACCESS SEAT gen- ● tly to check that the seat is stowed properly. If not stowed properly, the seat may move unexpectedly, and could cause injuries.
Page 33 1-2. Operating the AUTO ACCESS SEAT NOTICE To prevent AUTO ACCESS SEAT damage ■ Press and hold the wireless remote control switches, instead of pressing ● them repeatedly. Wait for approximately 1 second before changing to another switch. ● Open the right-hand sliding door fully before returning the AUTO ACCESS ●...
Page 34: Operating With The Seat Raise/Lower Switch
1-2. Operating the AUTO ACCESS SEAT Operating with the seat raise/lower switch If the battery of the wireless remote control has discharged or another malfunction has occurred, the seat raise/lower switch can be used to operate the AUTO ACCESS SEAT. (The AUTO ACCESS SEAT will operate in the same way as when operated using the wire- less remote control).
Page 35 1-2. Operating the AUTO ACCESS SEAT When the AUTO ACCESS SEAT stops automatically, STEP release the switch. When returning the AUTO ACCESS SEAT to the vehicle, release the switch after the seat has stopped automatically and the beep has sounded once. Seat raise/lower switch ■...
Page 36 1-3. Adjustable components (seats, mirrors, steering wheel) Front seats Manual seat Seat position adjustment lever Seatback angle adjustment lever Vertical height adjustment lever (driver’s side only) Lumbar support adjustment knob (driver’s side only) SIENNA_U (OM45477U)
Page 37 1-3. Adjustable components (seats, mirrors, steering wheel) Power seat Seat position adjustment switch Seatback angle adjustment switch Seat cushion (front) angle adjustment switch (driver’s side only) Vertical height adjustment switch (driver’s side only) Lumbar support adjustment switch (driver’s side only) SIENNA_U (OM45477U)
Page 38 1-3. Adjustable components (seats, mirrors, steering wheel) Power easy access system (vehicles with driving position memory) When the driver enters and exits the vehicle, the driver’s seat will automatically perform the following operations: Exiting the vehicle: When all of the following actions have been performed, the seat will move backward (auto away function): •...
Page 39 1-3. Adjustable components (seats, mirrors, steering wheel) Entering vehicle: When either of the following actions has been performed, the seat will move forward (auto return function): • Vehicles without a smart key sys- tem: The engine switch has been turned to the “ACC” position. Vehicles with a smart key system: The “ENGINE START STOP”...
Page 40 1-3. Adjustable components (seats, mirrors, steering wheel) Active head restraints ■ Even small forces applied to the seatback may cause the head restraint to move. When a locked head restraint is pushed up forcibly, the head restraint inner structure may appear. This does not indicate a problem. During rear-end collision...
Page 41 1-3. Adjustable components (seats, mirrors, steering wheel) Rear seats Second seats (Tip-up seat) Seat position adjustment lever Seatback angle adjustment lever Second seats (Ottoman seat) Seat position adjustment lever Seatback angle adjustment lever Ottoman angle adjustment lever Second seats (AUTO ACCESS SEAT) Refer to “AUTO ACCESS SEAT OWNER’S MANUAL”.
Page 42 1-3. Adjustable components (seats, mirrors, steering wheel) Third seats (manual seat) Seatback angle adjustment strap Third seats (power seat) Seatback angle adjustment switch SIENNA_U (OM45477U)
Page 43 1-3. Adjustable components (seats, mirrors, steering wheel) Moving a second seat for third seat access Getting in the vehicle ■ Tip-up seats Pull the seatback angle adjust- ment lever and fold down the seatback. The cushion will tip up. The seat can slide forward. Move the seat to the frontmost position.
Page 44 1-3. Adjustable components (seats, mirrors, steering wheel) Getting out of the vehicle ■ Tip-up seats Pull the strap and fold down the seatback. The cushion will tip up. The seat can slide forward. Move the seat to the frontmost position. Make sure that no passenger is seated on the second seat before pulling the strap.
Page 45 1-3. Adjustable components (seats, mirrors, steering wheel) Removing the second seats Removing the second outside seats (Tip-up seats) ■ Pull the armrests up. STEP Pull the seatback adjustment lever and fold down the seat- back. The cushion will tip up. Slide the seat forward to a lock position.
Page 46 1-3. Adjustable components (seats, mirrors, steering wheel) Removing the second outside seats (Ottoman seats) ■ Pull the armrests up. STEP Pull the seatback adjustment lever and fold down the seat- back. Slide the seat to a forward lock position. STEP Pull the release lever behind the STEP seatback straight back, then up.
Page 47 1-3. Adjustable components (seats, mirrors, steering wheel) Removing the second center seat (if equipped) ■ Pull the lock release strap and STEP fold down the second center seatback. Make sure that the head restraint is in the lowest position. Pull the lock release strap under STEP the seat to remove the seat.
Page 48 1-3. Adjustable components (seats, mirrors, steering wheel) Installing the second seats Installing the second outside seats ■ Align the marking on the seat side cover to the marking on the STEP rail cover. Tip-up seat Align the marking on the seat front cover to the rail.
Page 49 1-3. Adjustable components (seats, mirrors, steering wheel) Lower the seat and engage the latches. STEP If you locked the seat latches unintentionally before installing securely, pull the release lever to unlock the latches. Make sure the seat is locked in place by trying to shake the seatback and lift up the seat cushion.
Page 50 1-3. Adjustable components (seats, mirrors, steering wheel) Folding down the third seats (manual seats) Before folding the third seats ■ Fold the outside head restraints STEP and lower the center head restraint to the lowest position, and stow the seat belt buckles. ITN13N045 Stow the center seat belt.
Page 51 1-3. Adjustable components (seats, mirrors, steering wheel) Folding down the third seats (power seats) You can operate the power third seats when the shift lever is in P. Before folding the third seats ■ Lower the center head restraints STEP to the lowest position and stow the seat belt buckles.
Page 52 1-3. Adjustable components (seats, mirrors, steering wheel) Stowing the third seats (manual seats) Before stowing or returning third seat, remove any items from the floor area to prevent interference with moving parts. Before stowing the third seats ■ Lower the center head restraint STEP to the lowest position, and stow the seat belt buckles.
Page 53 1-3. Adjustable components (seats, mirrors, steering wheel) Push the seat against the floor STEP and make sure it is locked securely. Open the flaps. Before returning the third seats ■ Be sure to move the second seats forward from the rearmost posi- tion, as they may interfere with the third seats returning operation.
Page 54 1-3. Adjustable components (seats, mirrors, steering wheel) Stowing the third seats (power seats) You can operate the power third seats when the shift lever is in P. Before stowing or returning third seat, remove any items from the floor area to prevent interference with moving parts. Before stowing the third seats ■...
Page 55 1-3. Adjustable components (seats, mirrors, steering wheel) Open the flaps. STEP ITN13N056 Before returning the third seats ■ Be sure to move the second seats forward from the rearmost posi- tion, as they may interfere with the third seats returning operation. Returning the third seats ■...
Page 56 1-3. Adjustable components (seats, mirrors, steering wheel) Power third seat ■ If the indicator light above the switches flashes three times when the fold- ● ing/returning switch is pressed, the folding operation will not start. Make sure the shift lever is in P. If any of the following conditions occur while the seat is operating, the ●...
Page 57 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION When folding the rear seatbacks down ■ Observe the following precautions. Failure to do so may result in death or serious injury. Do not fold the seatbacks down while driving. ● Stop the vehicle on level ground, set the parking brake and shift the shift ●...
Page 58 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION After returning the rear seatbacks or installing seats ■ Observe the following precautions. Failure to do so may result in death or serious injury. Make sure the seatback is securely locked by pushing it forward and rear- ●...
Page 59 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION When adjusting the seat position or the ottoman (vehicles with Otto- ■ man seats) Make sure to leave enough space around the feet so as not to get them caught. When using the ottoman (vehicles with Ottoman seats) ■...
Page 60 1-3. Adjustable components (seats, mirrors, steering wheel) NOTICE Stowing the seat belt ■ The seat belts and the buckles must be stowed before you fold down the rear seatbacks. To prevent an ottoman malfunction (vehicles with Ottoman seats) ■ Do not place any objects in the second passenger footwell that could pre- ●...
Page 61 1-3. Adjustable components (seats, mirrors, steering wheel) ∗ Driving position memory Your preferred driving position (the position of the driver’s seat and outside rear view mirrors) can be memorized and recalled with the touch of a button. It is also possible to set this function to activate automatically when the doors are unlocked.
Page 62 1-3. Adjustable components (seats, mirrors, steering wheel) Recalling the memorized position ■ Check that the shift lever is in P. Vehicles without a smart key system STEP Turn the engine switch to the “ON” position. Vehicles with a smart key system Turn the “ENGINE START STOP”...
Page 63 1-3. Adjustable components (seats, mirrors, steering wheel) Linking driving position memory with door unlock operation Record your driving position to button “1” or “2” before performing the following: Vehicles without a smart key system Carry only the wireless remote control to which you want to link the driving position.
Page 64 1-3. Adjustable components (seats, mirrors, steering wheel) Vehicles with a smart key system Carry only the electronic key to which you want to link the driving position. If 2 or more keys are in the vehicle, the driving position can- not be linked properly.
Page 65 1-3. Adjustable components (seats, mirrors, steering wheel) Operating the driving position memory after turning the engine off ■ Vehicles without a smart key system Memorized positions can be activated up to 180 seconds after the driver’s door is opened and another 60 seconds after it is closed again, even after turning the engine switch to the “LOCK”...
Page 66 1-3. Adjustable components (seats, mirrors, steering wheel) Head restraints Head restraints are provided for all seats. Front and second outside seats Pull the head restraints up. Down Push the head restraint down while pressing the lock release button. Lock release button Second center and third center seats Pull the head restraints up.
Page 67 1-3. Adjustable components (seats, mirrors, steering wheel) Adjusting the height of the head restraints ■ Make sure that the head restraints are adjusted so that the center of the head restraint is closest to the top of your ears. Adjusting the center seat head restraints ■...
Page 68 1-3. Adjustable components (seats, mirrors, steering wheel) Installing the head restraints (front, second and third center seats) ■ Align the head restraint with the installa- tion holes and push it down to the lock position. Press and hold the lock release button when lowering the head restraint.
Page 69 1-3. Adjustable components (seats, mirrors, steering wheel) Seat belts Make sure that all occupants are wearing their seat belts before driv- ing the vehicle. Correct use of the seat belts ■ Extend the shoulder belt so that it comes fully over the shoulder, does come into contact with the...
Page 70 1-3. Adjustable components (seats, mirrors, steering wheel) Adjusting the seat belt shoulder anchor height (front and ■ second outside Tip-up seats) Push the seat belt shoulder anchor down while pressing the release button. Push the seat belt shoulder anchor up. Move the height adjuster up and down as needed until you hear a click.
Page 71 1-3. Adjustable components (seats, mirrors, steering wheel) Release method ■ The belt can be completely released when not required, such as when folding down the third seat. Insert the key or tab “A” into the STEP hole on the center seat belt buckle to release the hooked tab “B”...
Page 72 1-3. Adjustable components (seats, mirrors, steering wheel) Seat belt pretensioners (front seats) The pretensioner helps the seat belt to quickly restrain the occu- pant by retracting the seat belt when the vehicle is subjected to certain types of severe frontal collision.
Page 73 1-3. Adjustable components (seats, mirrors, steering wheel) Pregnant women ■ Obtain medical advice and wear the seat belt in the proper way. (→P. 128) Women who are pregnant should position the lap belt as low as possible over the hips in the same manner as other occu- pants.
Page 74 Each seat belt should be used by one person only. Do not use a seat belt ● for more than one person at once, including children. Toyota recommends that children be seated in the rear seat and always ● use a seat belt and/or an appropriate child restraint system.
Page 75 If the pretensioner has activated, the SRS warning light will come on. In ● that case, the seat belt cannot be used again and must be replaced at your Toyota dealer. SIENNA_U (OM45477U)
Page 76 Ensure that the belt and tab are locked and the belt is not twisted. ● If the seat belt does not function correctly, immediately contact your Toyota dealer. Replace the seat assembly, including the belts, if your vehicle has been ●...
Page 77 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION When using the third center seat belt ■ Do not use the third center seat belt with either buckle released. Fastening only one of the buckles may result in death or serious injury in case of sudden braking or a collision.
Page 78 1-3. Adjustable components (seats, mirrors, steering wheel) Steering wheel The steering wheel can be adjusted to a comfortable position. Hold the steering wheel and STEP press the lever down. Adjust to the ideal position by STEP moving the steering wheel horizontally and vertically.
Page 79 1-3. Adjustable components (seats, mirrors, steering wheel) Inside rear view mirror Glare from the headlights of vehicles behind can be reduced by using the following functions. Manual anti-glare inside rear view mirror Normal position Anti-glare position Auto anti-glare inside rear view mirror In automatic mode, sensors are used to detect the headlights of vehicles behind and the reflected light is automatically reduced.
Page 80 1-3. Adjustable components (seats, mirrors, steering wheel) Adjusting the height of rear view mirror Adjust the height of the rear view mirror by moving it up and down. To prevent sensor error (vehicles with auto anti-glare inside rear view ■ mirror) To ensure that the sensors operate prop- erly, do not touch or cover them.
Page 81 1-3. Adjustable components (seats, mirrors, steering wheel) Outside rear view mirrors Mirror angle can be adjusted using the switch. To select a mirror to adjust, STEP press the switch. Left Right To adjust the mirror, press the STEP switch. Right Down Left SIENNA_U (OM45477U)
Page 82 1-3. Adjustable components (seats, mirrors, steering wheel) Folding back the mirrors Manual type Push the mirror back in the direc- tion of the vehicle’s rear. Power type Press the switch to fold the mir- rors. Press it again to extend them to the original position.
Page 83 1-3. Adjustable components (seats, mirrors, steering wheel) Mirror angle can be adjusted when ■ Vehicles without a smart key system The engine switch is in the “ACC” or “ON” position. Vehicles with a smart key system The “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode.
Page 84 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION When driving the vehicle ■ Observe the following precautions while driving. Failing to do so may result in loss of control of the vehicle and cause an acci- dent, resulting in death or serious injury. Do not adjust the mirrors while driving.
Page 85 1-4. Opening and closing the windows and moon roof Power windows The power windows can be opened and closed using the switches. Operating the switch moves the windows as follows: Closing One-touch closing Opening One-touch opening : Pressing the switch in the opposite direction will stop win- dow travel partway.
Page 86 1-4. Opening and closing the windows and moon roof The power windows can be operated when ■ Vehicles without a smart key system The engine switch is in the “ON” position. Vehicles with a smart key system The “ENGINE START STOP” switch is in IGNITION ON mode. Operating the power windows after turning the engine off ■...
Page 87 If you release the switch while the window is moving, start again from the beginning. If the window continues to close but then re-open slightly even after performing the above procedure correctly, have the vehicle inspected by your Toyota dealer. SIENNA_U (OM45477U)
Page 88 1-4. Opening and closing the windows and moon roof CAUTION Closing the windows ■ Observe the following precautions. Failing to do so may result in death or serious injury. Check to make sure that all passengers do not have any part of their body ●...
Page 89 1-4. Opening and closing the windows and moon roof Quarter windows The quarter windows can be opened to bring in fresh outside air for additional ventilation. Manual type Pull the handle and swing the window fully out to open. Power type Opening Closing Both the left and right quarter...
Page 90 1-4. Opening and closing the windows and moon roof The windows can be operated when (power type) ■ Vehicles without a smart key system The engine switch is in the “ON” position. Vehicles with a smart key system The “ENGINE START STOP” switch is in IGNITION ON mode. Operating the windows after turning the engine off (power type) ■...
Page 91 1-4. Opening and closing the windows and moon roof ∗ Moon roof Use the overhead switches to open and close the moon roof. Front moon roof ■ Opens the moon roof The moon roof will stop at the tilt up position once. To tilt down, press the opposite side of the switch.
Page 92 1-4. Opening and closing the windows and moon roof Rear moon roof (if equipped) ■ Opens the moon roof The moon roof stops just before it is opened fully. Press the switch again to open fully. Closes the moon roof : Lightly press either of the roof switches to stop the moon roof partway.
Page 93 1-4. Opening and closing the windows and moon roof The moon roof can be operated when ■ Vehicles without a smart key system The engine switch is in the “ON” position. Vehicles with a smart key system The “ENGINE START STOP” switch is in IGNITION ON mode. Operating the moon roof after turning the engine off ■...
Page 94 1-4. Opening and closing the windows and moon roof Sunshade ■ The sunshade can be opened and closed manually. However, both front and rear sunshades open automatically when the moon roof is opened. When the moon roof does not close normally ■...
Page 95 1-4. Opening and closing the windows and moon roof CAUTION Opening the moon roof ■ Observe the following precautions. Failing to do so may cause death or serious injury. Do not allow any passengers to put their hands or heads outside the vehi- ●...
Page 96 1-5. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap: Before refueling the vehicle ■ Vehicles without a smart key system Turn the engine switch off and ensure that all the doors and win- dows are closed.
Page 97 1-5. Refueling Hang the fuel tank cap on the STEP back of the fuel filler door. Closing the fuel tank cap After refueling, turn the fuel tank cap until you hear a click. Once the cap is released, it will turn slightly in the opposite direction.
Page 98 1-5. Refueling CAUTION When refueling the vehicle ■ Observe the following precautions while refueling the vehicle. Failure to do so may result in death or serious injury. After exiting the vehicle and before opening the fuel door, touch an ● unpainted metal surface to discharge any static electricity.
Page 99 When replacing the fuel cap ■ Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 100 1-6. Theft deterrent system ∗ Engine immobilizer system The vehicle’s keys have built-in transponder chips that prevent the engine from starting if a key has not been previously registered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehicle. Vehicles without a smart key system The indicator light flashes after...
Page 101 1-6. Theft deterrent system System maintenance ■ The vehicle has a maintenance-free type engine immobilizer system. Conditions that may cause the system to malfunction ■ If the grip portion of the key is in contact with a metallic object ● If the key is in close proximity to or touching a key to the security system ●...
Page 102 1-6. Theft deterrent system CAUTION Certifications for the immobilizer system ■ Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTICE To ensure the system operates correctly ■ Do not modify or remove the system.
Page 103 1-6. Theft deterrent system ∗ Alarm The system sounds the alarm and flashes the lights when forced entry is detected. Triggering of the alarm ■ The alarm is triggered in the following situations when the alarm is set: ● A locked door is unlocked or opened in any way other than using the entry function, wireless remote control or mechani- cal key.
Page 104 1-6. Theft deterrent system Deactivating or stopping the alarm ■ Do one of the following to deactivate or stop the alarm: ● Unlock the doors. ● Vehicles without a smart key system: Turn the engine switch to the “ACC” or “ON” position, or start the engine. Vehicles with a smart key system: Turn the “ENGINE START STOP”...
Page 105 1-6. Theft deterrent system Triggering of the alarm ■ The alarm may be triggered in the following situations. (Stopping the alarm deactivates the alarm system.) A person inside the vehicle opens a ● door or hood. The battery is recharged or replaced ●...
Page 106 1-6. Theft deterrent system Theft prevention labels (for U.S.A.) These labels are attached to the vehicle to reduce vehicle theft by facilitating the tracing and recovery of parts from sto- len vehicles. Do not remove under penalty of law. SIENNA_U (OM45477U)
Page 107 1-7. Safety information Correct driving posture Drive with a good posture as follows: Sit upright and well back in the seat. (→P. 95) Adjust the position of the seat forward or backward to ensure the pedals can be reached easily depressed to the extent required.
Page 108 1-7. Safety information CAUTION While driving ■ Do not adjust the position of the driver’s seat. ● Doing so could cause the driver to lose control of the vehicle. Do not place a cushion between the driver or passenger and the seatback. ●...
Page 109 1-7. Safety information SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. SIENNA_U (OM45477U)
Page 110 1-7. Safety information SRS front airbags SRS driver airbag/front passenger airbag Can help protect the head and chest of the driver and front pas- senger from impact with interior components. SRS driver knee airbag Can help provide driver protection. SRS side and curtain shield airbags SRS side airbags Can help protect the torsos of the front seat occupants.
Page 111 1-7. Safety information Airbag system components Front passenger airbag Side and curtain shield air- bag sensors Curtain shield airbags Driver’s seat belt buckle Side airbags switch Front passenger occupant Driver’s seat position sen- classification system (ECU and sensors) Driver knee airbag Curtain shield airbag sen- sors Front airbag sensors...
Page 112 1-7. Safety information Your vehicle is equipped with ADVANCED AIRBAGS designed based on US motor vehicle safety standards (FMVSS208). The airbag sys- tem controls airbag deployment power for the driver and front pas- senger. The driver airbag system consists of the driver seat’s position sensor etc.
Page 113 1-7. Safety information If the SRS airbags deploy (inflate) ■ Bruising and slight abrasions may result from contact with a deploying ● (inflating) SRS airbag. A loud noise and white powder will be emitted. ● Parts of the airbag module (steering wheel hub, airbag cover and inflator) ●...
Page 114 1-7. Safety information SRS airbag deployment conditions (SRS front airbags) ■ The SRS front airbag will deploy in the event of an impact that exceeds ● the set threshold level (the level of force corresponding to an approxi- mately 12 - 18 mph [20 - 30 km/h] frontal collision with a fixed wall that does not move or deform).
Page 115 1-7. Safety information Conditions under which the SRS airbags may deploy (inflate), other ■ than a collision The SRS front airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration. Hitting a curb, edge of pavement or ●...
Page 116 1-7. Safety information Types of collisions that may not deploy the SRS airbags (SRS side air- ■ bags and curtain shield airbags) The SRS side airbag and curtain shield airbag system may not activate if the vehicle is subjected to a collision from the side at certain angles, or a colli- sion to the side of the vehicle body other than the passenger compartment.
Page 117 1-7. Safety information When to contact your Toyota dealer ■ In the following cases, contact your Toyota dealer as soon as possible. Any of the SRS airbags have been inflated. ● The front of the vehicle is damaged or ●...
Page 118 1-7. Safety information CAUTION SRS airbag precautions ■ Observe the following precautions regarding the airbags. Failure to do so may cause death or serious injury. The driver and all passengers in the vehicle must wear their seat belts ● properly. The SRS airbags are supplemental devices to be used with the seat belts.
Page 119 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are safer for infants and children than the front passenger seat.
Page 120 1-7. Safety information CAUTION SRS airbag precautions ■ Do not sit on the edge of the seat or ● lean against the dashboard. Do not allow a child to stand in front of ● the SRS front passenger airbag unit or sit on the knees of a front passenger.
Page 121 1-7. Safety information CAUTION SRS airbag precautions ■ Do not attach anything to or lean any- ● thing against areas such as the dash- board or steering wheel pad and lower portion of the instrument panel. These items can become projectiles when SRS driver, front passenger and knee airbags deploy.
Page 122 Wash off any residue as soon as possible to prevent skin irritation. If the areas where the SRS airbags are stored, such as the steering wheel ● pad and front and rear pillar garnishes, are damaged or cracked, have them replaced by your Toyota dealer. SIENNA_U (OM45477U)
Page 123 Modification and disposal of SRS airbag system components ■ Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.
Page 124 1-7. Safety information Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classifica- tion system. This system detects the conditions of the front passen- ger seat and activates or deactivates the devices for the front passenger.
Page 125 1-7. Safety information Conditions and operation of the front passenger occupant classification system Adult ■ “AIR BAG ON” and “AIR BAG OFF” “AIR BAG indicator lights ON” Indicator/ SRS warning light warning light Front passenger’s seat belt reminder Flashing light Front passenger airbag Side airbag on the front passenger seat Devices...
Page 126 1-7. Safety information Unoccupied ■ “AIR BAG ON” and “AIR BAG OFF” indicator lights illuminated Indicator/ SRS warning light warning light Front passenger’s seat belt reminder light Front passenger airbag Deactivated Side airbag on the front passenger seat Devices Activated Curtain shield airbag in the front passenger side Front passenger’s seat belt pretensioner...
Page 127 1-7. Safety information : The system judges a person of adult size as an adult. When a smaller adult sits in the front passenger seat, the system may rec- ognize him/her as a child depending on his/her physique and pos- ture.
Page 128 1-7. Safety information CAUTION Front passenger occupant classification system precautions ■ Observe the following precautions regarding the front passenger occupant classification system. Failure to do so may cause death or serious injury. Wear the seat belt properly. ● Make sure the front passenger’s seat belt plate has not been left inserted ●...
Page 129 Do not kick the front passenger seat or subject it to severe impact. Other- ● wise, the SRS warning light may come on to indicate a malfunction of the detection system. In this case, contact your Toyota dealer immediately. Child restraint systems installed on the rear seat should not contact the ●...
Page 130 1-7. Safety information Child restraint systems A child restraint system for a small child or baby must itself be prop- erly restrained on the seat with the lap portion of the lap/shoulder belt. The laws of all 50 states of U.S.A. and Canada now require the use of child restraint systems.
Page 131 1-7. Safety information Types of child restraints Child restraint systems are classified into the following 3 types according to the age and size of the child: Rear facing ⎯ Infant seat/convertible seat Forward facing ⎯ Convertible seat Booster seat SIENNA_U (OM45477U)
Page 132 In an accident, the child can be crushed against the windshield, or between you and the vehicle’s interior. Toyota strongly urges the use of a proper child restraint system that con- ●...
Page 133 1-7. Safety information CAUTION Child restraint precautions ■ Do not use the seat belt extender when installing a child restraint system ● on the front or rear passenger seat. If installing a child restraint system with the seat belt extender connected to the seat belt, the seat belt will not securely hold the child restraint system, which could cause death or seri- ous injury to the child or other passengers in the event of a sudden stop, sudden swerve or an accident.
Page 134 1-7. Safety information CAUTION When children are in the vehicle ■ Do not allow children to play with the seat belt. If the seat belt becomes twisted around a child’s neck, it may lead to choking or other serious injuries that could result in death.
Page 135 1-7. Safety information Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the rear seats using the LATCH anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compatible with the LATCH (Lower Anchors and Tethers for Chil- dren) system.
Page 136 1-7. Safety information Third seats Child restraint LATCH anchors LATCH anchors are provided for center seat. (Buttons dis- playing the location of the anchors are attached to the seats.) Using the seat belts ■ Seat belts equipped with a child restraint locking mecha- nism (ALR/ELR belts except driver’s seat belt) (→P.
Page 137 1-7. Safety information Second seats (8-passenger models) Anchor brackets are provided for second outside seats. Second seats (7-passenger models) Anchor brackets are provided for both second seats. Third seats An anchor bracket is provided for center seat. SIENNA_U (OM45477U)
Page 138 1-7. Safety information Installation with LATCH system (second seat) Fold the seatback while pulling STEP the lever and move to the rear- most recline position. Widen the gap between the seat cushion and seatback STEP slightly. Type A Latch the buckles onto the STEP LATCH anchors.
Page 139 1-7. Safety information Type B Latch the hooks of the lower STEP straps onto the LATCH anchors. If the child restraint has a top tether strap, the top tether strap should be latched onto the top tether strap anchor. For owners in Canada: The symbol on a child restraint system indicates the presence of a lower connector system.
Page 140 1-7. Safety information Installation with LATCH system (third seat) Manual seat 1st lock position STEP 11th lock position Fold the seatback while pulling the strap. Return the seatback and secure it at the 1st lock posi- tion (most upright position). Adjust the seatback to the 11th lock position.
Page 141 1-7. Safety information Type A Latch the buckles onto the STEP LATCH anchors. If the child restraint has a top tether strap, the top tether strap should be latched onto the top tether strap anchor. For owners in Canada: The symbol on a child restraint system indicates the presence of a lower connector system.
Page 142 1-7. Safety information Installing child restraints using a seat belt (child restraint lock function belt) Rear facing ⎯ Infant seat/convertible seat ■ Place the child restraint system STEP on the rear seat facing the rear of the vehicle. Run the seat belt through the STEP child restraint system and insert the plate into the buckle.
Page 143 1-7. Safety information While pushing the child restraint STEP system down into the rear seat, allow the shoulder belt to retract until the child seat is securely in place. After shoulder belt retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
Page 144 1-7. Safety information Fully extend the shoulder belt STEP and allow it to retract to put it in lock mode. In lock mode, the belt cannot be extended. While pushing the child restraint STEP system into the rear seat, allow the shoulder belt to retract until the child restraint system is securely in place.
Page 145 1-7. Safety information Booster seat ■ Place the child restraint system STEP on the seat facing the front of the vehicle. Sit the child in the child restraint STEP system. Fit the seat belt to the child restraint system according to the manufacturer’s instruc- tions and insert the plate into the buckle.
Page 146 1-7. Safety information Child restraint systems with a top tether strap (second seat) Secure the child restraint system STEP using the seat belt or LATCH anchors, and adjust the head restraint to the uppermost posi- tion. : Ottoman seat only Latch the hook onto the anchor STEP bracket and tighten the top tether...
Page 147 1-7. Safety information Child restraint systems with a top tether strap (third seat) Secure the child restraint system STEP using the seat belt or LATCH anchors. Adjust head restraint to the uppermost posi- tion. Latch the hook onto the anchor STEP bracket and tighten the top tether strap.
Page 148 1-7. Safety information CAUTION When installing a booster seat ■ To prevent the belt from going into ALR lock mode, do not fully extend the shoulder belt. ALR mode causes the belt to tighten only which could cause injury or discomfort to the child. (→P. 131) When installing a child restraint system ■...
Page 149 1-7. Safety information CAUTION When installing a child restraint system ■ When installing a child restraint system on the third center seat, adjust ● both seatbacks at the same angle. Otherwise, the child restraint system cannot be securely restrained and this may cause death or serious injuries in the event of sudden braking, sudden swerving or an accident.
Page 150 1-7. Safety information CAUTION When installing a child restraint system to the AUTO ACCESS SEAT ■ (if equipped) Do not operate the AUTO ACCESS ● SEAT while a child restraint system is fixed to the seat by the child restraint lock function belt.
Page 151 1-7. Safety information SIENNA_U (OM45477U)
Page 152: Checking And Replacing Fuses
2-1. Maintenance Checking and replacing fuses If the AUTO ACCESS SEAT does not operate when the switches are pressed, a fuse may have blown. If this happens, check and replace the fuses as necessary. Fuse layout and amperage rating AUTO ACCESS SEAT ■...
Page 153 2-1. Maintenance After a fuse is replaced ■ Have the vehicle inspected by your Toyota dealer in the following situations. If the replaced fuse blows again. ● If the AUTO ACCESS SEAT does not operate. ● CAUTION To prevent system breakdowns and vehicle fire ■...
Page 154: Wireless Remote Control Battery
2-1. Maintenance Wireless remote control battery Replace the battery with a new one if it is discharged. You will need the following items: ■ ● Flathead screwdriver ● Lithium battery CR2032 Replacing the battery ■ Remove the cover using a STEP coin protected with tape etc.
Page 155 The wireless remote control will not function properly. Use a CR2032 lithium battery ■ Batteries can be purchased at your Toyota dealer, local electrical appli- ● ance shops or camera stores. Replace only with the same or equivalent type recommended by the ●...
Page 156 2-1. Maintenance NOTICE For normal operation after replacing the battery ■ Observe the following precautions to prevent accidents. Always work with dry hands. ● Moisture may cause the battery to rust. Do not touch or move any other components inside the wireless remote ●...
Page 157 2-2. Instrument cluster and information display Gauges and meters Tachometer Displays the engine speed in revolutions per minute. Speedometer Displays the vehicle speed. Fuel gauge Displays the quantity of fuel remaining in the tank. Engine coolant temperature gauge Displays the engine coolant temperature. Odometer and trip meter display Odometer: Displays the total distance the vehicle has been driven.
Page 158 2-2. Instrument cluster and information display Changing the display Pressing this button switches among odometer display, trip meter dis- plays and Eco Driving Indicator Light setting screen. Odometer Trip meter A Trip meter B Eco Driving Indicator Light setting screen : Pressing and holding the but- ton will reset the trip meter.
Page 159 2-2. Instrument cluster and information display The meters and display illuminate when (Optitron type meters) ■ Vehicles without a smart key system: The engine switch is in the “ON” position. Vehicles with a smart key system: The “ENGINE START STOP” switch is in IGNITION ON mode. NOTICE To prevent damage to the engine and its components ■...
Page 160 2-2. Instrument cluster and information display Indicators and warning lights The indicator and warning lights on the instrument cluster and cen- ter panel inform the driver of the status of the vehicle’s various sys- tems. Instrument cluster ■ Center display ■...
Page 161 2-2. Instrument cluster and information display Indicators ■ The indicators inform the driver of the operating state of the vehicle’s various systems. Turn signal indicator Cruise control indicator (→P. 241) (→P. 293, 298) (if equipped) Cruise control “SET” Headlight high beam indicator indicator (→P.
Page 162 There may be a malfunction in a system if a light does not come on, or if the lights do not turn off. Have the vehicle inspected by your Toyota dealer. : The light flashes to indicate that the system is operating.
Page 163: Warning Lights
There may be a malfunction in a system if a light does not come on, or if the lights do not turn off. Have the vehicle inspected by your Toyota dealer for details. : The light flashes to indicate a malfunction.
Page 164 Have the vehicle inspected by your Toyota dealer immediately if this occurs.
Page 165 2-2. Instrument cluster and information display ∗ Multi-information display The multi-information display presents the driver with a variety of driving-related data, including the clock and current outside temper- ature. The display varies depending on its specification. ● Clock (→P. 256) Indicates and sets the time.
Page 166 2-2. Instrument cluster and information display ● Warning messages (→P. 744) Automatically displayed when a malfunction occurs in one of the vehi- cle’s systems. ● Customizable features setting display (→P. 820) Switching the display “INFO” button “SELECT RESET” button “SETUP” button Display items Display items can be switched by pressing the “INFO”...
Page 167 2-2. Instrument cluster and information display Current Fuel Economy ■ Displays the current rate of fuel consumption. Distance to Empty ■ Displays the estimated maximum distance that can be driven with the quantity of fuel remaining. • This distance is computed based on your average fuel consumption.
Page 168 2-2. Instrument cluster and information display Trip Timer ■ Displays the elapsed time since the timer was reset. The timer only functions when the engine is running. The timer can be started and paused by pressing the “SELECT RESET” button, and reset by pressing and holding the “SELECT RESET”...
Page 169 2-2. Instrument cluster and information display Select the desired item by press- STEP ing the “INFO” or “SETUP” but- ton. Press the “SELECT RESET” but- ton to enter the setting mode. The current setting is indicated by yellow text. Setting the clock ■...
Page 170 2-2. Instrument cluster and information display Selecting the language ■ Select “Language” on the “Display Settings” screen, and STEP press the “SELECT RESET” button. Select the language you want to STEP read by pressing the “INFO” or “SETUP” button. Press the “SELECT RESET” but- ton to set the language.
Page 171 2-2. Instrument cluster and information display ● Setting the brightness Select “Brightness” STEP “Screen Settings” screen, and press the “SELECT RESET” but- ton. Press the “INFO” or “SETUP” STEP button to adjust the brightness. +: Brighter -: Darker Press the “SELECT RESET” but- ton to exit the screen.
Page 172 2-2. Instrument cluster and information display ● Setting the contrast Select “Contrast” on the “Screen STEP Settings” screen, and press the “SELECT RESET” button. Press the “INFO” or “SETUP” STEP button to adjust the contrast. +: Strengthen -: Weaken Press the “SELECT RESET” but- ton to exit the screen.
Page 173 2-2. Instrument cluster and information display ● Setting the brightness Select “Brightness” STEP “Screen Settings” screen, and press the “SELECT RESET” but- ton. Press the “INFO” or “SETUP” STEP button to adjust the brightness. +: Brighter -: Darker Press the “SELECT RESET” but- ton to the exit screen.
Page 174 2-2. Instrument cluster and information display Press the “INFO” or “SETUP” STEP button to adjust the contrast. +: Strengthen -: Weaken Press the “SELECT RESET” but- ton to exit the screen. ● Setting the color Select “Color” on the “Screen STEP Settings”...
Page 175 2-2. Instrument cluster and information display ● Setting the tone Select “Tone” on the “Screen STEP Settings” screen, and press the “SELECT RESET” button. Press the “INFO” or “SETUP” STEP button to adjust the tone. +: Brighter -: Darker Press the “SELECT RESET” but- ton to exit the screen.
Page 176 2-2. Instrument cluster and information display If the vehicle is moved while settings are being changed on the multi- ■ information display If the vehicle speed exceeds approxi- mately 3 mph (5 km/h) while the settings are being changed, “Please Stop Vehicle to Change Settings”...
Page 177 2-2. Instrument cluster and information display Eco Driving Indicator ■ Eco Driving Indicator Light During Eco-friendly acceleration (Eco driving), Eco Driving Indicator Light will turn on. Eco Driving Indicator Zone Display Suggests Zone of Eco driving with cur- rent Eco driving ratio based on accel- eration.
Page 178 When “--”, “E” or “F” is displayed on the outside temperature display ■ The system may be malfunctioning. Take your vehicle to your Toyota dealer. Outside temperature display ■ In the following situations, the correct outside temperature may not be dis- played, or the display may take longer than normal to change.
Page 179 2-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. Turning the end of the lever turns on the lights as follows: The illustration is intended as an example. Type A The side marker, park- ing, tail, license plate, daytime running lights equipped)
Page 180 2-3. Operating the lights and wipers Off. (if equipped) Vehicles with the day- time running light sys- tem: daytime running light system is Off. (if equipped) Vehicles with the day- time running light sys- tem: daytime running light system is SIENNA_U (OM45477U)
Page 181 2-3. Operating the lights and wipers Turning on the high beam headlights With the headlights on, push the lever away from you to turn on the high beams. When the light switch is in position, Automatic High Beam system will be activated. (→P.
Page 182 2-3. Operating the lights and wipers Manual headlight leveling dial (vehicles with discharge headlights) The level of the headlight aim can be adjusted according to the num- ber of passengers and the loading condition of the vehicle. Raises the level of the head- lights Lowers the level of the head- lights...
Page 183 2-3. Operating the lights and wipers Daytime running light system (if equipped) ■ To make your vehicle more visible to other drivers, the headlights turn on ● automatically (at a reduced intensity) whenever the engine is started and the parking brake is released. Daytime running lights are not designed for use at night.
Page 184 2-3. Operating the lights and wipers Automatic light off system ■ Vehicles without a smart key system When the headlights are on: The headlights and tail lights turn off 30 sec- ● onds after a door is opened and closed if the engine switch is turned to the “ACC”...
Page 185 2-3. Operating the lights and wipers Customization that can be configured at Toyota dealer or by the multi- ■ information display Settings (e.g. light sensor sensitivity) can be changed. (Customizable features →P. 815) NOTICE To prevent battery discharge ■ Do not leave the lights on longer than necessary when the engine is not run- ning.
Page 186 2-3. Operating the lights and wipers ∗ Automatic High Beam The Automatic High Beam uses an in-vehicle camera sensor to assess the brightness of streetlights, the lights of oncoming and preceding vehicles, etc., and automatically turns high beam on or off as necessary.
Page 187 2-3. Operating the lights and wipers Turning the high beam on/off manually ■ Switching to low beam Pull the lever to the original position. Switching to high beam Turn the light switch to the position. SIENNA_U (OM45477U)
Page 188 2-3. Operating the lights and wipers High beam automatic turning on or off conditions ■ When all of the following conditions are fulfilled, high beam will be automatically turned on (after approximately 1 second): ● Vehicle speed is above approximately 20 mph (32 km/h). ●...
Page 189 2-3. Operating the lights and wipers Limitations of the Automatic High Beam ■ Do not rely on the Automatic High Beam. Always drive safely, taking care to observe your surroundings and turning high beam on or off manually if nec- essary.
Page 190 2-3. Operating the lights and wipers In the situations below, the system may not be able to correctly detect the ● surrounding brightness levels, and may flash or expose nearby pedestri- ans to the high beam. Therefore, you should consider turning the high beam on or off manually rather than relying on the Automatic High Beam system.
Page 191 2-3. Operating the lights and wipers If the Automatic High Beam indicator flashes... ■ It may indicate a malfunction in the system. Contact your Toyota dealer. Customization that can be configured at Toyota dealer or by the multi- ■ information display The Automatic High Beam can be turned off.
Page 192 ● Do not modify the vehicle. ● Do not replace windshield with a non-genuine windshield. ● Contact your Toyota dealer. Headlight leveling ■ When the vehicle is loaded, headlight level should be adjusted to appropri- ate dial setting. (→P. 269)
Page 193 2-3. Operating the lights and wipers ∗ Fog light switch The fog lights secure excellent visibility in difficult driving condi- tions, such as in rain and fog. Type A Turns the front fog lights off Turns the front fog lights on ∗...
Page 194 2-3. Operating the lights and wipers Type B Turns the front fog lights off Turns the front fog lights on Fog lights can be used when ■ The headlights are on in low beam. SIENNA_U (OM45477U)
Page 195 2-3. Operating the lights and wipers Windshield wipers and washer Intermittent windshield wipers with interval adjuster The wiper operation is selected by moving the lever as follows. When intermittent windshield wiper operation is selected, the wiper interval can be also adjusted. Type A Intermittent wind-...
Page 196 2-3. Operating the lights and wipers Washer/wiper dual opera- tion The wipers will automatically operate a couple of times after the washer squirts. Type B Intermittent wind- shield wiper opera- tion speed wind- shield wiper opera- tion High speed wind- shield wiper opera- tion Temporary operation...
Page 197 2-3. Operating the lights and wipers Increases the intermittent windshield wiper frequency Decreases the intermittent windshield wiper frequency Washer/wiper dual opera- tion The wipers will automatically operate a couple of times after the washer squirts. SIENNA_U (OM45477U)
Page 198 2-3. Operating the lights and wipers Rain-sensing windshield wipers (if equipped) When “AUTO” is selected, the wipers will operate automatically when the sensor detects falling rain. The system automatically adjusts wiper timing in accordance with rain volume. When “AUTO” is selected, the sensor sensitivity can be adjusted as follows by turning the switch ring: Type A Rain-sensing wiper...
Page 199 2-3. Operating the lights and wipers Increases the sensitivity Decreases the sensitivity Washer/wiper dual opera- tion The wipers will automatically operate a couple of times after the washer squirts. Type B Rain-sensing wiper operation (“AUTO”) speed wiper operation High speed wiper operation Temporary operation SIENNA_U (OM45477U)
Page 200 2-3. Operating the lights and wipers Increases the sensitivity Decreases the sensitivity Washer/wiper dual opera- tion The wipers will automatically operate a couple of times after the washer squirts. SIENNA_U (OM45477U)
Page 201 2-3. Operating the lights and wipers The windshield wipers and washer can be operated when ■ Vehicles without a smart key system: The engine switch is in the “ON” position. Vehicles with a smart key system: The “ENGINE START STOP” switch is in IGNITION ON mode. Raindrop sensor (vehicles with rain-sensing windshield wipers) ■...
Page 202 Do not operate the switch continually as the washer fluid pump may over- heat. When a nozzle becomes blocked ■ In this case, contact your Toyota dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged. SIENNA_U (OM45477U)
Page 203 2-3. Operating the lights and wipers Rear window wiper and washer The wiper operation is selected by moving the lever as follows: Type A Intermittent window wiper operation Normal window wiper operation Washer/wiper dual operation Washer/wiper dual operation SIENNA_U (OM45477U)
Page 204 2-3. Operating the lights and wipers Type B Intermittent window wiper operation Normal window wiper operation Washer/wiper dual operation Washer/wiper dual operation The rear window wiper and washer can be operated when ■ Vehicles without a smart key system: The engine switch is in the “ON” position. Vehicles with a smart key system: The “ENGINE START STOP”...
Page 205 2-3. Operating the lights and wipers NOTICE When the rear window is dry ■ Do not use the wiper, as it may damage the rear window. When the washer fluid tank is empty ■ Do not operate the switch continually as the washer fluid pump may over- heat.
Page 206 2-4. Using other driving systems ∗ Cruise control Use cruise control to maintain a set speed without depressing the accelerator pedal. Indicators Cruise control switch Setting the vehicle speed ■ STEP Press the “ON-OFF” button to activate the cruise control. Cruise control indicator will come on.
Page 207 2-4. Using other driving systems Adjusting the set speed ■ To change the set speed, operate the lever until the desired set speed is obtained. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direction.
Page 208 2-4. Using other driving systems Canceling and resuming the constant speed control ■ Pulling the lever toward you cancels the constant speed control. The speed setting is also can- celed when the brakes are applied. Pushing lever resumes constant speed control. Resuming is available when the vehicle speed is more than approximately 25 mph...
Page 209 If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer. SIENNA_U (OM45477U)
Page 210 2-4. Using other driving systems CAUTION To avoid operating the cruise control by mistake ■ Switch the cruise control off using the “ON-OFF” button when not in use. Situations unsuitable for cruise control ■ Do not use cruise control in any of the following situations. Doing so may result in loss of control and could cause an accident resulting in death or serious injury.
Page 211 2-4. Using other driving systems ∗ Dynamic radar cruise control Dynamic radar cruise control supplements conventional cruise con- trol with a vehicle-to-vehicle distance control. In vehicle-to-vehicle distance control mode, the vehicle automatically accelerates or decelerates in order to maintain a set following distance from vehi- cles ahead.
Page 212 2-4. Using other driving systems Setting the vehicle speed (vehicle-to-vehicle distance con- ■ trol mode) Press the “ON-OFF” button to STEP activate the cruise control. Dynamic radar cruise control indicator will come on. Press the button again to deactivate the cruise control. Accelerate or decelerate to STEP the desired speed and push...
Page 213 2-4. Using other driving systems Adjusting the set speed ■ To change the set speed, operate the lever until the desired set speed is displayed. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direction.
Page 214 2-4. Using other driving systems Changing the vehicle-to-vehicle distance ■ Pressing the button changes vehicle-to-vehicle dis- Preceding tance as follows: vehicle mark Long Medium Short Vehicles without a smart key system: The vehicle-to-vehicle distance is set automatically to long mode when the engine switch is turned to the “ON”...
Page 215 2-4. Using other driving systems Vehicle-to-vehicle distance settings ■ Select a distance from the table below. Note that the distances shown correspond to a vehicle speed of 50 mph (80 km/h). Vehi- cle-to-vehicle distance increases/decreases in accordance with vehicle speed. Distance options Vehicle-to-vehicle distance Long...
Page 216 2-4. Using other driving systems Driving in vehicle-to-vehicle distance control mode This mode employs a radar sensor to detect the presence of vehicles up to approximately 400 ft. (120 m) ahead, determines the current vehicle-to-vehicle following distance, and operates to maintain a suit- able following distance from the vehicle ahead.
Page 217 2-4. Using other driving systems Example of follow-up cruising When following a vehicle driving slower than the set speed The system continues follow-up cruising while adjusting for changes in the speed of the vehicle ahead in order to maintain the vehicle-to-vehicle dis- tance set by the driver.
Page 218 2-4. Using other driving systems Selecting conventional constant speed control mode Constant speed control mode differs from vehicle-to-vehicle distance control mode. When constant speed control mode is selected, your vehicle will maintain a set speed regardless of whether or not there are other vehicles in the lane ahead.
Page 219 2-4. Using other driving systems Vehicles without a smart key sys- tem: If the engine switch is turned off and then turned to the “ON” posi- tion again, the vehicle will auto- matically return to vehicle-to- vehicle distance control mode. Vehicles with a smart key system: If the “ENGINE START STOP”...
Page 220 “AUTO” mode or the high speed wiper operation posi- tion). If vehicle-to-vehicle distance control driving is automatically canceled for any other reason, there may be a malfunction in the system. Contact your Toyota dealer. SIENNA_U (OM45477U)
Page 221 2-4. Using other driving systems Automatic cancelation of constant speed control ■ The cruise control will stop maintaining the vehicle speed in the following sit- uations. Actual vehicle speed is more than approximately 10 mph (16 km/h) ● below the set vehicle speed. At this time, the memorized set speed is not retained.
Page 222 2-4. Using other driving systems Certification ■ U.S.A. FCC ID: HYQDNMWR005 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 223 2-4. Using other driving systems CAUTION Before using dynamic radar cruise control ■ Do not overly rely on vehicle-to-vehicle distance control. Be aware of the set speed. If automatic deceleration/acceleration is not appropriate, adjust the vehicle speed, as well as the distance between your vehicle and vehicles ahead by applying the brakes, etc.
Page 224 2-4. Using other driving systems CAUTION Situations unsuitable for dynamic radar cruise control ■ Do not use dynamic radar cruise control in any of the following situations. Doing so may result in inappropriate speed control and could cause an acci- dent resulting in death or serious injury.
Page 225 2-4. Using other driving systems CAUTION When the sensor may not be correctly detecting the vehicle ahead ■ Apply the brakes as necessary when any of the following types of vehicles are in front of you. As the sensor may not be able to correctly detect these types of vehicles, the approach warning (→P.
Page 226 If the sensor moves even slightly off position, the system may malfunction. If the sensor or surrounding area is subject to a strong impact, always have the area inspected and adjusted by a Toyota dealer. Do not disassemble the sensor.
Page 227 2-4. Using other driving systems ∗ Intuitive parking assist The distance from your vehicle to nearby obstacles when parallel parking or maneuvering into a garage is measured by the sensors and communicated via the multi-information display, the touch screen and a buzzer. Always check the surrounding area when using this system.
Page 228 2-4. Using other driving systems Display When the sensors detect an obstacle, a graphic is shown on the multi information display or touch screen depending on the position and distance to the obstacle. Multi-information display Touch screen (with navigation system) : Depending on the type of navigation system.
Page 229 2-4. Using other driving systems The distance display and buzzer When a sensor detects an obstacle, the direction of and the approxi- mate distance to the obstacle are displayed and the buzzer sounds. Corner sensor operation and distance to an obstacle ■...
Page 230 2-4. Using other driving systems Back sensor operation and distance to an obstacle ■ The system operates when the vehicle approaches within the fol- lowing distances to an obstacle. The indicator flashes and the buzzer sounds when the system is operating. Approximate distance to obstacle Indicator and buzzer / Color 5.9 to 2.8 ft.
Page 231 2-4. Using other driving systems Detection range of the sensors Approximately 2.0 ft. (60 cm) Approximately 2.8 ft. (85 cm) Approximately 5.9 ft. (180 cm) The diagram shows the detection range of the sensors. Note that the sensors cannot detect obsta- cles that are extremely close to the vehicle.
Page 232 2-4. Using other driving systems Sensor detection information ■ Certain vehicle conditions and the surrounding environment may affect ● the ability of the sensor to correctly detect obstacles. Particular instances where this may occur are listed below. • There is dirt, snow or ice on the sensor. •...
Page 233 This ISM device complies with Canadian ICES-001. When there is a malfunction ■ In the following cases, have the vehicle inspected by your Toyota dealer. If the bumper is damaged. ● If the intuitive parking assist indicator light remains on without a beep ●...
Page 234 2-4. Using other driving systems ∗ Rear view monitor system The rear view monitor system assists the driver by displaying an image of the area behind the vehicle while reversing. The image is displayed in reverse on the screen. This reversed image is a similar image to the one on the inside rear view mirror.
Page 235 2-4. Using other driving systems Displayed area ■ The area covered by the camera is lim- ited. Objects that are close to either cor- ner of the bumper or under the bumper cannot be seen on the screen. The area displayed on the screen may vary depending on vehicle orientation or road conditions.
Page 236 2-4. Using other driving systems Rear view monitor system camera ■ In the following cases, it may be difficult to see the images on the screen, even when the system is functioning correctly. • The vehicle is in a dark area, such as at night.
Page 237 2-4. Using other driving systems Driving precautions ■ When the grade behind the vehicle slopes up sharply, objects appear to be farther away than they actually are. When the grade behind the vehicle slopes down sharply, objects appear to be closer than they actually are. SIENNA_U (OM45477U)
Page 238 2-4. Using other driving systems When any part of the vehicle sags due to the number of passengers or the distribu- tion of the load, there is a margin of error between the guide lines on the screen and the actual distance/course on the road.
Page 239 ■ If the back of the vehicle has been hit, the camera’s position and mounting ● angle may have changed. Have the vehicle inspected by your Toyota dealer. Rapid temperature changes, such as when hot water is poured on the ●...
Page 240 2-4. Using other driving systems Driving assist systems To help enhance driving safety and performance, the following sys- tems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle. ABS (Anti-lock Brake System) ■...
Page 241 2-4. Using other driving systems Active Torque Control 4WD (AWD models only) ■ Automatically switches from front-wheel drive to AWD (All-Wheel Drive) according to driving conditions, helping to ensure reliable handling and stability. Examples of conditions where the system will switch to AWD are when cornering, going uphill, starting off or accelerating, and when the road surface is slippery due to snow or rain etc.
Page 242 2-4. Using other driving systems Disabling TRAC and VSC system If the vehicle gets stuck in fresh snow or mud, TRAC and VSC may reduce power from the engine to the wheels. You may need to turn the system off to enable you to rock the vehicle in order to free it. Turning off the TRAC system only ■...
Page 243 When the “TRAC OFF” indicator light comes on even if the VSC OFF ■ switch has not been pressed TRAC and hill-start assist control cannot be operated. Contact your Toyota dealer. Sounds and vibrations caused by ABS, brake assist, Enhanced VSC ■...
Page 244 2-4. Using other driving systems Reduced effectiveness of the EPS system ■ The effectiveness of the EPS system is reduced to prevent the system from overheating when there is frequent steering input over an extended period of time. The steering wheel may feel heavy as a result. Should this occur, refrain from excessive steering input or stop the vehicle and turn the engine off.
Page 245 The ABS and Enhanced VSC systems will not function correctly if different tires are installed on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. Handling of tires and suspension ■...
Page 246 2-4. Using other driving systems ∗ Hill-start assist control Hill-start assist control helps to prevent the vehicle from rolling backwards when starting on an incline or slippery slope. To engage hill-start assist con- trol, further depress the brake pedal when the vehicle is stopped completely.
Page 247 • The brake pedal is depressed again. • The brake pedal has been depressed for more than approximately 3 minutes. If the slip indicator comes on... ■ It may indicate a malfunction in the system. Contact your Toyota dealer. SIENNA_U (OM45477U)
Page 248 2-4. Using other driving systems CAUTION Hill-start assist control ■ Do not overly rely on hill-start assist control. Hill-start assist control may ● not operate effectively on extremely steep inclines or roads covered in ice. Unlike the parking brake, hill-start assist control is not intended to hold the ●...
Page 249 2-4. Using other driving systems ∗ PCS (Pre-Collision System) When the radar sensor detects that a frontal collision is highly likely or even unavoidable, the systems such as the brakes and seat belts are automatically engaged to lessen impact to occupants as well as vehicle damage.
Page 250 2-4. Using other driving systems Disabling pre-collision braking Pre-collision braking disabled Pre-collision braking enabled The “PCS” warning light flashes when pre-collision braking is dis- abled. Radar sensor The radar sensor detects vehi- cles or other obstacles on or near the road ahead and deter- mines whether a collision is imminent based on the position, speed, and heading of the obsta-...
Page 251 2-4. Using other driving systems The pre-collision system is operational when ■ Pre-collision seat belts (type A): ● • Vehicle speed is greater than about 4 mph (5 km/h). • The speed at which your vehicle is approaching the obstacle or oncom- ing vehicle is greater than about 19 mph (30 km/h).
Page 252 2-4. Using other driving systems Conditions that may trigger the system even if there is no possibility of ■ a collision When there is an object by the roadside at the entrance to a curve ● When passing an oncoming vehicle on a curve ●...
Page 253 2-4. Using other driving systems When there is a malfunction in the system ■ Warning lights will turn on or flash. (→P. 729) Certification ■ U.S.A. FCC ID: HYQDNMWR005 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 254 2-4. Using other driving systems CAUTION Limitations of the pre-collision system ■ Do not overly rely on the pre-collision system. Always drive safely, taking care to observe your surroundings and checking for any obstacles or other road hazards. Cautions regarding the assist contents of the system ■...
Page 255 If the sensor moves even slightly off position, the system may malfunction. If the sensor or surrounding area is subject to a strong impact, always have the area inspected and adjusted by your Toyota dealer. Do not disassemble the sensor.
Page 256 2-5. Driving information Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load: ● Stow cargo and luggage in the luggage compartment whenever possible. ● Be sure all items are secured in place. ●...
Page 257 2-5. Driving information Capacity and distribution Cargo capacity depends on the total weight of the occupants. (Cargo capacity) = (Total load capacity) - (Total weight of occupants) Steps for Determining Correct Load Limit ⎯ (1) Locate the statement “The combined weight of occupants and cargo should never exceed XXX kg or XXX lbs.”...
Page 258 2-5. Driving information Example based on your vehicle Cargo capacity Total load capacity When 2 people with the combined weight of 366 lb. (166 kg) are riding in your vehicle, which has a total load capacity of 1660 lb. (750 kg) , the available amount of cargo and luggage load capacity will be as follows: 1660 lb.
Page 259 2-5. Driving information Roof luggage carrier (if equipped) Roof luggage carrier components ■ Roof rails Cross rails Adjusting the position of cross rails ■ Turn the knobs counterclockwise to release the cross rails. Slide the cross rails to the appro- priate position for loading lug- gage turn...
Page 260 2-5. Driving information Seating configuration variation Cargo capacity Weight of the removed second seat If removing the second seats, it is possible to load extra cargo equal to the weight of the removed seats. (Cargo capacity) = (Total load capacity) - (Total weight of occupants) + (Weight of the removed second seats) Second seats weight: 7-passenger models...
Page 261 2-5. Driving information CAUTION Things that must not be carried in the luggage compartment ■ The following things may cause a fire if loaded in the luggage compart- ment: Receptacles containing gasoline ● Aerosol cans ● Storage precautions ■ Observe the following precautions. Failing to do so may result in death or serious injury.
Page 262 2-5. Driving information CAUTION Storage precautions ■ Secure all items in the occupant compartment, as they may shift and ● injure someone during sudden braking, sudden swerving or an acci- dent. When you fold down the rear seats, long items should not be place ●...
Page 263 2-5. Driving information CAUTION When loading cargo ■ Observe the following precautions: Place the cargo so that its weight is distributed evenly between the ● front and rear axles. If loading long or wide cargo, never exceed the vehicle overall length ●...
Page 264 2-5. Driving information Vehicle load limits Vehicle load limits include total load capacity, seating capacity, TWR (Trailer Weight Rating) and cargo capacity. Total load capacity: (→P. 784) ■ Total load capacity means the combined weight of occupants, cargo and luggage. Seating capacity: 7 or 8 occupants (Front 2, Rear 5 or 6) ■...
Page 265 2-5. Driving information Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a manner appropri- ate to the prevailing weather conditions. Pre-winter preparations ■ ● Use fluids that are appropriate to the prevailing outside tem- peratures.
Page 266 2-5. Driving information When driving the vehicle ■ Accelerate the vehicle slowly and drive at a reduced speed suit- able to road conditions. When parking the vehicle ■ Park the vehicle and move the shift lever to P without setting the parking brake.
Page 267 2-5. Driving information Tire chain installation ■ Observe the following precautions when installing and removing chains. Install and remove tire chains in a safe location. ● Install tire chains on the front tires only. Do not install tire chains on the ●...
Page 268 NOTICE Repairing or replacing snow tires ■ Request repairs of or replacement of snow tires from Toyota dealers or legit- imate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
Page 269 To tow a trailer safely, use extreme care and drive the vehicle in accordance with your trailer’s characteristics and operating condi- tions. Toyota warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. Contact your Toyota dealer for further information about additional requirements such as a towing kit, etc.
Page 270 2-5. Driving information Towing related terms GCWR (Gross Combination Weight Rating) ■ The maximum allowable gross combination weight. The gross combination weight is the sum of the total vehicle weight (including the occupants, cargo and any optional equipment installed on the vehicle) and the weight of the trailer being towed (including the cargo in the trailer).
Page 271 2-5. Driving information GAWR (Gross Axle Weight Rating) ■ The maximum allowable gross Front GAWR axle weight. The gross axle weight is the load placed on each axle (front and rear). Rear GAWR TWR (Trailer Weight Rating) ■ The maximum allowable gross (With brakes) trailer weight.
Page 272 2-5. Driving information Unbraked TWR (Unbraked Trailer Weight Rating) ■ The trailer weight rating for tow- (Without brakes) ing a trailer without a trailer ser- vice brake system. Tongue Weight ■ The load placed on the trailer hitch ball. (→P. 362) SIENNA_U (OM45477U)
Page 273 2-5. Driving information Weight limits ● The gross trailer weight must never exceed 3500 lb. (1588 kg). ● The gross combination weight must never exceed the GCWR described below. 2WD models: 8900 lb. (4037 kg) AWD models: 8990 lb. (4078 kg) ●...
Page 274 2-5. Driving information GCWR, TWR and Unbraked TWR Confirm that the gross trailer weight, gross combination weight, gross vehicle weight, gross axle weight and tongue weight are all within the limits. ∗ GCWR ■ 2WD models: 8900 lb. (4037 kg) AWD models: 8990 lb.
Page 275 2-5. Driving information Trailer Tongue Weight ● A recommended tongue weight varies in accordance with the types of trailers or towing as described below. ● To ensure the recommended values shown below, the trailer must be loaded by referring to the following instructions. •...
Page 276 Toyota hitch/bracket for your vehicle. For details, contact your Toyota dealer. ● If you wish to install a trailer hitch, contact your Toyota dealer. ● Use only a hitch that conforms to the gross trailer weight require- ment of your vehicle.
Page 277 2-5. Driving information Selecting trailer ball Use the correct trailer ball for your application. Trailer ball load rating Matches or exceeds the gross trailer weight rating of the trailer. Ball diameter Matches the size of the trailer coupler. Most couplers stamped with the required trailer ball size.
Page 278 2-5. Driving information Positions for towing hitch receiver Hitch receiver pin hole posi- tion: 37.3 in. (949.8 mm) Connecting trailer lights Please consult your dealer when installing trailer lights, as incorrect installation may cause damage to the vehicle’s lights. Please take care to comply with your state’s laws when installing trailer lights.
Page 279 ● Speed limits for towing a trailer vary by state or province. Do not exceed the posted towing speed limit. ● Toyota recommends that the vehicle-trailer speed limit is 65 mph (104 km/h) on a flat, straight, dry road. Do not exceed this limit, the posted towing speed limit or the speed limit for your trailer as set forth in your trailer owner’s manual, whichever is lowest.
Page 280 2-5. Driving information ● Reversing with a trailer attached is difficult and requires practice. Grip the bottom of the steering wheel and move your hand to the left to move the trailer to the left. Move your hand to the right to move the trailer to the right.
Page 281 2-5. Driving information ● Take care when passing other vehicles. Passing requires consider- able distance. After passing a vehicle, do not forget the length of your trailer, and be sure you have plenty of room before changing lanes. ● To maintain engine braking efficiency and charging system perfor- mance when using engine braking, do not put the transmission in Transmission shift range position must be in 4 in the S mode.
Page 282 2-5. Driving information ● Always place wheel blocks under both the vehicle’s and the trailer’s wheels when parking. Apply the parking brake firmly, and put the transmission in P. Avoid parking on a slope, but if unavoid- able, do so only after performing the following: Apply the brakes and keep them applied.
Page 283 2-5. Driving information Matching trailer ball height to trailer coupler height ■ No matter which class of tow hitch applies, for a safe trailer hookup, the trailer ball setup on must be proper height for the coupler on the trailer. Coupler Trailer ball Before towing...
Page 284 ■ If your vehicle is new or equipped with any new power train components (such as an engine, transmission, differential or wheel bearing), Toyota rec- ommends that you do not tow a trailer until the vehicle has been driven for over 500 miles (800 km).
Page 285 2-5. Driving information If trailer sway occurs ■ One or more factors (crosswinds, passing vehicles, rough roads, etc.) can adversely affect handling of your vehicle and trailer, causing instability. If trailer swaying occurs: ● • Firmly grip the steering wheel. Steer straight ahead. Do not try to control trailer swaying by turning the steering wheel.
Page 286 2-5. Driving information CAUTION Trailer towing precautions ■ To tow a trailer safely, use extreme care and drive the vehicle in accordance with the trailer’s characteristics and operating conditions. Failure to do so could cause an accident resulting in death or serious injury. Vehicle stability and braking performance are affected by trailer stability, brake setting and performance, and the hitch.
Page 287 2-5. Driving information CAUTION To avoid accident or injury ■ Do not use cruise control when towing. ● Slow down and downshift before descending steep or long downhill ● grades. Do not make sudden downshifts while descending steep or long downhill grades.
Page 288 NOTICE When installing a trailer hitch ■ Use only the position recommended by your Toyota dealer. Do not install the trailer hitch on the bumper; this may cause body damage. Do not directly splice trailer lights ■...
Page 289 2-5. Driving information Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE To avoid serious damage to your vehicle ■ Do not tow your vehicle with four wheels on the ground.
Page 290 2-5. Driving information SIENNA_U (OM45477U)
Page 291: When You Think A Malfunction Has Occurred Auto Access Seat
If the seat still does not operate even after trying the procedures, it is likely that the seat is malfunctioning. Do not use the AUTO ACCESS SEAT, and have the seat inspected by your Toyota dealer immedi- ately. If the AUTO ACCESS SEAT does not move after being ■...
Page 292 3-1. When you think a malfunction has occurred Reason Correction procedure Start the engine. If the AUTO ACCESS SEAT is operated The engine is not running. while the engine is stopped and the vehicle battery is low, the AUTO ACCESS SEAT may stop during operation.
Page 293 3-1. When you think a malfunction has occurred If the AUTO ACCESS SEAT retreats a little and then stops Reason Correction procedure The AUTO ACCESS SEAT has hit an obstacle, or opera- Remove the obstacle and try operating the tion has been otherwise AUTO ACCESS SEAT again.
Page 294: If The Auto Access Seat Does Not Move While Outside The Vehicle
If the AUTO ACCESS SEAT still does not move even after the fuses have been checked and replaced, have the seat inspected by your Toyota dealer. If the AUTO ACCESS SEAT stops moving while raising, lowering or rotating, or while it is outside the vehicle, you will not be able to close the right-hand sliding door.
Page 295 3-1. When you think a malfunction has occurred Press and hold the seat position STEP adjustment switch on the right- hand side of the seat in either the front or back direction and, at the same time as press and hold the seat raise/lower switch in either the raise or lower direction for approximately 10 seconds,...
Page 296 3-1. When you think a malfunction has occurred If the AUTO ACCESS SEAT moves when a switch is pressed ● Initialize the seat position information before conducting the opera- tions listed here. ● The movements of the seat while conducting these operations will be different from normal.
Page 297 3-1. When you think a malfunction has occurred Press the rear side of the seat STEP position adjustment switch on the right-hand side of the seat, and slide the AUTO ACCESS SEAT toward the rear of the vehicle by 2 in. (5 cm). If the rear side of the seat position adjustment switch is pressed and held while the lower side of the...
Page 298 3-1. When you think a malfunction has occurred Press the rear side of the seat STEP position adjustment switch on the right-hand side of the seat, and slide the AUTO ACCESS SEAT toward the rear of the vehicle until the beep sounds. If the rear side of the seat position adjustment switch is pressed and held while the lower side of the...
Page 299 3-1. When you think a malfunction has occurred Press and hold the front side of STEP the seatback angle adjustment switch on the right-hand side of the seat until a long beep sounds. SIENNA AAS_U (OM45471U)
Page 300 3-1. When you think a malfunction has occurred If the AUTO ACCESS SEAT does not move even when a switch is pressed Before conducting this procedure, conduct the procedures explained in the “Initializing the seat position information” and “If the AUTO ACCESS SEAT moves when a switch is pressed”...
Page 301 3-1. When you think a malfunction has occurred Take combination STEP wrench. Removal Replacement Combination wrench Remove the connector. STEP Turn the bolt with yellow marking STEP using the combination wrench, and move the AUTO ACCESS SEAT until the marks are aligned as shown in the illustration.
Page 302 3-1. When you think a malfunction has occurred Use the combination wrench to STEP remove the 2 bolts on the under- side of the AUTO ACCESS SEAT. Slide the AUTO ACCESS SEAT STEP into the vehicle. Turn the bolt with yellow marking STEP using the combination wrench, and move the AUTO ACCESS...
Page 303 3-1. When you think a malfunction has occurred Turn the bolt with yellow marking STEP clockwise using the combination wrench, and slide the seat until the marks are aligned as shown in the illustration. If you are unable to slide the seat until marks aligned...
Page 304 Turn the power sliding door main switch off and close the STEP right-hand sliding door manually. Have the seat inspected by your Toyota dealer immediately. The power sliding door will not operate if the AUTO ACCESS SEAT has been stowed inside the vehicle manually.
Page 305 3-1. When you think a malfunction has occurred CAUTION When stowing the AUTO ACCESS SEAT manually ■ Do not put your feet or hands into the AUTO ACCESS SEAT stowage space. Your feet or hands may be caught in the movable parts of the AUTO ACCESS SEAT, which could cause injuries.
Page 306: Wireless Remote Control
Use the seat raise/lower switch to operate the AUTO ACCESS SEAT (→P. 35), and have the wireless remote control inspected by your Toyota dealer immediately. If the AUTO ACCESS SEAT does not move...
Page 307 Replace the battery. (→P. 40) control is discharged. If the indicator light is illuminated or flashing even though the wireless remote control switches are not being pressed Reason Correction procedure The wireless remote control may be Contact your Toyota dealer. malfunctioning. SIENNA AAS_U (OM45471U)
Page 308 3-2. Using the audio system ∗ Audio system type With navigation system Owners of models equipped with a navigation system should refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”. Without navigation system Type A and B: CD player with AM/FM radio Type C: CD player with changer and AM/FM radio.
Page 309 3-2. Using the audio system Type B Type C SIENNA_U (OM45477U)
Page 310 3-2. Using the audio system Title Page Using the radio P. 412 Using the CD player P. 422 Playing back MP3 and WMA discs P. 431 Operating an iPod P. 442 Operating a USB memory P. 449 Optimal use of the audio system P.
Page 311 3-2. Using the audio system Using cellular phones ■ Interference may be heard through the audio system’s speakers if a cellular phone is being used inside or close to the vehicle while the audio system is operating. CAUTION For vehicles sold in the U.S.A. ■...
Page 312 3-2. Using the audio system NOTICE To prevent battery discharge ■ Do not leave the audio system on longer than necessary with the engine off. To avoid damaging the audio system ■ Take care not to spill drinks or other fluids over the audio system. SIENNA_U (OM45477U)
Page 313: Using The Radio
3-2. Using the audio system Using the radio Type A Power Volume Adjusting the frequency Station selector (AM, FM mode) or channel (SAT mode) Seeking the Changing the channel frequency AM•SAT/FM mode buttons Displaying radio text messages Scanning for receivable stations SIENNA_U (OM45477U)
Page 314 3-2. Using the audio system Type B and C Power Volume Adjusting the frequency Station selector (AM, FM mode) or channel (SAT mode) Seeking Changing the channel the frequency Silencing the sound Displaying radio text messages Scanning for receivable stations AM/FM/SAT mode button Selecting the preset station pages SIENNA_U (OM45477U)
Page 315 3-2. Using the audio system ® Setting station presets (excluding XM Satellite Radio) Search for desired stations by turning STEP pressing “∧” or “∨” on Press and hold the button (from or one of STEP until you hear a beep. Type B and C: Each time is pressed, station pages are changed.
Page 316 3-2. Using the audio system ® Scanning radio stations (excluding XM Satellite Radio) Scanning the preset radio stations ■ Press and hold until you hear a beep. STEP Preset stations will be played for 5 seconds each. When the desired station is reached, press once STEP again.
Page 317 3-2. Using the audio system ® Satellite Radio (if equipped) ® Receiving XM Satellite Radio ■ Press STEP The display changes as follows each time the button is pressed. Type A AM → SAT1 → SAT2 → SAT3 Type B and C AM →...
Page 318 3-2. Using the audio system Changing the channel category ■ Press “∧” or “∨” on ® Scanning XM Satellite Radio channels ■ ● Scanning channels in the current category Press STEP When the desired channel is reached, press the button STEP again.
Page 319 3-2. Using the audio system Silencing the sound (type B and C) Press Press the button again to turn the system back on. When the battery is disconnected (type A only) ■ All preset stations are erased. Radio antenna type ■...
Page 320 3-2. Using the audio system ® Receiving XM Satellite Radio ■ ® An XM Satellite Radio is a tuner designed exclusively to receive broadcasts provided under a separate subscription. Availability is limited to the 48 con- tiguous states and 10 Canadian provinces. ®...
Page 321 ANTENNA securely. CHECK There is a short-circuit in the antenna or the sur- ANTENNA rounding antenna cable. See a Toyota certified dealer. ® You have not subscribed to XM Satellite Radio. The radio is being updated with the latest encryp- ®...
Page 322 3-2. Using the audio system There is no song/program title or artist name/fea- ----- ture associated with the channel at that time. No action needed. The channel you selected is no longer available. Wait for about 2 seconds until the radio returns to the previous channel or “CH001”.
Page 323: Using The Cd Player
3-2. Using the audio system Using the CD player Type A Power Volume Reverse CD eject Fast-forward Selecting Selecting a track a track Searching playback Playback Random playback Displaying text messages Repeat play SIENNA_U (OM45477U)
Page 324 3-2. Using the audio system Type B and C Power Volume CD eject CD load (type C only) Selecting a track/fast-forwarding Selecting a track and reversing Playback/ pause Playback Repeat play Displaying text messages Searching playback CD selection Random play Loading CDs Loading a CD (type A and B) ■...
Page 325 3-2. Using the audio system Loading multiple CDs (type C only) ■ Press and hold until you hear a beep. STEP Insert a CD when the indicator on the slot turns from amber to STEP green. The indicator on the slot turns to amber when the CD is inserted. Insert the next CD when the indicator on the slot turns from STEP amber to green again.
Page 326 3-2. Using the audio system Selecting a track Turn or press “∧” or “∨” on to select the desired track. Fast forwarding and rewinding tracks Type A Press Type B and C Press and hold “∧” or “∨” on Scanning tracks Press STEP The first 10 seconds of each track will be played.
Page 327 3-2. Using the audio system Selecting a CD (type C only) Selecting a CD to play ■ Press that corresponds to “DISC ” or “ DISC”. Scanning loaded CDs ■ Press and hold until you hear a beep. STEP The first 10 seconds of the first track on each CD will be played. To cancel, press again.
Page 328 3-2. Using the audio system Repeat play Repeating a track ■ Press that corresponds to “RPT”. To cancel, press the button again. Repeating all of the tracks on a CD (type C only) ■ Press that corresponds to “RPT” twice. To cancel, press the button again.
Page 329 Operation has stopped due to a high temper- ature inside the player. Wait for a while and then press . Contact your Toyota dealer if the CD still cannot be played back. Discs that can be used ■ Discs with the marks shown below can be used.
Page 330 3-2. Using the audio system NOTICE CDs and adapters that cannot be used ■ Do not use the following types of CDs, 3 in. (8 cm) CD adapters or Dual Disc. Doing so may damage the player and/or the CD insert/eject function. CDs that have a diameter that is not ●...
Page 331 3-2. Using the audio system NOTICE Player precautions ■ Failure to follow the precautions below may result in damage to the CDs or the player itself. Do not insert anything other than CDs into the CD slot. ● Do not apply oil to the CD player. ●...
Page 332 3-2. Using the audio system Playing MP3 and WMA discs Type A Power Volume CD eject Fast-forwarding Selecting Reversing Selecting a folder a file Selecting a file Playback Searching playback Repeat play Displaying text messages Random playback SIENNA_U (OM45477U)
Page 333 3-2. Using the audio system Type B and C Power Volume CD eject CD load (type C only) Selecting a file/fast-forwarding Selecting a file and reversing Playback/ pause Playback Repeat play Displaying text messages Searching playback CD selection Random play Loading and ejecting MP3 and WMA discs →P.
Page 334 3-2. Using the audio system Selecting and scanning a folder Selecting folders one at a time ■ Press “∧” or “∨” on to select the desired folder. Scanning the first file of all the folders ■ Press and hold until you hear a beep. STEP The first 10 seconds of the first file in each folder will be played.
Page 335 3-2. Using the audio system Selecting and scanning files Selecting one file at a time ■ Turn the dial or press “∧” or “∨” on select the desired file. Selecting the desired file by cueing the files in the folder ■...
Page 336 3-2. Using the audio system Fast forwarding and reversing files Type A Press Type B and C ∧ Press and hold “ ” or “∨” on Playing and pausing files (type B and C) Press Random playback Playing files from a particular folder in random order ■...
Page 337 3-2. Using the audio system Repeat play Repeating a file ■ Press that corresponds to “RPT”. To cancel, press the button again. Repeating all of the files in a folder ■ Type A Press and hold until you hear a beep. To cancel, press the button again.
Page 338 Operation has stopped due to a high temper- ature inside the player. Wait for a while and then press . Contact your Toyota dealer if the CD still cannot be played back. Discs that can be used ■ →P. 428 CD player protection feature ■...
Page 339 3-2. Using the audio system Lens cleaners ■ →P. 428 MP3 and WMA files ■ MP3 (MPEG Audio LAYER3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 compression. WMA (Windows Media Audio) is a Microsoft audio compression format.
Page 340 3-2. Using the audio system Compatible media ● Media that can be used for MP3 and WMA playback are CD-Rs and CD- RWs. Playback in some instances may not be possible, depending on the status of the CD-R or CD-RW. Playback may not be possible or the audio may jump if the disc is scratched or marked with fingerprints.
Page 341 3-2. Using the audio system Multi-sessions ● As the audio system is compatible with multi-sessions, it is possible to play discs that contain MP3 and WMA files. However, only the first session can be played. ID3 and WMA tags ● ID3 tags can be added to MP3 files, making it possible to record the track title and artist name, etc.
Page 342 3-2. Using the audio system Extensions ● If the file extensions .mp3 and .wma are used for files other than MP3 and WMA files, they will be mistakenly recognized and played as MP3 and WMA files. This may result in large amounts of interference and damage to the speakers.
Page 343: Operating An Ipod
3-2. Using the audio system ∗ Operating an iPod Connecting an iPod enables you to enjoy music from the vehicle speakers. Connecting an iPod ■ Open the cover and connect STEP an iPod using an iPod cable. Turn on the power of the iPod if it is not turned on.
Page 344 3-2. Using the audio system Selecting a play mode Press that corresponds to “BROWSE” to select iPod STEP menu mode. Press that corresponds to the desired play mode. STEP Play mode list ■ First Second Third Fourth Play mode selection selection selection selection...
Page 345 3-2. Using the audio system Selecting a list ■ Turn to display the first selection list. STEP Press to select the desired item. STEP Pressing that corresponds to “MORE” changes to the second selection list. Repeat the same procedure to select the desired song name. STEP To return to the previous selection list, press that corresponds...
Page 346 3-2. Using the audio system Playing and pausing songs Press the Fast-forwarding and rewinding songs ∧ Press and hold “ ” or “∨” on Shuffle playback Playing songs from one playlist or album in random order ■ Press that corresponds to “RDM”. To cancel, press the button twice.
Page 347 3-2. Using the audio system Switching the display Press Each time the button is pressed, the display changes in the following order: Track title → Track title/Artist name → Track title/Album name → Track title/Elapsed About iPod ■ Apple is not responsible for the operation of this device or its compliance ●...
Page 348 3-2. Using the audio system Compatible models ■ Model Generation Software version iPod 5th generation Ver. 1.2.0 or higher iPod nano 1st generation Ver. 1.3.0 or higher 2nd generation Ver. 1.1.2 or higher 3rd generation Ver. 1.0.0 or higher iPod touch 1st generation Ver.
Page 349 3-2. Using the audio system CAUTION While driving ■ Do not connect iPod or operate the controls on the iPod. NOTICE To prevent damage to iPod ■ Do not leave iPod in the vehicle. The temperature inside the vehicle may ●...
Page 350: Operating A Usb Memory
3-2. Using the audio system ∗ Operating a USB memory Connecting a USB memory enables you to enjoy music from the vehicle speakers. Connecting a USB memory ■ Open the cover and connect a STEP USB memory. Turn on the power of the USB memory if it is not turned on.
Page 351 3-2. Using the audio system Selecting and scanning a folder Selecting a folder ■ Press “∧” or “∨” on to select the desired folder. Returning to the first file of the first folder ■ Press and hold “∨” on until you hear a beep. Scanning the first file of all the folders ■...
Page 352 3-2. Using the audio system Selecting and scanning files Selecting a file ■ Turn or press “∧” or “∨” on to select the desired file. Scanning the files in a folder ■ Press STEP The first 10 seconds of each file will be played. To cancel, press again.
Page 353 3-2. Using the audio system Random playback Playing files from a folder in random order ■ Press that corresponds to “RDM”. To cancel, press the button twice. Playing all the files from a USB memory in random order ■ Press that corresponds to “RDM”...
Page 354 3-2. Using the audio system USB memory functions ■ Depending on the USB memory that is connected to the system, certain functions may not be available. Disconnecting the device and reconnecting it once again may resolve some malfunctions. Error messages ■...
Page 355 3-2. Using the audio system MP3 and WMA files ● MP3 (MPEG Audio LAYER 3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size using MP3 compression. WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 format.
Page 356 3-2. Using the audio system ID3 and WMA tags ● ID3 tags can be added to MP3 files, making it possible to record the track title, artist name, etc. The system is compatible with ID3 Ver. 1.0, 1.1, and Ver. 2.2, 2.3, 2.4 ID3 tags.
Page 357 3-2. Using the audio system CAUTION While driving ■ Do not connect USB memory or operate the controls on the USB memory. NOTICE To prevent damage to USB memory ■ Do not leave USB memory in the vehicle. The temperature inside the vehi- ●...
Page 358: Optimal Use Of The Audio System
3-2. Using the audio system Optimal use of the audio system Type A Adjusting the sound quality and ASL Type B and C Selector knob Selector buttons Menu button SIENNA_U (OM45477U)
Page 359 3-2. Using the audio system Using the audio control function Changing sound quality modes ■ Type A Pressing selects the mode in the following order. “BAS” → “TRE” → “FAD” → “BAL” → “ASL” Type B and C Press STEP Press that corresponds to the desired mode.
Page 360 3-2. Using the audio system Adjusting sound quality ■ Turning adjusts the level. Sound quality Mode Turn to the Turn to the Level mode displayed left right Low-pitched -5 to 5 tones Mid-pitched -5 to 5 High tones High-pitched -5 to 5 tones Front/rear Shifts to...
Page 361 3-2. Using the audio system Adjusting the Automatic Sound Levelizer (ASL) ■ Type A When “ASL” is selected, turning to the right changes the “ASL” level in the order of “LOW”, “MID” and “HIGH”. Turning to the left turns “ASL” off. ASL automatically adjusts the volume and tone quality according to vehi- cle speed.
Page 362 3-2. Using the audio system Setting the number of preset pages (type B and C) ■ The number of preset pages desired can be set from 1 to 6. The initial setting is 6 pages. Press STEP Press that corresponds to “MORE”. STEP Press that corresponds to “PRESET”.
Page 363: Using The Aux Port
3-2. Using the audio system Using the AUX port This port can be used to connect a portable audio device and listen to it using the vehicle’s speakers. Open the cover and connect STEP the portable audio device. Press STEP Operating portable audio devices connected to the audio system ■...
Page 364: Using The Steering Switches
3-2. Using the audio system ∗ Using the steering switches Some audio features can be controlled using the switches on the steering wheel. Volume Power on, select audio source Radio mode: Selects a radio station CD mode: Selects track, file (MP3 and WMA) and disc ®...
Page 365 3-2. Using the audio system Turning on the power Press when the audio system is turned off. The audio system can be turned off by holding the switch down until you hear a beep. Changing the audio source Press when the audio system is turned on. The audio source changes as follows each time the button is pressed.
Page 366 3-2. Using the audio system Selecting a radio station Press to select the radio mode. STEP Press “∧” or “∨” on to select a radio station. STEP To scan for receivable stations, press and hold the switch until you hear a beep. Selecting a track/file or song ®...
Page 367 3-2. Using the audio system Selecting a disc in the CD changer (type C only) Press to select the CD mode. STEP Press and hold “∧” or “∨” on until you hear a beep. STEP Selecting a track/file or chapter (vehicles with rear seat entertainment system) Press to select the RSE mode.
Page 368 3-2. Using the audio system ∗ Detachable pole antenna The antenna can be removed. Removing the antenna ■ Place the included wrench STEP around the antenna. When not in use, the wrench is stored in glove box. Loosen the antenna with the STEP wrench and remove it.
Page 369 3-2. Using the audio system Installing the antenna ■ Tighten the antenna by one STEP hand until it will not turn any more. Using the wrench, tighten the STEP antenna an additional 1/8th turn (20 to 45 degrees) to secure it in place. After tightening the antenna, remove the wrench.
Page 370 3-2. Using the audio system NOTICE To avoid damaging the antenna ■ Remove the antenna in the following situations. When using an automatic carwash. ● When the antenna will touch the ceiling of a garage, etc. ● When covering the vehicle with a car cover. ●...
Page 371 ® 3-3. Using the Bluetooth audio system ® ∗ Bluetooth audio system ® The Bluetooth audio system enables you to enjoy music played on a portable digital audio player (portable player) from the vehicle speakers via wireless communication. ® This audio system supports Bluetooth , a wireless data system capable of playing portable audio music without cables.
Page 372 ® 3-3. Using the Bluetooth audio system Conditions under which the system will not operate ■ ® If using a portable player that does not support Bluetooth ● If the portable player is switched off ● If the portable player is not connected ●...
Page 373 ® 3-3. Using the Bluetooth audio system Compatible models ■ ® Bluetooth specifications: ● Ver. 1.2, or higher (Recommended: Ver. 2.0+EDR or higher) Following Profiles: ● • A2DP (Advanced Audio Distribution Profile) Ver. 1.0 or higher • AVRCP (Audio/Video Remote Control Profile) Ver. 1.0 or higher (Ver.
Page 374 ® 3-3. Using the Bluetooth audio system CAUTION FCC WARNING ■ Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Radio Frequency Radiation Exposure. This equipment complies with FCC/ IC radiation exposure limits set forth for uncontrolled equipment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65 and RSS-102 of the IC radio frequency (RF) Exposure rules.
Page 375 ® 3-3. Using the Bluetooth audio system ® Using the Bluetooth audio system Audio unit ■ Display A message, name, number, etc. is displayed. Lower-case characters and special characters cannot be displayed. Selects items such as menu and number Turn: Selects an item Press: Inputs the selected item ®...
Page 376 ® 3-3. Using the Bluetooth audio system Operating the system using voice commands By following voice guidance instructions output from the speaker, ® voice commands enable to the operation of the Bluetooth audio sys- tem without the need to check the display or operate Operation procedure when using voice commands ■...
Page 377 ® 3-3. Using the Bluetooth audio system ® Using the Bluetooth audio system for the first time ® Before using the Bluetooth audio system, it is necessary to register ® a Bluetooth enabled portable player in the system. Follow the proce- dure below to register (pair) a portable player: Press until “BT AUDIO”...
Page 378 ® 3-3. Using the Bluetooth audio system Select “Confirm” using a voice command or STEP A passkey is displayed and heard, and a voice guidance instruction for inputting the passkey into the portable player is heard. Input the passkey into the portable player. STEP Refer to the manual that comes with the portable player for the oper- ation of the portable player.
Page 379 ® 3-3. Using the Bluetooth audio system ® Menu list of the Bluetooth audio system Normal operation ■ Second First menu Third menu Operation detail menu “Pair Audio Registering a portable player Player” “Select Audio Selecting a portable player to Player”...
Page 380 ® 3-3. Using the Bluetooth audio system When using a voice command ■ For numbers, say a combination of single digits from zero to nine. Say the command correctly and clearly. Situations in which the system may not recognize your voice ■...
Page 381 ® 3-3. Using the Bluetooth audio system ® Operating a Bluetooth enabled portable player Power Volume Selecting an album Selecting a track/ fast-forwarding Selector buttons and reversing Playback Playback/pause Displaying text messages Selecting an album Press “∧” or “∨” on Selecting tracks Press “∧”...
Page 382 ® 3-3. Using the Bluetooth audio system Playing and pausing tracks Press Fast-forwarding and rewinding tracks ∧ Press and hold “ ” or “∨” on Switching the display Press Each time the button is pressed, the display changes in the following order: Track title →...
Page 383 ® 3-3. Using the Bluetooth audio system ® Setting up a Bluetooth enabled portable player ® Registering a portable player in the Bluetooth audio system allows the system to function. The following functions can be used for reg- istered portable players: Functions and operation procedures ■...
Page 384 ® 3-3. Using the Bluetooth audio system Registering a portable player Select “Pair Audio Player” using a voice command or , and perform the procedure for registering a portable player. (→P. 476) Selecting a portable player to be used Select “Select Audio Player” using a voice command or STEP Select the portable player to be used by either of the following STEP...
Page 385 ® 3-3. Using the Bluetooth audio system Vehicles without a smart key system When the portable player is on standby for the connection, it will be automatically connected whenever the engine switch is in either “ACC” or “ON” position. If a portable player that has already been paired is selected, it is nec- essary to select “From Car”...
Page 386 ® 3-3. Using the Bluetooth audio system Listing the registered portable players Select “List Audio Players” using a voice command or . The list of registered portable players will be read aloud. When listing is complete, the system returns to “BT•A Setup”. Pressing the talk switch while the name of a portable player is being read aloud selects the portable player, and the following functions will become available:...
Page 387 ® 3-3. Using the Bluetooth audio system Deleting a registered portable player Select “Delete Audio Player” using a voice command or STEP Select the portable player to be deleted by either of the follow- STEP ing methods and select “Confirm” using a voice command or a.
Page 388 ® 3-3. Using the Bluetooth audio system ® Bluetooth audio system setup System setup items and operation procedures ■ →P. 553 SIENNA_U (OM45477U)
Page 389 3-4. Using the rear audio system ∗ Rear seat entertainment system features The rear seat entertainment system is designed to allow the rear pas- sengers to enjoy audio and DVD video separately from the front audio system. Front audio system DVD player Display Headphone volume control dials and headphone jacks...
Page 390 3-4. Using the rear audio system Opening and closing the display Opening and closing the display ■ Press the lock release button to open the display. Pull the display down to an easily viewable angle (at 100° or 120°). To close the display, push the display up until a click is heard.
Page 391 3-4. Using the rear audio system Loading a disc Open the cover. STEP Insert the disc into the slot with STEP the label side up. The “DISC” indicator light turns on while the disc is loaded. The player will play the track or chapter, and will repeat it after it reaches the end.
Page 392 3-4. Using the rear audio system Turning the rear seat entertainment system power on/off Operating from the front audio system ■ Selecting either the front audio system or DVD player audio for the speakers Press that corresponds to “OFF”, to turn off the rear seat entertainment system.
Page 393 3-4. Using the rear audio system Setting the rear seat entertainment system lock Vehicles with a navigation system Owners of models equipped with a navigation system should refer to the “NAVIGATION SYSTEM OWNER’S MANUAL”. Vehicles without a navigation system Front audio system Selecting either the front audio system or DVD player audio for the speakers...
Page 394 3-4. Using the rear audio system Adjusting and turning off the screen Adjusting the screen ■ Press on the remote con- troller. Select the brightness, contrast, tone or color, and make adjust- ments. Press to input it. “-” or “Red” “+”...
Page 395 3-4. Using the rear audio system Headphone jacks To use the headphones, con- nect them to the jack. To adjust the volume Turn the knob clockwise to increase the volume. Turn the knob counterclock- wise to decrease the volume. The rear seat entertainment system can be used when ■...
Page 396 • Operation is stopped • If the malfunction still due to a high tempera- exists, take the vehicle ture inside the player to your Toyota dealer This indicates that no No music files playable data is Eject the disc found...
Page 397 3-4. Using the rear audio system Before using the remote controller (for new vehicle owners) ■ Remove the cover. STEP Remove the insulating sheet. STEP When the remote controller batteries are fully depleted ■ Remove the depleted batteries and install new 2 AA batteries.
Page 398 When using AA batteries ■ Batteries can be purchased at your Toyota dealer, electric appliance shops, or camera stores. Replace only with the same or equivalent type recommended by a Toyota dealer. Dispose of used batteries according to the local laws. Headphones ■...
Page 399 3-4. Using the rear audio system CAUTION While driving ■ Do not use headphones. Doing so may cause an accident, resulting in death or serious injury. When the rear seat entertainment system is not used ■ Keep the display closed. In the event of an accident or sudden braking, the opened display may hit an occupant’s body, resulting in injury.
Page 400 3-4. Using the rear audio system Using the DVD player (DVD video) Remote controller ■ Turning on or off the rear entertainment screen Turning on the DVD mode Selecting a chapter Turning on the title selection screen Reversing a disc Playing/pausing a disc Turning on or off the opera- tion switches (icon) on the...
Page 401 3-4. Using the rear audio system Display (Page 1) ■ Turning off the operation switches (icon) on the dis- play Displaying page 2 Turning on the title selection screen for the disc Turning on the menu screen for the disc Reversing a disc Stopping a disc Pausing the disc/canceling...
Page 402 3-4. Using the rear audio system Display (Page 2) ■ Displaying the initial setting screen Displaying page 1 Search for a title Returning to the previous screen Changing the audio lan- guage Changing the subtitle lan- guage Changing the angle Front audio system ■...
Page 403 3-4. Using the rear audio system NOTICE To prevent damage to the remote controller ■ Keep the remote control away from direct sunlight, temperature heat and ● high humidity. Do not drop or knock the remote controller against hard objects. ●...
Page 404 3-4. Using the rear audio system Turning on the menu screen Press or select to turn on the menu screen. For the operation of the menu screen, see the separate manual for the DVD disc. Slow playback Press or select to pause video and then press or select .
Page 405 3-4. Using the rear audio system Searching for a title Select on the control icon screen. STEP Input the desired title number STEP and then select : deletes the last input number : returns to the previous screen Changing the subtitle language Select on the control icon screen.
Page 406 3-4. Using the rear audio system Changing the audio language Select on the control icon screen. STEP STEP Select to display the audio language screen. Each time you press the next available language is selected. : returns to the previous screen Changing the angle Select...
Page 407 3-4. Using the rear audio system DVD player and DVD video discs ■ This DVD player is compatible NTSC color TV formats. DVD video discs conforming to other formats such as PAL or SECAM cannot be used. Region codes ■ Some DVD video discs have a region code indicating where you can use them.
Page 408 3-4. Using the rear audio system DVD video disc glossary ■ DVD video discs: Digital Versatile Discs that hold world’s standard video. ● DVD video discs have adopted “MPEG2”, one of the world standards of digital compression technologies. The picture data is compressed by 1/ 40 on average and stored.
Page 409 3-4. Using the rear audio system Multi-angle feature: Allows you to enjoy the same scene at different ● angles. Multi-language feature: Allows you to select the language of the subtitles ● and audio. Region codes: Region codes are provided on DVD players and DVD ●...
Page 410 3-4. Using the rear audio system Using the DVD player (video CD) Remote controller ■ Selecting a switch (icon) Selecting a chapter Reversing a disc Playing/pausing a disc Fast forwarding a disc Inputting selected switch (icon) Display (page 1) ■ Turning off the menu screen Displaying page 1 Reversing a disc...
Page 411 3-4. Using the rear audio system Display (page 2) ■ Selecting a disc menu num- Displaying page 2 Turning on the disc menu Returning to the previous page screen (with the disc menu displayed) Proceeding to the next page screen (with the disc menu displayed) Changing to a multiplex transmission...
Page 412 3-4. Using the rear audio system Selecting a desired screen Selecting a menu number ■ Select on the control icon screen. STEP Input the desired menu number STEP and select : deletes the last input num- : returns to the previous screen Searching manually ■...
Page 413 3-4. Using the rear audio system Changing the sound-multiplex mode Select on the control icon screen. The mode cycles through each time the is pressed. “Main” → “Sub” → “Main/Sub” Slow playback Press or select to pause video and then press or select .
Page 414 3-4. Using the rear audio system Using the DVD player (audio CD/CD text) Press to display the control screen. Repeat play Random playback Search playback Front audio system ■ Press: Selecting a chapter Press and hold: Fast-for- warding/reversing a disc Playing/pausing a disc Selecting the DVD mode Repeat play (→P.
Page 415 3-4. Using the rear audio system Using the DVD player (WMA/MP3 discs) Using the control screen ■ Press to display the control screen. Repeat play Random playback Search playback Front audio system ■ Press: Selecting a chapter Press and hold: Fast-for- warding/reversing a disc Playing/pausing a disc Selecting the DVD mode...
Page 416 3-4. Using the rear audio system Random playback Playing files from a particular folder in random order ■ Select Playing all of the files on a disc in random order ■ Select , and press and hold Search playback Selecting the desired file by cueing the files in the folder ■...
Page 417 3-4. Using the rear audio system Using the video mode Press to select the video mode. Before switching to the video mode, connect audio device to the A/V input port. Using the port Type A Open the cover. The A/V input port is composed of 3 input ports.
Page 418 3-4. Using the rear audio system A/V input port ■ The rear seat entertainment system plays video and sound when an audio- video device is connected to the A/V input port. For details, refer to the man- ufacturer’s instructions. Power outlet ■...
Page 419 3-4. Using the rear audio system Changing the DVD initial setting Select to display the initial setting screen. The following initialization can be changed here. ● Audio language ● Subtitle language ● DVD language ● Angle mark ● Parental lock SIENNA_U (OM45477U)
Page 420 3-4. Using the rear audio system Changing the audio language Select “Audio Language”. Select the language you want to hear, and press to input : returns to the previous screen Select “Others” if you cannot find the language you want to hear. Enter the appropriate 4-digit lan- guage code.
Page 421 3-4. Using the rear audio system Changing the subtitle language Select “Subtitle Language”. Select the language you want to read, and press to input : returns to the previous screen Select “Others” if you cannot find the language you want to read. Enter the appropriate 4-digit lan- guage code.
Page 422 3-4. Using the rear audio system Changing the DVD language Select “DVD Language”. Select the language you want to read, and press to input : returns to the previous screen Select “Others” if you cannot find the language you want to read. Enter the appropriate 4-digit lan- guage code.
Page 423 3-4. Using the rear audio system Turning on or off the angle mark The angle mark can be turned on for discs that are multi-angle com- patible. Each time you press when “Angle Mark” is selected, the angle mark turns on or off alternately. SIENNA_U (OM45477U)
Page 424 3-4. Using the rear audio system Setting viewer restriction levels Setting a password allows the viewer restriction to be effective. Input the desired personal code and select : deletes the last input number : returns to the previous screen The setting cannot be changed unless the password is entered.
Page 425 3-4. Using the rear audio system Setting the display mode Display size ■ Single screen mode: Pressing changes the display modes sequentially as follows: Normal → Wide → Super wide → Ultra wide → Ultra zoom Split screen mode: Pressing changes the display mode sequentially as fol- lows:...
Page 426 3-4. Using the rear audio system Returning to the previous screen ■ Select and press To initialize the password ■ Press on the remote controller or unit ten times when the screen to enter the personal code is displayed. When changing the display size ■...
Page 427 3-4. Using the rear audio system Language code list ■ Code Language Code Language 0514 English 0208 Bihari 0618 French 0209 Bislama 0405 German 0214 Bengali 0920 Italian 0215 Tibetan 0519 Spanish 0218 Breton 2608 Chinese 0301 Catalan 1412 Dutch 0315 Corsican 1620...
Page 428 3-4. Using the rear audio system Code Language Code Language 0721 Gujarati 1311 Macedonian 0801 Hausa 1312 Malayalam 0809 Hindi 1314 Mongolian 0818 Croatian 1315 Moldavian 0821 Hungarian 1318 Marathi 0825 Armenian 1319 Malay 0901 Interlingua 1320 Maltese 0905 Interlingue 1325 Burmese 0911...
Page 429 3-4. Using the rear audio system Code Language Code Language 1914 Shona 2014 Setswana 1915 Somali 2015 Tonga 1917 Albanian 2018 Turkish 1918 Serbian 2019 Tsonga 1919 Siswati 2020 Tatar 1920 Sesotho 2023 1921 Sundanese 2111 Ukrainian 1923 Swahili 2118 Urdu 2001 Tamil...
Page 430 3-5. Using the hands-free phone system (for cellular phone) ∗ Hands-free phone system (for cellular phone) features The hands-free system is a function that allows you to use your cel- lular phone without touching it. ® This system supports Bluetooth , which allows you to make or receive calls without using cables to connect a cellular phone to the system, and without operating the cellular phone.
Page 431 3-5. Using the hands-free phone system (for cellular phone) Title Page Using the hands-free phone system ■ Operating the system using a voice command P. 534 ■ Using the hands-free phone system for the first time ■ Menu list of the hands-free phone sys- Making a phone call ■...
Page 432 3-5. Using the hands-free phone system (for cellular phone) Conditions under which the system will not operate ■ ® If using a mobile phone that does not support Bluetooth ● If the mobile phone is switched off ● If you are outside service range ●...
Page 433 3-5. Using the hands-free phone system (for cellular phone) ® About Bluetooth ■ Bluetooth is a registered trademark of Bluetooth SIG. Inc. Compatible models ■ Compatible with HFP (Hands Free Profile) Ver. 1.5 and OPP (Object Push Profile) Ver. 1.1. ®...
Page 434 3-5. Using the hands-free phone system (for cellular phone) CAUTION FCC WARNING ■ Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Radio Frequency Radiation Exposure. This equipment complies with FCC/ IC radiation exposure limits set forth for uncontrolled equipment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65 and RSS-102 of the IC radio frequency (RF) Exposure rules.
Page 435 3-5. Using the hands-free phone system (for cellular phone) ∗ Using the hands-free phone system (for cellular phone) Audio unit ■ Displays such items as messages, name, phone number Lower-case characters and special characters, such as an umlaut, cannot be dis- played.
Page 436 3-5. Using the hands-free phone system (for cellular phone) Steering wheel telephone switches ■ Volume The voice guidance volume cannot be adjusted using this button. Hands-free phone system off/ends a call/refuses a call Hands-free phone system on/starts a call Press: Voice command sys- tem on Press and hold: Voice com- mand system off...
Page 437 3-5. Using the hands-free phone system (for cellular phone) Operating the system using a voice command By following voice guidance instructions output from the speaker, voice commands can be given to allow for operation of the hands- free phone system without checking the display or operating Operation procedure when using a voice command ■...
Page 438 3-5. Using the hands-free phone system (for cellular phone) Using the hands-free phone system for the first time Before using the hands-free phone system, it is necessary to register a cellular phone in the system. The phone registration mode will be entered automatically when starting the system with no cellular phone registered.
Page 439 3-5. Using the hands-free phone system (for cellular phone) Registration to the hands-free phone system only Select “Phone Only” using a voice command or STEP Registration to the hands-free phone system and Bluetooth® audio system at the same time Select “Internal Audio (Int, Audio)” using a voice command or STEP Select “Confirm”...
Page 440 3-5. Using the hands-free phone system (for cellular phone) Menu list of the hands-free phone system Normal operation ■ Second First menu Third menu Operation detail menu Dialing a number stored in “Callback” the incoming call history memory Dialing a number stored in “Redial”...
Page 441 3-5. Using the hands-free phone system (for cellular phone) Second First menu Third menu Operation detail menu “Set PIN” Setting a PIN code “Phonebook Locking the phone book “Security” Lock” “Phonebook Unlocking the phone book Unlock” Registering the cellular “Pair Phone” phone to be used “Change Changing a registered name...
Page 442 3-5. Using the hands-free phone system (for cellular phone) Using a short cut key ■ First menu Second menu Operation detail Dialing a number registered “Dial XXX (name)” in the phone book “Dial XXX (number)” Dialing the input numbers “Phone book add Adding a new number entry”...
Page 443 3-5. Using the hands-free phone system (for cellular phone) Automatic adjustment of volume ■ When vehicle speed is 50 mph (80 km/h) or more, the volume automatically increases. The volume returns to the previous volume setting when vehicle speed drops to 43 mph (70 km/h) or less. When using a voice command ■...
Page 444 3-5. Using the hands-free phone system (for cellular phone) Making a phone call Making a phone call ■ ● Dialing by inputting a number “Dial by number” ● Dialing by inputting a name “Dial by name” ● Speed dialing ● Dialing a number stored in the outgoing history memory “Redial”...
Page 445 3-5. Using the hands-free phone system (for cellular phone) Dialing by inputting a number Press the talk switch and say “Dial by number”. STEP Press the talk switch and say the phone number. STEP Dial by one of the following methods: STEP a.
Page 446 3-5. Using the hands-free phone system (for cellular phone) Speed dialing Press the off-hook switch. STEP Press the preset button in which the desired number is regis- STEP tered. Press the off-hook switch. STEP When receiving a phone call Answering the phone ■...
Page 447 3-5. Using the hands-free phone system (for cellular phone) Using the call history memory Follow the procedure below to use a number stored in the call history memory: Press the talk switch and say “Redial” (when using a number STEP stored in the outgoing call history memory) or “Call back”...
Page 448 3-5. Using the hands-free phone system (for cellular phone) Call history ■ Up to 5 phone numbers can be stored in each of the outgoing and incoming call history memories. When talking on the phone ■ Do not talk simultaneously with the other party. ●...
Page 449 3-5. Using the hands-free phone system (for cellular phone) Setting a cellular phone Registering a cellular phone in the hands-free phone system allows the system to function. The following functions can be used for reg- istered cellular phones: Functions and operation procedures ■...
Page 450 3-5. Using the hands-free phone system (for cellular phone) Registering a cellular phone Select “Pair Phone” using a voice command or , and do the procedure for registering a cellular phone. (→P. 537) Selecting the cellular phone to be used Select “Select Phone”...
Page 451 3-5. Using the hands-free phone system (for cellular phone) Changing a registered name Select “Change Name” using a voice command or STEP Select the name of the cellular phone to be changed by one of STEP the following methods: a. Press the talk switch and say the desired phone name, and select “Confirm”...
Page 452 3-5. Using the hands-free phone system (for cellular phone) Listing the registered cellular phones Selecting “List Phones” using a voice command or causes the list of registered cellular phones to be read aloud. When listing is complete, the system returns to “Phone Setup”. Pressing the talk switch while the name of a cellular phone is being read selects the cellular phone, and the following functions will be available:...
Page 453 3-5. Using the hands-free phone system (for cellular phone) Changing the passkey Select “Set Passkey” using a voice command or STEP Press the talk switch, say a 4 to 8-digit number, and select STEP “Confirm” using a voice command or The number should be input 1 digit at a time.
Page 454 3-5. Using the hands-free phone system (for cellular phone) Security and system setup To enter the menu of each setting, follow the steps below: Security setting items and operation procedure ■ ● Setting or changing the PIN (Personal Identification Number) 1.
Page 455 3-5. Using the hands-free phone system (for cellular phone) Setting or changing the PIN Setting a PIN ■ Select “Set PIN” using a voice command or STEP Enter a PIN using a voice command or STEP When using , input the code 1 digit at a time. Changing the PIN ■...
Page 456 3-5. Using the hands-free phone system (for cellular phone) Locking or unlocking the phone book Select “Phonebook Lock (Phbk Lock)” or “Phonebook unlock STEP (Phbk Unlock)” using a voice command or Input the PIN by either of the following methods and select STEP “Confirm”...
Page 457 3-5. Using the hands-free phone system (for cellular phone) ® Displaying the Bluetooth device address and name Select “Device Name” using STEP ® Turn to display the Bluetooth device address and STEP name. Select “Go Back” using to return to “System Setup”. STEP Initialization Select “Initialize”...
Page 458 3-5. Using the hands-free phone system (for cellular phone) Initialization ■ The following data in the system can be initialized: ● • Phone book • Outgoing and incoming call history • Speed dials • Registered cellular phone data • Security code Once the initialization has been completed, the data cannot be restored ●...
Page 459 3-5. Using the hands-free phone system (for cellular phone) Using the phone book To enter the menu of each setting, follow the steps below: ● Adding a new phone number 1. “Phonebook” → 2. “Add Entry” ● Setting speed dial 1.
Page 460 3-5. Using the hands-free phone system (for cellular phone) Adding procedure ■ Select “Add Entry” using a voice command or STEP Use one of the following methods to input a phone number: STEP Inputting a phone number using a voice command STEP2-1: Select “By Voice”...
Page 461 3-5. Using the hands-free phone system (for cellular phone) Inputting a phone number using STEP2-1: Select “Manual Input” using STEP2-2: Input a phone number using , and press once again. Input the phone number 1 digit at a time. Selecting a phone number from outgoing or incoming call his- tory STEP2-1: Select “Call History”...
Page 462 3-5. Using the hands-free phone system (for cellular phone) Select the name to be registered by either of the following STEP methods, and select “Confirm” using a voice command or a. Press the talk switch and say the desired name. b.
Page 463 3-5. Using the hands-free phone system (for cellular phone) Setting speed dials Select “Set Speed Dial (Speed Dial)” using a voice command STEP Select the data to be registered as a speed dial by one of the STEP following methods: a.
Page 464 3-5. Using the hands-free phone system (for cellular phone) Changing a registered name Select “Change Name” using a voice command or STEP Select the name to be changed by one of the following meth- STEP ods. a. Press the talk switch, say desired name, and select “Con- firm”...
Page 465 3-5. Using the hands-free phone system (for cellular phone) Deleting registered data Select “Delete Entry” using a voice command or STEP Select the data to be deleted by either of the following meth- STEP ods, and select “Confirm” using a voice command or a.
Page 466 3-5. Using the hands-free phone system (for cellular phone) Listing the registered data Selecting “List names” using a voice command causes a list of the registered data to be read aloud. When listing is complete, the system returns to “Phonebook”. Pressing the talk switch while the desired data is being read aloud selects the data, and the following functions will be available.
Page 467 3-6. Using the interior lights Interior lights list Outer foot lights (if equipped) Rear interior light Rear personal/interior lights (→P. 569) Rear ceiling lights (if equipped) (→P. 570) Front personal/interior lights (→P. 568) Engine switch light (if equipped) Front door courtesy lights (if equipped) SIENNA_U (OM45477U)
Page 468 3-6. Using the interior lights Personal/interior light main switch Personal/interior light main switch (vehicles with overhead console) Type A Push to activate the inte- rior lights. The personal/interior lights can- not be individually turned off with this switch. Door position When door mode is active it will Type B be indicated by a green light on...
Page 469 3-6. Using the interior lights Personal/interior lights Personal/interior lights (vehicles with overhead console) Front type A On/off Front type B SIENNA_U (OM45477U)
Page 470 3-6. Using the interior lights Personal/interior lights Rear On/off Rear personal/interior lights turn on when the personal/interior main switch is in door position. Personal/interior lights can also be turned on/off from each indi- vidual light. When an individual light is activated it must be turned off at its location.
Page 471 3-6. Using the interior lights Personal lights and rear ceiling lights Personal lights (vehicles without overhead console) Front On/off Rear On/off Rear ceiling lights (if equipped) On/off SIENNA_U (OM45477U)
Page 472 If the lights remain on when a door is not fully closed and the personal/inte- rior light main switch is in door position, the lights will go off automatically after 30 seconds. Customization that can be configured at Toyota dealer ■ Settings (e.g. the time elapsed before lights turn off) can be changed.
Page 473 3-7. Using the storage features List of storage features Auxiliary boxes Cup holders Door pockets Bottle holders Overhead console (if equipped) Glove boxes Console box (if equipped) SIENNA_U (OM45477U)
Page 474: Glove Boxes
3-7. Using the storage features Glove boxes CAUTION Items that should not be left in the storage spaces ■ Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the following when cabin temperature becomes high: Glasses may be deformed by heat or cracked if they come into contact ●...
Page 475 3-7. Using the storage features Glove boxes Lower glove box The lower glove box can be opened by pulling the lever and can be locked and unlocked by using the master key (vehicles without a smart key) or the mechanical key (vehicles with a smart key system). Unlock Lock Open...
Page 476 3-7. Using the storage features Console box Console box (if equipped) Using the console box ■ Type A Press the tab. Type B Press the tab. SIENNA_U (OM45477U)
Page 477 3-7. Using the storage features Console box Sliding the console box (type B) ■ From front Press the tab and slide the console box. From rear Pull up the lever and slide the console box. Console box light ■ The console box light turns on when the headlight switch is on. SIENNA_U (OM45477U)
Page 478 3-7. Using the storage features Console box CAUTION Caution while driving ■ Keep the console box closed when not in use. In the event of sudden brak- ing or sudden swerving, an accident may occur due to an occupant being struck by the open console box or the items stored inside.
Page 479 3-7. Using the storage features Overhead console Overhead console (if equipped) Push the lid. The overhead console is useful temporarily storing small items. CAUTION While driving ■ Do not leave the overhead console open. Items may fall out and cause injury. Maximum storage weight ■...
Page 480 3-7. Using the storage features Cup holders Cup holders Front Press in and release the front cup holder. Console box (if equipped) Console box type A (if equipped) Pull the lid down. SIENNA_U (OM45477U)
Page 481 3-7. Using the storage features Cup holders Console box type B (if equipped) Second center seat (if equipped) Removing the second center seat. (→P. 106) Rear SIENNA_U (OM45477U)
Page 482 3-7. Using the storage features Cup holders Removing the separator (front) ■ Pull the separator up. The separator may be removed for clean- ing. Cup holder light (console box type A and B) ■ The cup holder light turns on when the headlight switch is on. CAUTION Items unsuitable for the cup holder ■...
Page 483 3-7. Using the storage features Bottle holders Bottle holders Type A Type B SIENNA_U (OM45477U)
Page 484 3-7. Using the storage features Bottle holders CAUTION Items unsuitable for the bottle holder ■ Do not place anything other than a bottle in the bottle holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
Page 485 3-7. Using the storage features Door pockets Door pockets Type A Type B NOTICE Door pockets (type B) ■ Make sure magazines are not bent or protruding from the sliding door pockets. Do not insert anything too big so that the shape of the sliding door pockets is dis- torted.
Page 486 3-7. Using the storage features Auxiliary boxes Auxiliary boxes Type A Push down the knob. Type B (if equipped) Type C SIENNA_U (OM45477U)
Page 487 3-7. Using the storage features Auxiliary boxes Type D (if equipped) Type E (if equipped) Type F Lift the lid. SIENNA_U (OM45477U)
Page 488 3-7. Using the storage features Auxiliary boxes Type G Removing the second center seat. (→P. 106) ITN37N026 Type H (if equipped) ITN37N027 Type I (if equipped) SIENNA_U (OM45477U)
Page 489 3-7. Using the storage features Auxiliary boxes Type J (if equipped) Type K (if equipped) SIENNA_U (OM45477U)
Page 490 3-7. Using the storage features Auxiliary boxes Coin holder (type A) ■ Nickels, quarters and dimes can be stored separately. CAUTION Caution while driving (type A and F) ■ Keep the auxiliary boxes closed. Injuries may result in the event of an accident or sudden braking. SIENNA_U (OM45477U)
Page 491 3-8. Other interior features Sun visors To set the visor in the for- ward position, flip it down. To set the visor in the side position, flip down, unhook, and swing it to the side. To use the side extender, place the visor in the side position, then slide it back- ward.
Page 492 3-8. Other interior features Vanity mirrors Flip down. Open the cover. The light turns on when the cover is opened. NOTICE To prevent battery discharge ■ Do not leave the vanity lights on for extended periods while the engine is off. SIENNA_U (OM45477U)
Page 493 3-8. Other interior features ∗ Clock Adjusts the hours. Adjusts the minutes. The clock is displayed when ■ Vehicles without a smart key system The engine switch is in the “ACC” or “ON” position. Vehicles with a smart key system The “ENGINE START STOP”...
Page 494 3-8. Other interior features ∗ Conversation mirror The conversation mirror can provide the driver and the front passen- ger with a view of the rear seat area without the need to turn around. Push the lid and allow the lid STEP to open.
Page 495 3-8. Other interior features Power outlets The power outlet can be used for the following components: 12 V: Accessories that run on less than 10 A 120 V AC: Accessories that use less than 100 W 12 V ■ Center panel type A Center panel type B SIENNA_U (OM45477U)
Page 496 3-8. Other interior features Luggage compartment 120 V AC (if equipped) ■ Power outlet socket console box type A Power outlet socket console box type B SIENNA_U (OM45477U)
Page 497 3-8. Other interior features Power outlet socket luggage compartment The power outlet can be used when ■ Vehicles without a smart key system 12 V: The engine switch is in the “ACC” or “ON” position. 120 V AC: The engine switch is in the “ON” position. Vehicles with a smart key system 12 V: The “ENGINE START STOP”...
Page 498 3-8. Other interior features NOTICE To avoid damaging the power outlet ■ Close the power outlet lid when the power outlet is not in use. Foreign objects or liquids that enter the power outlet may cause a short cir- cuit. To prevent blown fuse ■...
Page 499 3-8. Other interior features ∗ Seat heaters For driver’s seat For front passenger’s seat The indicator light comes on. Adjusts the seat tempera- ture The further you move the dial upward, the warmer the seat becomes. The seat heaters can be used when ■...
Page 500 3-8. Other interior features CAUTION Burns ■ Use caution when seating the following persons in a seat with the seat ● heater on to avoid the possibility of burns: • Babies, small children, the elderly, the sick and the physically chal- lenged •...
Page 501 3-8. Other interior features Armrests Front seat Pull the armrest down for use. Second seat (if equipped) Pull the armrest down for use. SIENNA_U (OM45477U)
Page 502 3-8. Other interior features Adjusting the armrests (if equipped) ■ Push the armrest down while pressing the button. NOTICE To prevent damage to the armrest ■ Do not place too much strain on the armrest. SIENNA_U (OM45477U)
Page 503 3-8. Other interior features ∗ Rear side sunshades Rear door window Pull the tab up. Secure the sunshade using the hooks. To retract the sunshade, pull the tab up slightly to unhook the sunshade, and lower the sunshade slowly. Rear quarter window Pull the tab up.
Page 504 3-8. Other interior features Grocery bag hooks The hooks are designed to hang things like a grocery bag. Type A (front seatback) (if equipped) Type B (third seatback) Type C (luggage compartment) Pull the hook up. SIENNA_U (OM45477U)
Page 505 3-8. Other interior features Type D (luggage compartment) ITN38N036 CAUTION When not in use (type C) ■ Keep the grocery bag hook stowed. Injuries may result in the event of sudden braking, sudden swerving or an accident. NOTICE Grocery bag hook weight capacity (type A and B) ■...
Page 506 ■ Do not use floor mats designed for other models or different model year ● vehicles, even if they are Toyota Genuine floor mats. Only use floor mats designed for the driver’s seat. ● Always install the floor mat securely using the retaining hooks (clips) pro- ●...
Page 507 3-8. Other interior features CAUTION Before driving ■ Check that the floor mat is securely ● fixed in the correct place with all the provided retaining hooks (clips). Be especially careful to perform this check after cleaning the floor. With the engine stopped and the shift ●...
Page 508 3-8. Other interior features Luggage compartment features Cargo hooks ■ Cargo hooks are provided for securing loose items. Cargo net hooks ■ Pattern 1 Pattern 2 SIENNA_U (OM45477U)
Page 509 3-8. Other interior features Storage box (if equipped) ■ Engage the latch buckle. CAUTION When the cargo hooks are not in use ■ To avoid injury, always return the cargo hooks to their positions when they are not in use. NOTICE To prevent damage to the cargo net hooks ■...
Page 510 3-8. Other interior features ∗ Garage door opener The garage door opener can be programmed to operate garage doors, gates, entry doors, door locks, home lighting systems, secu- rity systems, and other devices. ® The garage door opener (HomeLink Universal Transceiver) is manufac- ®...
Page 511 3-8. Other interior features ® Programming the HomeLink ■ Point the remote control for the STEP device 1 to 3 in. (25 to 75 mm) ® from the HomeLink control but- tons. Keep the indicator light on the ® HomeLink in view while pro- gramming.
Page 512 3-8. Other interior features Test operation STEP ® HomeLink pressing newly programmed button. If programming a garage door opener, check to see if the garage door opens and closes. If the garage door does not operate, see if your garage transmitter is of the Rolling Code type.
Page 513 3-8. Other interior features Programming a Rolling Code system (for U.S.A. owners) ■ If your device is Rolling Code equipped, follow the steps under the ® heading “Programming the HomeLink ” before proceeding with the steps listed below. Locate the training button on the ceiling mounted garage door STEP opener motor.
Page 514 ® the remaining HomeLink buttons. Programming other devices ■ To program other devices such as home security systems, home door locks or lighting, contact your authorized Toyota dealer for assistance. Reprogramming a button ■ ® The individual HomeLink buttons cannot be erased but can be reprogrammed.
Page 515 3-8. Other interior features ® Operating the HomeLink ® ® Press the appropriate HomeLink button. The HomeLink indicator ® light on the HomeLink transceiver should turn on. ® The HomeLink continues to send a signal for up to 20 seconds as long as the button is pressed.
Page 516 3-8. Other interior features Before programming ■ Install a new battery in the transmitter. ● The battery side of the transmitter must be pointed away from the ● ® HomeLink button. Certification for the garage door opener ■ For vehicles sold in the U.S.A. FCC ID: NZLWZLHL4 NOTE: This device complies with Part 15 of the FCC Rules.
Page 517 3-8. Other interior features CAUTION When programming a garage door or other remote control device ■ The garage door may operate, so ensure people and objects are out of dan- ger to prevent potential harm. Conforming to federal safety standards ■...
Page 518 3-8. Other interior features ∗ Compass The compass on the trip information display indicates the direction in which the vehicle is heading. Operation ■ To turn the compass on or off, press the switch. Displays and directions ■ Display Direction North Northeast East...
Page 519 3-8. Other interior features Calibrating the compass Samoa: 5 Guam: 8 Saipan: 8 The direction display deviates from the true direction determined by the earth’s magnetic field. The amount of deviation varies according to the geographic position of the vehicle. If you cross over a map boundary shown in illustration, the compass will deviate.
Page 520 3-8. Other interior features Deviation calibration ■ Stop the vehicle where it is safe to drive in a circle. STEP Press and hold the switch. STEP A number (1 to 15) appears on the compass display. Referring to the map above, press the switch to select the STEP number of the zone you are in.
Page 521 3-8. Other interior features Conditions unfavorable to correct operation ■ The compass may not show the correct direction in the following conditions: The vehicle is stopped immediately after turning. ● The vehicle is on an inclined surface. ● The vehicle is in a place where the earth’s magnetic field is subject to ●...
Page 522 3-8. Other interior features NOTICE To avoid a compass malfunctions ■ Do not place magnets or any metal objects near the roof of the vehicle. Doing this may cause a malfunction of the compass sensor. To ensure normal operation of the compass ■...
Page 523 Telematics Subscription Service Agreement and its Terms and Conditions, as in effect and amended from time to time, a current copy of which is available at Toyota.com. All use of the Safety Con- nect service is subject to such then-applicable Terms and Condi- tions.
Page 524 After you have signed the Telematics Subscription Service Agreement and are enrolled, you can begin receiving services. A variety of subscription terms is available for purchase. Contact your Toyota dealer, call 1-800-331-4331, or push the “SOS” but- ton in your vehicle for further subscription details. SIENNA_U (OM45477U)
Page 525 ● during Safety Connect. Safety Connect is available beginning Fall 2009 on select Toyota models. ● Contact with the Safety Connect response center is dependent upon the telematics device being in operative condition, cellular connection avail- ability, and GPS satellite signal reception, which can limit the ability to reach the response center or receive emergency service support.
Page 526 ● Green indicator light flashing = Safety Connect call in process ● Red indicator light (except at vehicle start-up) = System malfunc- tion (contact your Toyota dealer) ● No indicator light (off) = Safety Connect service not active Safety Connect services Automatic Collision Notification ■...
Page 527 In addition to assisting law enforcement with recovery of a stolen vehicle, Safety-Connect-equipped vehicle location data may, under certain circumstances, be shared with third parties to locate your vehicle. Further information is available at Toyota.com. Emergency Assistance Button (“SOS”) ■...
Page 528 3-8. Other interior features Safety information for Safety Connect Important! Read this information before using Safety Connect. Exposure to radio frequency signals ■ The Safety Connect system installed in your vehicle is a low-power radio transmitter and receiver. It receives and also sends out radio frequency (RF) signals.
Page 529 3-8. Other interior features Certification for Safety Connect ■ FCC ID: O9EGTM1 FCC ID: O6Y-CDMRF101 NOTE: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interfer- ence that may cause undesired operation.
Page 530 4-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition: ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 531 4-1. Maintenance and care High pressure car washes ■ Do not allow the nozzles of the car wash to come within close proximity ● of the windows. Before using car wash, check that the fuel filler door on your vehicle is ●...
Page 532 4-1. Maintenance and care CAUTION When washing the vehicle ■ Do not apply water to the inside of the engine compartment. Doing so may cause the electrical components etc. to catch fire. When cleaning the windshield (vehicles with rain-sensing windshield ■...
Page 533 4-1. Maintenance and care NOTICE To prevent paint deterioration and corrosion on the body and compo- ■ nents (aluminum wheels etc.) Wash the vehicle immediately in the following cases: ● • After driving near the sea coast • After driving on salted roads •...
Page 534 4-1. Maintenance and care NOTICE Cleaning the exterior lights ■ Wash carefully. Do not use organic substances or scrub with a hard brush. ● This may damage the surface of the lights. Do not apply wax on the surfaces of the lights. ●...
Page 535 4-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior ■ Remove dirt and dust using a vacuum cleaner. Wipe dirty sur- faces with a cloth dampened with lukewarm water.
Page 536 4-1. Maintenance and care Caring for leather areas ■ Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. Shampooing the carpets ■ There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 537 4-1. Maintenance and care NOTICE Cleaning detergents ■ Do not use the following types of detergent, as they may discolor the vehi- ● cle interior or cause streaks or damage to painted surfaces: • Non-seat portions: Organic substances such as benzene or gasoline, alkaline or acidic solutions, dye, and bleach •...
Page 538 4-1. Maintenance and care NOTICE Water on the floor ■ Do not wash the vehicle floor with water. Vehicle systems such as the audio system may be damaged if water comes into contact with electrical components such as the audio system above or under the floor of the vehicle.
Page 539 It is recommended that genuine Toyota parts be used for repairs to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than a Toyota dealer performs repairs, confirm the war- ranty coverage.
Page 540 4-2. Maintenance Allow inspection and repairs to be performed by a Toyota dealer ■ Toyota technicians are well-trained specialists and are kept up to date ● with the latest service information. They are well informed about the operations of all systems on your vehicle.
Page 541 4-2. Maintenance CAUTION If your vehicle is not properly maintained ■ Improper maintenance could result in serious damage to the vehicle and possible serious injury or death. Handling of the battery ■ Engine exhaust, some of its constituents, and a wide variety of automobile ●...
Page 542 Booklet” “Owner’s Manual Supplement/Scheduled Maintenance Guide”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment Items Check points Check the indicator and Battery connections.
Page 543: Vehicle Interior
4-2. Maintenance Vehicle interior Items Check points • The accelerator pedal should Accelerator pedal move smoothly (without uneven pedal effort or catching). • When parked on a slope with the Automatic transaxle “Park” mech- shift lever in P, is the vehicle anism securely stopped? •...
Page 544 4-2. Maintenance Items Check points • Do the indicators and buzzers Indicators/buzzers function properly? • Do all the lights come on? Lights • Are the headlights aimed cor- rectly? • Does the parking brake lever or pedal move smoothly? Parking brake •...
Page 545: Vehicle Exterior
4-2. Maintenance Vehicle exterior Items Check points Doors • Do the doors operate smoothly? • Does the engine hood lock sys- Engine hood tem work properly? • There should not be any signs of Fluid leaks fluid leakage after the vehicle has been parked.
Page 546 The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/ M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. Your vehicle may not pass the I/M test in the following situa- ■...
Page 547 Brake fluid level (→P. 665) • Rag or paper towel • Funnel (used only for adding brake fluid) • “Toyota Super Long Life Coolant” or similar high quality ethylene glycol based non-silicate, non- amine, non-nitrite and non-borate coolant with long-life hybrid organic acid technology.
Page 548 4-3. Do-it-yourself maintenance Items Parts and tools • “Toyota Genuine Motor Oil” or equivalent (→P. 657) Engine oil level • Rag or paper towel • Funnel (used only for adding engine oil) • Fuse with same amperage rating Fuses (→P. 696) as original •...
Page 549 4-3. Do-it-yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury, observe the following precautions: When working on the engine compartment: ■ Keep hands, clothing and tools away from the moving fan and engine ●...
Page 550 4-3. Do-it-yourself maintenance CAUTION Safety glasses ■ Wear safety glasses to prevent flying or falling material, fluid spray, etc. from getting in your eyes. NOTICE If you remove the air cleaner filter ■ Driving with the air cleaner filter removed may cause excessive engine wear due to dirt in the air.
Page 551 4-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood release lever. STEP The hood will pop up slightly. Pull up the auxiliary catch STEP lever and lift the hood. Hold the hood open by insert- STEP ing the supporting rod into the...
Page 552 4-3. Do-it-yourself maintenance CAUTION Pre-driving check ■ Check that the hood is fully closed and locked. If the hood is not locked properly, it may open while the vehicle is in motion and cause an accident, which may result in death or serious injury. After installing the support rod into the slot ■...
Page 553 4-3. Do-it-yourself maintenance Positioning a floor jack When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement may damage your vehicle or cause injury. Front ■ Rear ■ 2WD models AWD models SIENNA_U (OM45477U)
Page 554 4-3. Do-it-yourself maintenance CAUTION When raising your vehicle ■ Make sure to observe the following precautions to reduce the possibility of death or serious injury: Lift up the vehicle using a floor jack ● such as the one shown in the illustra- tion.
Page 555 4-3. Do-it-yourself maintenance Engine compartment 1AR-FE engine Washer fluid tank (→P. 671) Brake fluid reservoir (→P. 665) Engine oil level dipstick (→P. 657) Fuse box (→P. 696) Engine oil filler cap Battery (→P. 667) (→P. 659) Electric cooling fans Engine coolant reservoir Condenser (→P.
Page 556 4-3. Do-it-yourself maintenance 2GR-FE engine Washer fluid tank (→P. 671) Brake fluid reservoir (→P. 665) Engine oil filler cap (→P. 659) Fuse box (→P. 696) Engine oil level dipstick Battery (→P. 667) (→P. 657) Electric cooling fans Engine coolant reservoir Condenser (→P.
Page 557 4-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. Checking the engine oil ■ Park the vehicle on level ground. After warming up the engine STEP and turning it off, wait more than five minutes for the oil to drain back into the bottom of the engine.
Page 558 4-3. Do-it-yourself maintenance Wipe the dipstick and reinsert it fully. STEP 1AR-FE engine Full 2GR-FE engine SIENNA_U (OM45477U)
Page 559 4-3. Do-it-yourself maintenance Adding engine oil ■ If the oil level is below or near the low level mark, add engine oil of the same type as that already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 560 Oil consumption: Max. 1.1 qt./600 miles, 0.9 Imp.qt./600 miles (1.0 L per ● 1000 km) If your vehicle consumes more than 1.1 qt. (1.0 L, 0.9 Imp.qt.) every ● 600 miles (1000 km), contact your Toyota dealer. SIENNA_U (OM45477U)
Page 561 ● not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal. Do not leave used engine oil within the reach of children.
Page 562: Engine Coolant
If the coolant level drops within a short time of replenishing ■ Visually check the radiator, hoses, engine coolant reservoir caps drain cock and water pump. If you cannot find a leak, have your Toyota dealer test the cap and check for leaks in the cooling system. SIENNA_U (OM45477U)
Page 563 4-3. Do-it-yourself maintenance CAUTION When the engine is hot ■ Do not remove the engine coolant reservoir cap. The cooling system may be under pressure and may spray hot coolant if the cap is removed, causing serious injuries, such as burns. NOTICE When adding coolant ■...
Page 564 Check the radiator and condenser and clear away any foreign objects. If either of the above parts is extremely dirty or you are not sure of their condition, have your vehicle inspected by your Toyota dealer. CAUTION When the engine is hot ■...
Page 565 4-3. Do-it-yourself maintenance Brake fluid Checking fluid level ■ The brake fluid level should be between the “MAX” and “MIN” lines on the tank. “MAX” “MIN” Adding fluid ■ Lift the cover off. Make sure to check the fluid type and prepare the necessary item. Fluid type FMVSS No.116 DOT 3 or SAE J1703 brake fluid Item...
Page 566 4-3. Do-it-yourself maintenance Brake fluid can absorb moisture from the air ■ Excess moisture in the brake fluid can cause a dangerous loss of braking efficiency. Use only newly opened brake fluid. CAUTION When filling the reservoir ■ Take care as brake fluid can harm your hands and eyes and damage painted surfaces.
Page 567 4-3. Do-it-yourself maintenance Battery Check the battery as follows: Battery exterior ■ Make sure that the battery terminals are not corroded and that there are no loose connections, cracks, or loose clamps. Terminals Hold-down clamp Before recharging ■ When recharging, the battery produces hydrogen gas which is flammable and explosive.
Page 568 Take extra care when connecting the battery if the “ENGINE START STOP” switch mode prior to discharge is unknown. If the system will not start even after multiple attempts, contact your Toyota dealer. Disconnecting the battery (vehicles with an AUTO ACCESS SEAT) ■...
Page 569 4-3. Do-it-yourself maintenance CAUTION Chemicals in the battery ■ Batteries contain poisonous and corrosive sulfuric acid and may produce hydrogen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near the battery: Do not cause sparks by touching the battery terminals with tools.
Page 570 4-3. Do-it-yourself maintenance CAUTION How to recharge the battery ■ Only perform a slow charge (5 A or less). The battery may explode if charged at a quicker rate. Emergency measures regarding electrolyte ■ If electrolyte gets in your eyes ●...
Page 571 4-3. Do-it-yourself maintenance Washer fluid If any washer does not work or the low washer fluid warning light comes on, the washer tank may be empty. Add washer fluid. CAUTION When refilling washer fluid ■ Do not refill washer fluid when the engine is hot or running, as washer fluid contains alcohol and may catch fire if spilled on the engine etc.
Page 572 4-3. Do-it-yourself maintenance Tires Replace or rotate tires in accordance with maintenance sched- ules and treadwear. Checking tires ■ New tread Treadwear indicator Worn tread The location of treadwear indicators is shown by the “TWI” or “ ” marks, etc., molded on the sidewall of each tire.
Page 573 Vehicles with a spare tire of a different wheel type from the installed tires Rotate the tires in the order shown. To equalize tire wear and extend tire life, Toyota recom- mends that tire rotation is Front carried out at the same inter- val as tire inspection.
Page 574 Have tire pressure warning valve and transmitter ID codes registered by your Toyota dealer. (→P. 676) Initializing the tire pressure warning system When the tire size is changed, the tire pressure warning system must be initialized.
Page 575 4-3. Do-it-yourself maintenance Turn the engine switch to the “ON” position (vehicles without a STEP smart key system) or “ENGINE START STOP” switch to IGNI- TION ON mode (vehicles with a smart key system). Press and hold the tire pressure STEP warning reset switch until the tire pressure warning light blinks...
Page 576 A tire goes flat repeatedly or cannot be properly repaired due to the ● size or location of a cut or other damage If you are not sure, consult with your Toyota dealer. Replacing tires and wheels ■ If the ID code of the tire pressure warning valve and transmitter is not registered, the tire pressure warning system will not work properly.
Page 577 4-3. Do-it-yourself maintenance Tire life ■ Any tire over 6 years old must be checked by a qualified technician even if it has seldom or never been used or damage is not obvious. Routine tire inflation pressure checks ■ The tire pressure warning system does not replace routine tire inflation pressure checks.
Page 578 4-3. Do-it-yourself maintenance Tire types ■ 1 Summer tires Summer tires are high-speed performance tires best suited to highway driving under dry conditions. Since summer tires do not have the same traction performance as snow tires, summer tires are inadequate for driving on snow-covered or icy roads.
Page 579 If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by your Toyota dealer. When operating the tire pressure warning reset switch, the tire pres- ●...
Page 580 4-3. Do-it-yourself maintenance Tire pressure warning system certification ■ FCC ID:GQ4-45T FCC ID:GQ4-32T FCC ID:GQ4-37R For vehicles sold in the U.S.A. NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 581 Do not mix tires of different makes, models or tread patterns. ● Also, do not mix tires of remarkably different treadwear. Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply ●...
Page 582 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
Page 583 4-3. Do-it-yourself maintenance Tire inflation pressure Tire inflation pressure ■ The recommended cold tire inflation pressure and tire size are displayed on the tire and loading information label. (→ P. 794 SIENNA_U (OM45477U)
Page 584 4-3. Do-it-yourself maintenance Inspection and adjustment procedure ■ Tire valve Tire pressure gauge Remove the tire valve cap. STEP Press the tip of the tire pressure gauge onto the tire valve. STEP Read the pressure using the gauge gradations. STEP If the tire inflation pressure is not at the recommended lev- STEP els, adjust the pressure.
Page 585 Reduced safety ● Damage to the drive train ● If a tire needs frequent refilling, have it checked by your Toyota dealer. Instructions for checking tire inflation pressure ■ When checking tire inflation pressure, observe the following: Check only when the tires are cold.
Page 586 4-3. Do-it-yourself maintenance CAUTION Proper inflation is critical to save tire performance ■ Keep your tires properly inflated. Otherwise, the following conditions may occur and result in an accident causing death or serious injury. Excessive wear ● Uneven wear ● Poor handling ●...
Page 587 ● Bent wheels that have been straightened Aluminum wheel precautions ■ ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
Page 588 4-3. Do-it-yourself maintenance When replacing wheels ■ The wheels of your vehicle are equipped with tire pressure warning valves and transmitters that allow the tire pressure warning system to provide advanced warning in the event of a loss in tire inflation pressure. Whenever wheels are replaced, tire pressure warning valves and trans- mitters must be installed.
Page 589 Because tire repair or replacement may affect the tire pressure ● warning valves and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.
Page 590 4-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be cleaned or changed regularly to maintain air conditioning efficiency. Removal method ■ Turn the engine switch (vehicles without a smart key sys- STEP tem) or “ENGINE START STOP” switch (vehicles with a smart key system) off.
Page 591 Hold the air gun 2 in. (5 cm) from the filter and blow for approximately 2 minutes at 72 psi (500 kPa, 5.0 kgf/cm bar). If an air gun is not available, have the filter cleaned by your Toyota dealer. SIENNA_U (OM45477U)
Page 592 4-3. Do-it-yourself maintenance Checking interval ■ Inspect, clean and replace the air conditioning filter according to the mainte- nance schedule. In dusty areas or areas with heavy traffic flow, more fre- quent cleaning or early replacement may be required. (For scheduled maintenance information, please refer to the “Scheduled Maintenance Guide”...
Page 593 4-3. Do-it-yourself maintenance Wireless remote control/electronic key battery Replace the battery with a new one if it is discharged. You will need the following items: ■ ● Flathead screwdriver ● Lithium battery CR2032 Replacing the battery (vehicles without a smart key system) ■...
Page 594 4-3. Do-it-yourself maintenance Replacing the battery (vehicles with a smart key system) ■ Take out the mechanical key. STEP Remove the cover. STEP To prevent damage to the key, cover the tip of the screwdriver with a rag. Remove the depleted battery. STEP Insert a new battery with the “+”...
Page 595 4-3. Do-it-yourself maintenance Use a CR2032 lithium battery ■ Batteries can be purchased at your Toyota dealer, local electrical appli- ● ance shops or camera stores. Replace only with the same or equivalent type recommended by the ● manufacturer. Dispose of used batteries according to local laws.
Page 596 4-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. Vehicles without a smart key system STEP Turn the engine switch off. Vehicles with a smart key system Turn the “ENGINE START STOP”...
Page 597 4-3. Do-it-yourself maintenance After a system failure, see “Fuse layout and amperage rat- STEP ings” (→P. 699) for details about which fuse to check. Take out the pullout tool. STEP Only type A fuses can be removed using the pullout tool. Check if the fuse has blown.
Page 598 4-3. Do-it-yourself maintenance Type C Normal fuse Blown fuse Contact your Toyota dealer. Type D Normal fuse Blown fuse Contact your Toyota dealer. Type E Normal fuse Blown fuse Contact your Toyota dealer. SIENNA_U (OM45477U)
Page 599 4-3. Do-it-yourself maintenance Fuse layout and amperage ratings Engine compartment ■ Fuse Ampere Circuit H-LP LVL 7.5 A Headlight leveling system PCS (Pre-collision system), DSS1 7.5 A dynamic radar cruise control sys- Starting system, multiport fuel ST NO.2 7.5 A injection system/sequential multi- port fuel injection system H-LP LH...
Page 600 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Multiport fuel injection system/ 7.5 A sequential multiport fuel injection system, automatic transaxle Multiport fuel injection system/ EFI NO.2 10 A sequential multiport fuel injection system H-LP RH HI 10 A Right-hand headlight (high beam) H-LP LH HI 10 A Left-hand headlight (high beam)
Page 601 4-3. Do-it-yourself maintenance Fuse Ampere Circuit 60 A Electric cooling fans Turn signal lights, gauges and 15 A meters 15 A Rear seat entertainment system Outside rear view mirror control, MIRROR 10 A outside rear view mirror heaters 30 A Audio system Vehicle dynamics integrated man- VSC NO.2...
Page 602 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Charging system, horn, left-hand headlight (low beam), right-hand headlight (low beam), fog light, out- 140 A side rear view mirror heaters, rear window defoggers, windshield wiper de-icer RAD NO.1 15 A Audio system Vanity lights, personal/interior lights, personal lights, engine switch light, rear ceiling lights, door DOME...
Page 603 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Multiport fuel injection system/ 25 A sequential multiport fuel injection system, “IG NO.2” and “IG2” fuses ECU-B NO.2 7.5 A Air conditioning system Multiplex communication system, AM2 NO.2 7.5 A starting system Multiport fuel injection system/ sequential multiport fuel injection EFI NO.1 25 A...
Page 604 4-3. Do-it-yourself maintenance Under the driver’s side instrument panel ■ Fuse Ampere Circuit P/OUTLET 15 A Power outlets Audio system, navigation system, RAD NO.2 7.5 A rear seat entertainment system Main body ECU, clock, shift lock system, power rear view mirror ECU-ACC 10 A control, multiplex communication...
Page 605 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Multiplex communication system, stop lights, navigation system, vehicle stability control system, Active Torque Control 4WD, intui- tive parking assist, auto anti-glare ECU-IG NO.1 10 A inside rear view mirror, pre-collision seat belt, outside rear view mirror, seat heater, TPMS, yaw rate &...
Page 606 4-3. Do-it-yourself maintenance Fuse Ampere Circuit PSD LH 25 A Power sliding door (left-side) 7.5 A Active Torque Control 4WD 10 A Starting system Gauges and meters, multi informa- GAUGE NO.2 7.5 A tion display Automatic transaxle, multiport fuel injection system/sequential multi- port fuel injection system, SRS air- 7.5 A bag system, front passenger...
Page 607 4-3. Do-it-yourself maintenance Fuse Ampere Circuit Tail lights, trailer lights (tail lights), TAIL 10 A license plate light, rear combination lights Windshield wiper and rear window WIP ECU 7.5 A wiper P/VENT 15 A Power quarter windows 10 A Automatic High Beam 30 A Windshield wiper WASHER...
Page 608 The fuses are designed to blow, protecting the wiring harness from damage. When replacing light bulbs ■ Toyota recommends that you use genuine Toyota products designed for this vehicle. Because certain bulbs are connected to circuits designed to prevent overload, non-genuine parts or parts not designed for this vehicle may be unusable.
Page 609 You may replace the following bulbs by yourself. The difficulty level of replacement varies depending on the bulb. If necessary bulb replacement seems difficult to perform, contact your Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer.
Page 610 4-3. Do-it-yourself maintenance Rear bulb locations ■ Tail light Rear turn signal light License plate lights Back-up light Replacing light bulbs Headlight low beams (halogen bulb) ■ For left side only: STEP Open the fuse box cover. (→P. 696) Unplug connector while STEP...
Page 611 4-3. Do-it-yourself maintenance Turn the bulb base counterclock- STEP wise. Headlight high beams and daytime running lights ■ For left side only: STEP Open the fuse box cover. (→P. 696) Turn the bulb base counterclock- STEP wise. Unplug connector while STEP pushing the lock release.
Page 612 4-3. Do-it-yourself maintenance Front fog lights (if equipped) ■ Remove the engine under cover STEP bolt and pull down the engine under cover. Unplug connector while STEP pushing the lock release. Turn the bulb base counterclock- STEP wise. SIENNA_U (OM45477U)
Page 613 4-3. Do-it-yourself maintenance Front turn signal/parking and front side marker lights ■ For left side only: STEP Open the fuse box cover. (→P. 696) Vehicles without discharge headlights Turn the bulb base counterclock- STEP wise. Vehicles with discharge headlights STEP Remove the light bulb.
Page 614 4-3. Do-it-yourself maintenance Rear turn signal lights ■ Remove the securing bolts and STEP remove the unit. Turn the bulb base counterclock- STEP wise. Remove the light bulb. STEP SIENNA_U (OM45477U)
Page 615 4-3. Do-it-yourself maintenance Tail and back-up lights ■ Remove the back door trim STEP board. Turn the bulb base counterclock- STEP wise. Tail light Back-up light Remove the light bulb. STEP Tail light Back-up light SIENNA_U (OM45477U)
Page 616 4-3. Do-it-yourself maintenance License plate lights ■ Remove the back door trim STEP board. Turn the bulb base counterclock- STEP wise. Remove the light bulb. STEP SIENNA_U (OM45477U)
Page 617 Toyota dealer to have the light replaced. Condensation build-up on the inside of the lens ■ Contact your Toyota dealer for more information in the following situations. Temporary condensation build-up on the inside of the headlight lens does not indicate a malfunction.
Page 618 4-3. Do-it-yourself maintenance CAUTION Replacing light bulbs ■ Turn off the lights. Do not attempt to replace the bulb immediately after ● turning off the lights. The bulbs become very hot and may cause burns. Do not touch the glass portion of the light bulb with bare hands. Hold the ●...
Page 619 4-3. Do-it-yourself maintenance CAUTION Discharge headlights (if equipped) ■ Contact your Toyota dealer before replacing discharge headlights (includ- ● ing light bulbs). Do not touch the discharge headlight’s high voltage socket when the head- ● lights are turned on. An extremely high voltage of 30000 V will be discharged and could result in serious injury or death by electric shock.
Page 620 4-3. Do-it-yourself maintenance SIENNA_U (OM45477U)
Page 621 5-1. Essential information Emergency flashers Use the emergency flashers if the vehicle malfunctions or is involved in an accident. Press the switch to flash all the turn signal lights. To turn them off, press the switch once again. NOTICE To prevent battery discharge ■...
Page 622 If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or a commercial towing service, using a wheel-lift type truck or flat bed truck. Use a safety chain system for all towing, and abide by all state/pro- vincial and local laws.
Page 623 5-1. Essential information Towing with a sling-type truck Do not tow with a sling type truck to prevent body damage. Towing with a wheel-lift type truck From the front (2WD models) Release the parking brake. SIENNA_U (OM45477U)
Page 624 5-1. Essential information From the front (AWD models) Use a towing dolly under the rear wheels. From the rear Use a towing dolly under the front wheels. Using a flatbed truck If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45°.
Page 625 5-1. Essential information NOTICE To prevent body damage when towing with a sling-type truck ■ Do not tow with a sling-type truck, either from the front or rear. To prevent causing serious damage to the transaxle and Active Torque ■ Control 4WD system (AWD models) when towing using a wheel-lift type truck 2WD models: Never tow this vehicle from...
Page 626 5-1. Essential information If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms ■ ● Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)
Page 627 5-1. Essential information Fuel pump shut off system To minimize the risk of fuel leakage when the engine stalls or when an airbag inflates upon collision, the fuel pump shut off system stops the supply of fuel to the engine. Follow the procedure below to restart the engine after the system is activated.
Page 628 If a light comes on or flashes, but then goes off, this does not necessarily indicate a malfunction in the system. However, if this continues to occur, have the vehicle inspected by your Toyota dealer. Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous.
Page 629 Have the vehicle inspected immediately. Failure to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident. Have the vehicle inspected by your Toyota dealer immediately. Warning light Warning light/Details Malfunction indicator lamp Indicates a malfunction in: (U.S.A.)
Page 630 5-2. Steps to take in an emergency Warning light Warning light/Details “ABS” warning light (U.S.A.) Indicates a malfunction in: • The ABS; or • The brake assist system (Canada) Electric power steering system warning light Indicates a malfunction in the EPS (Electric Power Steer- ing) system Pre-collision system warning light (if equipped) Indicates a malfunction in the pre-collision system...
Page 631 5-2. Steps to take in an emergency Warning light Warning light/Details Automatic High Beam indicator light (if equipped) Indicates a malfunction in the Automatic High Beam sys- tem (→P. 273) (Flashes) Cruise control indicator light (if equipped) Indicates a malfunction in the cruise control system (→P.
Page 632 5-2. Steps to take in an emergency Follow the correction procedures. After taking the specified steps to correct the suspected problem, check that the warning light turns off. Warning light Warning light/Details Correction procedure Open door warning light (warning buzzer) Check that all the doors are Indicates that a door is not closed.
Page 633 • Flat tire (→P. 745, 747) pressure is adjusted, have the system checked by your Toyota dealer. When the light comes on after blinking for 1 minute: Have the system checked Malfunction in the tire by your Toyota dealer.
Page 634 5-2. Steps to take in an emergency Warning light Warning light/Details Correction procedure Maintenance required reminder light Indicates that mainte- nance is requires accord- ing to the driven distance on the maintenance schedule. Illuminates for about 3 sec- onds and then flashes for about 15 seconds approxi- If necessary, perform main- mately 4500 miles...
Page 635 When the light comes on: Malfunction in the Active Have the system checked Torque Control 4WD sys- by your Toyota dealer. tem. :Open door warning buzzer: A buzzer will sound if the vehicle reaches a speed of 3 mph (5 km/h) with any door open.
Page 636 5-2. Steps to take in an emergency SRS warning light ■ This warning light system monitors the airbag sensor assembly, front airbag sensors, side and curtain shield airbag sensors, curtain shield airbag sen- sors, driver’s seat position sensor, driver’s seat belt buckle switch, front pas- senger occupant classification system (ECU and sensors), “AIR BAG ON”...
Page 637 The malfunction indicator lamp will go off after taking several driving trips. If the malfunction indicator lamp does not go off even after several trips, con- tact your Toyota dealer as soon as possible. When the tire pressure warning light comes on ■...
Page 638 If there is a lot of snow or ice on the vehicle, in particular around the ● wheels or wheel housings. If non-genuine Toyota wheels are used. (Even if you use Toyota ● wheels, the tire pressure warning system may not work properly with some types of tires.)
Page 639 If the tire pressure warning light frequently comes on after blinking 1 minute when the “ENGINE START STOP” switch is turned to IGNITION ON mode, have it checked by your Toyota dealer. Customization that can be configured at Toyota dealer ■...
Page 640 Check the tires. If a tire is flat, change it with the spare tire and have the flat tire repaired by the nearest Toyota dealer. • Avoid abrupt maneuvering and braking. If the vehicle tires deterio- rate, you could lose control of the steering wheel or the brakes.
Page 641 5-2. Steps to take in an emergency CAUTION If a blowout or sudden air leakage should occur ■ The tire pressure warning system may not activate immediately. Maintenance of the tires ■ Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label (tire and load information label).
Page 642 5-2. Steps to take in an emergency CAUTION Your vehicle has also been equipped with a TPMS (tire pressure warning system) malfunction indicator to indicate when the system is not operat- ing properly. The TPMS (tire pressure warning system) malfunction indi- cator is combined with the low tire pressure telltale (tire pressure warning light).
Page 643 A buzzer may sound when a warning message is shown on the multi-information display. If the warning message is shown again after its correction ■ procedure has been performed Contact your Toyota dealer as soon as possible. ∗ : If equipped SIENNA_U (OM45477U)
Page 644 Run-flat tires (A “RFT” or “DSST” mark is molded on the ■ sidewall) Take your vehicle to the near- est Toyota dealer or autho- rized tire dealer as soon as possible if any tire goes flat. The vehicle can be driven for...
Page 645 When replacing the tires ■ When removing or fitting the wheels, tires or the tire pressure warning valve and transmitter, contact your Toyota dealer as the tire pressure warning valve and transmitter may be damaged if not handled correctly. When driving over bumps ■...
Page 646 5-2. Steps to take in an emergency If you have a flat tire (vehicles with standard tires) Remove the flat tire and replace it with the spare tire provided. Before jacking up the vehicle ■ ● Stop the vehicle on a hard, flat surface. ●...
Page 647 5-2. Steps to take in an emergency Taking out the jack and tools Remove the cover. STEP Remove the adapter socket. STEP Remove the jack. STEP SIENNA_U (OM45477U)
Page 648 5-2. Steps to take in an emergency Remove the wheel nut wrench. STEP Taking out the spare tire Slide the front passenger’s seat to the frontmost lock position STEP and the right side second seat to the rearmost lock position so they will not interfere with the jack handle.
Page 649 5-2. Steps to take in an emergency Attach the adapter socket over STEP the spare tire clamp bolt. Connect the jack handle and the adapter socket. Turn the jack handle. The tire will be lowered com- pletely to the ground. Take the spare tire out from STEP underneath...
Page 650 5-2. Steps to take in an emergency Replacing a flat tire Chock the tires. STEP Flat tire Wheel chock positions Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire Left-hand side In front of the front right-hand side tire Rear Right-hand side In front of the front left-hand side tire...
Page 651 5-2. Steps to take in an emergency Turn the tire jack portion “A” by STEP hand until the notch of the jack is in contact with the jack point. Raise the vehicle until the tire is STEP slightly raised off the ground. Remove all the wheel nuts and STEP the tire.
Page 652 5-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign mat- STEP ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, causing the tire to come off.
Page 653 5-2. Steps to take in an emergency Firmly tighten each wheel nut STEP two or three times in the order shown in the illustration. Tightening torque: 76 ft•lbf (103 N•m, 10.5 kgf•m) Stow the flat tire, tire jack and all tools. STEP Stowing the flat tire Remove clasps and strap.
Page 654 5-2. Steps to take in an emergency Clip clasp to outboard hook. STEP Clip other clasp to center or STEP opposite hook location. Pull strap to tighten and secure STEP tire. The compact spare tire ■ The compact spare tire is identified by the label “TEMPORARY USE ●...
Page 655 5-2. Steps to take in an emergency Jack point guide ■ The jack point guides are located on the side of rocker moulding. They indi- cate the jack point positions. After completing the tire change ■ The tire pressure warning system must be reset. (→P. 674) When using the compact spare tire ■...
Page 656 5-2. Steps to take in an emergency CAUTION When using the compact spare tire ■ Remember that the compact spare tire provided is specifically ● designed for use with your vehicle. Do not use your compact spare tire on another vehicle. Do not use more than one compact spare tire simultaneously.
Page 657 5-2. Steps to take in an emergency CAUTION Speed limit when using the compact spare tire ■ Do not drive at speeds in excess of 50 mph (80 km/h) when a compact spare tire is installed on the vehicle. The compact spare tire is not designed for driving at high speeds. Failure to observe this precaution may lead to an accident causing death or seri- ous injury.
Page 658 • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by your Toyota dealer. • When installing the wheel nuts, be sure to install them with the tapered end facing inward.
Page 659 5-2. Steps to take in an emergency CAUTION Replacing a flat tire for vehicles with power sliding door and/or ■ power back door In cases such as when replacing tires, make sure to turn off the power sliding door main switch (→P. 70) and/or the power back door main switch (→P.
Page 660 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
Page 661 5-2. Steps to take in an emergency If the engine will not start If the engine will not start even though correct starting procedures are being followed (→P. 226, 229), consider each of the following points: The engine will not start even though the starter motor ■...
Page 662 ● There may be a malfunction in the steering lock system (vehi- cle with a smart key system). Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function (vehicles with a smart key system) When the engine does not start, the following steps can be used as an interim measure to start the engine if the “ENGINE START STOP”...
Page 663 (a system to pre- vent accidental operation of the shift lever). Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted: Set the parking brake.
Page 664 5-2. Steps to take in an emergency If the beep sounds continuously when the shift lever is shifted from P ■ (vehicles with an AUTO ACCESS SEAT) The AUTO ACCESS SEAT may not be locked in place. For details, refer to “AUTO ACCESS SEAT OWNER’S MANUAL”. SIENNA_U (OM45477U)
Page 665 5-2. Steps to take in an emergency If you lose your keys New genuine keys can be made by your Toyota dealer. For vehicles with the smart key system, bring the other key and the key number stamped on the key number plate. For vehicles without the smart key system, bring a master key and the key number stamped on the key number plate.
Page 666 5-2. Steps to take in an emergency ∗ If the electronic key does not operate properly For vehicles with a smart key system: If communication between the electronic key and vehicle is interrupted (→P. 36) or the electronic key cannot be used because the battery is depleted, the smart key system and wireless remote control cannot be used.
Page 667 5-2. Steps to take in an emergency Changing “ENGINE START STOP” switch modes and starting the engine Shift the shift lever to P and apply the brakes. STEP Touch the Toyota emblem side of STEP electronic “ENGINE START STOP” switch. An alarm will sound to indicate...
Page 668 5-2. Steps to take in an emergency Stopping the engine ■ Shift the shift lever to P and press the “ENGINE START STOP” switch as you normally do when stopping the engine. Replacing the key battery ■ As this above procedure is a temporary measure, it is recommended that the electronic key battery be replaced immediately when the battery depletes.
Page 669 The following procedures may be used to start the engine if the vehi- cle’s battery is discharged. You can call your Toyota dealer or qualified repair shop. If you have a set of jumper (or booster) cables and a second vehi- cle with a 12-volt battery, you can jump start your vehicle by follow- ing the steps below.
Page 670 5-2. Steps to take in an emergency 1AR-FE engine 2GR-FE engine Positive (+) battery terminal on your vehicle Positive (+) battery terminal on the second vehicle Negative (-) battery terminal on the second vehicle Connect the clamp at the other end of the negative cable to a solid, stationary, unpainted metallic point away from the battery and any moving parts, as shown in the illustration.
Page 671 Vehicles with a 2GR-FE engine only: To install the engine STEP cover, conduct the removal procedure in reverse. After installing, check that the fixed pins are inserted securely. Once the engine starts, have the vehicle inspected at your Toyota dealer as soon as possible. SIENNA_U (OM45477U)
Page 672 5-2. Steps to take in an emergency Starting the engine when the battery is discharged ■ The engine cannot be started by push-starting. To prevent battery discharge ■ Turn off the headlights and the audio system while the engine is off. ●...
Page 673 5-2. Steps to take in an emergency CAUTION Battery precautions ■ The battery contains poisonous and corrosive acidic electrolyte, while related parts contain lead and lead compounds. Observe the following pre- cautions when handling the battery: When working with the battery, always wear safety glasses and take care ●...
Page 674 Wait until the temperature of the engine (shown on the instrument cluster) begins to fall and then stop the engine. If the fans are not operating: Stop the engine immediately and call your Toyota dealer. After the engine has cooled STEP STEP...
Page 675 Water can be used in an emer- gency if engine coolant is (→ unavailable. P. 790 Have the vehicle inspected at the nearest Toyota dealer as soon as possible. Overheating ■ If you observe the following, your vehicle may be overheating: The engine coolant temperature gauge enters the red zone or a loss of ●...
Page 676 5-2. Steps to take in an emergency CAUTION To prevent an accident or injury when inspecting under the hood of ■ your vehicle If steam is seen coming from under the hood, do not open the hood until ● the steam has subsided. The engine compartment may be very hot, caus- ing serious injuries such as burns.
Page 677 5-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt, or snow. Stop the engine. Set the parking brake and shift the shift STEP lever to P.
Page 678 5-2. Steps to take in an emergency NOTICE To avoid damaging the transaxle and other components ■ Avoid spinning the wheels and pressing the accelerator pedal more than ● necessary. If the vehicle remains stuck even after these procedures are performed, ●...
Page 679 5-2. Steps to take in an emergency If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the following pro- cedure: Steadily step on the brake pedal with both feet and firmly STEP...
Page 680 5-2. Steps to take in an emergency Vehicles with a smart key sys- STEP tem: Stop the engine by press- ing and holding the “ENGINE START STOP” switch for 3 consecutive seconds or more. Press and hold for 3 seconds or more Stop the vehicle in a safe place by the road.
Page 681 5-2. Steps to take in an emergency SIENNA_U (OM45477U)
Page 682 6-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weights Overall length 200.2 in. (5085 mm) Overall width 78.1 in. (1985 mm) ASL30L-PFTEKA, 69.5 in. (1765 mm) ASL30L-PRTEKA Overall models GSL30L-PRTSKA 68.7 in. (1745 mm) height Others 68.9 in. (1750 mm) AWD models 69.5 in.
Page 683 Vehicle identification number ■ The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
Page 684 6-1. Specifications Engine number ■ The engine number is stamped on the engine block as shown. 1AR-FE engine 2GR-FE engine SIENNA_U (OM45477U)
Page 685 6-1. Specifications Engine Model 1AR-FE, 2GR-FE Type 1AR-FE engine 4-cylinder in line, 4-cycle, gasoline 2GR-FE engine 6-cylinder V type, 4-cycle, gasoline Bore and stroke 3.54 × 4.13 in. (90.0 × 105.0 mm) 1AR-FE engine 3.70 × 3.27 in. (94.0 × 83.0 mm) 2GR-FE engine Displacement 1AR-FE engine...
Page 686: Lubrication System
Engine oil selection ■ “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: ILSAC multigrade engine oil...
Page 687 6-1. Specifications Oil viscosity (0W-20 is explained here as an example): • The 0W in 0W-20 indicates the characteristic of the oil which allows cold startability. Oils with a lower value before the W allow for easier starting of the engine in cold weather. •...
Page 688: Ignition System
11.0 qt. (10.4 L, 9.2 Imp.qt.) With towing package 11.7 qt. (11.1 L, 9.8 Imp.qt.) Use either of the following. • “Toyota Super Long Life Coolant” • A similar high-quality ethylene glycol-based non- Coolant type silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technol- Do not use plain water alone.
Page 689 Toyota dealer. NOTICE Transmission fluid type ■ Using transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of your transmission accompanied by vibration and, ultimately, damage to the vehicle’s transmission. SIENNA_U (OM45477U)
Page 690 Oil type and viscosity SAE 75W-85 GL-5 or equivalent Your Toyota vehicle is filled with “Toyota Genuine Differential Gear Oil” at the factory. Use Toyota approved “Toyota Genuine Differential Gear Oil” or an equivalent oil of matching quality to satisfy the above specification. Please con- tact your Toyota dealer for further details.
Page 691 6-1. Specifications Brakes Pedal clearance 2.99 in. (76 mm) 0.04 ⎯ 0.24 in. (1 ⎯ 6 mm) Pedal free play Brake pad wear limit 0.04 in. (1.0 mm) Parking brake lining wear limit 0.04 in. (1.0 mm) 3 ⎯ 6 clicks Parking brake pedal travel Fluid type SAE J1703 or FMVSS No.116 DOT 3...
Page 692 6-1. Specifications Tires and wheels 17-inch tires P235/60R17 100T, Tire size T155/80R17 101M (spare) Tire inflation pressure Front: 35 psi (240 kPa, 2.4 kgf/cm or bar) (Recommended cold tire Rear: 35 psi (240 kPa, 2.4 kgf/cm or bar) inflation pressure) Spare: 60 psi (420 kPa, 4.2 kgf/cm or bar) Wheel size...
Page 693 6-1. Specifications 19-inch tires P235/50R19 99V, Tire size T155/80R17 101M (spare) Tire inflation pressure Front: 36 psi (250 kPa, 2.5 kgf/cm or bar) (Recommended cold tire Rear: 36 psi (250 kPa, 2.5 kgf/cm or bar) inflation pressure) Spare:60 psi (420 kPa, 4.2 kgf/cm or bar) Wheel size 19 x 7J, 17 x 4T (spare)
Page 694 6-1. Specifications Light bulbs Light Bulbs Bulb No. Type Headlights (low beam) ⎯ Discharge bulbs ⎯ Halogen bulbs Headlights (high beam) 9005 ⎯ Front fog lights Front turn signal/parking/side 3457NAK 28/8 Exterior marker lights Rear turn signal lights WY21W Tail lights Back-up lights License plate lights Outer foot lights...
Page 695 ASTM D4814 in the U.S.A. and CGSB3.5-M93 in Canada. Fuel tank opening for unleaded gasoline ■ To help prevent incorrect fueling, your Toyota has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps. Gasoline quality ■...
Page 696 6-1. Specifications Recommendation of the use of gasoline containing detergent additives ■ Toyota recommends the use of gasoline that contains detergent additives ● to avoid build-up of engine deposits. All gasoline sold in the U.S.A. contains detergent additives to clean and/ ●...
Page 697 ■ Some gasoline contains an octane enhancing additive called MMT (Methyl- cyclopentadienyl Manganese Tricarbonyl). Toyota does not recommend the use of gasoline that contains MMT. If fuel containing MMT is used, your emission control system may be adversely affected. The malfunction indicator lamp on the instrument panel may come on. If this happens, contact your Toyota dealer for service.
Page 698 6-1. Specifications NOTICE Notice on fuel quality ■ Do not use improper fuels. If improper fuels are used, the engine will be ● damaged. Do not use leaded gasoline. ● Leaded gasoline can cause damage to your vehicle’s catalytic converters causing the emission control system to malfunction.
Page 699 6-1. Specifications Tire information Typical tire symbols Run-flat tire or standard tire Compact spare tire Tire size (→P. 804) DOT and Tire Identification Number (TIN) (→P. 803) Uniform tire quality grading For details, see “Uniform Tire Quality Grading” that follows. Location of treadwear indicators (→P.
Page 700 6-1. Specifications Run-flat tire (RFT) or standard tire (→P. 745) This vehicle can be equipped with either run-flat tires (RFT) or stan- dard tires. An “RFT” or “DSST” mark is molded on the sidewall of the run-flat tire. Tire ply composition and materials Plies are layers of rubber-coated parallel cords.
Page 701 6-1. Specifications Typical DOT and Tire Identification Number (TIN) DOT symbol Tire Identification Number (TIN) Tire manufacturer’s identifica- tion mark Tire size code Manufacturer’s optional tire type code (3 or 4 letters) Manufacturing week Manufacturing year : The DOT symbol certifies that the tire conforms to applicable Federal...
Page 702 6-1. Specifications Tire size Typical tire size information ■ The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 or 3 digits) Speed symbol...
Page 703 U.S. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. DOT quality grades ■...
Page 704 6-1. Specifications Treadwear ■ The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a speci- fied government test course. For example, a tire graded 150 would wear one and a half (1-1/2) times as well on the government course as a tire graded 100.
Page 705 6-1. Specifications Temperature A, B, C ■ The temperature grades are A (the highest), B, and C, represent- ing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a speci- fied indoor laboratory test wheel.
Page 706 6-1. Specifications Glossary of tire terminology Tire related term Meaning Tire pressure when the vehicle has been Cold tire inflation pres- parked for three hours or more, or has not sure been driven more than 1 mile or 1.5 km under that condition The maximum cold inflated pressure to which a Maximum inflation...
Page 707 6-1. Specifications Tire related term Meaning 150 lb. (68 kg) times the number of occupants Normal occupant specified in the second column of Table 1 that weight follows Distribution of occupants in a vehicle as speci- Occupant distribution fied in the third column of Table 1 below The combined weight of installed regular pro- duction options weighing over 5 lb.
Page 708 6-1. Specifications Tire related term Meaning The load on an individual tire that is determined by distributing to each axle its share of curb Vehicle normal load weight, accessory weight, and normal occu- on the tire pant weight (distributed in accordance with Table 1 below), and dividing by two The surface area of the rim not covered by the...
Page 709 6-1. Specifications Tire related term Meaning A pneumatic tire with an inverted flange tire and rim system in which the rim is designed with rim flanges pointed radially inward and the tire is designed to fit on the underside of the rim in a manner that encloses the rim flanges inside the air cavity of the tire A tire designed to operate at higher loads and...
Page 710 6-1. Specifications Tire related term Meaning Maximum permissible The maximum cold inflation pressure to which inflation pressure a tire may be inflated The rim on which a tire is fitted for physical Measuring rim dimension requirements Any parting at any junction of tread, sidewall, or Open splice innerliner that extends to cord material Outer diameter...
Page 711 6-1. Specifications Tire related term Meaning A tire designed to operate at higher loads and Reinforced tire at higher inflation pressures than the corre- sponding standard tire The linear distance between the exteriors of the sidewalls of an inflated tire, excluding ele- Section width vations due to labeling, decoration, or protec- tive bands...
Page 712 6-1. Specifications Tire related term Meaning The projections within the principal grooves Treadwear indicators designed to give a visual indication of the (TWI) degrees of wear of the tread The fixture used to hold the wheel and tire Wheel-holding fixture assembly securely during testing : Table 1 ⎯...
Page 713 Programming these preferences requires specialized equipment and may be performed by your Toyota dealer. Some function settings are changed simultaneously with other functions being customized. Contact your Toyota dealer for further details. Customized Item Function Default setting setting Drivers door...
Page 714 6-2. Customization Customized Item Function Default setting setting Wireless remote control Level 1 to 6 Operation signal Level 7 (Buzzer volume) Panic function Wireless remote Power sliding door control Press twice operation → P. 53) Press and hold One short press Power back door oper- Press twice ation...
Page 715 6-2. Customization Customized Item Function Default setting setting Drivers door unlocked in one All doors Unlocking using a key step, all doors unlocked in one unlocked in two step steps Speed-detecting auto- matic door lock func- Door lock tion → P. 60) Opening drivers door unlocks all doors Shifting gears to P...
Page 716 6-2. Customization Customized Item Function Default setting setting Operation signal Power (buzzer) sliding door (if equipped) Opening and closing One short push Push and hold → P. 67) operation Time elapsed before 0 second headlights automati- 60 seconds 30 seconds cally turn off after doors 90 seconds are closed...
Page 717 6-2. Customization Customized Item Function Default setting setting 7.5 seconds Time elapsed before 15 seconds lights turn off 30 seconds Operation when the doors are unlocked Illumination → P. 566) Operation after the engine switch is turned to the “LOCK” position Rear ceiling light Outer foot lights Intuitive...
Page 718 6-2. Customization Customizing the features by using the multi-information display Press the “SETUP” button while STEP the vehicle is stopped. The “Custom Settings” screen is displayed on the multi-information display. If left idle for approximately 20 seconds, the display will return to the previous screen.
Page 719 6-2. Customization Choose a desired setting by STEP pressing the “INFO” or “SETUP” button, then press the “SELECT RESET” button to select. If any settings are changed, the display will revert to the previous screen. The illustration assumes that “Auto Locking” was chosen in STEP The current setting is indicated by yellow text.
Page 720 6-2. Customization Select “Default Settings” STEP pressing the “INFO” or “SETUP” button, and press the “SELECT RESET” button. If you select “Exit” and press the “SELECT RESET” button, the display will revert to the previous screen. Select “Yes” by pressing the STEP “INFO”...
Page 721 6-3. Initialization Items to initialize The following items must be initialized for normal system operation after such cases as the battery being reconnected, or maintenance being performed on the vehicle. Item When to initialize Reference Power sliding door After reconnecting or changing the P.
Page 722 6-3. Initialization SIENNA_U (OM45477U)
Page 723 If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800-331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 724 Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English. SIENNA_U (OM45477U)
Page 725 SIENNA_U (OM45477U)
Page 726 SRS airbag instructions for Canadian owners (in French) The following is a French explanation of SRS airbag instructions extracted from the SRS airbag section in this manual. See the SRS airbag section for more detailed SRS airbag instruc- tions in English. SIENNA_U (OM45477U)
Page 727 SIENNA_U (OM45477U)
Page 728 SIENNA_U (OM45477U)
Page 729 SIENNA_U (OM45477U)
Page 730 SIENNA_U (OM45477U)
Page 731 ATTENTION Précautions relatives aux coussins gonflables SRS ■ Si la rallonge de ceinture de sécurité a ● été reliée à la boucle des ceintures de sécurité des sièges avant sans avoir été attachée à la plaque de blocage des ceintures de sécurité, le coussin gonflable SRS avant considérera que le conducteur et le passager avant portent tout de même leur ceinture même si...
Page 732 SIENNA_U (OM45477U)
Page 733 SIENNA_U (OM45477U)
Page 734 SIENNA_U (OM45477U)
Page 735 SIENNA_U (OM45477U)
Page 736 SIENNA_U (OM45477U)
Page 737 SIENNA_U (OM45477U)
Page 738 Abbreviation list Abbreviation/Acronym list ABBREVIATIONS MEANING 2 Wheel Drive Air Conditioning Anti-lock Brake System Accessory AI-SHIFT Artificial Intelligence Shift control Automatic Locking Retractor Average All Wheel Drive Child Restraint System Economy/Ecology Electronic Control Unit Event Data Recorder Emergency Locking Retractor Electric Power Steering English/U.S.
Page 739 Abbreviation list ABBREVIATIONS MEANING Emission inspection and maintenance LATCH Lower Anchors and Tethers for Children Light Emitting Diode Maximum Minimum Methylcyclopentadienyl Manganese Tricarbonyl M + S Mud and Snow MTBE Methyl Tertiary Butyl Ether On Board Diagnostics Pre-Collision System Run-Flat Tire Supplemental Restraint System Tire Identification Number TPMS...
Page 740: Alphabetical Index Alphabetical Index
Alphabetical index Alphabetical index Armrests ........11 Operating with the seat AUTO ACCESS SEAT ....6 raise/lower switch ....35 Battery Replacing the fuses....38 Disconnecting......7 Returning the seat to Beep sounds ......22 the vehicle........ 30 Before operating the seat..20 Seat position adjustment Child safety switch .........6 Installing child restraint...
Page 741 What to do if... What to do if... P. 745/ If you have a flat tire A tire punctures P. 747 P. 762 If the engine will not start The engine does not start P. 159 Engine immobilizer system P. 770 If the battery is discharged If the shift lever cannot be shifted The shift lever cannot be...
Page 742: Instrument Cluster
What to do if... If a warning light turns on or a A warning light or indicator light P. 729 warning buzzer sounds... comes on Instrument cluster Center display SIENNA_U (OM45477U)
Page 743 What to do if... ■Warning lights Brake system warning Open door warning light light P. 733 Driver’s seat belt reminder light P. 729 P. 733 Front passenger’s seat belt Charging system reminder light warning light P. 730 P. 733 Third seat warning light Low engine oil pressure warning light P.
Page 744 What to do if... SIENNA_U (OM45477U)
Page 745: Gas Station Information
Without filter 4.2 (4.0, 3.5) 6.0 (5.7, 5.0) reference) With filter 4.6 (4.4, 3.9) 6.4 (6.1, 5.4) Toyota Genuine Motor Oil or equivalent Oil grade: P. 788 Engine oil type ILSAC multigrade engine oil Recommended oil viscosity: 0W-20 SIENNA_U (OM45477U)
