PACKAGE INCLUSIONS
QUANTITY
1 unit Main Station with Hot Air Gun
4 pcs
Air Nozzles (1124, 1130，1196，1197)
1 pc Z003 Hot Air Gun Holder
1 pc Vacuum Suction Pen （For Int852A+ pro) only
1 pc G001 IC Popper (for Int852A++ pro)
1 pc Power Cord
1 pc Instruction Manual
* Type of soldering tip included might change depending on availability.
** Kindly refer to soldering iron stand installation insert for parts and
instructions.
FUNCTION and FEATURES
Microprocessor-controlled ESD safe equipment.
●
Switchable temperature readout between Fahrenheit and
●
Centigrade.
Fast heating response with built-in thermal protector
●
Built-in temperature sensor that aids in providing stable
●
(temperature) measurements.
Integrated airflow gauge for precise airflow level adjustment
●
Digital control and display of hot air temperature and air pressure.
●
User configurable sleep mode for additional device protection
●
and power saving.
Built-in auto-cooling process that protects the system and its
●
components from excessive heat, prolonging usage life.
Compatibility with air nozzles of various types.
●
4
PART DESCRIPTION
OPERATING GUIDELINES
G. Line Frequency Selection
By default, the system's line frequency has been programmed
from the factory but for some cases when a manual override of the
line frequency is needed the following procedure can be done.
1. Follow System Setting
selection menu to "SEL 4", then press the air flow control up
button "C3".
2. If successful the display "B2" would show "-50" indicating
frequency is being set.
3. Adjust the frequency with the air flow control buttons "C3 and
C4". Select "-50" for 50 Hz and select "-60" for 60 Hz.
4. Save the selected settings and exit from the frequency selection
menu by pressing the Hot Air gun function switch "F" .
H. Utilizing the Hot Air Gun Digital Temperature Calibration
By default, the system is properly calibrated but for some cases
when a little adjustment of the Hot Air Gun temperature is required
the following procedure can be done.
1. Follow System Setting
selection menu to "SEL 4", then press the air flow control up
button "C3".
2. If successful the display would show " Add 000" indicating hot air
gun digital calibration is being set.
3. Adjust the offset value with the air flow control buttons "C3 and
C4", the word "Add" signifies a positive calibration value while the
word "Sub" signifies a negative calibration value. Value is
adjustable from –50 to 90 degrees with "000" signifying no offset.
4. Save the selected calibration settings and exit from the calibration
adjustment menu by pressing the Hot Air gun function switch "F" .
5. Enter hot air gun function and set to desire temperature to check
if additional calibration is needed.
procedures 1 to 6. Adjust system
procedures 1 to 6. Adjust system
13
