- Page 1 Wired Controller 29FWC-100E INSTRUCTION MANUAL WARNING! Read and follow all safety precautions in Instruction Manual - improper use can cause serious injury. www.delta-dct.com...
- Page 2 User Notice Please carefully read this manual before installation and use of this product Thanks for choosing DELTA duct type air conditioners. Please read this manual carefully ◆ before operating this product and keep it properly for future reference. In addition, please take notice of the symbols below.
-
Page 3: Table Of Contents
Contents 1 Introduction to the Wired Controller ..............1 1.1 Appearance and LCD Icons ............... 1 1.2 Introduction to the LCD Icons ..............2 2 Press Buttons ....................4 2.1 Buttons ....................... 4 2.2 Instruction to the Function of Press Buttons ..........4 3 OPERATION INSTRUCTION ................. - Page 4 3.15 E-HEATER Setting .................18 3.16 Blow Function Setting ................18 3.17 Filter Setting ...................19 3.18 Quiet Function Setting ...............21 3.19 Ultra-Dry Setting ..................22 3.20 Other Functions ..................22 4 Installation of the Wired Controller ...............24 4.1 Standard Parts ..................24 4.2 Installation Location and Installation Requirements ........25 4.3 How to Install the Wired Controller ............25 4.4 How to Remove the Wired Controller ............26 5 Error Display ....................26...
-
Page 5: Introduction To The Wired Controller
1 Introduction to the Wired Controller Fig.1 Appearance of the Wired Controller 1.1 Appearance and LCD Icons Fig.2 Appearance of the LCD... -
Page 6: Introduction To The Lcd Icons
1.2 Introduction to the LCD Icons Table 1 Icons Introduction Left and right swing function Up and down swing function Air exchange function Sleep function Auto mode COOL mode DRY mode FAN mode HEAT mode Health function I-Demand function Vacation function Status display of master and slave wired controller Shield function The button operation, temperature setting, "On/Off"... - Page 7 Electric heater Blow function Defrosting function Filter cleaning Timer Setting Keycard control / Detected status sensed by human body Quiet function Lock function...
-
Page 8: Press Buttons
2 Press Buttons 2.1 Buttons Fig.3 Press Buttons 2.2 Instruction to the Function of Press Buttons Table 2 Press Buttons Function Introduction ① .Function selection and canceling; Enter/Cancel ② .Press it for 5s to enquiry the outdoor and indoor ambient temperature. ①... -
Page 9: Operation Instruction
3 OPERATION INSTRUCTION 3.1 On/off Press the On/Off button to turn on or off the unit. Notes: The state shown in Fig.4 indicates the OFF state of the unit after energization. ① . The state shown in Fig.5 indicates the ON state of the unit after energization. ②... -
Page 10: Temperature Setting
3.3 Temperature Setting Press ▲ or ▼button to increase or decrease setting temperature under on-state of the unit. If press either of them continuously, temperature will be increased or decreased by 1°C every 0.5s. In Cooling, Dry, Fan and Heating mode, temperature setting range is 16°C~30°C. In Auto mode, the setting temperature is un-adjustable. -
Page 11: Right And Left Swing
3.5 Right and Left Swing Under the ON state of unit, press the Function button to select the “Right and Left Swing” function option and then press the Enter/Cancel button to activate it. When the Swing function is activated, press the Function button to select the "Right and Left Swing"... -
Page 12: Up And Down Swing
3.6 Up and Down Swing Under the ON state of unit, press the Function button to select the "Up and Down Swing" function option and then press the Enter/Cancel to activate it. When the Swing function is activated, press the Function button to select the "Up and Down Swing"... -
Page 13: Air Exchange Setting
Cancellation of Timer Setting: The timer setting can be canceled by press “Timer”. Then , xx. Hour won’t be displayed. Timer Setting under the ON state of the Unit is as shown in Fig.11: Unit On, no timer function Press “Timer” button to set timer off adjust timer time Press “timer”... - Page 14 1――The unit continuously runs for 60min, and fresh air valve runs for 6 min. 2――The unit continuously runs for 60min, and fresh air valve runs for 12 min. 3――The unit continuously runs for 60min, and fresh air valve runs for 18 min. 4――The unit continuously runs for 60min, and fresh air valve runs for 2 4 min.
-
Page 15: Sleep Setting
3.9 Sleep Setting Sleep on: Press the Function button under the ON state of the unit to select the “Sleep” function option and then press the Enter/Cancel button to activate it. Sleep off: When the Sleep function is activated, press the Function button to select the Sleep function option and then press the Enter/Cancel button to deactivate this function. - Page 16 e.g. If the setting temperature is 25°C, the temperature will rise by 1°C in each hour until it reaches 27°C. 7 hours later, the temperature will drop to 26°C. After that, the unit will run at this temperature. Time/(hour) Fig.14 Sleep Curve under the COOL Mode Under the Heat mode, the Sleep function is ON, the setting temperature range can be 16°C, 17~20°C, 21~27°C or 28~30°C.
-
Page 17: Health Setting
3.10 Health Setting Under unit on status, press “Function” button to select health function with “Health” icon flashing. Press “Enter/Cancel” button to activate health function. When health is on, press “Function” button to set function, with “health” icon flashing. Then press the “Enter/Cancel”... -
Page 18: Vacation Setting
Unit On, no I-Demand function Press “Function” button to set Press “Enter/Cancel” button to I-Demand function activate I-Demand function Press “Enter/Cancel” button to Press “Function” button to set cancel I-Demand function I-Demand function Fig.17 I-Demand Setting Note: The I-Demand function can be cancelled by mode switch and unit ON/OFF. ①... -
Page 19: Turbo Function Setting
Unit On, no Vacation function Press “Function” button to set Press “Enter/Cancel” button to vacation function activate vacation function Press “Enter/Cancel” button to Press “Function” button to set cancel vacation function vacation function Fig.18 Vacation Setting Note: The vacation function can be only set under heating mode. ①... -
Page 20: Save Function Setting
button to select the "Turbo" option and then pressing the Enter/Cancel button. Turbo function setting is as shown in Fig.19: Unit On, no Turbo function Press “Function” button to set Press “Enter/Cancel” button to turbo function activate turbo function Press “Enter/Cancel” button to Press “Function”... - Page 21 Cancel button to activate this function. The activated SAVE function can be deactivated by firstly pressing the “Function” button to select the “SAVE” option and then pressing the “Enter/Cancel” button. The energy saving setting is as shown in the Fig.20: Unit On, no Save function Press “Function”...
-
Page 22: E-Heater Setting
3.15 E-HEATER Setting E-HEATER: in the HEAT mode, “E-HEATER” function is allowed to be activated to improve the heating efficiency. Generally, it will be activated automatically as the unit goes into the HEAT mode through any button operations . Activation of the “E-HEATER” Function: firstly press the Function button to select the “E-HEATER”... -
Page 23: Filter Setting
Deactivation of the “Blow” Function: The activated “Blow” function can be deactivated by firstly pressing the Function button to select the “Blow” option and then pressing the Enter/Cancel button. BLOW function setting is as shown in Fig.22: Unit On, no Blow function Press “Function”... - Page 24 Unit On, no Filter function Press “Function” button to set filter function the pollution level Press “Function” button to set Press “Enter/Cancel” button “00” shown at the timer area filter function to activate filter function Press “Enter/Cancel” button to cancel filter function Fig.23 Filter Setting While setting Filter, two numbers will be shown on the timer area.
-
Page 25: Quiet Function Setting
“0” shows up at the second place, the accumulated operating hour reaches 1400h. Every increase of the number means another 400h is accumulated. When “9” shows up, it means the operating hour reaches 5000h. When the filter reaches serious-level pollution, “3” will be shown at the first place, When ④... -
Page 26: Ultra-Dry Setting
Unit On, no Quiet function Press “Function” button to set Press “Enter/Cancel” button to quiet function activate quiet function Press “Enter/Cancel” button to Press “Function” button to set cancel quiet function quiet function Fig.24 Quiet function setting Notes: "QUIET" function is unavailable in Fan or Dry mode. Owing to power failure, the "Quiet" ①... - Page 27 3.20.2 Memory Function Memory switchover: Under the OFF state of the unit, press the Mode and ▲ buttons at the same time for 5s to switch memory modes. When setting the memory mode, “MEMORY” will be displayed. If this function is deactivated, the unit will go to the OFF state after power recovery. Memory recovery: If the memory function is On, the wired controller after power failure will resume its original running state upon power recovery.
-
Page 28: Installation Of The Wired Controller
Unit off Simultaneously press “Function” Press “Mode” button to set till and “Timer” button for 5s, the “05” is shown on the temperature wired controller will enter displayed area. Then the unit will parameter setting interface. enter the indoor fan shutdown mode. Press “Enter/Cancel”... -
Page 29: Installation Location And Installation Requirements
4.2 Installation Location and Installation Requirements (1). Do not install the wired controller in the damp place or under direct sunlight. (2). Do not install the wired controller close to the hi-temperature object or place where the wired controller is likely to suffer water spray. (3). -
Page 30: How To Remove The Wired Controller
Brief instructions: Pull out the 2-core signal line from the mounting hole and pass this line through the round ① . hole located at the bottom of the wired controller. Use M4×25 screws to fix the soleplate of the wired controller on the wall. ②... - Page 31 Error codes and their meanings: Table 5 Number Error code Error Compressor high pressure protection Indoor anti-freeze protection Compressor low pressure protection, refrigerant lack protection and refrigerant colleting mode Compressor high discharge temperature protection Communication error Indoor fan motor error Full water protection Indoor ambient temperature sensor error Evaporator temperature sensor error...
- Page 32 Drive module over temperature protection Zero passage protection AC current protection Drive current error Sensor connecting protection Temperature drift protection Bus low voltage protection Bus high voltage protection Charge loop error Input voltage abnormality Drive memory chip error...
- Page 33 Thank you for Choosing airconditioners Perfectly engineered for your comfort. www.delta-dct.com...
