Nano Phono
V2
Nano Phono Headphone
V2
Bedienungsanleitung
User Manual
clearaudio electronic
®
GmbH
Spardorfer Str. 150 • D-91054 Erlangen • Tel. +49 9131 40300100 • FAX + 49 9131 40300119
www.clearaudio.de • www.analogshop.de • info@clearaudio.de
© clearaudio electronic GmbH 2016
Version: 1.2_26.09.2016_E+D

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Nano Phono Headphone V2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Clearaudio Nano Phono Headphone V2

  • Page 1 Nano Phono Nano Phono Headphone Bedienungsanleitung User Manual clearaudio electronic ® GmbH Spardorfer Str. 150 • D-91054 Erlangen • Tel. +49 9131 40300100 • FAX + 49 9131 40300119 www.clearaudio.de • www.analogshop.de • info@clearaudio.de © clearaudio electronic GmbH 2016 Version: 1.2_26.09.2016_E+D...
  • Page 2 English Nano Phono V2 / Nano Phono “H” V2 Congratulations on the purchase of your new MC/MM Nano Phono V2 / Nano Phono “H” V2 phonostage. The features a power switch: we recommend that you keep the unit switched on in order to maintain a constant temperature for the electronic Nano Phono V2 / Nano Phono “H”...
  • Page 3 The standard input impedance is set at 47 kΩ, which ensures an optimal setting for all MM Cartridges. For the perfect input matching with MC cartridges, Clearaudio now includes the following resistor pairs: - 51...
  • Page 4 Deutsch Nano Phono V2 Nano Phono „H“ V2 (Headphone) Die RIAA MC- und MM-Vorverstärker erfüllen die höchsten Ansprüche an die analoge Musikwiedergabe. Nano Phonos V2 Beide verfügen über einen Netzschalter. Aus klanglichen Gründen empfehlen wir Ihnen das Gerät nicht vom Netz zu trennen um eine konstante Betriebstemperatur beizubehalten. -Inbetriebnahme- (für Nano phono V2 und Nano phono „H“...
  • Page 5 Ist kein Widerstand im MC Betrieb mit eingesetzt, ist der MC Tonabnehmer mit 47 Kilo Ohm trotzdem abgeschlossen. Für clearaudio MC Tonabnehmer empfehlen wir die Widerstände mit 402 Ohm zu verwenden. Für andere MC Tonabnehmer Typen folgen Sie bitte den Empfehlungen der Hersteller angaben.
  • Page 6 Technical data: Technische Daten - Mode Verstärkung: bei 1 kHz: 54 bis / to 68 dB (MC-Betrieb/ Amplification: Mode 34 bis / to 48 dB (MM-Betrieb/ Eingangsimpedanz: 47 kOhm/ 220pF / MM-Mode Input load: User Individual / / MC-Mode MM / MC – Eingang: schaltbar mit Steckbrücke (auf Unterseite) MM / MC - input: switchable (at bottom)
  • Page 7 To achieve the full Clearaudio warranty, it is necessary that you fill out and send the corresponding part of the warranty registra- tion certificate /card back to Clearaudio, within two weeks after purchase. Only if the product is returned in it’s original packing Nano Phono V2.
